1. STRUCTURE OF PROGRAMMING LANGUAGES
Dr Yasser Fouad
STRUCTURE OF PROGRAMMING LANGUAGES

2. Book

3. Quote of the Day “A language that doesn't affect
the way you think about programming,
is not worth knowing.”
- Alan Perlis

4. Then you decide to get a PhD
You get tired of the PowerPoint and its animations. You embed a domain-specific language (DSL) into Ruby. …

5. Reasons for Studying Concepts of Programming Languages
Increased ability to express ideas
Improved background for choosing appropriate languages
Increased ability to learn new languages
Better understanding of significance of implementation
Overall advancement of computing

6. How is this class different?
It’s about:
foundations of programming langauges
but also how to design your own languages
how to implement them
and about PL tools, such as analyzers
also learn about some classical C.S. algorithms.

7. Why a developer needs PL
New languages will keep coming
Understand them, choose the right one.
Write code that writes code
Be the wizard, not the typist.
Develop your own language.
Are you kidding? No.
Learn about compilers and interpreters.
Programmer’s main tools.

8. Overview how many languages does one need?
how many languages did you use? Let’s list them here:

9. Develop your own language
Are you kidding? No. Guess who developed:
PHP
Ruby
JavaScript
perl
Done by smart hackers like you
in a garage
not in academic ivory tower
Our goal: learn good academic lessons
so that your future languages avoid known mistakes

10. Programming Domains Scientific applications Business applications
Large number of floating point computations
Fortran
Business applications
Produce reports, use decimal numbers and characters
COBOL
Artificial intelligence
Symbols rather than numbers manipulated
LISP
Systems programming
Need efficiency because of continuous use C
Web Software
Eclectic collection of languages: markup (e.g., XHTML), scripting (e.g., PHP), general-purpose (e.g., Java)

12. Figure by Brian Hayes (who credits, in part, Éric Lévénez and Pascal Rigaux): Brian Hayes, “The Semicolon Wars.” American Scientist, July-August 2006, pp
Also see figure A.1 in [S], p.820.

13. Genealogy of Common Language

14. Programming Paradigms
A programming language is a problem-solving tool.
Imperative style:
program = algorithms + data
good for decomposition
Functional style:
program = functions o functions
good for reasoning
Logic programming style:
program = facts + rules
good for searching
Object-oriented style:
program = objects + messages
good for modeling(!)
Other styles and paradigms: blackboard, pipes and filters, constraints, lists, ...
PS — Introduction
© O. Nierstrasz

15. Language Categories Imperative Functional Logic Object-oriented Markup
Central features are variables, assignment statements, and iteration
Examples: C, Pascal
Functional
Main means of making computations is by applying functions to given parameters
Examples: LISP, Scheme
Logic
Rule-based (rules are specified in no particular order)
Example: Prolog
Object-oriented
Data abstraction, inheritance, late binding
Examples: Java, C++
Markup
New; not a programming per se, but used to specify the layout of information in Web documents
Examples: XHTML, XML

16. Program
A program is a machine-compatible representation of an algorithm
If no algorithm exists for performing a task, then the task can not be performed by a machine
Programs and algorithms they represent collectively referred to as Software

17. What is a Programming Language?
A formal language for describing computation?
A “user interface” to a computer?
Syntax + semantics?
Compiler, or interpreter, or translator?
A tool to support a programming paradigm?
A programming language is a notational system for describing computation in a machine-readable and human-readable form.
— Louden
© O. Nierstrasz
PS — Introduction

18. Programming Methodologies Influences
1950s and early 1960s: Simple applications; worry about machine efficiency
Late 1960s: People efficiency became important; readability, better control structures
structured programming
top-down design and step-wise refinement
Late 1970s: Process-oriented to data-oriented
data abstraction
Middle 1980s: Object-oriented programming
Data abstraction + inheritance + polymorphism

