2 Copyright © 2005 Toshiba Corporation. All rights reserved. The Portégé S100 Sales presentation

3 June 20052/Portégé S100 Notebook & AV Notebook PC segmentation: usage pattern / performance price Qosmio G20 Qosmio F20 Qosmio G10 Satellite M60 price Portégé M200 Tecra M4 price Libretto U100 Portégé R200 Portégé M300 Portégé S100 price Satellite M50Tecra A5 Tecra M3 Tecra A4 Satellite L10Satellite Pro L10 Satellite M40X price Tecra S2 Tecra A3 Performance Mobile Entertainment Centre Ultra-mobile Mobile Tablet PC Desktop replacement 1.click to see picture 2.click to hide picture

4 June 20053/Portégé S100 Positioning Portégé S100: The world’s 1st thin and light notebook with RAID support

5 June 20054/Portégé S100 Why choose the Portégé S100? Equipped with the Toshiba EasyGuard package for carefree mobile computing, the better way to enhanced data security, advanced system protection and easy connectivity Toshiba RAID* support offers improved data protection by mirroring data to a second HDD in order to prevent accidental data loss and minimise downtime Experience amazing mobility weighing from just 1.99 kg, featuring a 14.1" XGA TFT display with stunning 3D NVIDIA® GeForce™ graphics, common docking support and swappable Ultra-slim SelectBay modularity Superb system performance thanks to the latest Intel® Centrino™ mobile technology, Mobile Intel® 915 PM Express chipset, high speed DDR2 memory and Serial ATA HDD Experience the rewards of seamless connectivity with everything onboard, including Wireless LAN 802.11a/b/g, Ethernet Gigabit LAN, i.LINK® port, 2 USB ports, Fast InfraRed and modem 1 2 3 4 5 * Optional second HDD and HDD adapter is required for Toshiba RAID support

6 June 20055/Portégé S100 New and exclusive: Toshiba EasyGuard Toshiba EasyGuard is the better way to enhanced data security, advanced system protection and easy connectivity. This next-generation computing experience incorporates technologies enabling optimal connectivity and security, Toshiba anti-accident innovations and advanced software utilities for carefree mobile computing.

7 June 20056/Portégé S100 Toshiba Assist button to access PC diagnostics, expansion/connectivity utilities and added productivity features instantly. Enter the world of carefree mobile computing with Toshiba EasyGuard. Simply press the button

8 June 20057/Portégé S100 Three core elements for carefree mobile computing In addressing the need for enhanced data security, advanced system protection and easy connectivity. Toshiba EasyGuard features can be divided into its three core elements: Secure Features that deliver enhanced system and data security Protect & Fix Protective design features and diagnostics utilities for maximum uptime Connect Features and software utility that ensures easy and reliable wired and wireless connectivity BenefitsElements Product shown: Portégé M300

