1. Introduction to the Hot New LDAP Features in Novell eDirectory™ 8.7
Novell BrainShare 2002
Introduction to the Hot New LDAP Features in Novell eDirectory™ 8.7
Gary L. Anderson
Senior Development Manager
Novell, Inc.
Alan Clark
Senior Manager, eDirectory Access
Novell, Inc.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

2. Deployed Versions Novell eDirectory™ and Novell Directory Services® (NDS®)
Product Version
Build Version
Platforms
NetWare 5.1 SP4 (NDS 7)
DS.nlm v7.57
NetWare 5.1
NetWare 5.1 SP 4 (NDS 8)
DS.nlm v8.79
eDirectory 8
DS.nlm & DS.dlm v8.79
NetWare 5.0,Win NT/2K
eDirectory 8.5.x
DS v85.23
NetWare 5.x,Win,Solaris
NetWare 6 (eDirectory 8.6)
DS.nlm v
NetWare 6
eDirectory 8.6.1
DS v
NW 5.1,NW 6,Win,Solaris,Linux
NetWare 6 SP1 (eDirectory 8.6.2)
DS.nlm v
eDirectory 8.6.2
DS v103xx.xx
eDirectory 8.7
DS v10410.xx
NW 5.1,NW 6,Win,Solaris,Linux,AIX

3. Differences between eDirectory and NDS
Novell BrainShare 2002
Differences between eDirectory and NDS
NDS
eDirectory
NOS directory focused on managing NetWare® servers
A cross-platform, scalable, standards-based directory used for managing identities that span all aspects of the network—eDirectory is the foundation for eBusiness
NetWare 5
NetWare
NetWare 6
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

4. Novell BrainShare 2002
Abstract
This session provides an overview of the hot new LDAP features available in eDirectory 8.7
Rights-based object access
Dynamic groups
Object-based schema
Search simplification
Event monitoring
Configurable transport security
Multiple LDAP authentication methods
Device provisioning with embedded LDAP clients
Specific implementation details and code samples are presented in DL204 and DL307
Rights-based object access (ACLs)
Event monitoring (LDAP extension, and persistent search)
Dynamic Groups
Object-based Schema (Auxiliary Classes)
Search Scope Reduction (Extensible Match)
Selectable Transport Encryption (Start TLS)
Biometric Authentication (SASL support)
Device Provisioning using embedded LDAP clients
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

5. Welcome to Outdoor Adventures
This tree shows the logical layout of Outdoor Adventures, the sample company used in this presentation and in Tech Lab

6. Using LDAP to Set Directory Rights
Novell BrainShare 2002
Using LDAP to Set Directory Rights
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

7. Terminology
ACM—The Access Control Model used in a directory to specify who has rights to what
ACI—The X.500 standard name for Access Control Information (the rights to access objects)
ACL—List maintained as an attribute of an object showing the rights that other objects have to the object

8. The eDirectory Access Control Model
Novell BrainShare 2002
The eDirectory Access Control Model
Access Control Lists (ACLs) reside on resources, and grant permissions to individual objects, containers (and subtrees), and groups
How do students get rights to course information?
Grant rights to all students, registered or not
Here, we want to review the general idea that an ACL is an attribute that resides on a resource, that names a subject (trustee), and a set of permissions.
An ACL can specifically grant a permission to a single object, a group of object, or a container full of objects (actually subtree).
An ACL can reside at a higher point in the tree and grant subtree rights.
Individually grant rights to each registered student
Grant rights to a dynamic group
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

9. Access Rights Directory allows rights per object and user
Novell BrainShare 2002
Access Rights
Directory allows rights per object and user
Easy management of rights
Inheritance of rights based on tree structure
User abilities depend on ACLs for the object, the user, and the groups and subtrees the user belongs to
Rights are held in the ndsAcl attribute of each object
Databases limit access on a table basis. Access can allow read, write, modify and delete.
Directory allows rights to be assigned per object and user. Rights can be assigned to a superior container and inherited down the tree from that point. Management consoles provide easier access and management for users and rights assignments.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

10. Effective Privileges
It’s hard to understand exactly which rights an object has to a resource because
ACLs are held on resources, parents of resources, and groups
ACLs may be blocked by inheritance rights filters
eDirectory allows an object’s “Effective Privileges” to be interrogated
Check out DL204 for details on coding in C and Java

11. Programmatic ACL Modification
How do I allow a student to access information on a course section?
The answer is obvious, right? Use ConsoleOne® or iManager and assign student1 as a trustee of section1
But how do I do this with LDAP?

