1. C Programming A Modern Approach
K. N. King,
C Programming A Modern Approach,
W. W. Norton & Company, 1996.

2. Note About Coverage
This class has only part of the semester dedicated to C
You already know Java, which has similar syntax
You should be able to read the book quickly

3. Similarities of C to Java
/* Comments */
Variable declarations
If / else statements
For loops
While loops
Function definitions (like methods)‏
Main function starts program

4. Differences between C and Java
C does not have objects
There are “struct”ures
But data are not tied to methods
C is a functional programming language
C allows pointer manipulation
Input / Output with C
Output with printf function
Input with scanf function

5. C Strengths Efficiency Limited amount of memory Fast Portability
Compilers are small and easily written
C: UNIX and ANSI/ISO standard
Power
Flexibility
Standard library
Input/output, string handling, storage allocation, etc.
Integration with UNIX

6. C Weakness Can be error-prone Flexibility
C compiler doesn’t detect many programming mistakes
Pitfalls
Can be difficult to understand
Some features are easier to be misused
Can be difficult to modify
No modules

7. Compiling and Linking

8. Variables and Assignments
C is case-sensitive
Compiler remembers only first 31 characters
Type
Should be declared
int height, length, width;
Declarations must precede the statements.
The value should be assigned before using the variable in computations:
height = 8;
length = 12;
width = 5;
int volume = height * length * width;

9. Constants Macro definition: #define SCALE_FACTOR (5.0/9.0)
No semicolon at the end!

10. Formatted Output: printf
printf(string, expr1, expr2,…)
Format string contains both ordinary characters and conversion specifications
Conversion specification is a placeholder representing a value to be filled in during printing.
The information after % specifies how the value is converted form its internal form(binary) to printed form (characters)

13. Pitfalls

15. Formatted Input: scanf
scanf(string, expr1, expr2,…)
Reads input according to a particular format.
Format string contains both ordinary characters and conversion specifications
scanf(“%d%d%f%f”, &i, &j, &x, &y);
Number of conversion specification should match number of variables.
Each conversion should be appropriate for type of the variable.
while (scanf (“%d”, &i)==1) {
… }

16. How scanf Works
For each conversion specification, tries to locate an item of appropriate type, skipping blank spaces if necessary.
Reads it, stopping when it encounters the symbol that can’t belong o item.
Ignores white-space characters.
scanf(“%d%d%f%f”, &i, &j, &x, &y);

18. Assignment Operators Simple assignment(right associative): =
int i=5, j=3;
int k = 5*3;
i = 72.99;
float f;
f = 136;
i = j = k = 7;
f = i = 33.3;
k = 1 + (j = i);
Compound assignments(right associative): =, -=, *=, /=, %=
i += j += k;
i += k; vs i =+ k;

19. Increment and Decrement Operators
Prefix operators: ++i, --i
Postfix operators: i++, i—

20. Precedence and Associativity

21. Sub expression Evaluation
c = (b = a + 2) – (a = 1);
i = 2;
j = i * i ++;
Any expression can be used as a statement
i++;
i*j -1;
i + j ; /* i = j */

22. Relational Operators 0 (false) and 1 (true)
Their precedence is lower than the precedence of the arithmetic operators.
Left associative
i < j < k

23. Equality Operators 0 (false) and 1 (true)
Their precedence is lower than the precedence of the relational operators.
i < j == j < k
Left associative

24. Logical Operators Logical negation: !
!expr : 1 if expr has the value 0
Right associative
The same precedence as unary plus and minus
Logical and: &&
expr1 && expr2 : 1 if both expr1 and expr2 has non-zero values
Logical or: ||
expr1 || expr2 : 1 if either expr1 or expr2 (or both) has non-zero values
Short-circuit evaluation
Left associative
The precedence is lower that that of the relational and equality operators

25. if … else Statement if (expression) statement
if (expression) statement else statement
Statement can be compound: { statements}
if (i==0) vs if (i=0)
if (expression)
statement
else if (expression) …
else

27. “Dangling else” Problem
if (y != 0)
if (x != 0)
result = x / y;
else
printf (“Error: y is equal to ) \n”);
Use compound statement {}
Compiler always match the closest unmatched if statement

28. Conditional Expression
expr1 ? expr2: expr3
int i, j, k;
i = 1;
j = 2;
k = i > j ? i : j ;
k = (i > 0 ? i : 0) + j ;
return (i > j ? i : j);
printf (“%d\n”, i > j ? i : j);

29. switch Statement switch ( expression ){
case constant-expression: statements …
default: statements }
Controlling expression should be an integer expression (characters)
Constant expression can’t contain variables or function calls.
Statements do not require {}. Usually, the last statement is break.

