Use of Software from Cockpit Equipment in the Training Environment
Take your title slide (minus any graphics you may have on the slide) and make it the first slide of your presentation. This is the slide that will show up when searching for your presentations within PowerPoint. Kevin O’Brien Program Manager Honeywell Training Solutions
2
Purpose of this Presentation
Inform AICC members with experience gained from a true avionics Rehost Help align AICC efforts with best practices identified from that experience Identify overlapping or exclusive areas of influence between system engineers and content/lesson authors AICC System Engineers Content Authors Here are the basic elements of the Honeywell PowerPoint template. The Walk-away message box and the Subhead are not part of the master page because of the limitation in PowerPoint to one title and one text area. Generate the discussion
3
Introduction AICC and Airline calls for rehosted Flight Management System drove the need Honeywell was beginning development of new Integrated Avionics system call Primus Epic® Hardware resembles PC cards Software written in C/C++ Represented best opportunity yet for a rehost
4
Epic Rehost Project Objectives
Enable use of Epic aircraft software for pilot training Classroom operation should have high fidelity Minimize number of changes to rehosted aircraft software Updates to field are quick, and training kept current Should not require extraordinary PC host Rehosted software should run in 50% of 2 GHz Pentium 4 PC
5
Project History Honeywell hosted an industry meeting in April of 2002 to define the requirements and determine feasibility. Chose the Dassault Falcon 900EX EASy Meeting resulted in the first formal Application Specification Team chose to build infrastructure from the ground up in order to avoid existing obstacles. Proof of concept occurred in July 2002 Relied on Moore’s Law during development
6
Definitions Rehosted vs. Reimplemented GGF’s ASCB-D
During our development we came across issues in the aircraft code that Windows couldn’t cope with i.e. null references. Made those changes and communicated back with product engineering to make changes for next aircraft software release. Needed to define the difference between “touched” and “untouched” code. Reimplemented meant “dropped in” code. GGF’s Graphics executables with a .exe extension OpenGL based ASCB-D Primus Epic’s primary communication bus DEOS-Digital Engine Operating System Aircraft’s Operating System
7
Scope of the Rehost Build an abstraction layer and services on top of Windows, that looks like DEOS. Result was EASE. Rehost the FMS and GGF’s applications on top of EASE. Holy Cow, it worked!!!! The “why not?” approach expanded even further to include Monitor Warning Central Maintenance Electronic Checklists Terrain Display Radio Tuning ….AFCS, WX Radar, MCDU, Flight Plan uploading.
8
Technical Approach 2. Port graphics and Flight Management software to the PC 1. Create a software environment that allows use of Epic applications on an ordinary PC 3. Wrap around pilot lesson plans and flight simulation
9
Honeywell Content Aircraft Software
Displays All the Graphics Generation Function (GGF) processes Graphics Control CALF and DUCTL Flight Management System Monitor Warning Function Electronic Checklist Epic Application Simulation Environment Provides a PC environment that appears like the aircraft to Epic applications DEOS API, Epic ASCB communication, File System and Core Graphics software, …
10
PFD with Flight Management Window
This picture represents an aircraft parked on the ground and displays fuel and weight parameters
11
Honeywell/Vendor Software Interfaces
Aircraft data, two options: GenericPddClient capability allows aircraft simulation software (ordinary Windows processes) to produce or consume ASCB data Reuse EASE interface for Epic Test Interface Unit (TIU) Graphics rendering Honeywell provides specification for rendering Epic graphics as well as source code for our implementation of rendering process CCD input EASE reuses the Epic CCD specification Platform control Honeywell provides DLLs for controlling rehosted software, Start, Stop, Suspend, Resume, TimesN Snapshot/Recall, Reposition, Freezes Relation to Snapshot Data Model??? XML?
12
GenericPddClient Process
In the aircraft, PDD requires that the process that produces IRS data be named “genIo” IRS “genIo” PDD ASCB ARINC 429 MAU proc card In EASE, we use GenericPddClient to replace the “genIo” process and transfer simulated IRS data to ASCB Aircraft simulation ASCB simulation GPC “genIo” PDD EASE platform
13
System Architecture DU1 DU2 FMS Graphics Rendering Simulated ASCB Bus
Epic Application Simulation Environment DU1 DU2 FMS Graphics Rendering Simulated ASCB Bus GPC TiuFBS Pilot Training Software Flight Simulator Lesson Control
14
Epic Rehost runs on an ordinary Windows PC
Host Hardware Windows XP or 2000 2 GHz Pentium 4 processor Game-grade video card Laptop or Desktop Epic Rehost runs on an ordinary Windows PC
15
Other Uses of EASE in Honeywell
Epic testers are using EASE for DU1310 V&V (Falcon and Gulfstream) GGF, CALF, MWF and ECLF Test development Run-for-score FMS developers Investigating EASE for use with TOLD development and FMS testing Miscellaneous other uses Epic programmer training Flight plan development Verifying NAV databases
16
Customer Benefits Development time to integrate vs. development time of reverse-engineering (or source/object rehosting and retargeting). Avoids the “It doesn’t look like my aircraft” syndrome Looks just like the airplane Updates to the HI product coincide can occur simultaneously with updates to the field System architecture allows for fast end-item update Independent of training device implementation
17
Drawbacks Not easily customizable.
It is actual airplane software Requires some knowledge of target system interface/operation All necessary internal variables must be addressed.
18
Observations System engineers are not content developers
Unaware of initiatives like AICC CMI, SCORM It’s all about the interface The less we exposed the content developers to Epic, the better off we were Reusabilty isn’t always the best thing Needed to abandon previous attempts to rehost parts of the system Rehost engineers had no idea what they were looking at when successful
19
Quick Demo
20
Conclusion Rehosting of aircraft avionics will become more prevalent
Have proof of concept for all Pegasus FM Plans to rehost the A380 Are standards needed, and if so, what/where? If communications modules are standard i.e. ASCB, is all that is needed is an interface spec? LMS interoperability
21
This is the closing slide that should appear at the end of all presentations. If you are using an existing presentation, you should copy this slide and insert it at the end. The old Honeywell closing slide, with the red background and tagline “Helping You Control Your World” should not be used. This slide should not be altered in anyway. Do not add any additional elements to the slide, alter the web address, add additional copy, etc. Use it as it appears here. 18 4 4
22
If you are giving your presentation electronically, it is always good to insert a black slide at the end. This ensures that the computer will not jump back to the Windows screen or program manager, and distract the audience from your closing remarks
