1. Converting Kinetic Energy Of Fluid Currents Into Electricity
Blue Energy
Ocean Power
(Rack & Rake Wheel)
Converting Kinetic Energy Of Fluid Currents Into Electricity By
IP Management Pte Ltd

2. Ocean Power – Rack & Rake Wheel Scope
Introduction
Concept
Video
Q & A
End

3. Ocean Power – Rack & Rake Wheel
Introduction
The World is facing the continuous challenge of supplying enough energy to fuel economic growth.
Est. Ocean currents can meet 3000 times the current power needs of the entire World’s population.
Waves energy alone can potentially produce one third of the World’s electricity supply.

4. Ocean Power – Rack & Rake Wheel
Concept
M/S IP Management Pte Ltd has invented a double acting Racks & Rake Wheel fluid current energy converter device to tap kinetic energy of Ocean, river and wind currents.

5. Ocean Power – Rack & Rake Wheel
Mechanical devices
Moveable device - Double acting rack
1) Vertical racks
2) Curved racks
3) Horizontal racks
4) Planar circular racks
5) Ring racks

6. Ocean Power – Rack & Rake Wheel
Mechanical devices
b) Fixed device
Rake wheel-generator assembly

7. Ocean Power – Rack & Rake Wheel Mechanical Action
Rising Wave
Falling Wave

8. Wave Power Reference - Wikipedia, the free encyclopedia
Waves are generated by wind passing over the surface of the sea.
As long as the waves propagate slower than the wind speed just above the waves, there is an energy transfer from the wind to the waves.

9. Wave Power Reference - Wikipedia, the free encyclopedia
Wave power formula
Example: Consider moderate ocean swells, in deep water, a few km off a coastline, with a wave height of 3 meters and a wave period of 8 seconds. Using the formula to solve for power, we get
meaning there are 36 kilowatts of power potential per meter of wave crest.

10. WAVE ENERGY CONVERTER IN SHALLOW WATER
The maximum power capture of a floating buoy is given by (Matt Folley, et al, )
P = ½ F .. x (1- ½ r)
When the motion is highly constrained, r ---> 0, then the power capture is proportional to the incident wave force, not the incident wave power intensity given above. This is evident for shallow water converters where the water depth is less than a quarter of the wave wavelength.
where
F - is the wave force
X - is the amplitude of motion
r - is the ratio of amplitude of motion to optimum amplitude of motion
1 Matt Folley, Trevor Whittaker, Alan Henry, 6th European Wave and Tidal Energy Conference, Glasgow, UK August 29th - September 2nd 2005

11. Power Capture of a Floating Buoy
The power capture of a floating buoy is also given by (Evans, )
where
 - is the applied hydrodynamic damping coefficient (in Ns/m)
 - is the angular velocity (in rad/s)
X - is the amplitude of motion (in m)
2 Evans D. V. (1985) "The Hydrodynamic Efficiency of Wave-Energy Devices", Hydrodynamics of Ocean
Wave-Energy Utilization, Lisbon. Springer-Verlag: 1-34.

12. Ocean Power – Rack & Rake Wheel
Comparative advantages:
Simple design
Tap energy of different forms of fluid currents.
Inexpensive and easily available parts.
Suitable for mass production
No technological incertitude.

13. Ocean Power – Rack & Rake Wheel
Main applications:
Install at locations near coastlines.

14. Ocean Power – Rack & Rake Wheel http://www. lamtengchoy. com/main/
Ocean Power – Rack & Rake Wheel Video

15. Ocean Power – Rack & Rake Wheel
Q & A

16. Ocean Power – (Rack & Rake Wheel)
The End By
