1. Operant Conditioning
The Learner is NOT passive. Learning based on consequence!!!

2. Operant Conditioning
Learning controlled by a connection to the consequence of one’s behavior
Consequences of behavior determine whether it will be repeated in future
Vs. Classical Conditioning
Behavior is…
CC: elicited, automatic, reflexive
OC: emitted, voluntary, complex behaviors
Reward is…
CC: provided independent of actions
OC: dependent on behavior
Where as classical conditioning involved reflexive behaviors, Operant conditioning involves voluntary behaviors connected to a response or consequence
These behaviors are complex, like folding laundry, washing dishes, hailing a cab

6. B.F. Skinner
The most influential behaviorist and proponent of Operant Conditioning.
Nurture guy through and through.
Used a Skinner Box (Operant Conditioning Chamber) to prove his concepts.

7. Skinner
Operant box—non-reflexive behaviors could be altered by learning
Skinner Box:
-Developed by B. F. Skinner, innovator of radical behaviorism
-Recorded sustained periods of conditioning
----Allowed researcher to continue conditioning process for extended periods of time and record behaviors without having to actually be present
-Bar delivers food when pressed, light signals food
A recording device prints out a cumulative record of the animal’s activity. Skinner box usually contains a bar that delivers food when pressed, and usually a light to signal when the food (reward) is coming.

9. Chaining Behaviors
Subjects are taught a number of responses successively in order to get a reward.
Click picture to see a rat chaining behaviors.
Click to see a cool example of chaining behaviors.

10. Thorndike’s Puzzle and The Law of Effect
Edward Thorndike
Locked cats in a cage
Behavior changes because of its consequences.
If a response is rewarded, that response is more likely to occur
If consequences are unpleasant, the Stimulus- Reward connection will weaken. (LOE)
Called the whole process instrumental learning.
Instrumental behaviors
As you saw in the video, animals learned to escape through trial and error, they did not have insight. When the cat did the right thing, he was rewarded by escaping to the food. Over time, the cat learns what behaviors produce rewards, and do these behaviors more quickly. Behaviors that do not produce rewards (i.e. cannot escape) are done less frequently.
The chart shows the learning curve for the cat. At first it took several minutes for the cat to escape the box, but with successive trials, it took less and less time.
Click picture to see a better explanation of the Law of Effect.

11. Thorndike Operant Conditioning:
-X-Axis: number of trials in the puzzle box
-Y-Axis: time it took cats to escape the box
-Time went from about 4 minutes to 30 seconds

12. Operant Conditioning Reinforcement Punishment
Increases probability of response
Positive: desirable stimulus is added
Negative: undesirable stimulus is removed
Punishment
Decreases probability of response
Positive: adding something bad
Negative: removing something good
Example: Child’s Behavior
-Behavior to Increase: cleaning room
-Positive Reinforcement: give kid dessert
-Negative Reinforcement: take away vegetables
-Behavior: hitting his sibling
-Positive Punishment: spank the kid
-Negative Punishment: take away his toys
[“Positive” means adding something]
[“Negative” means removing something]

13. Reinforcement
When an event increases the likelihood that a response will occur again
Positive
Adding something good
Designed to increase behavior
Negative
Removing something bad
Reinforcement:
-Math Terms: positive is plus sign (+), means adding something
-Math Terms: negative is minus sign (-), means taking something away
Example: Studying
-Positive Reinforcement: adding something good (good grade)
-Negative Reinforcement: removing something bad (nagging)
-Both outcomes are satisfying and will increase the behavior

14. Types of reinforcers Primary vs. secondary Immediate & delayed
Primary: inherently satisfying to most people
Secondary: gain value from conditioning
Immediate & delayed
Usually needs to be immediate, but humans can handle delayed reinforcers
Important for self-control
Primary reinforcer: e.g. food
Secondary reinforcer: e.g. money, poker chips – not inherently exciting for people, but becomes associated with ability to purchase stuff – so can be rewarded

15. What type of learning was this an example of?
Rat basketball
What type of learning was this an example of?
Can you explain what helped the rats learn to score a basket?
Consider the type of learning as you watch this clip.

16. Punishment/Consequence
When an event decreases the likelihood that a response will occur again
Two types: Positive & Negative
Positive ≠ Good. POSITIVE = ADD
Adding something bad
Designed to decrease behavior
Negative ≠ Bad. NEGATIVE = SUBTRACT
Removing something good
Punishment usually involves an aversive event that leads to a decreased probability that the response will occur again. Most people are familiar with punishment, yelling, spanking, are all examples of punishment. Book doesn’t differentiate between positive and negative punishment but I will.

