1. ROTACOD Absolute Encoder
ROTACOD Absolute encoders
ROTACOD Absolute Encoder

2. ROTACOD Absolute encoders

3. ROTACOD Absolute encoders
( Fieldbus Encoders )

4. ROTACOD Absolute encoders
Absolute encoder generates a digital signal related to the position of a rotary axis
The value of the signal is transmitted to a control logic that manages the received data
In presence of a power supply fail the physical position is not lost
The zero setting of the mechanical part is required only in the initial installation
No batteries or memories required to keep the position absolute value

5. Absolute Measuring Systems
ROTACOD Absolute encoders
Absolute Measuring Systems

6. ROTACOD Absolute encoders
Working Principle
The source of signals is a disc with a grated design forming tracks
Tracks have zones where light can pass through and obscured tracks through which light cannot pass
The light emitted by a lighting source go through the disc and is collected by a photo-diode on disc’s other side
While disc is rotating the photo-diode detects light variations, switching the output signal on and off

7. ROTACOD Absolute encoders
Working Principle
Using multiple tracks, the combination of On and Off of the single tracks generates an absolute value of position
As power is turned On, this value position is read from tracks and immediately sent to the output circuit
If disc has 12 tracks then positions (4096 info/revolution) are available.
No repetitions of combinations of 1 and 0 are present on disc (unique code).
The main disc uses a Gray code as pattern
Track 1
Track 12

8. ROTACOD Absolute encoders
Output signals
Binary
Decimal 23 22 21 20 1 1 = 5 2 3 1 15 14 13 12 4 6 7 5 8 9 10 11 D0 D1 D2 D3 1 1 = 9 1 1 1 = 14
each line data line is a bit
1 = bit high / 0 = bit low
the combination of 1 and 0 gives a coded value (position) to the control unit

9. Binary Coded Decimal (BCD) Code 4 Bits (8 4 2 1)/ ตัวเลข [0 – 9]
ROTACOD Absolute encoders
Binary Coded Decimal (BCD) Code 4 Bits ( )/ ตัวเลข [0 – 9]
เลขฐานสิบ
360
BCD
==>

10. ROTACOD Absolute encoders
Gray code รหัสที่อยู่ในตำแหน่งติดกันจะมีบิทที่แตกต่างกันเพียง 1 บิทเท่านั้น เช่น 0010 ลำดับต่อไปคือ รหัสเกรย์จะนำไปใช้ประโยชน์มากในระบบการตรวจจับสัญญาณด้วยแสงหรือระบบการทำรหัสด้วยแกนหมุนทางกล (machanics) เพื่อบอกตำแหน่งของเพลาหมุน

11. Gray and Binary Code ROTACOD Absolute encoders Binary Code
Position 7 > 8
= 7
= 8
= = X

12. ROTACOD Absolute encoders
การแปลงเลข Binary ให้เป็น Gray code
วิธีทำ
Binary
Gray code

13. + + + + 1 0 0 1 0 Binary ROTACOD Absolute encoders
การแปลง Gray code ให้เป็น เลข Binary
วิธีทำ
Gray code
Binary

14. ROTACOD Absolute encoders
The value sent to the control unit can be as follows:
BINARY (more bits can change at the same time)
GRAY (successive values change a bit per time maximum)
BCD (binary code for each single number)
The absolute value can be sent to the control in several interfaces:
Parallel
PROS: faster CONS: many wires to connect
Serial
PROS: few wires to connect CONS: speed reduced
Field-bus
PROS: several devices on the same line, bi-directional data transmission CONS: more sophisticated electronics
Value is read by the control and used for positioning and control of motors installed on the machinery

15. เทคนิคและวิธีการเลือก Absolute Encoder
ROTACOD Absolute encoders
เทคนิคและวิธีการเลือก Absolute Encoder
Counts Per Revolution (steps) > Single turn

16. ROTACOD Absolute encoders

17. ROTACOD Absolute encoders
2) Revolutions > Multi Turn

18. ROTACOD Absolute encoders
3) Output Code
BCD
Binary
Gray

19. ROTACOD Absolute encoders
4) Supply and Output Circuit
Supply : Standard VDC
Output Circuit :
NPN
PNP
Push-Pull > NPN/PNP
SSI serial output RS422
Fieldbus