9 June 20058/Portégé S100 Toshiba EasyGuard features and benefits: Portégé S100 Benefit Feature 2 1 3 4 Execute Disable Bit (XD-Bit)Industry standard that prevents buffer overflow virus attacks. Trusted Platform Module (TPM) Industry standard hardware / software security solution that protects sensitive data, encryption and digital signatures to ensure content integrity and privacy. Device LockToshiba software utility that allows flexible locking of specific devices in order to prevent unauthorised access to computer or copying of confidential files. Password UtilitiesToshiba software utilities that allows system administrators and users to set up of boot and HDD access passwords. Antivirus SoftwareSymantec's Norton Internet Security 2004 provides essential protection from viruses, hackers, and privacy threatsand is pre- installed as 90 day free trial version. Toshiba RAIDLevel 1 RAID support leads to minimised downtime by protecting against data loss and ensuring quick data recovery Spill-resistant KeyboardPrevents system damage from accidental spills onto the keyboard (up to 30 cc water). Shock Protection DesignSpecially designed shock absorption that encloses key components, such as HDD, LCD and inverter to help reduce risk of damage in case of accidental shock, vibration or fall. HDD ProtectionShock absorption in combination with Toshiba’s own 3-axis motion monitoring for reduced risk of hard disk drive damage and data loss in case of fall, shock or vibration. Data BackupBackup your data to protect it against accidental loss and store your backup copies on external hard disk drive, CDs, DVDs, or some other storage format. Easy Fix ComponentsEasy to access and exchange of components, such as memory, HDD, modem, Wireless LAN and Bluetooth™ modules can save maintenance cost and minimise system downtime. Durable DesignRobust system design for improved product quality, reliability and durability. Magnesium CaseworkSpecial alloy casework that ensures robustness while providing the light weight required from a notebook computer. PC DiagnosticsSpecially developed Toshiba software that provides one-touch system support and services to save maintenance cost and minimise system downtime. Kensington LockIndustry standard external locking device that helps to prevent notebook theft. Toshiba ConfigFree™Software developed by Toshiba that allows users to quickly and easily set up a network connection, troubleshoot any connectivity problems, and capture a complete set of location settings for easy, one-button future use. Toshiba SummitSoftware developed by Toshiba for net meeting productivity and easy wireless file sharing. Diversity AntennaToshiba innovation (2 Wi-Fi™ antenna and 1 Bluetooth™ antenna in LCD display) that provides better Wi-Fi™ signal reception for optimal wireless connectivity. Wireless LAN SwitchSliding switch for easy and secure activation / deactivitation of integrated Wireless LAN or Bluetooth™ modules 5 6 7 8

10 June 20059/Portégé S100 4 3 2 1 0 4 3 2 1 0 RAID-1 4 3 2 1 0 Unable to read data in the bad block. Standalone Application Read from 2 nd HDD and fix No2 of 1 st HDD Application Fixed 4 3 2 1 0 4 3 2 1 0 RAID-1 Read from 2 nd HDD. But does not fix No2 of 1 st HDD Application Not fixed Toshiba RAID1Intel IAA’s RAID1 Toshiba RAID* support What is RAID ? RAID stands for Redundant Array of Inexpensive (or sometimes "Independent") Disks. RAID is a method of creating one or more pools of data storage space from several hard drives. It can offer fault tolerance and higher throughput levels than a single hard drive or group of independent hard drives. Supports RAID Level 1* and ensures that data from main HDD (hard disk drive) is mirrored to optional Ultra-slim SelectBay HDD for full data redundancy and protection against accidental data loss Data mirroring ensures data availability in event of HDD crash and allows for quick and simple swapping of defective HDD with intact HDD for minimum downtime * Optional second HDD and HDD adapter is required for Toshiba RAID support

11 June 200510/Portégé S100 What is the benefit of Toshiba RAID support RAID-1 supported Customer can continue computing with zero downtime even when one of hard drives is crushed (reliable computing by RAID- 1 technology). Hard drive hot plug is supported Hot insertion/extraction of the select bay hard drive is still supported on the RAID-1 system as same as stand alone configuration. Hard drive password is supported Hard drive password is still supported on the RAID system when insert the select bay hard drive on Windows running state as same as stand alone configuration. Hot Reconfiguration is supported Customer can change the configuration status from/to stand alone to/from RAID-1 mutually by using RAID utility on Windows. Easy access to RAID status icon on task tray Easy to open the RAID utility and to check/change the status of RAID configuration. Alarm by buzzer and pop up message The RAID system notify users by buzzer and pop up message when one of the two hard drives have trouble (hardware crush or one of two hard drives is extracted).

12 June 200511/Portégé S100 Shock Protection Design Summary of features and benefits Shock protection through larger base, rounded and protruding corners Rubber protection surround LCD Rubber tabs encase the hard disk drive for increased cushion Rubber security encircles and protects the delicate inverter What is the Shock Protector? Toshiba Shock Protection Design delivers enhanced system component protection against notebook damage in instances of drop, collision and physical impact of the notebook. The concept offers specialised features to withstand the physical trials of travelling, while also protecting against accidents.