17. Importance of reinforcement
Punishment signals undesirable behavior but doesn’t inform of desired behavior
Punished behavior is suppressed
Punishment teaches stimulus discrimination
Punishment (esp. physical) teaches fear & aggression
Ignore behavior that one wants to punish; look for what to reinforce
Suppressed but not forgotten – but suppression negatively reinforces the parent’s punishing behavior
Stimulus discrimination – learn not to swear in front of mom – not that swearing is wrong
Shows kids that aggression is a way to solve problems
Some advocate --

18. Punishment tends to be ineffective
It tells the organism what not to do, rather than what to do
Creates anxiety that can interfere with future learning
Encourages subversive behavior (sneakiness)
Provides a model for aggressive behavior
Only true for some races/cultures
Review punishment cons. 18

19. Neg. reinforcement ≠ punishment
Pos vs neg reinforcement – both encourage continuation of behavior – pos – add something good, neg – remove something bad
Pos Punishment – give something bad – discourages beh
Neg Reinforcement – Take away something bad – encourages beh

20. The Decision Tree How to solve operant conditioning problems
Should the behavior increase or decrease?
Is something being added or taken away?
Review decision tree
Increase.
(Reinforcement)
Decrease.
(Punishment)
Added. (Positive)
Removed.
(Negative)

21. Review Positive Negative Punishment decreases behavior Reinforcement
ADD something unfavorable
SUBTRACT something desirable
Reinforcement
increases
behavior
ADD something desirable
SUBTRACT something unfavorable
Review chart

22. Applications of Operant Conditioning

23. Behavior Modification
Started with Thorndike
Altering individual behavior (frequency) through positive and negative reinforcement and positive and negative punishment
Adaptive behaviors
Reduction of behavior through its extinction and punishment
A.K.A. – Applied Behavior Analysis or Positive Behavior Support (PBS)
A child is riding with an adult, and the child is thirsty. So, the child asks to stop and get a drink. The adult says no, the child asks again, and again, and again... Finally, the adult gives in, saying, "All right, just this once." Big mistake, right? Why? The adult has now put the child on a partial schedule, guaranteeing a repetition of the same behavior later on. Instead, the adult should have said, "All right, I'll get you a drink IF you don't ask for one for the next 10 (time may have to vary, depending on the child) minutes." Then, the adult is providing the child with positive reinforcement for being quiet.
Ending a Relationship?????

24. Behavior Modification
Reinforcement provides a system of rewards and punishments to change negative behavior into positive responses.
Provides rewards when someone acts in a positive manner. Rewards can range from a compliment to granting a special privilege to the patient whose behavior becomes desirable.
A negative consequence might be the result of unwanted behavior, with the removal of a favorite object or taking away a privilege.
Cognitive behavior modification techniques focus on thought patterns that affect behavior,
Involve teaching a patient to recognize thoughts that may be unrealistic or distort reality.
Keeping a journal, role-playing, and being asked to defend thoughts that defy reality.
Eating disorders, anxiety disorder, OCD, Panic attacks
Aversion behavior modification techniques center on the premise that all behavior is learned and can be unlearned. (aka CC)
Electrical shock treatment is one example of adverse stimuli used to treat deviant behavior.
(Mild) medication given to alcoholics that might make them ill if they drink while using the drug.
The token system provides immediate rewards while setting goals for future conduct.
Distribute a token or similar object each time a patient or student exhibits positive behavior.
Tokens can be amassed and later exchanged for a prize or privilege, or lost due to unwanted behavior.
This form of behavior modification is commonly used in mental institutions and prisons to help control individuals who show violent tendencies.

25. Premack principle
A less frequently performed behavior can be increased by reinforcing it with a more frequent behavior
Eat your vegetables before you can have dessert!
Review premack principle. For those interested, this is a raspberry, white chocolate and coconut cupcake. Tastespotting.com. No tastespotting until your studying is done.

26. Operant Conditioning in Daily Life
To train a dog to get your slippers, you would have to reinforce him in small steps. First, to find the slippers. Then to put them in his mouth. Then to bring them to you and so on…this is shaping behavior.
Do we wait for the subject to deliver the desired behavior?
Sometimes, we use a process called shaping.
Shaping is reinforcing small steps on the way to the desired behavior.
To get Barry to become a better student, you need to do more than give him a massage when he gets good grades. You have to give him massages when he studies for ten minutes, or for when he completes his homework. Small steps to get to the desired behavior.

27. Shaping
Reinforcing responses that come successively closer to the desired response
Successive approximations
Used a lot in animal training – gradually reinforce the behavior you’re looking for
By using shaping - a conditioning procedure of reinforcing successively closer approximations of the desired behavior, until the desired behavior happens.
We used behaviors that increasingly resemble the desired behavior and reinforced each of these – these are called successive approximations. When a baby learns to walk, first the baby learns to roll over, then stand on his hands and knees, then crawl, then hold on to furniture, and finally to walk. Each of these behaviors are successive approximations to walking, and are rewarded with cheers from his parents.