20. ROTACOD Absolute encoders
5) Shaft , Bore Diameter
Flexible Coupling

21. ROTACOD Absolute encoders
5) Dimension
Body Size ( Europe= mm, U.S. = Inch )

22. ROTACOD Absolute encoders
6) Connection
Connector (7-pin,10-pin, 12-pin ,19-pin, pin,32-pin,41-pin.)
Cable (1,3,5,10 meter etc.)
12-pin
7-pin
10-pin
25-pin
19-pin
32-pin

23. ROTACOD Absolute encoders

24. ROTACOD Absolute encoders

25. ROTACOD Absolute encoders

26. ROTACOD Absolute encoders
ASC58 AS58 AS58S
Standard singleturn encoder
based on Ø 58 mm standard
several customizations possible
up to 16 bits (65536 positions)
parallel or SSI interface
Gray or binary code
parity bit, electronic zero setting
complementary (sense of rotation) is standard for all models

27. ROTACOD Absolute encoders
ASC58 AS58 AS58S
Standard singleturn encoder
materials handling, storage systems
packaging and food industry
metallurgy plants, marine industry
folding machines, presses
compatible to almost all competitors
Replacement of old Lika encoders by adapting flanges

28. ROTACOD Absolute encoders
AMC58 AM58 AM58S
Standard multiturn encoder
up to bits
parallel or SSI interface
Gray or binary code
parity bit, electronic zero setting

29. ROTACOD Absolute encoders
AMC58 AM58 AM58S
Standard multiturn encoder
long-travel measuring
handling machinery, food, etc.
telescopic cranes, telescopes
high lift storage systems, conveyors
metallurgy plants
preferential encoder

30. ROTACOD Absolute encoders
AM58P - programmable multiturn encoder
max inf./rev. x 4096 rev.
programmable with Lika SW or terminal SW
programmable code (gray, binary, BCD), parity bit (even, odd), resolution, complementary, zero setting, offset, latch, tri-state
• teach-in function (resolution self-learning)

31. ROTACOD Absolute encoders
AM58P - programmable multiturn encoder
fits all applications
replacement for any absolute encoder
preferential encoder for distributors
stock version AM5812/4096PS-6

32. ROTACOD Absolute encoders
Absolute encoders with Fieldbus interface
Fieldbus interfaces as per the manufacturer specifications
up to 16 bits (singleturn) and (multiturn)
all parameters programmable, device address set by dip-switches
CC-xx (connection caps) must be ordered separately

33. ROTACOD Absolute encoders
Absolute encoders with Fieldbus interface
factory automation
all automated machines
SW and manual on Lika’s website
preferential types available on stock (Profibus)

34. absolute encoder with incremental output
ROTACOD Absolute encoders
AS58 ISI - AM58 ISI
absolute encoder with incremental output
incremental counting AB0, /AB0
at power ON, it sends out an absolute position information
resolutions: –2048 (S)
1024 PPRx4096 rev. (M)
2048 PPRx4096 rev. (M)

35. absolute encoder with incremental output
ROTACOD Absolute encoders
AS58 ISI - AM58 ISI
absolute encoder with incremental output
an incremental axis becomes absolute by a simple hardware change
packaging, retrofit of old machines
PLCs with incremental encoder inputs
fits to any incremental counter
only competitor is T+R Electronic

36. ASR58 with integrated cam programmer
ROTACOD Absolute encoders
ASR58 with integrated cam programmer
integrated cam programmer
0,1° resolution (3600 CPR)
120 cams per program
16 programs can be stored
pulse output for speed measurement
fault signal indicating output status
analogue output

37. ASR58 with integrated cam programmer
ROTACOD Absolute encoders
ASR58 with integrated cam programmer
packaging and food machines
tobacco machines
rotary index tables
tool changer

38. ROTACOD Absolute encoders
AS58 A - AM58 A
encoder with analogue output
0-5V, 0-10V, 4-20 mA outputs
resolutions: 4096
4096 x 16
512 x 64
256 x 256
Shaft: Ø 6, 8, 9.52, 10, 12 mm

39. ROTACOD Absolute encoders
AS58 A - AM58 A
encoder with analogue output
replacement of potentiometers and gear potentiometers
steering gears control

40. ROTACOD Absolute encoders
AST6 encoder with square flange
based on Ø 65 mm standard
up to 16 bits (65536 positions)
parallel or SSI
Gray, binary, BCD
parity bit, electronic zero setting
IP66 on the shaft side