13 June 200512/Portégé S100 Spill-resistant Keyboard What is the Spill-resistant Keyboard? Prevents system damage from accidental spills onto the keyboard Spill-resistant Keyboard - A layer of bending insulation beneath the keyboard holder to cover areas that would otherwise be exposed. What is the benefit? The Spill-resistant Keyboard gives users enough time to save their data and shut down their notebook in the event of an accidental spill. This allows them to save valuable data as well as ensure that the liquid is not contacting running components. KB Cover Insulator Tape Two-sided Tape Front Back Will not work when water is spilt. w/o Spill-resistant Keyboard with Spill-resistant keyboard Will work when water is spilt.

14 June 200513/Portégé S100 HDD Protection (3-axis) Toshiba system board with accelerometer sensor Unload head from HDD disks Improvement durability of HDD What is the benefit? The unique combination of Toshiba cutting-edge 3D accelerometer and HDD Protection offers an enhanced impact protection solution compared to systems without these features. The 3D monitoring capability accurately filters out minor tilt movements and detects sudden vibrations to unload the HDD head before impact. What is the HDD Protection ? Prevents HDD from being damaged from shock or vibration (full 3-axis motion monitoring):

15 June 200514/Portégé S100 Execute Disable Bit (XD-Bit) What is the XD-Bit ? Execute Disable Bit is a system feature that, if present and enabled, allows the notebook’s processor to distinguish between bits of code that should be executed and the ones that cannot be, as they pose a threat to the system. What is the benefit? Prevention of buffer overflow virus attacks by enabling the system processor to distinguish between code that can and cannot be executed.

16 June 200515/Portégé S100 Toshiba summit Summary of features and benefits Quickly send files to other computers and devices in the local area Create a virtual meeting room, inviting all the local computers you want to have access to your file Simply drag and drop files into the middle of the “room” or send it directly to one of the participant only Provides a “quick share” feature by drag and drop a file onto the “wireless radar” icon What is the Toshiba summit? Toshiba Summit software to increase productivity, featuring efficient wireless conferencing functionality – including file sharing and chat.

17 June 200516/Portégé S100 Toshiba ConfigFree™ Connectivity Doctor Analyze your network connection and assist in fixing the problem. Enables an easy and automatic switch between network configurations. Profile Settings Get connect with the members nearby. Members icon will show around the table, and document can be shared by dragging the file on the center. ConfigFree™ Summit Displays nearby active WiFi access point and Bluetooth in radar GUI. Draw a line to connect to devices. Wireless radar 1 2 3 4 What is Toshiba ConfigFree™? Makes it easy for non-technical users to connect wired and wireless networks and Bluetooth™ devices and share files amongst locally connected users.

18 June 200517/Portégé S100 Diversity Antenna What is the Diversity Antenna? This Toshiba innovation is in reality three antennae. Selected notebooks now have two Wi-Fi™ antennae and one Bluetooth™ antenna incorporated into the top lid of the LCD display as well as automatic antenna selection that provides users with optimal wireless connectivity. Summary of features and benefits Two W-LAN antennae - Increases the reliability and stability of wireless connectivity Antennae in top lid of LCD display - Prevents signal interference from users’ desk hands, etc Dual-band antennae - Makes it easier to connect quickly and maintain stable performance Bluetooth™ antenna between the two W-LAN antennas maintains the diversity effect and maximises the user’s ability to connect quickly and easily with Diversity Antenna with Standard Antenna

19 June 200518/Portégé S100 Maximize business uptime Weighing from just 1.99 kg Magnesium-alloy case for greater durability 14.1“ TFT optimized display Swappable Ultra-slim SelectBay modularity Best-in-class lightweight platform Mainstream professional notebook with latest Toshiba EasyGuard features for carefree mobile computing Sleek and light package combined with stylish, dynamic design for maximum mobile productivity Groundbreaking mobility and wireless performance, exceptional graphics and support for an innovative docking solution The stylish and super thin design Portégé S100 is the supreme choice for highly mobile professionals who refuse to compromise performance for portability:

20 June 200519/Portégé S100 Extraordinary form factor and design weighing from just 1.99 kg small footprint of only 319 x 269 mm only 22.8 (front) / 31,2 (back) mm slim Delivering exceptional mobile performance in a new thin & light 14-inch footprint, making it a pure pleasure to carry around for work or play.

