2. Chemical-Induced Mutagenesis
Chapter 10
Chemical-Induced Mutagenesis

3. DNA and Mutations A mutation is a permanent change in the DNA.
DNA is in our chromosomes and it codes for all the information that makes us unique.
It codes for all cellular proteins (e.g., enzymes) that are critical to life.

4. DNA and Mutations
Human DNA is packaged in 23 pairs of chromosomes: 22 homologous pairs and 2 sex chromosomes (XX in females and XY in males).
Each chromosome is composed of a DNA molecule that is complexed with numerous proteins.
DNA must be able to replicate, segregate, and maintain its integrity from replication to replication.

5. Figure 10-1 DNA: the informational molecule of life
Courtesy of Oak Ridge National Laboratory, U.S. Dept. of Energy.

6. Structure of DNA
DNA is organized into genes, of which 30,000 or so encode information that is critical to maintain human life.
The DNA is a base sequence that codes the information necessary for cellular growth, differentiation, and replication.

7. Structure of DNA DNA is composed of the following bases:
Purines: adenine (A), guanine (G)
Pyrimidines: cytosine (C), thymine (T)
Bases are organized into the DNA nucleotide, which contains a purine or pyrimidine base + sugar (deoxyribose) + a phosphate group.

8. Figure 10-2 Molecular components and their arrangement in DNA.

9. DNA and Mutations The pairing of bases is A-T and C-G.
Incorrect base pairing can result in the potential alteration of information that may be important to the normal physiology of the individual.
The deletion or replacement of a single nucleotide can result, for example, in an altered protein, such as an enzyme.
If these changes occur in an informational portion of the DNA, then an abnormal protein may result.

10. Did You Know?
Experimentally, choosing the right mutagen means selecting the right combination of mutagen efficiency and mutagen specificity. Ethane methyl sulfonate (EMS) for example is a chemical mutagen that most commonly causes transitions by methylation of G residues but can also yield a variety of other types of mutations and has become an important experimental tool for routine genetic analysis. Other studies that need to produce large multigene deletions, gamma irradiation, UV irradiation, and formaldehyde are commonly used mutagens.

11. Figure 10-3 Deletion of a nucleotide
Modified from Genetics Home Reference. A Service of the National Library of Medicine. (2010). Deletion Mutation. Accessed January 24, 2013.

12. Figure 10-3 Replacement of a nucleotide
Modified from Genetics Home Reference. A Service of the National Library of Medicine. (2010). Deletion Mutation. Accessed January 24, 2013.

13. DNA and Mutations
Damage to DNA occurs both spontaneously and as a result of exposures to environmental agents.
We have the capacity to both recognize and repair mutated DNA.
This may well be the only biological macromolecule that can be repaired.

14. Figure 10-5 Messenger RNA is the cytoplasmic informational molecule transcribed from DNA
Adapted from National Institute of General Medical Sciences. (2010). Central Dogma Illustrated. Available at:
jpg. Accessed January 24, 2013.

15. Figure 10-6 Consequences of damaged DNA

16. Mutations
Mutations are acquired at some time during a person’s life, or they can be inherited. They can be:
Induced as a result of exposure of the DNA to environmental mutagens
Spontaneous as a result of “normal” cellular processes
Acquired (= somatic) some time during the life of an individual. Unless these occur in the gametes, they cannot be passed onto offspring.
Hereditary (= germline) acquired from a parent through the union of the gametes at fertilization and can be present in all the cells of the offspring.

17. Mutations and Apoptosis
Apoptosis is a form of planned or programmed cell death. It is a normal process that occurs during:
embryological development
normal cellular replacement
in response to physical, biological, or chemical stressors
Normal cell turnover occurs, w/o necrosis and inflammation.
Apoptosis is also an important way that genetically altered cells can be removed from the body if DNA repair does not occur.

18. Figure 10-7 Apoptosis Reproduced from Genetics Home Reference
Figure 10-7 Apoptosis Reproduced from Genetics Home Reference. A Service of the National Library of Medicine. (2010). The Process of Apoptosis. Available at: Accessed December 20, 2012.

19. Apoptosis
Unlike necrosis, in which large numbers of cells have died and which is frequently accompanied by inflammation and cellular replacement by connective tissue, the programmed cell death of apoptosis is a selective destruction of the cell.
As the cell dies, one can observe “apoptotic bodies” that in the final stage of apoptosis are digested by phagocytic cells.

20. Apoptosis
The triggering of apoptosis is complex and involves the cell receiving chemical messengers to “turn on” those genes involved in the self-destruction process.
If these genes become mutated and apoptosis is compromised, then the cell is at greater risk of becoming one that may transform into a cancerous cell.

21. Figure 10-8 Final stage of apoptosis
Reproduced from Genetics Home Reference. A Service of the National Library of Medicine. (2010). Final Stage of Apoptosis. Available at: Accessed January 12, 2013.

22. Tests for DNA Damage and Mutagenicity
The Ames test
Tests for chromosome aberrations
Micronuclei assays
Sister chromatid
Exchanges in populations of proliferating cells
DNA repair studies (unscheduled DNA synthesis assay)
And others that detect “changes” in the DNA.

23. Figure 10-9 The Ames mutagenicity test

24. Table 10-1 Not All Carcinogens Are Mutagens

25. Examples of Chemical Mutagens
Some chemical mutagens directly react to disrupt the base pairing within the DNA macromolecule.
Nitrous acid can deaminate the pyrimidine and purine bases.
This can convert adenine to hypoxanthine.
Hypoxanthine now pairs with cytosine.

26. Examples of Chemical Mutagens, cont.
The scientific literature contains numerous examples of chemical agents shown to be mutagenic.
Some of these chemicals, such as bromouracil, resemble the purine and pyrimidines bases of DNA.
Bromouracil was synthetically created and has been used extensively in research because it resembles the pyrimidine thymine but has a bromium atom instead of a methyl group.
Bromouracil is an example of a DNA base analogue.

27. Examples of Chemical Mutagens, cont.
DNA base analogues can be incorporated into the DNA and pairs with adenine during DNA replication.
DNA analogues may be of some value to the chemotherapy because the rapidly dividing cancerous cells may preferentially incorporate them into the DNA resulting in cellular death.
they are not specific for cancerous cells so other dividing cells may be affected

28. Examples of Chemical Mutagens, cont.
Intercalating agents tend to wedge in between the bases along the DNA molecule, thus preventing the functions of DNA polymerase and other normally present chemicals (e.g., binding proteins).
This results in the inability of the DNA to properly transcribe information or prevent DNA synthesis.
Examples include the dyes ethidium bromide and acridine orange
These chemicals can produce base frameshifts by molecular stretching of the DNA double helix
This may trick the DNA polymerase into placing an additional base into the DNA.

29. Examples of Chemical Mutagens, cont.
Other chemicals such as methyl or ethyl methanesulfonate, mustard gas, and nitrosoguanidine, can add methyl or ethyl groups onto the bases.
These types of chemicals are referred to as alkylating agents.
They can cause the replacement of a pyrimidine base with a purine base.

30. Examples of Chemical Mutagens, cont.
Some large molecules, such as benzo[a]pyrene and N-acetoxy-2-cetylaminofluorene, can bind to the DNA bases
This can cause chemical adducts formation.
The adducts may form noncoding regions within the affected DNA,
Peroxides (and other chemicals) may actually cause breaks within the DNA strand.
