Autonomous Computing Fiefdoms and Emissaries

Autonomous Computing Fiefdoms and Emissaries
Pat Helland Software Architect SQL Server Microsoft Corporation

Outline Introduction Autonomous Computing: The Basics
Working With Autonomous Fiefdoms Working Across Fiefdoms Conclusion

Legal Stuff The following page has definitions excerpted
from Bookshelf 99 ex·cerpt ex·cerpt (ĕkʹsûrpt´) noun A passage or segment taken from a longer work, such as a literary or musical composition, a document, or a film. Excerpted from The American Heritage Dictionary of the English Language, Third Edition Copyright © 1992 by Houghton Mifflin Company. Electronic version licensed from Lernout & Hauspie Speech Products N.V., further reproduction and distribution restricted in accordance with the Copyright Law of the United States. All rights reserved.

Terminology Autonomous Fiefdom Emissary Snapshot Stable Uncertainty
Not controlled by others or by outside forces; independent Autonomous Fiefdom 1. The estate or domain of a feudal lord Something over which one dominant person or group exercises control Emissary An agent sent on a mission to represent or advance the interests of another. Snapshot A photograph take with a small hand-held camera. Stable Resistant to change of position or condition; steadfast. Immutable; permanent; enduring. A place where horses live. Uncertainty Unsure about someone or something. A lack of assurance or conviction. Idem Something that has been mentioned previously; the same. Potent Possessing inner or physical strength; powerful.

What’re We Gonna Talk About? Computing Through the Decades Autonomous Computing: The Basics Working With Autonomous Fiefdoms Working Across Fiefdoms Conclusion

What Is Autonomous Computing?
Autonomous Computing starts with independent computer systems These are independently controlled and managed They don’t trust outsiders We are going to examine the consequences of this independence How do such machines interact? How is data handled? How can we accomplish work in such an environment?

What’s This .NET Stuff? .NET is about building loosely-coupled solutions that span autonomous systems Part of the solution may run locally Part is available as services running elsewhere Those services may, in turn, use other services How do you build a loosely-coupled app? What do the pieces look like? How do they communicate? How do you build the pieces? How do you do cooperative work across independent systems?

What’re We Gonna Talk About? Computing Through the Decades Autonomous Computing: The Basics Working With Autonomous Fiefdoms Working Across Fiefdoms Conclusion

The 50’s: Scheduling Time
In the 1950’s, you would schedule time on the computer… I have the machine from 3PM until 6PM Wipe it clean, load your data, do your work, save your results, wipe it clean… Data transfer between machines was rare

The 60’s: Batch Processing
In the 1960’s batch processing arrived You’d submit your work on a deck of cards Come back later & pick up your listing… Lots of concurrent batch jobs Data was exchanged using card decks and magnetic-tapes

The 70’s: Timesharing Arrives
As we move into the 1970’s Timesharing & OLTP (Online Transaction Processing) appear People sit online at terminals Files were exchanged using magnetic-tapes & occasionally over Wide Area Networks

The 80’s: PCs & Client-Server
In the 1980’s Local Area Networks arrive Systems inside a workgroup are connected Constrained access to the mainframe from the LAN Systems on the LAN are in the same company

The 90’s: Computing & the Web
People & businesses communicate across the Web For the first time, requests arrive from untrusted sources Web

Fiefdoms and Autonomous Computing Emissaries: Helping Interact With Fiefdoms Rethinking Data Rethinking the “N-Tier” Model Fiefdoms & Emissaries Working With Autonomous Fiefdoms Working Across Fiefdoms Conclusion

The Web is Autonomous Computing
The Web is lots of autonomous fiefdoms Define the term Fiefdom as: Computing function and applications which behaves as an independent entity Has private data An autonomous unit --- managed independently Usually one (or a few) machines Fiefdoms don’t trust outsiders...

Requesting Service from a Fiefdom
Fiefdoms don’t trust stuff from the outside Incoming requests will be inspected Fields will be validated Identity will be authenticated Data from outside requests is never trusted It must fit within prescribed values or it is rejected Please, kindly consider my humble request….