21 June 200520/Portégé S100 Superb mobile performance Thanks to the latest Intel ® Centrino™ Mobile Technology including - Intel ® Pentium ® M processors (up to 533 MHz Front-Side Bus and supporting Execute Disable Bit) - Mobile Intel ® 915PM Express chipset (up to 533 MHz Front-side Bus and Intel® Display Power Saving Technology) - Intel ® PRO/Wireless 2915ABG Network Connection (supports latest IEEE standard and new optional PROSet/Wireless software v.9.0 with improved GUI for simplified WLAN capabilities) The new Intel ® Centrino™ mobile technology features PCI Express technology which doubles data transfer rates and improves graphics performance.

22 June 200521/Portégé S100 Powerful, versatile mobile computing 512 MB DDR2 system memory, expandable to 2.048 MB, technology DDR2 RAM: DDR2 is the next-generation evolution of DDR memory technology. DDR2 memory features faster speeds, higher data bandwidths, lower power consumption and enhanced thermal performance. Primary 60 GB hard disk drive, 5,400 rpm, Serial ATA Serial ATA is an evolutionary replacement for the Parallel ATA physical storage interface Users of the Serial ATA interface benefit from greater speed, simpler upgradeable storage devices and easier configuration. NVIDIA® GeForce™ Go6200 TE 64M, 64 MB Video RAM, 16x PCI Express Advanced video capabilities of NVIDIA's PureVideo™technology, and support for the latest 3D games and applications

23 June 200522/Portégé S100 NVIDIA® NVRotate™ (LCD rotation utility) NVIDIA® NVRotate™ allows users to pivot display from landscape to portrait mode for easier information and user-friendly application viewing Just click the icon in the task bar when you rotate the screen to the person’s position in front of you Press Ctr+Shift+R (stands for return) to rotate back the screen image to your upright position

24 June 200523/Portégé S100 Greater usage flexibility with integrated Ultra-slim SelectBay modularity Featuring either The Ultra-slim SelectBay is a single drive bay that can accommodate modules such as: including optical disc drives, battery and 2nd HDD Ultra-slim SelectBayCD-RW/DVD-ROM combo drive or Ultra-slim SelectBay DVD Super Multi (Double Layer) drive allows users to copy all types of CDs and DVDs onto disc, while Double Layer supports recordable DVDs featuring two separate recording layers that can store 8.5 GB of data. 8,5 GB

25 June 200524/Portégé S100 Truly stylish business performance Microsoft ® Windows ® XP Professional with standards-based security, manageability and reliability Microsoft ® Office OneNote* 2003™ enables you to capture, organise and reuse your notes electronically Makes it easier to take notes and organize vital information. Enables teams to manage, prioritize, and manipulate information more effectively. Enables teams to maximise input from meetings and discussions by sharing information more effectively *Microsoft® Office OneNote™ 2003 is not available in all countries. For further information contact your Toshiba Authorised Reseller.

26 June 200525/Portégé S100 Easy to deploy and manage Reduce the cost of evaluating, deploying and training users on new models with the consistent software image and long lifecycles Backwards compatible common docking available with the optional Advanced Port Replicator III RGBDVIParallelSerialModem/LAN 1394 PS/2USB DC-IN Line in/out Great Versatility Full APR-III docking support offers a wide range of interfaces for using peripherals and digital devices. The ARP III enables users to step back into the office and immediately adjust back to their office environment; this enables consistent and ……. uncompromised mobile working.

