2. Getting a Logo for Your Windows Driver Framework Driver
Neslihan Bulut Software Design Engineer in Test Windows Driver Foundation

3. Agenda
Why get drivers logo’ed?
WDF Logo Requirements
WDF Logo Testing

4. Why Get Drivers Logo’ed?
Windows Logo Program identifies drivers that are designed and tested to deliver compatible experiences with Windows
Windows Logo provides Winqual signature
Trusted by every machine
Logo ensures:
Driver package integrity
Driver installs without any warnings or requests from an administrator
On 64-bit Windows unsigned drivers won’t load

5. WDF Logo Requirements Requirement # Title 1. DEVFUND-0036
User-Mode Driver Framework (UMDF) drivers must be secure, stable, reliable, and not have application compatibility issues 2.
DEVFUND-0037
Kernel-Mode Driver Framework (KMDF) drivers are designed to maximize reliability and stability and do not "leak" resources such as memory and KMDF objects 3
DEVFUND-0038
KMDF drivers are designed to handle device-driver interface (DDI) failures gracefully 4
DEVFUND-0039
Windows Driver Framework (WDF) drivers are packaged to contain the latest RTM fre versions of redistributables 5
DEVFUND-0040
WDF driver INF files are properly structured

6. WDF Logo Tests UMDF-specific & KMDF-specific Driver Settings
DDI Fault Injection and Driver Reliability Tests
WDF Redistributable Version Checks
INF File Validation with CheckInf

7. UMDF Settings Object Tracking will be enabled
Application Verifier will be on for the Host Process
Use !wudfext.Wudfdumpobjects in the debugger to see any leaked objects
Object Tracking will help catch WDF object leaks
UMDF will cause a driver stop because of leaked objects
If you discover object leaks, set Reference Count Tracking On
This setting provides add-release history of references

8. KMDF Settings Driver Verifier will be enabled
WDF Verifier will be enabled
Enhanced Verifier will be enabled
New feature for WDF 1.9
Performs IRQL and Critical Region checks for event callbacks
Handle Tracking will be enabled via TrackHandles registry value for all WDF objects
Set TrackHandles registry value to * in the Wdf subkey of driver’s Parameters key, WdfVerifier tool can be used for this.
With WDF 1.9, running the driver under Driver Verifier also enables WDF Verifier by default
Setting VerifierOn registry value to 0 in the Wdf subkey of the driver’s Parameters key turns this off

9. DDI Fault Injection
WDFTester from WDK Tools is used for fault injection
DDI return values will be fault-injected
When DDI return values are fault-injected, DDI out parameters can be fuzzed upon exit by the logo test
Drivers must inspect DDI return values properly

10. WDFTester Available in %wdk%\WDKVersionNumber\tools\wdf\wdftester\
Uses advanced kernel techniques similar to Driver Verifier for fault injecting the DDIs called from your driver
Fault injection is currently limited to DDIs that return NTSTATUS codes
Has a WMI Interface for use by applications and scripts
WdfTesterScript.wsf is provided in WDK as a reference
This script provides command line interfaces to call into Wdftester wmi methods
For more information, see wdftester.html in WDK
Provides call logging through traces
Use Traceview.exe (provided with the WDK) to view the call log

11. WDFTester (continued)
WdfTester order of execution
1. Register Driver
2. Execute Test
3. GetDdiCallInfo
4. ConfigureDdiFi
5. Execute Test
6. Unregister Driver

12. WDFTester (continued)
Use with your own tests
At the 2nd and 5th stages run a test against the driver
With any test, Wdftester can collect DDI’s called from the driver
and it can be used to fault inject those DDIs
1. Register Driver
2. Inject own test
3. GetDdiCallInfo
4. ConfigureDdiFi
5. Inject own test
6. Unregister Driver

13. WDFTester Scenario
Cscript wdftesterscript.wsf runtest <DriverName> <DeviceId>
Execute Test phase uses Device Disable Enable Test from WDK
Example with Osrusbfx2 from WDF samples
1. Register Driver
...registering driver osrusbfx2.sys
SUCCESS: Registered driver osrusbfx2.sys Successfully
2. Execute Test
...enabling Driver Verifier for osrusbfx2.sys
SUCCESS: Disabled driver
SUCCESS: Enabled driver

14. WDFTester Scenario (continued)
3.GetDdiCallInfo
...getting DDI call Info for osrusbfx2.sys
1) WdfDeviceAssignS0IdleSettings (1)
2) WdfDeviceAssignSxWakeSettings (1)
3) WdfDeviceInitSetPnpPowerEventCallbacks(1)
4) WdfDeviceInitSetIoType (1)
5) WdfDeviceCreate (1)
6) WdfDeviceCreateDeviceInterface (1)
7) WdfDeviceSetPnpCapabilities (1)
8) WdfDeviceConfigureRequestDispatching (2)
9) WdfDriverCreate (1)
10) WdfIoQueueCreate (4)
11) WdfIoTargetStart (1)
12) WdfObjectGetTypedContextWorker (4)
13) WdfUsbTargetDeviceCreate (1)
14) WdfUsbTargetDeviceRetrieveInformation (1) …