30. Example

31. while Loop while (expression) statement Statement can be compound: {}
while (i>0) printf (“%d\n”, i--);
while (i>0) {
printf (“%d\n”, i);
i--; }
Infinite loops: while(1)
Break, goto, return

32. Example
scanf(“%d”, &n);

33. do Loop do statement while (expression); Statement can be compound: {}
do printf (“%d\n”, i--); while (i>0) ; do {
printf (“%d\n”, i);
i--;
} while (i>0);

34. for Loop for (expr1; expr2; expr3) statement
Statement can be compound: {}
expr1;
while (expr2) {
statement
expr3; }
for (i=10; i>0; i--)
printf (“%d\n”, i);
Infinite loop: for (;;)
Comma operator:
for (i=1, j=2; i+j<10; i++, j++) printf (“%d\n”, i+j);

35. Example

36. Exiting From a Loop: break
for (d=2; d<n; d++)
if (n%d==0) break;
if (d<n) printf (“%d is divisible by %d\n”, n,d);
else printf(“%d is prime \n”,n);
for (;;){
printf (“Enter a number(0 to stop): ”);
scanf(“%d”,&n);
if (n==0) break;
printf(“%d cubed is %d\n”,n,n*n*n); }
break escapes only one level of nesting.

37. Skipping the Rest of Iteration: continue
sum = 0;
while (n-->0){
scanf(“%d”, &i);
if (i%2==0) continue;
sum+=i; }

38. Null statement ; for (d=2; d<n; d++) if (n%d==0) break;
for (d=2; d<n && n%d !=0 ; d++);
Accidentally putting a semicolon after the parentheses in if, while or for statement ends the statement prematurely.
if (i==0);
printf (“Zero\n”);
while (i>0); printf (“%d\n”, i--);

39. Basic Types: Integers Signedness: signed (defaut), unsigned
Size: short, long
<limits.h> holds ranges for int types.

40. Integer Constants Decimal (base 10) literals
digits between 0-9, no leading zero
15, 255, 32767
Octal (base 8) literals
digits between 0-7, must start with 0
017, 0377,
Hexadecimal (base 16) literals
digits between 0-9 and letters between A- F (a-f), must start with 0x (0X)
0xF, 0xFF, 0x7FFF

41. Basic Types: Floating Types
<float.h>
Assume IEEE 754 standard
Scientific notation: sign, an exponent, a fraction
.57e2, 57, 5.7e+1, 570.0e-1

42. Basic Types: char Character set: Latin (7 bit), ASCII (8 bit)
Treats as integers
unsigned (0-255) and signed ( ) version
Some compilers use unsigned by default, the other compilers use signed by default.
char ch=65; /* it’s ‘A’ now */
int i = ‘a’; /* it’s 97 */
ch++; /* it’s ‘B’ now */
if (‘a’< =ch && ch <=‘z’)
ch = ch – ‘a’ + ‘A’; /* ch=toupper(ch);*/
for (ch=‘A’; ch<=‘Z’; ch++) …
ch=‘a’ * ‘b’ / ‘c’ …

43. Read and Write char: Alternative
ch = getchar();
putchar(ch);
while ( ( ch = getchar() ) != ‘\n’ ) …
while ((ch=getchar())==‘ ’);
printf(“Enter an integer: ”);
scanf(“%d”, &i);
printf(“Enter a command: ”);
command = getchar();

44. sizeof Operator sizeof (type-name)
Unsigned integer representing the number of bytes required to store a value of type-name
sizeof(char) is always 1
Can be applied to constants, variables, expressions
int i, j;
int k= sizeof(i); /* k is assigned 2*/
k = sizeof (i + j );