Private Data and Fiefdoms
A fiefdom keeps its data private No one outside can read or write the data Only well defined requests are serviced from the outside These requests do not describe the contents of the fiefdom’s data Provide services, not data access Request

Transactions and Fiefdoms
Fiefdoms are (almost always) built using transactions internally It may use 2-phase commit across the nodes of a cluster A fiefdom (usually) will not agree to share a transaction with an outsider Transaction

Emissaries Fiefdoms may come with emissaries.
It knows how to fill out a request for the fiefdom It understands the rules of the fiefdom and how to (probably) get the request accepted Think of a mortgage broker… not the final approving party… Emissaries have two purposes: Displaying information to users Preparing requests to send to fiefdoms Emissaries are not trusted by the fiefdom The contents of the request is still inspected for correctness

Emissaries and Snapshot Data
Reference Data An emissary will frequently come with reference data. This information will support the emissary in doing its job Imagine an emissary that helps you order from Sears It will arrive with the Fall catalog under its arm

Emissaries & Single User Data
Reference Data Per-User State Emissaries gather information needed to prepare requests For example, a shopping basket accumulates the items to purchase

Mission Critical Data The “current” data is always kept inside the fiefdom It is the mission critical data that describes the business of the fiefdom This information is typically updated within a transaction Locks are held only for the duration of the transaction Transactions are not shared outside the fiefdom

Snapshot Data Once data is unlocked, it must be assumed to be a snapshot Snapshot data was accurate and up-to-date at some time in the past… it is not necessarily still current We must assume that snapshot data is no longer current… 1 sec old 1 min old 1 hour old 1 day old 1 week old 1 month old Current

Stable Data Stable data is meaningful across space and time
Anything to do with “current” is not stable Timestamping can make data stable Other techniques can make data stable Given an IID (Interface-ID), type-lib info is stable Stable data is never invalid It may be cached without worries for cache consistency It may be uninteresting, but it is never wrong…

All Web Data Is a Snapshot
Fiefdoms don’t hold locks when working with outsiders… This means they have unlocked their data… it might have changed… Snapshot Current

Labeling The Tiers Rendering
May accept HTML or some other rendering format Produces bits on the screen. Rendering May accept HTML or some other rendering format Produces bits on the screen. Present- ation Maps the interactions with the emissary into pages to be displayed to the user. Typically produces HTML. Present- ation Maps the interactions with the emissary into pages to be displayed to the user. Typically produces HTML. Emissary Logic Data Knows how to fill out requests to be submitted to the fiefdom. Possibly has snapshot data for submitting requests. Emissary Logic Data Knows how to fill out requests to be submitted to the fiefdom. Possibly has snapshot data for submitting requests. Fiefdom Business logic implementing the fiefdom. Doesn’t trust anyone. Takes requests into the fiefdom. Keeps mission critical data. Fiefdom Data Logic Business logic implementing the fiefdom. Doesn’t trust anyone. Takes requests into the fiefdom. Keeps mission critical data.

Slicing at the Front This is classic HTML 3.2 browser support
Rendering Emissary Logic & Data Present- ation Fiefdom This is classic HTML 3.2 browser support Do most of the work at the server Send HTML to the client Maximum “reach”

Pushing Down the Emissary
Present- ation Rendering Emissary Logic & Data Fiefdom Pushing Down the Emissary Can run the emissary down on the client Emissaries use snapshot data The data is never incorrect… It’s possible you’re missing some data you want but you will always know it We can download the code and snapshot data Run the emissary on the client Send the fiefdom requests over the wire

The Web Farm Can run the emissary separate from the fiefdom
Present- ation Rendering Emissary Logic & Data Fiefdom The Web Farm Can run the emissary separate from the fiefdom Talks over HTML 3.2 to the browser Talks to a dedicated machine with fiefdom logic and data Scalable solution Offloads the precious fiefdom Emissary can be replicated on webfarm for scale

Scaling the Web Farm A-J K-R S - Z Protected Intra-Net
Per-User Ref Data K-R Shared Writable Data Per-User Ref Data Ref Data S - Z Per-User Protected Intra-Net Ref Data De-Militarized-Zone

Management of Reference Data
Part of the Emissary code must keep the Reference Data advancing It’s always a bit stale… Need to keep dribbling the changes forward k Shared Writable Data De-Militarized-Zone Protected Intra-Net Ref Data A-J K-R S-Z