41. ROTACOD Absolute encoders
AST6 encoder with square flange
for heavy-duty applications
metallurgy plants
presses
tobacco industry

42. ROTACOD Absolute encoders
AMC9 - AM9 thin housing encoder
Body : 90 mm
reduced length (40 mm)
4096 or 8192 x 4096 total infos
SSI interface
international standard connections
AMC9 has shaft 15 mm
AM9 has shaft 10 mm

43. ROTACOD Absolute encoders
AMC9 - AM9 thin housing encoder
factory automation
short housing installations
high resolution with through hollow shaft

44. ROTACOD Absolute encoders
AS5 – AM5 small housing encoder
body  47 mm X 78 or 114 mm
Up to 2048 x 16, 64, 256 info
Parallel interface
Cable output with possibility of connector at its end

45. ROTACOD Absolute encoders
AS5 – AM5 small housing encoder
industrial applications
special applications
antennas, telescopes
when smaller body is required

46. ROTACOD Absolute encoders
XAC77 explosive-proof encoder
conformal to ATEX directive
16 bits x 14 bits max resolution
NPN, Push-Pull, SSI interface
body  77 mm
Hollow shaft  10, 14, 15 mm
IP66
NEW !

47. ROTACOD Absolute encoders
XAC77 explosive-proof encoder
For quick or after power loss position info recovering in hazardous areas
direct mounting
high temperature range

48. ROTAMAG Magnetic encoders
MA58 MA58S MAC58
absolute magnetic encoder
Based on the AS58, AS58S, ASC58 housing
12 bits x 16 bits max.
SSI or BISS output interface
Operating temperature °C÷+85°C max
IP67
For high shock and moisture conditions

49. ROTAPULS – COD ACCESSORIES
SF draw wire actuator
linear measurements with 58 encoders
measuring lengths 5000 and 6800 mm
IP54
approx. 0,1 mm accuracy
bridge cranes, hoists
automobile, trains, aircraft testing
ideal for retrofit, easy mounting
5000 mm version on stock

50. LINECODE Absolute Magnetic Measurement System
LINECOD Magnetic Measuring Systems
LINECODE Absolute Magnetic Measurement System

51. LINECOD Magnetic Measuring Systems
LINECOD System Combinations

52. LINECOD Magnetic Measuring Systems
MTA5 absolute magnetic tape
in plastic and steel
absolute magnetic coding
accuracy class ±50 μm/m
temperature coefficient: 11±1 μm/k
lenght available: up to 5.1 m

53. LINECOD Magnetic Measuring Systems

54. LINECOD Magnetic Measuring Systems
SMA5 absolute magnetic sensor
up to 5 m measuring length
integrated SSI interface
0,005 mm resolution
zero setting function
complementary function
IP67
to be used with MTA5 magnetic tape

55. LINECOD Magnetic Measuring Systems
SMA5 absolute magnetic sensor
insensitive to power outages
real absolute measurement
linear motors
tool machines
measuring equipment
compact design

56. POSICONTROL – Displays
MC150 display
96 x 72 x 71 mm
6 digit LED display
power: 24Vac/dc, 115Vac, 230Vac
counting frequency 330 kHz
2 digital outputs, 2 relay (O), RS232 (O)
IP43
for encoders and SMEx, SMK sensors

57. POSICONTROL  Displays
LD200: Universal programmable display
96 x 48 x 69 mm
8 digits, LED 10 mm
power supply: 18Vac, 24Vdc 20%
Max. 500 kHz counting frequency
inputs: AB0, SSI, 1Vpp, SMx sensor
RS232 interface
3 x 24V digital 50mA
IP54 protection (when mounted)
universal usage, ideal as stock unit
easy set-up (intelligent menue)
easy connection with block terminals and Dsub conn.
very compact, with mounting clips

58. POSICONTROL  Displays
M_Sens
Lika magnetic sensors
SM2, SM25, SM5
E_Incr
PP,LD (A, B, 0)
possible device types
LD200
E_1Vpp
SIN/COS 1Vpp
M_Incr
PP, LD (A, B, O)
M_1Vpp
SIN/COS 1Vpp
E_SSI
absolute SSI
M_SSI
absolute SSI