45. Implicit Type Conversion
Convert operands to the “narrowest” type that will safely accommodate both values.
If the type of either operand is a floating point:
float -> double - > long double
Otherwise:
if there are short and char operands, convert them to int, then
int -> unsigned int -> long int -> unsigned long int
int i= -10;
unsigned int u=10;

46. Conversion During Assignment
char c = ‘A’;
int ind;
float f;
double d;
i = c; /* will get 65 */
f = i; /* will get 65.0 */
d = f;
i = ; /* 824 */
c= ;
f = 1.0e1000;

47. Explicit Type Conversion: cast
(type-name) expression
Unary operator
float f = 3.45, frac;
frac = f – (int) f;
int num1=5, num2 =3;
float quotient = (float) num1/ num2;
int i=1000;
long int i = (long int) j * j;
long int i = (long int) (j * j)

48. Celsius vs Fahrenheit table (in steps of 20F)‏
C = (5/9)*(F-32);
#include <stdio.h>
int main() {
int fahr, celsius, lower, upper, step;
lower = 0;
upper = 300;
step = 20;
fahr = lower;
while (fahr <= upper) {
celsius = 5 * (fahr - 32) / 9;
printf("%d\t%d\n",fahr, celsius);
fahr += step; }
return 1;
5/9 = 0
Integer arithmetic: 0F = 17C instead of 17.8C
%d, %3d, %6d etc for formatting integers

49. New Version Using Float
#include <stdio.h>
int main() {
float fahr, celsius;
int lower, upper, step;
lower = 0;
upper = 300;
step = 20;
fahr = lower;
while (fahr <= upper) {
celsius = (5.0 / 9.0) * (fahr );
printf("%3.0f %6.2f \n", fahr, celsius);
fahr += step; }
return 1;
%6.2f 6 wide; 2 after decimal
5.0/9.0 =
Float has 32 bits
Double has 64 bits
Long Double has 80 to 128 bits
Depends on computer

50. Version 3 with “for” loop
#include <stdio.h>
int main() {
int fahr;
for (fahr=0; fahr <= 300; fahr += 20)‏
printf("%3d %6.1f \n", fahr,
(5.0 / 9.0) * (fahr – 32.0));
return 1; }

51. Version 4 with Symbolic Constants
#include <stdio.h>
#define LOWER 0
#define UPPER 300
#define STEP 20
int main() {
int fahr;
for (fahr=LOWER; fahr <= UPPER; fahr += STEP)‏
printf("%3d %6.1f \n", fahr,
(5.0 / 9.0) * (fahr ));
return 1; }

52. One –Dimensional Array
Data structure containing a number of values of the same type.
Declare array: type, name and number of elements
int a[10]
Subscripting:
for (i=0; i<N; i++) a[i]=0;
for (i=0; i<N; i++) scanf (“%d”, &a[i]);
i=0;
while (i<N)
a[i++] = 0;
const int month[]={31,28,31,30,31,30,31,31,30,31,30,31};

53. Array Initialization int a[10] = { 1,2,3,4,5,6,7};

54. sizeof Operator for Arrays
sizeof(varName)
Determines the size of variable in bytes.
for ( i = 0; i< sizeof(a) / sizeof(a[0]); i++)
a[i]=0;

55. Multidimensional Array
int m[i][j]
Stores in row-major order
int m[3][3]={{1,2,3},
{4,5,6},
{7,8,9}}
int m[3][3]={{1,2},{4,5,6}}

56. Arrays
Count #occurrences of each digit, blank, tab, newline, other characters
#include <stdio.h>
int main() {
int c, i, nwhite, nother;
int ndigit[10];
nwhite = nother = 0;
for (i=0; i<10; ++i)‏
ndigit[i] = 0;
while ((c = getchar()) != EOF)‏
if (c > '0' && c < '9')‏
++ndigit[c-'0'];
else if (c == ' ' || c == '\n' || c == '\t')‏
++nwhite;
else
++nother;
printf("digits = ");
for (i=0; i<10; ++i)‏
printf("%d ",ndigit[i]);
printf(", white space = %d, other = %d\n",nwhite, nother); }

57. Functions return type function-name (parameters) { declarations
statements }
Function can not return array
If function doesn’t return value, use void.
List of parameters: type name, type name… (void)
ex.:float average(float a, float b){ return (a+b)/2; }