27 June 200526/Portégé S100 A choice of 6 ways to connect Built-in dual-mode Wireless LAN 802.11a/b/g i.LINK® (IEEE1394) port Built-in Fast InfraRed SD™ Card media slot Internal international V.90 modem (V.92 ready) 10/100/1000 Gigabit Ethernet LAN port

28 June 200527/Portégé S100 VoIP Hardware ready feature VoIP ready function (Mic Array, Noise Canceling, Echo Canceling) When speaking on Hands-Free mode (no headset), it is likely the voice from the speaker is again picked up on the microphone, result as a echo. Toshiba reduces this echo with the “Echo Canceling” technology Hello! Echo Cancelling There are always some sort of noise that occurs around you when talking. The unnecessary sound can be reduced by using the “Noise Cancelling” feature. Noise Cancelling The integrated speaker is high quality speaker which produces above 80dB sound. The voice on from the other end can be clearly heard through the speaker. Toshiba notebooks are built with the high level speaker optimum for the speaker phone conversation. High Quality Speaker

29 June 200528/Portégé S100 Toshiba Power Saver utility This indicator shows of your PC performance standard, battery life optimized or performance optimized. The bar changes in corporation with your choice of the settings, Screen Brightness, CPU speed, Monitor Power, etc. This utility help you in configuration of your suitable PC performance in corporation with your business style

30 June 200529/Portégé S100 Zooming Utility Features Summary Zoom IN and OUT instantly Fn+1 to make fonts smaller Fn+2 to make fonts bigger Work for below applications Microsoft Internet Explorer Microsoft Office Windows Media Player Adobe Reader Icons on the desktop Toshiba Zooming utility Enlarge the text of explorer, Word, or Excel sheet instantly for easier viewing. The Toshiba Zooming utility allows you zoom in and zoom out of applications as well as the icons for Microsoft® Internet Explorer, Microsoft® Office, Windows® Media Player™, and Adobe® Reader.

31 June 200530/Portégé S100 One-touch resolution change Quick Switch Screen Resolution Fn+Space Bar zooms screen resolution Clean Stretch supported to view all resolutions on full-screen Resolution toggles from UXGA/SXGA+ to XGA to SVGA XGASVGA UXGA/SXGA+* Fn+Space XGA SVGA Fn+Space

32 June 200531/Portégé S100 Toshiba Presentation button Presentations made simple Touch’and’Present Ideal for mobile road warriors Programmable “One-Touch” switching from “Single Display (LCD only) with Single Image” to “Dual Display (LCD and CRT) with Single Image”. Programmable options –Single image on Dual Display –Ext. display resolution of 1,600 x 1,200, 1,280 x 1024, 1,024 x 768 or 800 x 600 –Dual image on Dual Display –Ext. display resolution the same as the notebook Single Display w/ Single Image (NB LCD only) Dual Display w/ Single Image (NB LCD & Ext. CRT) Toshiba Presentation Button Fn+F5 Toggle Menu vs