12. Modifying ACLs with LDAP
Novell BrainShare 2002
Modifying ACLs with LDAP
ACLs are attributes, so no special APIs are required to access or update them
The LDIF file to allow Student1 rights to section1 could be:
dn: cn=section1, ou=sections, l=Atlanta
changetype: modify
add: ndsACL
ndsAcl: 1#entry#cn=student1, ou=students, l=Atlanta#[Entry Rights]
ndsAcl: 3#entry#cn=student1, ou=students, l=Atlanta#[All Attributes Rights]
Refer to section 5.7 of
(Section 5.7 from draft-sermersheim-nds-ldap-schema-02.txt)
5.7 NDS ACL ( DESC 'NDS ACL')
Used for attributes whose values represent ACL entries. An ACL value can protect either an object or an attribute. The protected object is always the one that contains the ACL attribute. Values in this syntax are encoded according to the following BNF:
ndsAcl = privileges "#" scope "#" subjectname "#" protectedattrname
privileges = uint32string
scope = "entry" / "subtree"
subjectname = distinguishedname / "[Self]" / "[Creator]" / "[Public]" / "[Inheritance Mask]" / "[Root]"
protectedattrname = caseignorestring / "[Entry Rights]" / "[All Attributes Rights]"
The privileges field is number that represents the kind of access being granted. Performing a bitwise OR on the numbers that represent the desired access arrives at this number. Below a table is shown which specifies the values:
Value Attributes [Entry Rights]
Compare Attributes Browse Entry
Read Attributes Add Entry
Write, Add, Delete Attrs Delete Entry
Add/Delete Self Rename Entry
(none) Supervisory
Supervisory (none)
The scope field specifies whether or not the privileges are applied to the target entry (the entry containing the ACL) or the target and its subtree.
The subjectname either contains the distinguished name of the entry being granted the privileges, or one of the special values:
[Self] Indicates the user authenticated in the current connection. This can only be used in the Add Entry operation.
[Creator] The user who created the object. This can only be used in the Add Entry operation.
[Public] Includes all objects in the tree.
[Inheritance Mask] Filters or masks the privileges granted to an object.
[Root] Denotes the directory tree root object
[This] the user identified by the object
Any occurance of the # character in the subjectname MUST be escaped using the rules in Section 4.3 of [RFC2252]. The protectedattrname either names a specific attribute that the privileges are applied to, or it contains one of the following special values:
[Entry Rights] Privileges apply to the entire object, rather than an attribute.
[All Attributes Rights] Privileges apply to all attributes of the object. If the protectedattrname neither specifies a valid attribute as defined in the schema, nor one of the special values, an invalidSyntax error will be returned. The following ASN.1 data type is used to represent this syntax when transferred in binary form (see 4.1):
ndsAcl ::= SEQUENCE {
privileges uint32,
scope uint32,
subjectName LDAPDN,
protectedAttrName LDAPString }
The special string values for protectedAttrName and subjectName are the same as given in the BNF above. The privileges field is an integer which represents the bit mask as described above. The scope field is set to either 0 for "entry" or 1 for "subtree". Attributes of this syntax match for equality if all fields match for equality and match approximate if the attribute name and the subject name match, and any privilege bits set in the filter are also set in the target value.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

13. ACL Privileges Value [Attributes] [Entry Rights] 1 Compare Browse 2
Novell BrainShare 2002
ACL Privileges
The privileges field is number that is generated by performing a bitwise OR on the values that represent the desired access rights
The table below shows the values
Value
[Attributes]
[Entry Rights] 1
Compare
Browse 2
Read
Add 4
Write, Add,Del
Del 8
Add/Del Self
Rename 16
(na)
Supervisory 32
Dynamic
This slide is pretty self explanatory.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

14. The New ACL in Town [This]
Novell BrainShare 2002
The New ACL in Town
[This]
A new ACL subjectName, it can be inheritable or non-inheritable
Reduces the need to use per object ACLs to grant rights to object’s own attributes
Management now available through iManager
Question: How can you give everyone rights to modify their own phone number?
To solve this problem, you can
A: Go through object by object and grant individual access, or…
B: Apply read, compare, and write rights to [This] for the telephoneNumber attribute high up in the tree and let it inherit
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

15. Filter-Based Groups Novell BrainShare 2002
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

16. Novell BrainShare 2002
Creating Communities
Communities in a directory exist when objects are formed into groups
The original eDirectory group provided a static list of members and referential integrity between the members list of the group and the members of attribute on an object
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

17. Novell BrainShare 2002
Dynamic Groups
eDirectory 8.6 and 8.7 allow you to determine group membership dynamically by using a search filter
Search filter is in URL form (RFC 2255)
ldap:///<base-DN>??<scope>?<filter>
Example:
ldap:///ou=sales,o=acme??sub?(title=manager)
Additional capabilities
excludedMember—Objects specifically excluded
uniqueMember—Objects specifically included in the group
Web management interface in eDirectory 8.7
Available only via LDAP in eDirectory 8.6
vi. The 17th slide does not mention anything about the X-chaining.
vii. The 18th slide says, that the ACLs are applied to the DG filters. This needs to be clarified and corrected.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