15. WDFTester Scenario (continued)
4.ConfigureDdiFi
...getting list of DDIs to be failed for osrusbfx2.sys
1) WdfDeviceAssignS0IdleSettings (1)
2) WdfDeviceAssignSxWakeSettings (1)
3) WdfDeviceCreate (1)
4) WdfDeviceCreateDeviceInterface (1)
5) WdfDeviceConfigureRequestDispatching (2)
6) WdfDriverCreate (1)
7) WdfIoQueueCreate (4) …
...starting async notification for WdfTester_DdiFiEvent
************************************************************
* TEST CASE : 1
* DDI to fail : WdfDeviceAssignS0IdleSettings
...enabling FI for driver: osrusbfx2.sys
SUCCESS: Enabled FI for WdfDeviceAssignS0IdleSettings in osrusbfx2.sys

16. WDFTester Scenario (continued)
5.Execute Test
...disabling driver
SUCCESS: Disabled driver
...enabling driver
*** SUCCESS: FI occurred for WdfDeviceAssignS0IdleSettings in osrusbfx2.sys
SUCCESS: Enabled driver
6. Unregister Driver
...unregistering driver osrusbfx2.sys
SUCCESS: Unregistered driver osrusbfx2.sys Successfully!

17. Logo Test Logo Test runs in 2 phases
1st phase determines the DDIs called
2nd phase configures fault injection on those DDIs
If the driver calls a DDI n times, fault injection can:
Occur at random calls, or
Be configured for any call of the DDI, inclusive 1 … n
3 tests from WDK are run against the driver:
Device Disable/Enable
Sleep Test
PnP Tests

18. Logo Test (continued) Fault injection exercises these DDIs:
WdfDriverCreate
WdfDeviceCreate
WdfWaitLockCreate
WdfIoQueueCreate
WdfDeviceCreateDeviceInterface
WdfDeviceAssignMofResourceName
WdfWmiInstanceCreate
WdfDeviceOpenRegistryKey
WdfRegistryQueryULong

19. Logo Test (continued) … and these DDIs: WdfDeviceAssignMofResourceName
WdfWmiInstanceCreate
WdfDeviceConfigureRequestDispatching
WdfUsbTargetDeviceCreate
WdfUsbTargetDeviceSelectConfig
WdfUsbTargetDeviceRetrieveInformation
WdfDeviceAssignS0IdleSettings
WdfDeviceAssignSxWakeSettings
WdfUsbTargetPipeConfigContinuousReader
WdfIoTargetStart
. . .

20. WDF Redistributable Version Checks
Drivers can be packaged for logo with only latest RTM fre versions of the WDF co-installers
Before Windows 7 RTM, WDF v1.9 drivers can be submitted for logo only if:
Driver is not packaged with pre- RTM v1.9 co-installers
Before WDF v1.9 RTM, v1.9 drivers can be submitted for logo provided that there is not any co-installer in the driver package
KMDF drivers Inf file must adhere to the following requirements
Doesn’t have WDF co-installer section
Doesn’t reference WDF co-installer (WdfCoinstaller<Version>.dll) anywhere
UMDF drivers Inf file must adhere to the following requirements
Has WDF Co-installer section. WDF Co-installer section;
Has AddReg directive, it associates only the config co-installer (WUDFCoinstaller.dll) with the device
Doesn’t have CopyFiles directive
Doesn’t reference update co-installer (WUDFUpdate_<version>.dll) anywhere
Logo is required for Windows 7 only

21. INF File Validation Validation checks for:
Properly structured WDF-specific sections of INF
Coinstaller section
WDF section
KMDF Install section in KMDF drivers
UMDF Install section in UMDF drivers
Refer to MSDN and Developing Drivers with the Windows Driver Foundation book for details about WDF sections
CatalogFile directive in the [Version] section of INF
Service Names, Hardware Ids , CLSIDs and Display names against the ones provided with WDK samples
Don’t copy/paste service names, Hardware Ids, CLSIDs and Display Names from WDF samples

22. Call to Action Test using WdfTester
Test WDF drivers with WDF Verifier and DriverVerifier
Test UMDF drivers with Application Verifier
Diagnose with WDF-specific registry settings enabled, by using WdfVerifier application
Use the latest RTM fre co-installers
Review and provide feedback on logo program requirements via
Certify your driver’s quality with Windows Logo

23. Resources Book: Developing Drivers with the Windows Driver Foundation
Windows Logo Program
WDF Testing and INF Documentation on MSDN
WdfTester: WDF Driver Testing Toolset
Specifying WDF Directives
Installing the Framework's Co-installer
