1. Database I/O Mechanisms
Performance and persistence
Richard Banville Fellow, OpenEdge Development Progress Software

2. 1 2 3 4 5 Agenda Database I/O Types User Data I/O Recovery Data I/O
Other I/O 5
Summary

3. File Write I/O for File Types
Logical vs Physical
Database request vs OS I/O
Database I/O vs O/S I/O
Physical I/O always uses file system cache (no raw I/O)
Buffered vs unbuffered I/O
Unbuffered I/O considered durable after write system call
Recovery data with integrity
User data with -directio
Buffered I/O requires file system sync. for durability
Recovery data with no integrity
User data

4. OpenEdge I/O & The File System
System Memory
Process Shared Memory
Database Buffer Pool
BI Buffers
AI Buffers
I/O via F/S cache
File system cache
Physical Disk Devices
Multi level caches
Multi level caches .d .d .b .d .a

5. OpenEdge Data I/O & The File System
System Memory
Buffered I/O to F/S cache
F/S decides when to write to disk device
Disk device decides when to write to physical disk
At checkpoint, made durable via fdatasync() / FlushFileBuffers()
Required for crash recovery and Bi space reuse to work properly
Promon Checkpoints:
Process Shared Memory
Database Buffer Pool
File system cache
Sync Time: cost of fdatasync()
Duration: cost of cluster close => 1) flush bi bufs, 2) scan buffer pool 2a) flush bufs from prev checkpoint 2b) put dirty bufs on checkpoint queue 3) flush ai bufs 4) Synch file system cache - fdatasync()
Disk Devices
Flushes
Duration
Sync Time
0.20
0.02 4
0.04
0.17 2
0.22
0.03 .d
Multi level caches

6. OpenEdge –directio I/O & The File System
System Memory
-directio
Unbuffered I/O thru F/S cache
Not raw I/O to disk device
Each I/O sync‘d to disk device
Operational affects
No need to sync at checkpoint
Write I/O more expensive
Additional cost to page writers
Promon Checkpoints:
Process Shared Memory
Database Buffer Pool
File system cache
-directio is NOT what the name would imply.
Data written to F/S then immediately synced to disk
Disk Devices
Flushes
Duration
Sync Time
0.16
0.00 2
0.18 11 .d
Multi level caches

7. OpenEdge –directio I/O Performance
System Memory
How could the more expensive writes of –directio improve performance?
APWs absorb the additional cost
If they do all the writing without adding OLTP contention
Lower checkpoint costs
Each I/O sync‘d to disk device
No sync needed during checkpoint
Higher throughput due to less pause
May help on inadequate file system
Less useful for
Well tuned deployments
Properly sized systems
When buffers flushed at checkpoint
Process Shared Memory
Database Buffer Pool
File system cache
-directio is NOT what the name would imply.
Data written to F/S then immediately synced to disk
However, any buffers flushed at checkpoint are MUCH more expensive!
Disk Devices .d
Multi level caches

8. OpenEdge Recovery I/O & The File System
BI Buffers
File system cache
System Memory
Process Shared Memory
Multi level caches .d .b
Unbuffered I/O to F/S cache
Each I/O sync‘d to disk device
For .bi, called “reliable I/O”
BI blocks written when:
BIW notices full block in out buffer
APW writes data block with bi dependancy
Broker notices aged commit (-Mf)
User can‘t find empty bi block to store update notes
User must perform checkpoint
Disk Devices

9. OpenEdge Recovery: Making it unreliable
BI Buffers
File system cache
System Memory
Process Shared Memory
Multi level caches .d .b
Never in production
Specific maintenance only
-r: BI writes are buffered (un-reliable) to F/S
All change notes recorded
Rollback will work
Crash recovery likely to work
Recovery from OS crash will most likely fail
idxbuild some index, !“some; !”
Disk Devices
*** An earlier -r session crashed, the database may be damaged. (514)