18. What Is the Cost of Using Dynamic Groups?
Novell BrainShare 2002
What Is the Cost of Using Dynamic Groups?
Dynamic groups don’t show up in the groupMembership attribute of a user object
To find out if your object is a member of the dynamic group, you have to run the group query filter against your object to see if it matches
ACLs are applied to dynamic group filters
The search query essentially defines a policy.
Example of badge reader station. An application running on the badge reader station could do a directory search with a search filter. But this search filter defines the policy.
Suppose we wanted to change the policy from allowing all employees access to allowing only managers access. To change the policy would require changing the client software running on all the badge readers.
If the badge readers were coded to read the dynamic group, an admin could modify the dynamic group’s query, and the policy is instantly changed on all badge readers.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

19. Why Use Dynamic Groups? Policy is stored in the directory
Novell BrainShare 2002
Why Use Dynamic Groups?
Policy is stored in the directory
An application can be hard-coded to just read a dynamic group instead of searching with a search filter
This allows the “effective” filter to be modified at the directory without changing the application
ACLs may be used with dynamic groups
Put an ACL on a course section object granting access rights to the dynamic group
Now all students registered for the section (determined dynamically) will have access
Dynamic groups are scalable
The search query essentially defines a policy.
Example of badge reader station. An application running on the badge reader station could do a directory search with a search filter. But this search filter defines the policy.
Suppose we wanted to change the policy from allowing all employees access to allowing only managers access. To change the policy would require changing the client software running on all the badge readers.
If the badge readers were coded to read the dynamic group, an admin could modify the dynamic group’s query, and the policy is instantly changed on all badge readers.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

20. Dynamic Groups—Compatibility
Novell BrainShare 2002
Dynamic Groups—Compatibility
Static groups may be converted to dynamic groups
Add dynamicGroupAux to the objectClass attribute
Set a search query in memberQueryURL
For either static or dynamic groups, obtain a membership list by simply reading the “member” attribute
By default, the implicit search is limited to the local server
viii. The 19th slide, first statement could mention some example applications.
ix. The 20th slide, 3rd statment could talk about the X-chain facility.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

21. Object-Based Schema (Auxiliary Classes)
Novell BrainShare 2002
Object-Based Schema (Auxiliary Classes)
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

22. What Good Is Object-Based Schema?
Q: Peggy and Scott are managers—how can they have attributes specific to managers?
Q: Bill, Jean and Paul take turns handling the after-hours pager—how can the one holding the pager be uniquely identified?
To solve these problems, you can:
A. Add all attributes to base class definitions, or…
B: Use auxiliary classes to meet both of these requirements without adding attributes to other objects

23. Auxiliary Class Definition
Novell BrainShare 2002
Auxiliary Class Definition
Auxiliary (or aux) classes are dynamic classes that can be added to the object class attribute of individual objects
The object inherits all the attributes of the aux class while retaining all of its own attributes
When the aux class is removed from the object, all of the aux class attributes are removed
Only the objects that need the attributes have them
Doesn’t change the object class definition
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

24. Using Auxiliary Classes
Novell BrainShare 2002
Using Auxiliary Classes
Two steps
Modify the object class of an existing object to include the aux class name
Write values to attributes as you would any other attributes for that class
Easy to remove
Delete the aux class name from the objectClass attribute
Auxiliary classes are available from eDirectory 8 and beyond
Is this note right or were they available starting with NetWare 5?
All the cleaning up of the aux class attributes is done for you when you delete the aux class name from the object class attribute
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

25. Auxiliary Classes vs Structural Classes
Inherited Classes
Added to individual instances of an object
SuperInherited to all objects through class definition
eDirectory 8 and above
All versions of eDirectory and NDS
Removable from any object
Non removable from base classes
Single object may have many Aux classes
Multiple Inheritance
Requires write rights to the object’s object class attribute
Object class rights not required
Cannot define containment
Ability to define containment
All instances of use have to be removed prior to schema removal
May contain mandatory and optional attributes, including naming attributes