58. Function Calls A call of void function is a statement: void f (int a){
printf(“%d\n”, a); }
f(3+4*5);
A call of non-void function is an expression:
float average(float a, float b){
return (a+b)/2;
float av = average (3+4*5, 2);

59. Function Declaration
C doesn’t require to define function before its first use.
void main() {
int i =4, k=5;
float av = average (i,k); }
float average(float a, float b){ return (a+b)/2; }
To ensure error message, declare function before its first call (function prototype):
return-type function-name(parameters);
float average (float a, float b);
float average(float, float);

60. Arguments Parameters appear in function definition
Arguments are expressions in function calls.
In C, arguments are passed by value
int power (int x, int n);
void main {
int k=3, pow = power (2, k); }
int power (int x, int n){
int result=1;
while (n-- >0) result*=x;
return result;

61. Example void decompose (float x, int integer, float fract){
integer = (int) x;
fract = x – integer; }
void main(){
int i=5;
float f= 3.4;
decompose (3.14, i, f);

62. Array Arguments int f (int a[]) {…} int sum(int[], int);
int sum(int a[], int n){
int i,sum=0;
for(i=0; i<n; i++) sum+=a[i];
return sum; }
int a[10]={1,4,6,7,3,2,4};
int total = sum (a, 10);
int f(int a[][10]){…}

63. return and exit Statements
return expression;
double Largest (double x, double y){
return x>y? x : y; }
void print_int(int i){
if (i<0) return;
printf(“%d\n”,i);
The value returned by main is a status code.
In <stdlib.h>: exit(expression);
Normal success: EXIT_SUCCESS (0)
Abnormal termination: EXIT_FAILURE (1)

64. Recursive Function int power (int x, int n){
return n==0? 1: x*power(x, n-1); }
int factorial(int n){
return n<=1 ? 1 : n*factorial(n-1);
int sum_digits(int n){
return n==0 ? 0: n%10+sum_digits(n/10);

65. Functions #include <stdio.h>
int power(int, int); /* function prototype */
int main() {
int i;
for (i = 0; i < 10; i++)‏
printf("%d %d %d\n", i, power(2,i), power(-3,i)); }
int power(int base, int n) {
int p;
for (p = 1; n > 0; --n)‏
p = p * base;
return p;

66. Functions Call by value mechanism
Change in n's value not reflected in main
Using pointers, we can achieve Call by reference effect.

67. External (Global) Variables
All variables declared so far are local to the functions
External or Global variables are accessible to all functions
These are defined once outside of functions
Must be defined once more within each function which is going to use them

68. Scope Rules Automatic/Local Variables External/Global Variables
Declared at the beginning of functions
Scope is the function body
External/Global Variables
Declared outside functions
Scope is from the point where they are declared until end of file (unless prefixed by extern)‏

69. Scope Rules
Static Variables: use static prefix on functions and variable declarations to limit scope
static prefix on external variables will limit scope to the rest of the source file (not accessible in other files)‏
static prefix on functions will make them invisible to other files
static prefix on internal variables will create permanent private storage; retained even upon function exit

70. Example
int i; //global variable void f1 () { int j=0; //call every time when f invoked j++; }
void f2 () {
static int j=0; //only done once
j++; }

71. Scope Rules Variables can be declared within blocks too
scope is until end of the block

72. Data Structures (struct)
Engineering H192
Winter 2005
Data Structures (struct)
Arrays require that all elements be of the same data type.
C and C++ support data structures that can store combinations of character, integer floating point and enumerated type data. They are called a structs.
Instructor:
Often multiple variables must be passed from one function to another, and often these variables have different data types. Thus it is useful to have a container to store various types of variables in. Structs allow the programmer to do just that.
Lecture 23

73. Engineering H192
Winter 2005
Structures (struct)
A struct is a derived data type composed of members that are each fundamental or derived data types.
A single struct would store the data for one object. An array of structs would store the data for several objects.
A struct can be defined in several ways as illustrated in the following examples:
Structs can contain variables of any variable type previously mentioned as well as more structs. Thus a hierarchical tree can be created out of the user’s data via structs.
Lecture 23