10. OpenEdge Recovery: Making it more unreliable
BI Buffers
File system cache
System Memory
Process Shared Memory
Multi level caches .d .b
Never ever in production
Specific maintenance only
-i: no-integrity
BI writes are buffered
No data dependency check (!WAL)
No F/S sync at checkpoint
No record of purely physical notes
Rollback might work
OS, DB crash, abnormal termination
Must restore from backup
Roll back will never occur until after a micro-transaction completes so no record of purely physical notes is OK
Disk Devices
** Your database cannot be repaired You must restore a backup copy. (510)

11. 1 2 3 4 5 Agenda Database I/O Types User Data I/O Recovery Data I/O
Other I/O 5
Summary

12. … Buffer Pool I/O 1 Buffer pool cache 1 Hash table
Multiple LRU replacement chains
Database
Buffer
Lookup
Buffer pool hash table
Database
Buffer Pool (-B, -B2) 4
160 32
128 64 … 2
144
192
112 80
LRU buffer eviction policy
LRU2 buffer eviction policy
If not found via hash table lookup
Incur O/S read I/O – “page-in”
But where do you read into?

13. … Buffer Pool I/O 1 Buffer pool cache 1 Hash table
Multiple LRU replacement chains
Database
Buffer
Lookup
Buffer pool hash table
Database
Buffer Pool (-B, -B2) C D …
LRU buffer eviction policy
LRU2 buffer eviction policy
Start at LRU end of buffer replacement chain
Look for first “non-dirty” buffer (to avoid write)
Can’t find one after 10 tries?
“Page-out” least recently used buffer (O/S write I/O) “LRU writes”
May force (multiple) BI/AI writes, usually partial writes!
“Page-in” your block to available buffer (O/S read I/O)

14. DB Data Read I/O Tuning Increase performance by decreasing I/O
Avoiding read I/O
Large buffer pool (-B)
Utilize alternate buffer pool (-B2)
Improve queries; Avoid table scans; Cache data locally
Private “read-only” buffers (–Bp), utilities too!
Increase pool when read I/O unacceptable for properly tuned application
Too many buffers may cause O/S paging
Decrease file system cache
Avoid non-essential activities on production server
Consider buying more memory
Database Buffer Pool
-B & -B2 buffers
I/O DB
From the DBA side of things, its always ease to increase –B.
However, it will not improve performance for a poorly written application

15. Data I/O Performance Monitoring - Promon
Promon R&D => Performance indicators
Promon R&D => Buffer cache
O/S reads and O/S writes
Flushed at checkpoint
LRU Writes
APW enqueues*
Database Buffer Pool
-B & -B2 buffers
I/O DB
What about buffer pool hit ratio % (BHR)?
Too easily skewed by bad queries
Not a fine enough metric (hits / requests)
270,000 database read requests / second
Buffer hit ratio % of 98
Still means 5,400 O/S Read I/Os per second!
Fast F/S access still 75x slower than -B
A low BHR indicates a poorly tuned system
Low BHR indicates a poorly running system. 75x slower stat from Tom Bascom analysis
Great article to read more about why buffer hit ratios are not affective
A high BHR does not denote a well tuned system

16. DB Data Write I/O Tuning Increase performance by decreasing I/O
Avoiding write I/O
Large buffer pool lessens forced “page-outs”
Improve queries in the application
Reduce checkpoint frequency (see next section)
Run with APWs (Have someone else do it!)
Avoids user and server writes
Decreases LRU writes (forced “page-outs”)
Reduces checkpoint time
Performs DB buffer pool I/O
May flush AI and BI data
Database Buffer Pool
-B & -B2 buffers
I/O DB
75x slower stat from Tom Bascom analysis

17. Asynchronous Page Writer Activities
Checkpoint Queue
Primary –B buffer pool AND Alternate –B2 buffer pool C D …
LRU chains 4
148
200
120 BI
WAL
APW DB
APW Queue #2
Forced bi write only if cluster > 95% full #3 #1
Discuss Self tuning mechanism
Checkpoint Q writes can cause forced bi writes (resulting in partial BI writes)
If the cluster is 95% full, write will occur regardless – this can cause partial writes as well
This is why increasing cluster size can reduce partial bi writes – it is 95% full less of the time!
New adaptive mechanism for checkpoint processing
Avoids buffers flushed
10.2b FCS