26. Replication of Auxiliary Classes
Novell BrainShare 2002
Replication of Auxiliary Classes
8.5 v or 8.0 v8.78
eDirectory 8.7
Modify or Replication Error
-666
Incompatible
DS Version
Start this slide just showing the 4 servers.
First mouse click creates Fred on an 8.7 server, and replicates Fred. “Let’s create a user in the directory. As you know, eDirectory replicates this entry so that it shows up on all of the servers in the ring.”
“Now we want to make Fred a student at Aspen Outdoors” – click mouse – aux class appears on 8.7, and animation replicates to the other servers. “Note that the aux class also replicates to the other servers in the tree. On the 8.5 or 8.0 servers, if you have the current patch build show on the slide, Fred still retains his identity. However, notice that Fred’s object has gone unknown on the NDS 7 and NDS 6 servers. Now, all you system admins out there, what have you been trained to do with unknown objects – you usually delete them, right? Well, here’s what happens when you do that” – click the mouse here and the objects go away on all servers.
“What would have happened if this was your admin user? Auxiliary classses will require that you change your management methods for unknown objects. Don’t delete an object from an older server if it went unknown because an aux class was added.”
“So, let’s restore Fred to the tree” – click mouse – “ and then try to add an aux class to Fred again. If you are doing this from ConsoleOne, remember that you cannot control which server the update will be attempted on. You are simply pointing to a partition, and ConsoleOne can hit any server holding the partition. Let’s assume that the NDS 7 or NDS 6 server is the one that ConsoleOne attempts to update. If your NDS 7 server is 7.55c or earlier, or if your NDS 6 server is 6.13 or earlier, this will be the result” – click mouse again and wait for the error.
“We showed this for addition to the NDS 7 server, but the same problem exists if you add an aux class on NDS 6. These are very bad problems, and can cause real problems for your tree. Novell has released an upgrade to both NDS 7 and NDS 6 servers that will help to alleviate some of these problems. Let’s see what happens if you try to add an aux class to a 6 or 7 server running the latest code” – click mouse
“For NDS 6 and 7 latest release, attempts to modify the objectClasses attribute results in a –666 error (incompatible DS version). Thus, the object is not modified, and no replication problems occur. However, you may experience inconsistent performance in a mixed tree depending on which server the ConsoleOne instance is talking to.”
On NDS 7 and NDS 6 the objectClasses attribute is set to top and unknown
auxClassObjectClassBackup – list of aux classes
unkownBaseClass – original base class
auxiliaryClassCompatibility – holds ‘lie’ consistency information – appears on 8 if synched to 7Fred
eDirectory 8.6
NDS 7.55c
NDS 7.55d
NDS 7.x
eDirectory 8.7
NDS 6.13
NDS 6.14
NDS 6.x
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

27. Auxiliary Class Safety Precautions
Novell BrainShare 2002
Auxiliary Class Safety Precautions
Upgrade your tree to all eDirectory 8 servers
If you can’t go to all eDirectory 8, then make sure you have the latest released patches for NDS 7 and NDS 6
Never, never, never add auxiliary classes to objects on NDS 7 or NDS 6 servers
Break the old habit of deleting unknown objects if you are using auxiliary classes
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

28. Auxiliary Class Benefits
Novell BrainShare 2002
Auxiliary Class Benefits
You can now apply attributes at will to objects in the tree, without requiring the schema definitions to be applied to all objects in the class
Cleanup of auxiliary classes is a snap
Simply remove the aux class name from the objectClass attribute, and all attributes disappear automatically
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

29. Using Matching Rules to Reduce Searches
Novell BrainShare 2002
Using Matching Rules to Reduce Searches
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

30. cn=Terry,organizationalRole=adminAssistant,ou=sales,o=usa
Novell BrainShare 2002
Extensible Match
Extensible Match defined in LDAP v3
Support multiple matching rules for the same types of data
Can implement new rules, e.g., “sounds like”
Include DN elements in the search criteria
The DN specification allows matching on specific elements of the DN of an object
ou=sal
cn=Terry,organizationalRole=adminAssistant,ou=sales,o=usa
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

31. Novell BrainShare 2002
Task: Find All Admin Assistants in All the Sales Groups of this Company
Root
USA
Germany
England
Sales
Manufacturing
Sales
Finance
Sales
Engineering
Three clicks are required to pull up the animation.
East
West
Admin
assistant
Admin
assistant
Admin
assistant
Terry
Sam
Alice
Admin
assistant
Hilda
Bill
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

32. Novell BrainShare 2002
Possibility One
1. Search for all admin assistant containers in the tree
C:>ldapsearch … (organizationalRole=adminAssistant)
organizationalRole=adminAssistant,ou=sales,o=usa
organizationalRole=adminAssistant,ou=sales,o=germany
organizationalRole=adminAssistant,ou=finance,o=germany
organizationalRole=adminAssistant,ou=west,ou=sales,o=england
4 matches
2. In the client, evaluate each DN to see if it is subordinate to a sales-container
organizationalRole=adminAssistant,ou=sales,o=usa
organizationalRole=adminAssistant,ou=sales,o=germany
organizationalRole=adminAssistant,ou=finance,o=germany
organizationalRole=adminAssistant,ou=west,ou=sales,o=england
The first search returns the 4 organizationalRole containers
Evaluation of the DN results in 3 paths
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