74. Declaring Structures (struct)
Engineering H192
Winter 2005
Declaring Structures (struct)
struct date {
int day;
char month[3];
char year[4];
} ;
/* The name “date" is called a structure tag */
Struct date date1;
Struct date date2 = {3,”Jan”,”1912”};
Struct {
int day;
char month[3];
char year[4];
} my_date ;
my_date date3 = {2,”Jul”,”2010”};
Instructor:
A structure can be defined in two ways. The first method gives the compiler the layout or structure of the struct, but does not actually create one for use. This is useful when the programmer wishes to create global definitions for structs that he or she wishes to use later. The second method varies only in that a variable name now exists after the closing brace of the structure. This variable is now a struct which contains all the variables within the struct definition. Accessing the data in this variable will be discussed in a few slides.
Lecture 23

75. User Defined Data Types (typedef)
Engineering H192
Winter 2005
User Defined Data Types (typedef)
The C language provides a facility called typedef for creating synonyms for previously defined data type names. For example, the declaration:
typedef int Length;
makes the name Length a synonym (or alias) for the data type int.
The data “type” name Length can now be used in declarations in exactly the same way that the data type int can be used:
Length a, b, len ;
Length numbers[10] ;
Instructor:
Typedef acts as a macro for data types. In the given example, whenever the alias Length appears in code, the compiler automatically knows to replace this with int, thus effectively giving length the type definition of int.
Winter Quarter
Lecture 23

76. Engineering H192
Winter 2005
Typedef & Struct
Often, typedef is used in combination with struct to declare a synonym (or an alias) for a structure:
typedef struct /* Define a structure */ {
int label ;
char letter;
char name[20] ;
} Some_name ; /* The "alias" is Some_name */
Some_name mystruct ; /* Create a struct variable */
Instructor:
This struct looks nearly identical to the struct definition which reserves space, but it is important that students understand that NO space has been reserved yet due to the typedef command. Remember typedef (some_data_type) variable; assigns variable the some_data_type type. In this case some_data_type is the ENTIRE struct{} data structure.
Then looking at the last line, where ever Some_name exists the entire struct{} structure is replaced, and mystruct becomes an actual struct variable. Now the programmer can create multiple variables of the Some_name structure type without having to copy and paste the structure type every time he or she defines one of these variables.
Lecture 23

77. Accessing Struct Members
Engineering H192
Winter 2005
Accessing Struct Members
Individual members of a struct variable may be accessed using the structure member operator (the dot, “.”):
  mystruct.letter ;
Or , if a pointer to the struct has been declared and initialized
  Some_name *myptr = &mystruct ;
  by using the structure pointer operator (the “->“):
  myptr -> letter ;
  which could also be written as:
  (*myptr).letter ;
Instructor:
The most common method of accessing a struct is with the structure member operator as shown. Pointers can also be used with structs. The structure pointer operator must then be used to access struct members. Another method is to first dereference the structure pointer and then use the structure member operator to access the members.
Lecture 23

78. Sample Program With Structs
Engineering H192
Winter 2005
Sample Program With Structs
/* This program illustrates creating structs and then declaring and using struct variables. Note that struct personal is an included data type in struct "identity" */
#include <stdio.h>
struct personal //Create a struct {
long id;
float gpa;
} ;
struct identity //Create a second struct that includes the first one.
char name[30];
struct personal person;
int main ( ) {
struct identity js = {"Joe Smith"}, *ptr = &js ;
js.person.id = ;
js.person.gpa = 3.4 ;
printf ("%s %ld %f\n", js.name, js.person.id,
js.person.gpa) ;
printf ("%s %ld %f\n", ptr->name, ptr- >person.id,
ptr->person.gpa) ; }
Instructor:
In the main() function when the struct “js” is created with the structure “identity” a default value for the variable name[30] in the struct “identity” is given. The programmer knows this value will be assigned to name[30] since it is the first and only basic data type in the top-level structure. Following this, a struct pointer is assigned the address of the struct “js.”
The program then shows how values can be assigned and used in multi-level structs given both the struct and a pointer to the struct.
Lecture 23

