Pseudomonas - Microscopic appearance - Cultural characteristics

Similar presentations

Presentation on theme: "Pseudomonas - Microscopic appearance - Cultural characteristics"— Presentation transcript:

1 Pseudomonas - Microscopic appearance - Cultural characteristics
- Biochemical Tests of Pseudomonas species. - Identification of Pseudomonas using API 20E


3 Pseudomonas fluorescens
Pseudomonas putida Pseudomonas fluorescens

4 Pseudomonas aeruginosa

5 Pseudomonas aeruginosa causing :-
- Skin infections ( wound swab )* * Specimens depending on the site of infection.

6 - Urinary Tract infection ( urine )*
- Respiratory infections ( sputum & effusions )* - Otitis Externa ( ear swab )* * Specimens depending on the site of infection.

7 Pseudomonas aeruginosa is a Gram negative, non-sporing motile rod

8 P. aeruginosa produces large, flat,
spreading colonies which are often haemolytic and usually pigment-producing. The pigments diffuse into the medium giving it a dark greenish-blue colour

9 P. aeruginosa produces pale coloured colonies on MacConkey agar

10 On Nutrient agar P. aeruginosa can be recognized by the pigments, it produces a blue-green pigment (pyocyanin).

11 O–F Test The oxidative-fermentative test determines if certain gram-negative rods metabolize glucose by fermentation or aerobic respiration (oxidation). During the anaerobic process of glucose fermentation, the high concentration of acid produced will turn the bromthymol blue indicator in OF media from green to yellow in the presence or absence of oxygen

12 Acid production in both the open and oil-covered tubes indicates a fermentative result ( e.g. Escherichia coli )

13 Acid production in the open tube and not the oil-covered tube indicates an oxidative result.
P. aeruginosa incubated for 24 hours. P. aeruginosa incubated for 48 hours. P. aeruginosa incubated for 5 days.

14 No color change in the oil-covered tube and color change to alkaline in the open tube indicates a negative result. A. faecalis cannot use glucose fermentatively or oxidatively. The blue at the top of the open tube is due to amine production resulting from the metabolism of protein in the media.


16 Vibrio - Microscopic appearance - Cultural characteristics
Identification of Vibrio cholerae biochemically and serologically

17 Vibrio parahaemolyticus
Vibrio cholerae Vibrio alginolyticus Vibrio vulnificus Vibrio parahaemolyticus

18 Vibrio cholerae

19 V. cholerae causes cholera
( rice watery diarrhoea )* V. parahaemolyticus causes severe acute gastroenteritis ( faeces )* V. alginolyticus causes wound infection ( wound swab )* V. vulnificus causes wound infection and septicaemia ( wound swab )*

20 V. cholerae is a Gram negative motile usually curved rod

21 V. Cholerae has a single flagellum at one end

22 Alkaline Peptone Water
On Thiosulphate-citrate bile salt sucrose (TCBS) agar V. cholerae 01 and 0139 produce 2–3 mm in diameter sucrose-fermenting yellow colonies after overnight incubation at 35–37 ºC.

23 On TCBSV. mimicus, V. vulnificus and V
On TCBSV. mimicus, V. vulnificus and V. parahaemolyticus produce green-blue non-sucrose fermenting colonies

24 V. cholerae 01 and 0139 grow on blood agar, (subcultured from alkaline peptone water), producing betahaemolytic colonies.

25 On MacConkey agar V. cholerae produces small non-lactose fermenting colonies.

26 Fermentation of L-arabinose.
This test is of value in differentiating V. cholerae from V. fluvialis (both produce yellow colonies on TCBS agar). V. fluvialis ferments L-arabinose

27 Serotyping V. cholerae 01 and 0139:-
Separate antisera are required to identify V. cholerae 01 (Inaba and Ogawa) and V. cholerae 0139 (Bengal). Isolates from TCBS cultures require subculturing to nutrient agar before carrying out serotyping.

28 In most countries V. cholerae 01 cholera is caused by the El
Tor biotype. In India and Bangladesh where the Classical biotype also occurs, the Voges-Proskauer (VP) test can be used to differentiate the two biotypes. The El Tor biotype is VP positive and the Classical biotype is VP negative. When required other tests (haemagglutination and sensitivity to 50 iu polymyxin B) El Tor gives a positive agglutination test and is resistant to 50 iu polymyxin B. while Classical biotypes give a negative agglutination test and are sensitive to 50 iu polymyxin B.