33. Possibility One (cont.)
3. Using each admin assistant container as a base, do a subtree search for users in that container
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=sales,o=usa” (objectClass=user)
cn=Terry,organizationalRole=adminAssistant,ou=sales,o=usa
1 matches
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=sales,o=germany” (objectClass=user)
cn=Sam,organizationalRole=adminAssistant,ou=sales,o=germany
cn=Alice,organizationalRole=adminAssistant,ou=sales,o=germany
2 matches
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=west,ou=sales,o=england” (objectClass=user)
cn=Bill,organizationalRole=adminAssistant,ou=west,ou=sales,o=england

34. Possibility Two What’s wrong? This search assumes everything is at the
1. Search for all sales containers in the tree
C:>ldapsearch … (ou=sales)
ou=sales,o=usa
ou=sales,o=germany
ou=sales,o=england
3 matches
2. Using each sales container as a base, do a subtree search for users in the admin assistant container
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=sales,o=usa” (objectClass=user)
cn=Terry, organizationalRole=adminAssistant,ou=sales,o=usa
1 matches
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=sales,o=germany” (objectClass=user)
cn=Sam, organizationalRole=adminAssistant,ou=sales,o=germany
cn=Alice, organizationalRole=adminAssistant,ou=sales,o=germany
2 matches
C:>ldapsearch … -b “organizationalRole=adminAssistant,ou=sales,o=england” (objectClass=user)
0 matches
This search assumes
everything is at the
same level!
What’s wrong?

35. Novell BrainShare 2002
In eDirectory
1. Use extensibleMatch
C:>ldapsearch … (&(ou:dn:=Sales)(organizationalRole=adminAssistant))
cn=Terry, organizationalRole=adminAssistant,ou=sales,o=usa
cn=Sam, organizationalRole=adminAssistant,ou=sales,o=germany
cn=Alice, organizationalRole=adminAssistant,ou=sales,o=germany
cn=Bill, organizationalRole=adminAssistant,ou=west,ou=sales,o=england
4 matches
xii. The 37th slide, can specify the RFC and the section to refer for the extensible match.
xiii. In the 38th slide, we should say no matching rule supported still.
extensible = attr [":dn"] [":" matchingrule] ":=" value
/ [":dn"] ":" matchingrule ":=" value
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

36. eDirectory Support for extensibleMatch
Novell BrainShare 2002
eDirectory Support for extensibleMatch
eDirectory 8.7, available soon, supports extensibleMatch for matching on DN values
eDirectory 8.7 treats other extensibleMatch specifications as undefined terms in the filter and will ignore them
Versions of eDirectory prior to 8.7 would return a protocol error if an extensibleMatch term was specified in a search filter
Advertisement of matching rules in eDirectory 8.7 is done through the LDAP subschema subentry object using the standard matchingRules and matchingRuleUse schema attributes
From 2251, section 2.4.1:
The extensibleMatch is new in this version of LDAP. If the matchingRule field is absent, the type field MUST be present, and the equality match is performed for that type. If the type field is absent and matchingRule is present, the matchValue is compared against all attributes in an entry which support that matchingRule, and the matchingRule determines the syntax for the assertion value (the filter item evaluates to TRUE if it matches with at least one attribute in the entry, FALSE if it does not match any attribute in the entry, and Undefined if the matchingRule is not recognized or the assertionValue cannot be parsed.) If the type field is present and matchingRule is present, the matchingRule MUST be one permitted for use with that type, otherwise the filter item is undefined. If the dnAttributes field is set to TRUE, the match is applied against all the attributes in an entry's distinguished name as well, and also evaluates to TRUE if there is at least one attribute in the distinguished name for which the filter item evaluates to TRUE. (Editors note: The dnAttributes field is present so that there does not need to be multiple versions of generic matching rules such as for word matching, one to apply to entries and another to apply to entries and dn attributes as well). A filter item evaluates to Undefined when the server would not be able to determine whether the assertion value matches an entry. If an attribute description in an equalityMatch, substrings, greaterOrEqual, lessOrEqual, approxMatch or extensibleMatch filter is not recognized by the server, a matching rule id in the extensibleMatch is not recognized by the server, the assertion value cannot be parsed, or the type of filtering requested is not implemented, then the filter is Undefined. Thus for example if a server did not recognize the attribute type shoeSize, a filter of (shoeSize=*) would evaluate to FALSE, and the filters (shoeSize=12), (shoeSize>=12) and (shoeSize<=12) would evaluate to Undefined.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

37. Directory Events in LDAP
Novell BrainShare 2002
Directory Events in LDAP
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

38. How Do I Track Directory Changes?
Novell BrainShare 2002
How Do I Track Directory Changes?
Q: Students can change some of their own information—how can I track their changes in my instructor application using LDAP?
I can poll the directory looking for changes
Requires me to keep state information in my app
I can use directory events
Persistent Search
LDAP eDirectory events extension
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