79. Engineering H192
Enumeration: enum
Winter 2005
enum is a type whose values are listed (enumerated) by the programmer who creates a name (enumeration constant) for each of the values.
enum {yellow,red, green, blue} c1,c2;
enum colors {yellow,red, green, blue};
enum colors c1,c2;
typedef enum {yellow,red, green, blue} Colors;
Colors c1,c2;
typedef enum {FALSE, TRUE} Bool;
C treats enumeration variables and constants as integers.
Lecture 23

80. #include <stdio.h> int main( ) {
Engineering H192
Winter 2005
#include <stdio.h>
int main( ) {
int apr[5][7]={{0,0,0,0,1,2,3},{4,5,6,7,8,9,10},
{11,12,1314,15,16,17},{18,19,20,21,22,23,24},
{25,26,27,28,29,30}};
enum days {Sunday, Monday, Tuesday,
Wednesday, Thursday, Friday, Saturday};
enum week {week_1, week_2, week_3,
week_4, week_5};
printf ("Monday at the third week of April is
April %d\n“, apr [week_3] [Monday] ); }
Lecture 23

81. enum enum dept {CS=20, MATH=10, STAT=25};
enum colors {BLACK, GRAY=7, DK_GRAY, WHITE=15} c;
int i=GRAY; /*it’s 7 now*/
c=0; /*it’s BLACK now*/
c+=8; /*it’s DK_GRAY now*/
i= c+4 *2; /* it’s 16 now */
typedef struct {
enum {RANK, DEG} kind;
union status{
int rank ;
char deg[4]; }; }status;

82. Pointers Executable program consists of both code and data.
Each variable occupies one or more bytes of memory
The address of the first byte is said to be the address of the variable.
Pointer variable is a variable storing address.
int i=1;
int *p = &i;
Declaration:
type *name;
int i, j, *p; … p
2000 1 i …

83. The Address and Indirection operators
& operator: returns address of a variable
int i, *p;
p = &i;
int i, *p=&i;
p is alias for i.
i=1; *p=2;
* operator : returns an object that a pointer points to.
printf(“%d\n”, *p);
int j=*&I;

84. Pointer Assignment int x ,y, *p, *q; p = &x; q= &y; q=p; *p = 1;

85. Pointers as Argument
void decompose (float x, int *integer, float *fract){
*integer = (int) x;
*fract = x – *integer; }
void main(){
int i=5; float f= 3.4;
decompose (3.14, &i, &f); }
scanf(“%d”, &i);
*p= &i;
scanf(“%d”, p);

86. const to Protect Arguments
void f(const int *p){
int j;
p=&j;
*p=1; }
void f(int * const p){
void f(const int * const p){

87. Pointers as Return Values
double *Largest (double *x, double *y){
return *x>*y? x : y; }
int *p, x,y;
p =max(&x, &y);
You can return pointer to one element of the array passed as an argument, to static local variable, to external variable.
Never return a pointer to an automatic local variable!

88. Pointer Arithmetic int a[5], *p=&a[0]; *p=a; int *q; p=&a[2]; q=p+2;

89. Pointer Arithmetic int a[5], *q, *p=&a[4]; q=p-3; p-=4; p a q p a q p

90. Pointer Arithmetic int a[5]; int *q=&a[1], *p=&a[4]; int i=p-q; i=q-p;
Meaningful, if pointers point to the element of the same array.
p<=q
int sum=0;
for (p=&a[0];p<&a[N]; p++)
sum+=*p;

91. Combining * and ++ (--) int sum=0, *p=&a[0]; while (p<&a[N])

92. Array Name as a Pointer int a[10], *p=a; *a =7; *(a+1)=12;
*(a+i) is the same as a[i]
p[i] is the same as *(p+i)
for (p=a; p<a+N; p++) sum+=*p;
Array parameter is treated as pointer, so it’s not protected against change.
The time required to pass array to a function doesn’t depend on its size.
int f(int a[]){…} is the same as int f(int *a){…}
int max = f(&a[5],10);

93. Pointer Example $ cat ptr_example.c #include <stdio.h>
int main() {
int x=1;
int *p; /* p points to an integer */
p = &x; /* Set p to x's address */
printf(" x is %d\n", x);
*p = 0; /* Set p's value to 0 */
printf(" x now is %d\n", x);
return 0; }
$ gcc ptr_example.c -o ptr_example
$ ./ptr_example
x is 1
x now is 0