19. Favorite programming language June 2012
Python (3,054)
Ruby (1,723)
JavaScript (1,415)
C (970)
C# (829)
PHP (666)
Java (551)
C++ (529)
Haskell (519)
Clojure (459)
CoffeeScript (362)
Objective C (326)
Lisp (322)
Perl (311)
Scala (233)
Scheme (190)
Other (188)
Erlang (162)
Lua (145)
SQL (101)

22. job listings collected from Dice.com
Python 3,456 (+32.87%)
Ruby 2,141 (+39.03%)
HTML5 ( %)
Flash 1,261 (+95.2%)
Silverlight 865 (-11.91%)
COBOL 656 (-10.75%)
Assembler 209 (-1.42%)
PowerBuilder (-18.71%)
FORTRAN 45 (-33.82%)
Java 17,599 (+8.96%)
XML 10,780 (+11.70%)
JavaScript (+11.64%)
HTML 9,587 (-1.53%)
C# 9,293 (+17.04%)
C++ 6,439 (+7.55%)
AJAX 5,142 (+15.81%)
Perl 5,107 (+3.21%)
PHP 3,717 (+23%)

24. Languages in Common Use

25. A Brief Chronology Early 1950s “order codes” (primitive assemblers)
1957
FORTRAN
the first high-level programming language
1958
ALGOL
the first modern, imperative language
1960
LISP, COBOL
Interactive programming; business programming
1962
APL, SIMULA
the birth of OOP (SIMULA)
1964
BASIC, PL/I
1966
ISWIM
first modern functional language (a proposal)
1970
Prolog
logic programming is born
1972 C
the systems programming language
1975
Pascal, Scheme
two teaching languages
1978
CSP
Concurrency matures FP
Backus’ proposal
1983
Smalltalk-80, Ada
OOP is reinvented
1984
Standard ML
FP becomes mainstream (?)
1986
C++, Eiffel
OOP is reinvented (again)
1988
CLOS, Oberon, Mathematica
1990
Haskell
FP is reinvented
1990s
Perl, Python, Ruby, JavaScript
Scripting languages become mainstream
1995
Java
OOP is reinvented for the internet
2000 C#
PS — Introduction
© O. Nierstrasz

26. ENIAC (1946, University of Philadelphia)
ENIAC program for external ballistic equations:
1946
ENIAC was unveiled in Philadelphia. ENIAC represented still a stepping stone towards the true computer, for differently than Babbage, Eckert and Mauchly, although they knew that the machine was not the ultimate in the state-of-the-art technology, completed the construction. ENIAC was programmed through the rewiring the interconnections between the various components and included the capability of parallel computation. ENIAC was later to be modified into a stored program machine, but not before other machines had claimed the claim to be the first true computer was the year in which the first computer meeting took place, with the University of Pennsylvania organizing the first of a series of "summer meetings" where scientists from around the world learned about ENIAC and their plans for EDVAC. Among the attendees was Maurice Wilkes from the University of Cambridge who would return to England to build the EDSAC.
Later that year Eckert and Mauchly, in a patent dispute with the University of Pennsylvania, left the University to establish the first computer company -- Electronic Control Corp. with a plan to build the Universal Automatic Computer (UNIVAC). After many crises they built the BINAC for Northrup Aviation, and were taken over by Remington-Rand before the UNIVAC was completed. At the same time the Electronic Research Associates (ERA) was incorporated in Minneapolis and took their knowledge of computing devices to create a line of computers; later ERA was also assimilated into Remington-Rand.