18. Asynchronous Page Writer Performance
Checkpoint Queue
Primary –B buffer pool AND Alternate –B2 buffer pool R U …
LRU chains 4
148
200
120 BI
WAL
APW DB
APW Queue
Promon R&D => Page Writers
APW queue writes
Checkpoint queue writes
Buffers scanned
Scan writes
Tuning
Increase until 0 blocks flushed at checkpoint
Decrease if partial BI writes increase
Increasing BI cluster size can avoid:
partial BI writes
forcing BI writes (95% full less of the time)
Typically need more if running with Direct I/O
Discuss Self tuning mechanism – buffers flushed only when 95% of cluster is full
New adaptive mechanism changes number of buffers written from checkpoint queue based on # of flushes in previous checkpoint.
Checkpoint Q writes can cause forced bi writes (resulting in partial BI writes)
If the cluster is 95% full, write will occur regardless – this can cause partial writes as well
This is why increasing cluster size can reduce partial bi writes – it is 95% full less of the time!

19. 1 2 3 4 5 Agenda Database I/O Types User Data I/O Recovery Data I/O
Other I/O 5
Summary

20. BI BI Buffer Pool -bibufs 10 Modified Queue Backout Buffer
Forward Processing
Rollback Processing
-bibufs 10
Modified Queue
Current Output Buffer
Current Input Buffer
Free List
Free(a) 32 31 15
Free(b) 30
Backout Buffer
Backout Buffer
New Notes (Actions)
Free(c) 29 9 12
Free(d)
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability
Free(e) BI

21. BI Buffer Pool – Recording a change
Forward Processing
-bibufs 10
Modified Queue
Current Output Buffer
Empty buffer waits
Free List
Free(a) 32 31
Busy buffer waits
BIB latch contention
-bwdelay in ms (30ms)
Nap time when nothing dirty
Not much positive tuning affect
Free(b) 30
New Notes (Actions)
Free(c) 29
User
Free(d)
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability
B I W
Free(e) BI

22. BI Buffer Pool – Forced Write I/O
Forward Processing
Data Blocks
-bibufs 10
Modified Queue
Current Output Buffer
256
Free List
512
Free(a) 32 31
Buffer Pool
Associated BI note dependency ctr (based on fill %)
768
Free(b) 30
New Notes (Actions)
172
Checkpoint Queue
Free(c) 29
User
128
Free(d)
APW
WAL
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability DB
Free(e) BI

23. BI Buffer Pool – Write I/O
Forward Processing
Is it OK to buffer modified BI blocks?
-bibufs 10
Modified Queue
YES
Current Output Buffer
Free List
Is it OK to buffer committed BI data?
Free(a) 32 31
Delayed commit (-Mf) is up to you!
Free(b) 30
New Notes (Actions)
Free(c) 29
User
Delayed commit (Durability)
Based on –Mf value, Broker may flush BI buffers to disk
For aged txn ends
-Mf default 3
Increasing -Mf Pros/Cons:
Free(d)
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability
Broker
Free(e) BI

24. BI Buffer Pool – Change rollback
Forward Processing
Rollback Processing
-bibufs 10
Modified Queue
Current Output Buffer
Current Input Buffer
Free List
1 shared input buffer
Multiple private back out buffers
Free(a) 32 31 15
Free(b) 30
New Notes (Actions)
Backout Buffer
Backout Buffer
Free(c) 29 9 12
Free(d)
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability
Free(e) BI