94. Using pointers to achieve Call-By-Reference effect
Pass the address of a variable
Alter the value
void swap (int *px, int *py) {
int temp;
temp = *px;
*px = *py;
*py = temp; }
int a=10,b=20;
swap(&a,&b);

95. Main difference between arrays and pointers
Even though both contain addresses:
Array name is not a variable; so
pa = a; pa++ OK
a = pa; a++; NOT OK
When an array name is passed as a parameter to a function:
Actually the address of the first element is passed
Arrays are always passed as pointers

96. Strings
Double quotes
C treats string literals as character arrays, that is, a pointer of type char *.
For string literal of length n, it stores n characters of the string literal and null character (‘\0’) to mask the end of the string.
char ch = “abc”[1];
char digit_to_hex(int digit){
return “ ABCDEF”[digit]; }
char *p=“abc”;
*p=‘b’; /* not recommended*/

97. String Variables char str[length+1]; char date[8]=“June 14”;
char date[9]=“June 14”; /*2 null characters at the end*/
char date[]=“June 14”;
char *dt=“June 14”;
Characters of array date can be modified, dt points to string literal which characters should not be modified.
date is an array name, dt is a pointer and can point to the other string literal.
char str[length+1], *p;
p=str;

98. Writing Strings printf(“%s\n”,str);
printf(“%.4s\n”,”C is a fun language”);
printf(“%10s\n”,”Hi”);
printf(“%10.4s\n”,”C is a fun language”);
puts(str);

99. Reading Strings scanf(“%s”, str); / *never contain white spaces*/
gets(str);
Reads until finds newline character
It replaces newline character with null character before storing to a variable
Doesn’t skip leading white spaces

100. C String Library char str1[10],str2[10]; str1=“abc”; /*wrong*/
str2=str1; /*wrong*/
str1==str2 compares pointers!
<string.h>
char * strcpy(char *s1, const char *s2);
strcpy(str2, “abcd”);
strcpy(str1,strcpy(str2, “abcd”));

101. C String Library char * strcat(char *s1, const char *s2);
strcat(str1, “abc”); strcat(str2, “def”);
strcat(str1, strcat(str2,”gi”));
int strcmp(const char *s1, const char *s2);
Lexicographic ordering
if (strcmp(str1,str2)<0) …
size_t strlen(const char *s);
int len = strlen(“abc”);
len = strlen(“”);

102. String Idiom Search for the null character at the end of a string:
while(*s) s++;
while(*s++);
size_t strlen(const char *s){
const char *p=s;
while (*s++);
return s-p; }

103. Dynamic Storage Allocation
It’s ability to allocate storage during program execution
Available for all types of data
Mostly used for strings, arrays and structures.
Dynamically allocated structures can form lists, trees and other data structures.
<stdlib.h>
malloc : allocates a block of memory, but doesn’t initialize it
calloc: allocates a block of memory and clears it
free: releases the specified block of memory

104. NULL Pointer
If memory allocation function can’t allocate a block of the requested size, it returns a null pointer (NULL).
<locale.h>,<stddef.h>,<stdio.h>,<stdlib.h>, <string.h>, <time.h>
It is responsibility of a programmer to test if received pointer is a null pointer.
p=malloc(1000);
if (p==NULL) { /* appropriate actions*/ }
if ((p=malloc(1000))==NULL) { /*actions*/ }
if (p) …. is the same as if (p!=NULL)
if (!p) …. is the same as if (p==NULL)

105. Using malloc: Strings void *malloc(size_t size);
Allocates a block of size bytes and returns a pointer to it; if fails, returns NULL.
Since sizeof(char) is1, to allocate space for a string of n characters:
char *p=malloc(n+1);
Memory allocated using malloc isn’t cleared or initialized: strcpy(p, “abc”);
There are no checks to detect usage of memory outside the bounds of the block
Dynamical allocation makes possible to write functions that return a pointer to a “new” string: char *p= concat(“abc”,”def”);

106. #include<string. h> #include<stdlib. h> #include<stdio
#include<string.h> #include<stdlib.h> #include<stdio.h> char *concat(const char *s1, const char *s2 ){ char *result=malloc(strlen(s1)+strlen(s2)+1); if (result==NULL){ printf(“malloc failed\n”); exit(EXIT_FAILURE); } strcpy(result,s1); strcpy(result,s2); return result;