27. Programming the ENIAC

28. ENIAC (1946, University of Philadelphia)
programming done by
rewiring the interconnections
to set up desired formulas, etc
Problem (what’s the tedious part?)
programming = rewiring
slow, error-prone
solution:
store the program in memory!
birth of von Neuman paradigm
1946
ENIAC was unveiled in Philadelphia. ENIAC represented still a stepping stone towards the true computer, for differently than Babbage, Eckert and Mauchly, although they knew that the machine was not the ultimate in the state-of-the-art technology, completed the construction. ENIAC was programmed through the rewiring the interconnections between the various components and included the capability of parallel computation. ENIAC was later to be modified into a stored program machine, but not before other machines had claimed the claim to be the first true computer was the year in which the first computer meeting took place, with the University of Pennsylvania organizing the first of a series of "summer meetings" where scientists from around the world learned about ENIAC and their plans for EDVAC. Among the attendees was Maurice Wilkes from the University of Cambridge who would return to England to build the EDSAC.
Later that year Eckert and Mauchly, in a patent dispute with the University of Pennsylvania, left the University to establish the first computer company -- Electronic Control Corp. with a plan to build the Universal Automatic Computer (UNIVAC). After many crises they built the BINAC for Northrup Aviation, and were taken over by Remington-Rand before the UNIVAC was completed. At the same time the Electronic Research Associates (ERA) was incorporated in Minneapolis and took their knowledge of computing devices to create a line of computers; later ERA was also assimilated into Remington-Rand.

29. Assembly – the language (UNIVAC 1, 1950)
Idea: mnemonic (assembly) code
Then translate it to machine code by hand (no compiler yet)
write programs with mnemonic codes (add, sub), with symbolic labels,
then assign addresses by hand
Example of symbolic assembler
clear-and-add a
add b
store c
translate it by hand to something like this (understood by CPU)
B100 A200
C300
Drop this slide?
With assemblers and compilers not yet developed, for the Univac to access a number in memory required that I first give it a specific address out of the 1,000 available locations. For example, to add two numbers together that were found in locations 100 and 200, the following code would have to be executed:
Bring the contents of location 100 into the add register. Add the contents of location 200 to the add register. Store the sum, which was in the add register, into location 300.
Thus it took three instructions, or one and a half words, to add two numbers together and save the result. The coding would look like this:
B100 A200
C300
If we could use symbolic locations and assign the actual locations later, it would help to organize the memory more efficiently. Also, if we changed some record or code, it would not be so tedious to correct the code. After training, we manually coded symbolically such as clear and add a, add b, store c and supplied the exact addresses at the end of coding.

30. Assembly Language
ADDI R4 R2 21
ADDI R4,R2,21
Use symbols instead of binary digits to describe fields of instructions.
Every aspect of machine visible in program:
One statement per machine instruction.
Register allocation, call stack, etc. must be managed explicitly.
No structure: everything looks the same.

31. Assembler – the compiler (Manchester, 1952)
a loop example, in MIPS, a modern-day assembly code:
loop: addi $t3, $t0, -8
addi $t4, $t0, -4
lw $t1, theArray($t3) # Gets the last
lw $t2, theArray($t4) # two elements
add $t5, $t1, $t2 # Adds them together...
sw $t5, theArray($t0) # ...and stores the result
addi $t0, $t0, 4 # Moves to next "element“
# of theArray
blt $t0, 160, loop # If not past the end of
# theArray, repeat
jr $ra

32. High-level Language
Provides notation to describe problem solving strategies rather than organize data and instructions at machine-level.
Improves programmer productivity by supporting features to abstract/reuse code, and to improve reliability/robustness of programs.
Requires a compiler.

33. FORTRAN I (1954-57) Langauge, and the first compiler
Produced code almost as good as hand-written
Huge impact on computer science
Modern compilers preserve its outlines
By 1958, >50% of all software is in FORTRAN

34. FORTRAN I Example: nested loops in FORTRAN
a big improvement over assembler,
but annoying artifacts of assembly remain:
labels and rather explicit jumps (CONTINUE)
lexical columns: the statement must start in column 7
The MIPS loop from previous slide, in FORTRAN:
DO 10 I = 2, 40
A[I] = A[I-1] + A[I-2]
10 CONTINUE