28. Shaping
Reinforcers gradually increase organism’s actions toward desired end behavior
Successive approximations : behaviors closer & closer to end learning goal get rewarded
Simply turning toward the lever will be reinforced
Only stepping toward the lever will be reinforced
Only moving to within a specified distance from the lever will be reinforced
Only touching the lever with a part of the body will be reinforced
Only touching the lever with a specified paw will be reinforced
Only depressing the lever partially with the specified paw will be reinforced
Only depressing the lever completely with the specified paw will be reinforced

29. Schedules of reinforcement
How often to you give the reinforcer?
Every time or just sometimes you see the behavior.
Ratio schedules lead to higher response rate – makes sense, people/animals have control (to some extent) over when the rewards happen
-Variable schedules more consistent (straighter lines)
-Fixed-Interval schedules have scalloped pattern (increase just before interval)
-Variable-Ratio schedules have the highest response rates of all the schedules

30. Schedules of Reinforcement
Continuous reinforcement schedule:
Reinforcing a response every time
Learning occurs rapidly, extinction occurs rapidly
Partial reinforcement schedule:
Reinforcing a response only some of the time
Slower acquisition, but resistant to extinction
Fixed vs. Variable
Ratio vs. Interval
Fixed ratio: after set # of responses
Variable ratio: after unpredictable # of responses
Fixed interval: after set amount of time has passed
Variable interval: after unpredictable amount of time has passed
Review schedules, create examples

31. Continuous v. Partial Reinforcement
Reinforce the behavior EVERYTIME the behavior is exhibited.
Usually done when the subject is first learning to make the association.
Acquisition comes really fast.
But so does extinction.
Reinforce the behavior only SOME of the times it is exhibited.
Acquisition comes more slowly.
But is more resistant to extinction.
FOUR types of Partial Reinforcement schedules.

32. Schedules of reinforcement
Continuous vs. partial
Shows that partial reinforcement is harder to extinguish than continuous – Why? -- if you have only been reinforced sometimes, you can’t tell as quickly that you aren’t being rewarded
Slowest extinction is for variable ratio

33. Ratio schedules Fixed-ratio (FR) schedules:
Reinforcement after a fixed (predictable) number of responses
Ex: paid $1 for every 20 apples you pick
Variable-ratio (VR) schedules:
Reinforcement after a varying (unpredictable) number of responses
Induces very high rate of responding
Ex: scratch & win lottery tickets
Ratio schedules depend on the number of responses given.
Let’s consider the class as an organism. In a fixed-ratio schedule, that number is set. So every 5th student that answers a question gets a piece of candy.
The faster you respond, the more rewards you get, so it produces a high rate of responding.
In a variable-ratio schedule, the number of responses required before a reinforcement is given changes each time. So, maybe the first time, the 5th student who answers a question gets a piece of candy, then the 3rd student after that, then the 7th student, etc. This unpredictability produces a very high rate of responding and makes it difficult to extinguish.

34. Interval Schedules Fixed-interval (FI) schedule:
Reinforcement after a fixed (predictable) amount of time
Variable-interval (VI) schedule:
Reinforcement after varying (unpredictable) amounts of time
Interval schedules depend on the amount of time that elapses between rewards.
In a fixed-interval schedule, that amount of time is set. So after every 30 seconds a student is given a piece of candy for answering a question. Response occurs more frequently as anticipated time of reward draws near. If I want consistent performance not so great.
In a variable-interval schedule, the amount of time required before a reinforcement is given changes each time. So, maybe the first time, the interval is 30 seconds, the next time 2 minutes, the next time 1 minutes, etc. Produces slow and steady responding. Example: random pop quiz  will study more than if knew exactly when it would be

35. Reinforcement Schedules
Ratio
Interval
after set number of responses
after set amount of time
after random number of responses
after random amount of time
Fixed
Variable means that it is impossible to predict, random If you have something that is VI or VR 30, that means that the average of all the responses is every 30 responses/time interval whatever. So one time you might get it right away, another it might take you 59 tries.
Variable

36. Ratio Interval Fixed Variable
-Factories: reward (finished) after completing specific number of product, and same number required each time
-Slot Machine: reward (chips) after specific number of pulls on average, but number of pull needed between each win changes
-Office Work: reward (leaving) after specific time interval, and time interval stays the same each day
-Surfing: reward (big wave) after an unknown amount of time, and time between each wave changes

37. Name that Schedule! A B D C Variable Ratio C. Variable Interval
Fixed Ratio D. Fixed Interval A
Winning at the slot machines
Getting a free flight after accumulating 10,000 flight miles
Receiving an allowance every Saturday regardless of chores, as long as you’ve done one chore
Random drug testing at your job B D
Have students write down what they think the answers are for a minute, then review as a class. C