107. Dynamically Allocated Arrays
Elements of an array can be longer than one byte => sizeof should be used.
int *a=malloc(n * sizeof (int));
for(i=0;i<n;i++) a[i]=0;
void *calloc(size_t nmemb, size_t size);
Allocates space for an array with nmemb elements, each of which is size bytes; sets all bits to 0 and returns a pointer to it.
If space is not available, returns NULL.
int *a=calloc(n, sizeof(int));
struct point {int x,y;} *p;
p=calloc(1, sizeof(struct point));

108. Deallocating Storage
Memory block are obtained from a storage pool (heap).
Garbage is a block of memory that’s no longer accessible to a program.
A program that leaves garbage behind has a memory leak.
int *p=malloc(100), *q=malloc(100);
p=q;
void free (void *ptr);
free(p);

109. Memory Leak: Examples int *int_ptr; for (;;) {
int_ptr = malloc(100 * sizeof(int) );
if ( int_ptr == NULL ) {
fprintf(stderr, "...");
exit(1); }
for ( i = 1; i <= 5; i++)
printf("%s\n", concat(“abc”, “012345”[digit]));

110. Memory Leak for ( i = 1; i <= 5; i++) {
char *str=concat(“abc”, “012345”[digit]);
printf("%s\n", str);
free(str); }
free(str); }

111. Dangling Pointers char *p=malloc(4); … free(p);
strcpy(p,”abc”); /*wrong*/
Several pointers may point to the same block of memory. When the block is freed, all these pointers are left dangling.

112. Memory Allocation Rules
If memory is allocated it must be freed.
Do not use memory after it is freed.
Do not free memory that will be used later.
Do not free a block of memory more than once.
Do not free memory that was not allocated.
Do not use memory outside the bounds of an allocated block.

113. Linked Lists
A linked list is a chain of structures (nodes), with each node containing a pointer to the next node in the chain.
The last node in the list contains a null pointer.

114. Declaring a Node Type struct node{ int value; struct node *next; }
struct point {
double x,y; };
struct vertex {
struct point element;
struct vertex *next;}

115. Building Linked List new_node Store data into the node
First, create an empty list
struct node *first=NULL;
Then create nodes one by one:
Allocate memory for the node
struct node *new_node;
new_node=malloc(sizeof (struct node));
new_node
Store data into the node
(*new_node).value=10;
new_node->value=10;
Insert the node into the list 10
new_node

116. Inserting a Node at the Beginning of the List
If first points to the first node of the linked list:
new_node->next=first;
first=new_node;
struct node *first=NULL, *new_node;
first
new_node
new_node=malloc(sizeof (struct node));
first
new_node

117. Inserting a Node at the Beginning of the List
new_node->value=10; 10
new_node
first
new_node->next=first;
first 10
new_node
first=new_node;
first 10
new_node

118. Inserting a Node at the Beginning of the List
new_node=malloc(sizeof (struct node));
first 10
new_node
new_node->value=20;
first 10 20
new_node
new_node->next=first;
first 10 20
new_node
first=new_node;
first 20
new_node 10

119. Searching a Linked List
for (p=first; p!=NULL; p=p->next)
{… }
int value=20; struct node *p;
{ if (p->value== value) return p; }
struct node *find(struct node *list, int n){
while (list!=NULL and list->value!=n )
p=p->next;
return list; }
first 20 10

120. Inserting a Node at the Middle of the List
first 20 10
cur
struct *node p=first;
struct node * cur= find(p, 10);
struct node *tmp =malloc(sizeof (struct node));
tmp->value= cur->value;
tmp->next = cur->next_ptr; 10
tmp
cur->value = 15;
cur->next = tmp;
first 20
cur 15
first 20
cur 15

121. Deleting a Node from the List
first 20 15
cur
tmp 10
struct *node p=first;
struct node * cur= find(p, 20);
struct node *tmp;
tmp = cur->next;
cur->value = tmp->value;
first 15
cur 10
tmp
cur->next = tmp->next;
first 15
cur 10
tmp
free(tmp);
first 15 10

122. Review C versus Java C data types Functions Control Flow Scope
Pointers, Arrays
Strings