35. “Hello World” in FORTRAN
PROGRAM HELLO
DO 10, I=1,10
PRINT *,'Hello World'
10 CONTINUE
STOP
END
All examples from the ACM "Hello World" project:
www2.latech.edu/~acm/HelloWorld.shtml
© O. Nierstrasz
PS — Introduction

36. Side note: designing a good language is hard
Good language protects against bugs, but lessons take a while.
An example that caused a failure of a NASA planetary probe:
buggy line:
DO 15 I = 1.100
what was intended (a dot had replaced the comma):
DO 15 I = 1,100
because Fortran ignores spaces, compiler read this as:
DO15I = 1.100
which is an assignment into a variable DO15I, not a loop.
This mistake is harder to make (if at all possible) with the modern lexical rules (white space not ignored) and loop syntax
for (i=1; i < 100; i++) { … }

37. “Hello World” in COBOL 000100 IDENTIFICATION DIVISION.
PROGRAM-ID. HELLOWORLD.
DATE-WRITTEN. 02/05/ :04.
000400* AUTHOR BRIAN COLLINS
ENVIRONMENT DIVISION.
CONFIGURATION SECTION.
SOURCE-COMPUTER. RM-COBOL.
OBJECT-COMPUTER. RM-COBOL.
DATA DIVISION.
FILE SECTION.
PROCEDURE DIVISION.
MAIN-LOGIC SECTION.
BEGIN.
DISPLAY " " LINE 1 POSITION 1 ERASE EOS.
DISPLAY "HELLO, WORLD." LINE 15 POSITION 10.
STOP RUN.
MAIN-LOGIC-EXIT.
EXIT.
© O. Nierstrasz
PS — Introduction

38. ALGOL 60
History
Committee of PL experts formed in 1955 to design universal, machine-independent, algorithmic language
First version (ALGOL 58) never implemented; criticisms led to ALGOL 60
Innovations
BNF (Backus-Naur Form) introduced to define syntax (led to syntax-directed compilers)
First block-structured language; variables with local scope
Structured control statements
Recursive procedures
Variable size arrays
Successes
Highly influenced design of other PLs but never displaced FORTRAN
Motivations: fear of IBM; targeting general market
Recursive procedures — originally thought “academic”
Variable size arrays — bound when block is entered
© O. Nierstrasz
PS — Introduction

39. “Hello World” in BEALGOL
BEGIN
FILE F (KIND=REMOTE);
EBCDIC ARRAY E [0:11];
REPLACE E BY "HELLO WORLD!";
WHILE TRUE DO
WRITE (F, *, E);
END;
END.
© O. Nierstrasz
PS — Introduction

40. “Hello World” in PL/1 HELLO: PROCEDURE OPTIONS (MAIN);
/* A PROGRAM TO OUTPUT HELLO WORLD */
FLAG = 0;
LOOP: DO WHILE (FLAG = 0);
PUT SKIP DATA('HELLO WORLD!');
END LOOP;
END HELLO;
© O. Nierstrasz
PS — Introduction

41. “Hello World” in Functional Languages
SML
Haskell
print("hello world!\n");
hello() = print "Hello World"
© O. Nierstrasz
PS — Introduction

42. Goto considered harmful
L1: statement
if expression goto L1
statement
Dijkstra says: gotos are harmful
use structured programming
lose some performance, gain a lot of readability
how do you rewrite the above code into structured form?

43. Special-Purpose Languages
SNOBOL
First successful string manipulation language
Influenced design of text editors more than other PLs
String operations: pattern-matching and substitution
Arrays and associative arrays (tables)
Variable-length strings
...
Variable-length strings — uncommon in other languages!
OUTPUT = 'Hello World!'
END
© O. Nierstrasz
PS — Introduction

44. Object-Oriented Languages
History
Simula was developed by Nygaard and Dahl (early 1960s) in Oslo as a language for simulation programming, by adding classes and inheritance to ALGOL 60
Smalltalk was developed by Xerox PARC (early 1970s) to drive graphic workstations
Begin
while 1 = 1 do begin
outtext ("Hello World!");
outimage;
end;
End;
Transcript show:'Hello World';cr
© O. Nierstrasz
PS — Introduction