39. LDAP Persistent Search
Novell BrainShare 2002
LDAP Persistent Search
Alters the standard LDAP search operation to perform a continuous search, notifying the application of changes that occur on an LDAP server
Persistent search allows the client to be notified when changes are made to entries that satisfy the specified search filter
The connection to the server remains open until the search is abandoned
Persistent search is supported by multiple directories
xiiii. Could mention the ietf draft in the slide 42.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

40. Applications of Persistent Search
Novell BrainShare 2002
Applications of Persistent Search
What does Persistent Search enable?
Applications driven by business process events
Creating and updating a local cache easily
Auditing
Data logging
Data reporting
And more…
Persistent Search is an LDAP-standard way of getting directory events
Examples of these:
Business Processes: Whenever a new student is added to Aspen, an independent process can detect the change, send him a welcome and print an address label for a packet of information.
Allows a separate application to perform this work instead of building it all into the Aspen Demo.
Cache: Create a local cache of all course objects. Make the initial call with changesOnly=0 so you get all the courses. Then you get notified when any course object is added or removed.
Auditing/logging: A separate process does a persistent search of all user objects, reading the modifiers name and modification timestamp. (changes only). Gets notification of any user added, deleted, renamed, or modified.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

41. eDirectory Events Extension
Novell BrainShare 2002
eDirectory Events Extension
Novell extension allowing an LDAP client to be notified of the occurrence of various events on a Novell eDirectory server
Utilizes the LDAP v3-extended operation extension mechanism
It also uses an intermediate response Protocol Data Unit (PDU) as described in the IETF draft
draft-rharrison-ldap-intermediate-resp-00.txt
Available on all platforms supported by Novell eDirectory 8.7
This is Novell-specific and not standard LDAP
Psearch – data in the directory on the server, and I want a directory agnostic app
Extension – when I am eDirectory event specific
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

42. Selectively Monitor eDirectory Events
Novell BrainShare 2002
Selectively Monitor eDirectory Events
Novell eDirectory defines several directory-related events, including
Operations on individual entries and their attributes
Partition and replica operations
These events can be used for
Debugging
Auditing
Management
Access to each event is controlled by rights checking
If the user does not have the required privileges, the request will fail
An EventExtendedResponse will be returned by the server with an responseCode value of insufficientPrivileges
The eDirectory server has a directory event service that defines over 200 directory related events. The defined events span a large number of operations that occur within the directory. They include operations on individual entries and their attributes as well as partition and replica operations. Some of the events are used for debugging purposes, while others are designed to support auditing and management applications. This is an LDAP extension that allows an LDAP client to selectively monitor events that occur on an eDirectory server.
xvi. In slide 46, What are we debugging.
xvii. In slide 46, 3rd statement, could specify the default ACL.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

43. Event Handling Priority
Novell BrainShare 2002
Event Handling Priority
The eDirectory event system extension supports the equivalent of the eDirectory journal priority
Event notifications are sent to a client in the order in which the events occurred on the server after the underlying operations have completed
Order is guaranteed, and events are received after DS has processed the information
You cannot preempt an event or register for in-line processing
The eDirectory event system allows event notification to occur at three different priorities: in-line, journal, and work. When in-line priority is selected event notification occurs before the actual operation and the operation does not proceed until the recipient of the event completes processing of the event. In-line priority is designed for processing that can complete very quickly and may need to abort the underlying operation. The journal and work priorities are very similar. Both perform event notification after the underlying operation(s) have completed. The main difference is that journal priority guarantees that the client receives notification of events in the same order in which the events actually occurred. Work priority does not provide such a guarantee.
The eDirectory event system extension supports the equivalent of the journal priority. Event notifications are sent to a client in the order in which the events occurred on the server after the underlying operations have completed.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

44. Applications of eDirectory Events
What can I do with eDirectory Events?
eDirectory monitoring
Auditing
Automation of infrastructure changes
Automated business logic
All of these things can be done with eDirectory—they don’t exist in the same form on other directory products

45. Configurable Transport Security
Novell BrainShare 2002
Configurable Transport Security
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

46. eDirectory 8.7 Debuts Full TLS 1.0
SAS Library
Novell TLS Library
SSL v3.0 support
TLS 1.0 support (RFC 2246)
Cryptography using NICI
Limited interoperability with other clients
Full TLS 1.0 compliance, good interoperability
Limited support for EXTERNAL authentication
Fully configurable support for EXTERNAL authentication
No support for StartTLS
Supports LDAP StartTLS

47. Please may I have your Cert?
Connecting with TLS
Give me your Cert!
Please may I have your Cert?
eDirectory LDAP server can now be configured to use the following TLS handshakes
Server Certificate Only
Request Client Certificate
Require Client Certificate
This configuration is done through iManager

