1. SPACE MOUSE

2. OUTLINE: Introduction Principle Space mouse Types Specifications
Features
Working
Visual space mouse
Applications
Advantages
Future scope
Conclusion

3. Introduction:
Space mouse is developed by the DLR institute of robotics and mechatronics.
DLR- Deutsches Zenturum far Luft-und Raumfahrt.
First prototype applications of DLR control was showed from
The high sales price of about $8,000 per unit

4. Principle:
The basic principle behind its construction is mechatronics engineering and the multisensory concept.
Measuring system is drift-free and not subject to aging effects.
Movements were measured by electromagnetic or ultrasonic.
The measuring arrangement in the inner ring is composed of the LED, a slit and perpendicular to the slit on the opposite side of the ring a linear PSD.

5. SPACE MOUSE:
Space Mouse is a professional 3D controller manipulating objects in a 3D environment.
It has different modes of operation in which it can also be used as a two-dimensional mouse.
Groundbreaking interface.
Enables the user to intuitively zoom, pan and rotate models.

6. TYPES: Two types of space mouse
Space mouse classic
Space mouse plus

7. Specifications: PRODUCT Space Mouse Classic Space Mouse Plus
SENSITIVITY
adjustable
 BUTTONS
9, programmable
11, plus Quick tip programmable
INTERFACE
RS-232C
RS-232C or USB
CONNECTOR
D-sub 9 pin
D-sub 9 pin or USB
WEIGHT
Weight 1.46 lb (0.66 kg)
1.5 lb (0.68 kg)
DIMENSIONS (LxWxH)
6.50" x 4.41" x 1.57" (165 x 112 x 40mm)
7.40" x  4.72" x 1.73" (188 x 120 x 44mm)
 WARRANTY
36 Months

8. Features: Ease of use of manipulating objects in 3D applications.
Calibration free sensor technology for high precision and unique reliability.
Nine programmable buttons to customize users preference for motion control.
Fingertip operation for maximum precision and performance.
Adjust sensitivity and motion control to the users preference.
Small form factor frees up the desk space.
Natural hand position (resting on table) eliminates fatigue.

9. Working:
Inside a mouse:
Figure :1

10. The exposed portion of the ball touches the desktop
Figure :2

11. Rollers detection:
Figure :3

12. A typical optical encoding disk:
Figure :4

13. A close-up of one of the optical encoders that track mouse motion
Figure :5

14. The logic section of a mouse
Figure :6

15. Visual space mouse:
Visual space mouse can be divided into two main parts
Robot control
Image processing

16. Applications: Works in graphical applications.
Object manipulation in 3D applications.

17. Advantages: Drawing times is reduced by 20%-30% .
Works without an additional power supply.
Adapted for a wide range of tasks including
mechanical design,
real time video animation and
visual simulation.

18. Future scope: ROTEX is the only well known virtual environment.
Machine instruction allowance.
To develop virtual environment using space mouse.

19. Conclusion:
we believe there is no other man- machine interface technology comparable to Magellan in its simplicity and yet high precision. It is used for 3D manipulations in 6 doff, but at the same time may function as a conventional 2D mouse.