33 June 200532/Portégé S100 Specifications: Portégé S100 ModelPortégé S100-100Portégé S100-115 Processor/Technology Intel® Centrino™ mobile technology including Intel® Pentium® M processor 740(1.73 GHz, 533 MHz Front Side Bus, 2 MB 2nd level cache), Intel® PRO/Wireless2915ABG network connection and Mobile Intel® 915PM Express chipset Intel® Centrino™ mobile technology including Intel® Pentium® M processor 760 2.00 GHz, 533 MHz Front Side Bus, 2 MB 2nd level cache), Intel® PRO/Wireless 2915ABG network connection and Mobile Intel® 915PM Express chipset Operating system Microsoft® Windows® XP Professional Display 14.1“ TFT display, resolution 1,024 x 768 Hard disk 60 GB (5,400 rpm), Serial ATA80 GB (5,400 rpm), Serial ATA System memory 512 MB, maximum expandability: 1,536 MB, technology: DDR2 RAM Optical device Optical device Ultra-slim SelectBay CD-RW/DVD-ROM driveUltra-slim SelectBay DVD Super Multi drive Graphics adapter NVIDIA® GeForce™ Go 6200 TE 64M, 64 MB Video RAM, 16x PCI Express Pointing device Touch Pad Wired communication Gigabit Ethernet LAN, international V.90 modem Wireless communication Wireless LAN (802.11a/b/g), Fast InfraRed Sound system Toshiba Bass Enhanced Sound System, built-in stereo speakers, built-in microphone, volume dial Interfaces Interfaces DC-in, headphone, external monitor, expansion bus connector, RJ-11, RJ-45, external microphone, 2 x USB 2.0, i.LINK Expansion Connection to Advanced Port Replicator III (optional), PC Card slot for 1x Type II card, 2 memory slots (1 to configure) Battery Technology: lithium-ion, maximum life up to 3:17 hours (Mobile Mark™) Bundled software Microsoft® Office OneNote™ 2003, online user and modem manual, Management Console, Toshiba ConfigFree™, Connectivity Doctor, Sonic™ Record Now!, WinDVD, Norton Internet Security™ (90-day free trial version), Toshiba utilities and drivers, Toshiba RAID utility Microsoft® Office OneNote™ 2003, online user and modem manual, Management Console, Toshiba ConfigFree™, Connectivity Doctor, Sonic™ Record Now!, WinDVD, InterVideo® WinDVD Creator 2 Platinum, Norton Internet Security™ (90-day free trial version), Toshiba utilities and drivers, Toshiba RAID utility Bundled hardware AC adapter Special features ACPI support, SM BIOS compliant, common docking and options with other Toshiba notebooks, Toshiba Enhanced SpeedStep, Toshiba Power Saver utility, Toshiba Presentation button, Toshiba Assist button, Toshiba Zooming utility, VoIP ready function (Mic Array, Noise Canceling, Echo Canceling), One-touch resolution change, NVIDIA® NVRotate™ (LCD rotation utility) Toshiba EasyGuard Toshiba RAID, Execute Disable Bit Protection (XD-Bit), Trusted Platform Module (TPM), Device Lock, Password Utility, Magnesium Casework, Spill-resistant Keyboard, PC Diagnostics, HDD Protection (3-axis), Shock Protection Design, Toshiba Summit, Diversity Antenna, Toshiba ConfigFree™, Kensington Lock, Password Utility, Easy Fix Components, Data Backup, Durable Design, Wireless LAN Switch Physical dimensions W x L x H: 319 x 269 x 22.8 (front) / 31.2 (back) mm, weight: starting at 1.99 kg Warranty 1-year international warranty. Upgrade your standard warranty with Toshiba warranty extension and uplift packs. Contact your nearest Toshiba Authorised Reseller for details.

34 June 200533/Portégé S100 Options & Accessories: Portégé S100 Basic options Tecra A5PA number Power AC AdapterPA3378E-1ACA BatteryPA3356U-2BRS High Capacity BatteryPA3357U-1BRL Battery ChargerPA3091E-1CHG Expansion 1.024 MB (1 GB) PC2-4300 DDR2 MemoryPA3411U-1M1G Drives External USB FDDPA3109U-1FDD 80 GB HDDPA3407U-1H80 Ultra-slim SelectBay HDD AdapterPA3408U-1ETC Ultra-slim SelectBay CD-RW/DVD-ROM drivePA3409E-1CD2 Ultra-slim SelectBay DVD Super Multi drivePA3410E-1DV2 Connectivity Advanced Port Replicator IIIPA3314E-1PRP Communication USB Bluetooth™ V2.0 + EDR capable adapterPA3455U-1BTM Desk-based USB Retractable Travel MousePX1096E-1NAC Carry Cases Premium CasePX1195E-1NCA Services International Warranty ExtensionContact Dealer EMEA On-site Repair Next Business Day ServiceContact Dealer

35 June 200534/Portégé S100 "With the launch of EasyGuard, Toshiba continues to demonstrate its ability to meet the increasingly demanding needs and requirements of business," said Andrew Brown, program manager, European Mobile Computing and Mobile Devices, IDC. "Through significant R&D investment in innovative, new "beyond the box" technologies, Toshiba is providing professionals with a differentiated offering that reduces downtime, improves security and offers central management tools to help significantly lower TCO and increase ROI for IT decision makers.„ Product shown: Portégé M300

36 computers.toshiba-europe.com