48. Selectable Channel Encryption
Novell BrainShare 2002
Selectable Channel Encryption
I’m connected to the directory on the clear-text port, and I want to access my credit card information—what do I do?
I can drop my connection, re-authenticate to the SSL port, and get the data
xviii. In slide 53, why would the connection revert to anonymous connection.
xix. In slide 58, it should be supportedSASLMechanisms instead of registeredSASLMechanisms. OR
I can send the StartTLS extended request along with the query to read my credit card
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

49. Ending TLS on a Connection
Client or server sends a TLS end notification
All operations are abandoned
TLS is turned off by both client and server
Connection reverts to anonymous
Specified in RFC 2829

50. TLS Information Functionality is defined in RFC 2222, 2829, and 2830
Novell TLS Library* is based on the OpenSSL project (current version 0.9.c) with the cryptographic library replaced by NICI
* This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (

51. New LDAP Authentication Methods
Novell BrainShare 2002
New LDAP Authentication Methods
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

52. Is LDAP Simple Bind Secure Enough?
Are you confident that the user is who he claims to be?
Employee: Jane.Smith
Password: jsmith
Hacker aka: Jane.Smith
Password: jsmith

53. SASL Exposed
SASL (Simple Authentication and Security Layer) is an authentication negotiation framework
Server lists registered authentication mechanisms in the supportedSASLMechanisms attribute of root DSE
Client chooses the authentication method
Server implements authentication policy
Official SASL mechanisms are registered with IANA*
eDirectory 8.7 supports
EXTERNAL
DIGEST-MD5
NMAS_LOGIN
*Internet Assigned Numbers Authority

54. SASL EXTERNAL
TLS handshake establishes client identity by means of certificate-based client authentication
LDAP SASL EXTERNAL uses that identity for the user connection

55. SASL DIGEST-MD5
SASL bind packet with hashed password
Allows password to be securely sent over a clear text connection
Requires that the server maintain a clear text copy of the password in the NMAS encrypted store that can be hashed using data provided in the bind and then compared to the hashed password contained in the bind

56. SASL NMAS_LOGIN
Fingerprint
Password
Biometric
Smart card
Certificate
Allows the full functionality of Novell Modular Authentication Services to be applied to LDAP binds
Login policy maintained by the server
Provides for multiple levels of authentication and identification

57. Device Provisioning with Embedded LDAP Clients
Novell BrainShare 2002
Device Provisioning with Embedded LDAP Clients
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

58. Novell Leadership in Device Provisioning
Through our embedded technology effort Novell has been in the embedded eDirectory business for eight years
iPrint and eNDPS (embedded Novell Distributed Print Services™ (NDPS®) technology
Introducing
The Embedded Device Provisioning Agent (eDPrA)
Novell offers the market self-provisioning hardware managed by eDirectory

59. What Is Embedded Device Provisioning?
Novell BrainShare 2002
What Is Embedded Device Provisioning?
Directory-enabled device provisioning
Allows for non-computer connected devices to work with eDirectory
Improves security on hardware that has been limited by SNMP standards (simple login and passwords)
Allows for management of millions of devices at one time
Provides hands-free configuration and setup
Non-computer devices still have embedded processing capability, but typically don’t have keyboard/display capability. Being able to configure and manage this type of equipment provides greater flexibility.
LDAP provisions for enhanced authentication provide much better security than the simple login/password provided with SNMP
The scalability of eDirectory makes it so that you can manage millions of devices at one time. Authentication to the directory by a device on power-up provides a slick method of configuring the device.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

60. How a Directory Helps Provisioning
Novell BrainShare 2002
How a Directory Helps Provisioning
Increases deployment speeds of embedded hardware
Improves management of the overall system
Enhanced security from multiple authentication methods
More scalable than SNMP
Increases deployment speeds of embedded Hardware because the directory provides:
Directory based policies for self provisioning of hardware and software.
Integration with customer record, billing, and accounting systems (DirXML).
Manages process flow and relationships between companies/organizations.
Complements existing systems and infrastructure.
Improves management of the overall system.
Objects in the directory(ies) are aggregated into a secure system.
Can manage large groups of objects in various inter-related ways.
Globally, regionally, in groups, or individually.
Multiple directories interconnected in custom ways.
Secure System.
SSL and certificate based authentication.
Support for additional authentication models.
Multi-layered security model.
Directory objects can have individual access rights managed down to the attributes of an object.
Centralized (unlike SNMP).
Scalability.
Scales much larger than SNMP alone based management systems.
Easily manage millions of objects (CPE, Ports, etc.) in the directory.
Novell Directory Services scales to billions of objects.
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

