1 Vegetative Structures of Plants

2 leaves flower stem roots seed fruit Six Main Parts

3 Leaves 0 Capture light 0 Exchange gases 0 Provide a site for photosynthesis 0 Some leaves store food and water 0 Some form new plants and provide support

4 Photosynthesis 0 A process by which plants combine water and carbon dioxide in the presence of chlorophyll and sunlight and produce carbohydrates and release oxygen 0 The chemical equation for photosynthesis is: 6CO 2 + 6H 2 O → C 6 H 12 O 6 + 6O 2

5 Why is photosynthesis important? 0 Light is the most important source of energy for living things 0 Photosynthesis converts light into nutrients that can be used by plants and animals

6 Photosynthesis Reactions 0 Light Reactions 0 Produce chemical energy from light 0 Dark Reactions 0 Convert carbon dioxide into carbohy6drates

7 Gas Exchange Process 0 O 2, CO 2, and H 2 O are exchanged through small pores in the leaves called a stomata 0 Each stomata is surrounded by two guard cells 0 Guard cells open during the day allowing water to transpire 0 Guard cells close at night and during dry conditions to prevent water loss

8

9 Respiration 0 Plants, like animals respire 24 hours a day. 0 During respiration, plants consume oxygen and give off carbon dioxide, just like animals 0 Roots, stems, and leaves all use oxygen as they grown and breathe out carbon dioxide. 0 Poor soil drainage causes roots to suffer most from short oxygen supply and possible plant death.

10 True or False Plants produce more oxygen through photosynthesis than they consume through respirations and growth processes.

11 Respiration C 6 H 12 O 6 + 6O 2 → 6CO 2 + 6H 2 O + ATP 0 Respiration is a process in which energy is generated in cells 0 In respiration, glucose (sugar) and oxygen are converted into CO 2, H 2 0, and ATP (adenosine triphosphate) 0 Respiration takes places in the mitochondrion of both plant and animal cells

12 Parts of the Leaf petiole blade margin midrib axillar y bud stem internode node

13 External Leaf Parts 0 Petiole 0 The stalk of the leaf that attaches it to the stem 0 Midrib 0 The main vein of vascular tissue 0 Blade 0 The photosynthetic site of the leaf

14

15 Internal Parts of the leaf 0 Cuticle 0 A LAYER OF FATTY SUBSTANCES ON THE OUTSIDE OF THE LEAF THAT PREVENTS WATER FROM ESCAPING 0 Epidermis (Lower & Upper) 0 A layer of transparent cells that permit the passage of light to the photosynthetic cells 0 Parenchyma 0 The photosynthetic cells of the leaf

16 Internal Parts of the Leaf 0 Mesophyll 0 The middle of the leaf, composed of parenchyma cells 0 DIVIDED INTO PALISADE MESOPHYLL AND SPONGY MESOPHYLL 0 Palisade Mesophyll 0 Column shaped cells near the surface where most of the photosynthesis takes place 0 Spongy Mesophyll 0 Irregular shaped cells that underlie the palisade cells

17 Internal Parts of the Leaf 0 Veins 0 Vascular tissue which brings water from the roots and carries away the products of photosynthesis 0 Stoma 0 Function in transpiration and gas exchange 0 Guard Cells 0 Regulate the opening and closing of the stomata

18 Stomata 0 Stomata are openings with the epidermis of the leaf 0 Functions 0 To allow air into the leaf 0 To allow water and oxygen out of the leaf

19 Monocot vs. Dicot 0 Monocot 0 Tap Root 0 Dicot 0 Fibrous Root

20 Roots 0 absorb water and minerals 0 anchor the plant 0 Stores food 0 Propagation

21 Taproots 0 Advantages 0 Penetrate soil deeper 0 Obtain water from lower levels 0 Anchor the plant 0 Disadvantages 0 Difficult to remove and harvest plants 0 Do not stabilize the soil well

22 Fibrous Roots 0 Advantages 0 Shallower, therefore they respond more quickly to fertilization and irrigation 0 Stabilize the soil better 0 Disadvantages 0 Less drought resistant 0 Tend to get exposed during cultivation

23 Parts of the Root primary root secondary root root cap root hairs

24 Root Part Functions 0 primary root: the thickest part, grows down 0 secondary roots: not as thick as primary, grow out to the side 0 root hairs: thin, fine roots that absorb water and nutrients 0 root cap: on the end, protects and guides the tip

25 Root Types 0 Adventitious Roots 0 Come from stems of leaves instead of another root 0 Fibrous Roots 0 Structures in which the primary and lateral roots develop equally so that there is not a definite taproot 0 Storage Roots 0 Structures like carrots and sweet potatoes which are used for foot storage

26 Root Parts 0 Apical Meristem 0 region of active cell division; the growing point of the plant 0 Region of elongation 0 cells here grow longitudinally which causes the root to grow longer 0 Region of differentiation 0 the region of mature primary tissues which is an area of active water and mineral absorption 0 Xylem 0 transports water and nutrients upward 0 Phloem 0 transports carbohydrates and sugars downward

27 Stem 0 Water and mineral transport by capillary action and cohesion to the leaves 0 Transport food to the roots 0 Gas exchange 0 Produce and support new leaves, branches, and flowers

28 Internal Parts of the Stem 0 Phloem 0 Transports sugars and carbohydrates to roots 0 Xylem 0 Transports water and nutrients from roots to rest of tree 0 Cambium 0 Lateral meristem is the growing part of the stem

29 Internal Parts of the STem 0 Pith 0 Occupies the central area of the stem 0 Ray 0 Cortex 0 Composed of several layers of thick- walled cells and an area of thin-walled parenchyma cells interior to the thick- walled

30 External Parts of the Stem 0 Buds 0 Axillary and terminal 0 Nodes 0 Internodes

31 Flowers 0 where reproduction takes place 0 flowers contain male and female parts 0 becomes the fruit and seeds

32 Fruit 0 helps seeds spread 0 birds and animals eat the seeds or carry off the fruit 0 some seeds cling to fur and hair

33 Seeds 0 become the new plant 0 are spread by birds, animals, wind, and water

34 Parts of the Flower styl e stigma pistil stame n anther filament ovary petal polle n

35 Flower Part Functions 0 sepals: outer section; protects developing flower 0 petals: attract insects for pollination 0 pistil: female part of the flower 0 stigma 0 style 0 ovary 0 stamen: male part of the flower 0 anther 0 filament