25. BI Buffer Pool – Change rollback
Rollback Processing
Modified Queue
Current Output Buffer
Current Input Buffer 32 31 15 30
Read I/O to find notes
Write I/O when undoing
Promon:
BI Reads
Input buffer hits
Output buffer hits
Mod buffer hits
BO buffer hits
Back out Buffer
Back out Buffer 29 9 12
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
If note is in current out or mod buffer, only the note is copied, not the entire buffer.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability BI

26. Tuning the Bi Buffer Pool
Forward Processing
Run BIW
Promon: 5. BI Log Activity
Empty buffer waits – all full
Increase –bibufs (online)
-aibufs >= -bibufs
Start with –bibuf 150
Partial (forced) writes
-Mf expired
Increase if not risk adverse
Too many APWs
Tune checkpoint processing
Busy buffer waits – busy - OK
Log force waits/write – 2PC commit
-bibufs 10
Current Output Buffer
Modified Queue
Free List
Free(a) 32 31
Free(b) 30
New Notes (Actions)
Free(c) 29
User
Free(d)
For performance we buffer all I/O activity. The BI is no different.
Buffering BI activity maintains the Durability rule as long as when the txn commits all notes associated with the transaction are flushed to disk.
NF – Not Formatted
Blocks from Free list are formatted in memory for disk addressability
B I W
Free(e) BI

27. Monitoring BI Activity & Performance Summary
Forward Activity
Total BI writes
Records (notes) written
Clusters closed
Undo
Total BI reads
Notes read
Input buffer hits
Output buffer hits
Mod buffer hits
BO Buffer Hits
OK Waits & Writes
Busy buffer waits
BIW writes
Bad Waits & Writes
Empty buffer waits
Partial writes
Forced writes (2PC)
Flushed at checkpoint
Checkpoint duration (wait)
Forced Writes (tpflCt64) – 2PC only

28. Checkpoint Processing

29. Checkpoint Processing
Quiet DB
Database changes halted
Page writers continue
Flush bibufs
Output, Mod buffers
May cause 1 partial write
Scan buffer pool
Write bufs on chkpt queue
Dirty buffs added to chkpt queue
“Fuzzy” checkpoint
Hopefully flushed prior to next chkpt
Flush aibufs
Sync File System
F/S Sync system call
No more sync delay
Resume database activity
Dirty buffers are marked for chkpt & put on checkpoint queue
Fuzzy check pointing avoids I/O
Hopefully APWs flush these buffers before the next checkpoint

30. Promon Checkpoint Data
Database Writes
No.
Time …
CPT Q
Scan
APW Q
Flushes
(Cont.) 27
10:23:12
384 52 26
10:22:46
381 3 25
10:22:18
380 2 24
10:21:50
201
158
APW Specific Activity…
CPT Q: # data buffers APW wrote from checkpoint queue (from prev chkpt)
Dirty - # of dirty blocks in -B - marked modified
APW Q - NOT GOOD! May need to increase -B or add APW
Scan: # data buffers APW wrote while scanning -B
APW Q: # data buffers APW wrote from APW Q
Dirty buffers added to APWQ from -B LRU eviction

31. Promon Checkpoint Data
Database Writes
No.
Time …
CPT Q
Scan
APW Q
Flushes
(Cont.) 27
10:23:12
384 52 26
10:22:46
381 3 25
10:22:18
380 2 24
10:21:50
201
158
Flushes:
Number of database blocks written during checkpoint
Very costly operation (db updates paused)
Should add ai/bi flushes
Marked from previous checkpoint
Avoid with APWs and larger cluster sizes
Dirty - # of dirty blocks in -B - marked modified
APW Q - NOT GOOD! May need to increase -B or add APW

32. Promon Checkpoint Data
----- New Columns -----
No.
Time …
Duration
Sync Time 27
10:23:12
0.12
0.04 26
10:22:46
0.11
0.03 25
10:22:18 24
10:21:50
0.13
File System Cache DB
Duration:
Time to process checkpoint including:
Write chkpt queue, buffer pool scan, bi/ai flush, F/S Sync
Sync Time: Amount of time in seconds it took for fdatasync() or FlushFileBuffers()
Limit file system cache size and flush frequency
Faster disks for data files
Avoid with –directio (but increases all write I/Os)