61. Directory-based Provisioning
Novell BrainShare 2002
Directory-based Provisioning
Provisioning of Devices within the Enterprise
Order entry HR
Work order
Billing
Management
console
Novell
eDirectory
Provisioning policies
Trouble alert policies
Billing policies
Data sync policies
Security
Wireless device
Common data can be leveraged between systems. Simply adding attributes to objects to describe more information about the object, or associating objects together. This greatly simplifies the management.
NDS allows for auxiliary classes to be defined and associated with base classes for additional attribute customization.
Policy information is also maintained in the directory, scaling from individual objects up to all objects in the tree. Typically, objects are grouped or contained and policy is applied at that level.
Router
CPE
Caching or other hardware
Networked
hardware
Internet Data
DirXML Data
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

62. Bringing It All Together
Novell BrainShare 2002
Bringing It All Together
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

63. Outdoor Adventures: Bringing It All Together
Novell BrainShare 2002
Outdoor Adventures: Bringing It All Together
Let’s look at how these new features can benefit a hypothetical company, Outdoor Adventures
Auxiliary classes are used to identify students and instructors
ACLs are used to give students and instructors rights to view information they need on the web
The [This] ACL is used to allow students to modify their own object attributes
Access to specific course information is allowed by assigning ACLs to dynamic groups that identify students
Rights-based object access (ACLs)
Event monitoring (LDAP extension, and persistent search)
Dynamic Groups
Object-based Schema (Auxiliary Classes)
Search Scope Reduction (Extensible Match)
Selectable Transport Encryption (Start TLS)
Biometric Authentication (SASL support)
Device Provisioning using embedded LDAP clients
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

64. Outdoor Adventures: Bringing It All Together
Novell BrainShare 2002
Outdoor Adventures: Bringing It All Together
Instructors use Persistent Search to dynamically update their web display of class members
Searches in the tree simplified with DN matching rules
Credit card information is transmitted over TLS connections
Advanced authentication (thumbprint) is required for instructors to access student and course information
Outdoor Adventures network is run using switches and routers configured from the directory
Rights-based object access (ACLs)
Event monitoring (LDAP extension, and persistent search)
Dynamic Groups
Object-based Schema (Auxiliary Classes)
Search Scope Reduction (Extensible Match)
Selectable Transport Encryption (Start TLS)
Biometric Authentication (SASL support)
Device Provisioning using embedded LDAP clients
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

65. Outdoor Adventures: Bringing It All Together
Novell BrainShare 2002
Outdoor Adventures: Bringing It All Together
Want to learn more about these concepts and see them in operation?
The “How To” information is given in sessions DL204, DL307, and TUT242
The Outdoor Adventures web site showcasing all of these concepts can be experienced in the tech lab
Rights-based object access (ACLs)
Event monitoring (LDAP extension, and persistent search)
Dynamic Groups
Object-based Schema (Auxiliary Classes)
Search Scope Reduction (Extensible Match)
Selectable Transport Encryption (Start TLS)
Biometric Authentication (SASL support)
Device Provisioning using embedded LDAP clients
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

66. Novell eDirectory 8.7—It’s Not Just a NOS Directory Anymore
Novell BrainShare 2002
Novell eDirectory 8.7—It’s Not Just a NOS Directory Anymore
How do I get this great full-service LDAP directory product for re-distribution with my applications?
You can have your customers go out and buy individual licenses as needed, OR
Need to push the RDK here. Developer has unlimited internal licenses for development, 250,000 for internal business use, and 250,000 for each product shipped.
Developers can sign up for the Novell eDirectory Re-distribution Kit by visiting developer.novell.com/edirectory/ and receiving 250,000 eDirectory licenses for free (now that’s a DEAL)
IO137—Introduction to the Hot New LDAP Features in eDirectory 8.7

67. Vision…one Net Mission
A world where networks of all types—corporate and public, intranets, extranets, and the Internet—work together as one Net and securely connect employees, customers, suppliers, and partners across organizational boundaries
Mission
To solve complex business and technical challenges with Net business solutions that enable people, processes, and systems to work together and our customers to profit from the opportunities of a networked world

70. Developer References
Novell Developer LDAP SDKs, documentation, and samples
Novell eDirectory Evaluation Version and Redistribution kit
Novell Modular Authentication (NMAS™)
Novell Developer AppNotes

71. Developer References
LDAP Zone: The latest information and resources for LDAP
Directory Interoperability Forum
Works with LDAP certification

72. Developer References LDAP IETF standards Filters and extensibleMatch
The TLS protocol
Extension for TLS (startTLS)
SASL (Simple Authentication and Security Layer)

73. References eDirectory ACLs Dynamic Groups Persistent Search
Section 5.7
Dynamic Groups
App note on
Persistent Search
Soon to be App note on