45. 4GLs “Problem-oriented” languages PLs for “non-programmers”
Very High Level (VHL) languages for specific problem domains
Classes of 4GLs (no clear boundaries)
Report Program Generator (RPG)
Application generators
Query languages
Decision-support languages
Successes
Highly popular, but generally ad hoc
PLs for “non-programmers” — i.e., as opposed to COBOL!
RPG — first 4GL: 1960s
Application generators — routine applications
Decision-support languages — integrated DB, stats etc.
© O. Nierstrasz
PS — Introduction

46. “Hello World” in SQL CREATE TABLE HELLO (HELLO CHAR(12)) UPDATE HELLO
SET HELLO = 'HELLO WORLD!'
SELECT * FROM HELLO
© O. Nierstrasz
PS — Introduction

47. Scripting Languages History
Countless “shell languages” and “command languages” for operating systems and configurable applications
Unix shell (ca. 1971) developed as user shell and scripting tool
HyperTalk (1987) was developed at Apple to script HyperCard stacks
TCL (1990) developed as embedding language and scripting language for X windows applications (via Tk)
Perl (~1990) became de facto web scripting language
echo "Hello, World!"
on OpenStack
show message box
put "Hello World!" into message box
end OpenStack
puts "Hello World "
print "Hello, World!\n";
© O. Nierstrasz
PS — Introduction

48. How do Programming Languages Differ?
Common Constructs:
basic data types (numbers, etc.); variables; expressions; statements; keywords; control constructs; procedures; comments; errors ...
Uncommon Constructs:
type declarations; special types (strings, arrays, matrices, ...); sequential execution; concurrency constructs; packages/modules; objects; general functions; generics; modifiable state; ...
© O. Nierstrasz
PS — Introduction

49. Improved background for choosing appropriate languages
C vs. Modula-3 vs. C++ for systems programming
Fortran vs. APL vs. Ada for numerical computations
Ada vs. Modula-2 for embedded systems
Common Lisp vs. Scheme vs. Haskell for symbolic data manipulation
Java vs. C/CORBA for networked PC programs
[Scott]

50. Evolution of Programming Languages
ALGOL
- 60 (ALGOrithmic Language)
Goals : Communicating Algorithms
Features : Block Structure (Top-down design)
Recursion (Problem-solving strategy)
BNF - Specification
LISP (LISt Processing)
Goals : Manipulating symbolic information
Features : List Primitives
Interpreters / Environment

51. Evolution of Programming Languages
Pascal
Goal : Structured Programming, Type checking,
Compiler writing.
Features :
Rich set of data types for efficient
algorithm design
E.g., Records, sets, ...
Variety of “readable” single-entry
single-exit control structures
E.g., for-loop, while-loop,...
Efficient Implementation
Recursive descent parsing

52. Other Languages Functional Logic Object-oriented Hybrid
LISP, Scheme
ML, Haskell
Logic
Prolog
Object-oriented
Smalltalk, SIMULA, Modula-3, Oberon
C++, Java, C#, Eiffel, Ada-95
Hybrid
Python, Ruby, Scala
Application specific languages and tools

53. Programming LanguagesC
Bell labs  Dennis Ritchie, 1973
C++
Bjarne Stroustrup, 1980
Hybrid OOP
Java
Sun Microsystems (formally announced in May 1995)
Pure OOP
Web programming

54. Current Trend Multiparadigm languages
Functional constructs for programming in the small
Focus on conciseness and correctness
Object-Oriented constructs for programming in the large
Focus on programmer productivity and code evolution
Example languages
Older: Python, Ruby,
Recent: Scala, F#, etc

55. Scheme (dialect of LISP)
Recursive definitions
Symbolic computation : List Processing
Higher-order functions
Dynamic type checking
Functional + Imperative features
Automatic storage management
Provides a uniform executable platform for studying, specifying, and comparing languages.
The language we use for programming in CS784.