33. Tuning Checkpoint Processing
Physical
BI truncate
Values in K
-bi (cluster size in KB)
-biblocksize (size in KB)
Before-image block size set to 8 or 16 kb
Followed by sync command
proutil <db> -C truncate bi -biblocksize 8 -bi 8192
proutil <db> -C bigrow 8 -r
Runtime
BI bufs
BIW

34. Summary: Recovery Subsystem
AI/BI buffers
No LRU replacement mechanism
Database changes recorded orderly
Forward processing causes BI write I/O
Rollback may cause read I/O
Backout Buffers (BOB) help rollback contention
Checkpoints
Buffers flushed during checkpoint
Page writers
BIW/AIW processing
APW processing

35. 1 2 3 4 5 Agenda Database I/O Types User Data I/O Recovery Data I/O
Other I/O 5
Summary

36. Database Extend Database extend Recovery extend (AI/BI)
Storage area locked - no other extends
Writes performed 16K at a time
Extend by 64 blocks or cluster size
Recovery extend (AI/BI)
Acquire space from F/S
Unbuffered write
Bi grow after truncate
Performance Improvements
F/S interaction for extent create 11.3
BI extend, format & grow in 11.3
Maintenance cost
Performance
Concurrency
Frequency

37. Monitoring I/O With Promon R&D
Database Accesses vs File I/O
Database writes
O/S Writes
2. Activity Displays ...
1. Summary
3. Buffer Cache
4. Page Writers
5. BI Log / 6. AI Log
8. I/O Operations by Type
9. I/O Operations by File
3. Other Displays…
1. Performance Indicators
2. I/O Operations by Process
4. Checkpoints
5. I/O Operations by User by Table
6. I/O Operations by User by Index
I/O Operations by user are NOT operating system I/Os – they are logical database operations.

38. 1 2 3 4 5 Agenda Database I/O Types User Data I/O Recovery Data I/O
Other I/O 5
Summary

39. Summary
Always uses file system cache (no raw I/O)
Buffered vs unbuffered I/O
User data files: .d’s and recovery files: .ai, .bi, .tl
I/O Types
Checkpoint process
Page writers (APW, BIW, AIW)
Data and recovery I/O
Monitor via promon, VSTs and OS tools
Tuning tips
Performance

40. ?
Questions

41. www.progress.com/exchange-pug October 6–9, 2013 • Boston #PRGS13
Special low rate of $495 for PUG Challenge attendees with the code PUGAM
And visit the Progress booth to learn more about the Progress App Dev Challenge!

43. File Write I/O for File Types
I/O always uses file system cache (no raw I/O)
Buffered vs unbuffered I/O
Unbuffered I/O considered durable after write system call
Buffered I/O requires file system sync. for durability
User data files: <db>_<area>.d’s (table, index and LOB data)
Changes recorded in .bi/.ai for undo/redo purposes
Updates use buffered I/O
Can be overridden to use “unbuffered I/O” mechanism (-directio)
Recovery files: .ai, .bi, .tl (for recovery to work…)
Updates recorded using “unbuffered I/O” mechanism
Always written before user data (WAL rule)
Must be durable on disk when written
File system must observe write ordering

44. Other parameters affecting I/O operations
-groupdelay (when –Mf 0)
This is really group commit.
User waits # ms to write end note so several commits can occur in same bi buffer write
Since –Mf 0, each commit would immediately force the bi buffer to be written.
-bwdelay
Forces BIW to delay # seconds between each bi buffer pool scan

45. Recognizing You Have A Problem
Things are sluggish
Improve cache utilization
Avoid causes of I/O
Physical disk activity
File system cache – too large or too slow
Users blocked on I/O
Promon “Blocked Users” screen
Checkpoint duration > 0.50
Excessive I/O
Table scans, buffer pool hit ratio
Recovery subsystem (reads vs writes)
APW, BIW, User writes