56. Java vs Scala public String buildEpochKey(String... keys) {
//Java - what we're used to seeing
public String buildEpochKey(String... keys) {
StringBuilder s = new StringBuilder("elem")
for(String key:keys) {
if(key != null) {
s.append(".")
s.append(key) }
return s.toString(). toLowerCase()

57. Java vs Scala def buildEpochKey(keys: String*): String = {
("elem" +: keys) filter(_ != null)
mkString(".")
toLowerCase }
+: means add the item before the +: to the item after it
filter filters a collection based on the closure after it. Filter will pass each item into the closure. If the closure returns true, the item will be added to the new collection, otherwise it won't.
_ in a closure is a shortcut for saying the first parameter passed in
mkString is Scala's version of join. mkString also has a variant that takes delimiters.
toLowerCase is just that. A call on the string that is the result of mkString

58. Implementation Methods
Compilation
Programs are translated into machine language
Pure Interpretation
Programs are interpreted by another program known as an interpreter
Hybrid Implementation Systems
A compromise between compilers and pure interpreters

59. Compilation
Translate high-level program (source language) into machine code (machine language)
Slow translation, fast execution
Compilation process has several phases:
lexical analysis: converts characters in the source program into lexical units
syntax analysis: transforms lexical units into parse trees which represent the syntactic structure of program
Semantics analysis: generate intermediate code
code generation: machine code is generated

60. The Compilation Process

61. Additional Compilation Terminologies
Load module (executable image): the user and system code together
Linking and loading: the process of collecting system program and linking them to user program

62. Pure Interpretation No translation
Easier implementation of programs (run-time errors can easily and immediately displayed)
Slower execution (10 to 100 times slower than compiled programs)
Often requires more space
Becoming rare on high-level languages
Significant comeback with some Web scripting languages (e.g., JavaScript)

63. Hybrid Implementation Systems
A compromise between compilers and pure interpreters
A high-level language program is translated to an intermediate language that allows easy interpretation
Faster than pure interpretation
Examples
Perl programs are partially compiled to detect errors before interpretation
Initial implementations of Java were hybrid; the intermediate form, byte code, provides portability to any machine that has a byte code interpreter and a run-time system (together, these are called Java Virtual Machine)

64. Just-in-Time Implementation Systems
Initially translate programs to an intermediate language
Then compile intermediate language into machine code
Machine code version is kept for subsequent calls
JIT systems are widely used for Java programs
.NET languages are implemented with a JIT system

65. Programming Environments
The collection of tools used in software development
UNIX
An older operating system and tool collection
Nowadays often used through a GUI (e.g., CDE, KDE, or GNOME) that run on top of UNIX
Borland JBuilder
An integrated development environment for Java
Microsoft Visual Studio.NET
A large, complex visual environment
Used to program in C#, Visual BASIC.NET, Jscript, J#, or C++

66. What Does This C Statement Mean?
modifies *p
*p++ = q++
increments p
increments q
Does this mean…
… or
… or
*p = *q;
++p;
++q;
*p = *q;
++q;
++p;
tp = p;
++p;
tq = q;
++q;
*tp = *tq;

67. Languages Simula Smalltalk Algol Cobol F# Prolog Pascal Modula-2 ADA
PL/I
CORBA
PERL
BASIC
JAVASCRIPT
LISP
MIRANDA ML
SCHEMA
SNOBOL
APL
DELPHI
MAYA

68. Can you answer these questions?
Why are there so many programming languages?
Why are FORTRAN and COBOL still important programming languages?
Which language should you use to implement a spelling checker?
A filter to translate upper-to-lower case?
A theorem prover?
An address database?
An expert system?
A game server for initiating chess games on the internet?
A user interface for a network chess client?
© O. Nierstrasz
PS — Introduction