Contrast With Classic Tiers
All the tiers in one fiefdom Present- ation Rendering Emissary Logic & Data Fiefdom Present- ation Business Logic Data Rendering & Presentation Combined No concept of Emissaries Logic & Data are in the Fiefdom

Fiefdoms & Emissaries Fiefdoms use multi-user writable data
The business logic protects its integrity Emissaries use: Read-only reference data, and Single-user writable data (e.g. a shopping basket) Read-Only Reference Per-User Writable Shared

Working With Autonomous Fiefdoms Requesting Services Dialogs: Reliable Service Requests The Flow of Data in an Autonomous World Monologs: Reliable Publication of Snapshots Offline Work Working Across Fiefdoms Conclusion

Computing With Messages
Incoming work arrives in a message The response leaves in a message Fiefdom Logic Data

Classic OLTP & 3-Tier Sometimes online workers are part of the fiefdom
They are trusted and work using online transactions This is classic OLTP and 3-tier Less & less common with Intranet Fiefdom Logic Data

Making Requests Idempotent
Requests get lost… Gotta retry them to handle lost requests Requests arrive more than once… Those pesky retries may actually arrive Idempotent means it’s OK to arrive multiple times As long as the request is processed at least once, the correct behavior occurs In today’s internet, you must design your requests to be idempotent

Challenges With Idempotent Requests
Any request may arrive multiple times Sometimes after quite a while You might be a few messages farther along when an old one arrives The combinatoric complexity can be staggering This leads people to build very simple applications since only then can they cope with the failure complexity…

Dialogs Dialog Dialogs provide two-way messaging Dialogs offer:
Between two services (either fiefdom or emissary) Dialogs offer: Guaranteed delivery Full-duplex or half-duplex Long-lived Exactly-once and in-order delivery Crisp failure semantics: If can’t delivery any message, dialog will fail If dialog fails, both sides see the dialog failure Service Dialog

Multiple Related Messages
Dialogs may be used to send different messages that are related to each other When the second message arrives it is automatically correlated to the first When the answer returns, it is correlated to the request Ordering is preserved across different messages in the same dialog Service Dialog A B C

Long-Running Related Work
As services communicate, their work is spread across space and time The processing of the response may take place days after the request This make implementation of the service challenging “Customer” Service Dialog “P-O” “CreditChk” Transaction T1 “Buy Stuff” Transaction T2 “Check If Flake” Transaction T3 “He’s OK” Transaction T4 “Confirm Sale” Transaction T5

Content Syndication Joe’s
To fill out requests, an emissary needs snapshot reference data The fiefdom must publish this reference data Content Syndication is the buzzword for the publication of reference data Joe’s Price list for Joe’s Fiefdom Valid Mar 3, 02 thru Mar 6, 02

Using Syndicated Content In Requests for Service
Emissaries use syndicated content to prepare requests for service The processing of the request must be designed to tolerate some staleness Joe’s Price list for Joe’s Fiefdom Valid Mar 3, 02 thru Mar 6, 02

The Flow of Data Data flows in a big cycle:
The fiefdom published reference data This reference data is used in requests for service The processing of requests may impact the new reference data that is published later Requests Snapshots

Content Aggregation Another buzzword is Content Aggregation
You process syndicated content from multiple sources to glean interesting data For example, which supplier has the best price, quality, and availability Some emissaries perform sophisticated processing to aggregate content Aggregated Content

Monologs Monolog A monolog is 1-to-many messaging A subscriber will:
The publisher sends ordered messages There may be many subscribing services A subscriber will: Receive messages exactly-once, in-order Receive every message or is told of failure Subscribers Publisher Monolog

Monolog Failure Semantics
Monologs offer GUARANTEED delivery Every message will be delivered exactly once Every message will be delivered in the order it was sent If any message cannot be delivered exactly-once and in-order, the subscription will fail This is a notification to the subscribing program It is delivered under a transaction After failure, a brand-new subscription may be obtained This is especially useful for CHECKPOINTED monologs as they provide a well-defined semantic for restart See next slide!

Monologs With Checkpoints
In CHECKPOINTED MONOLOGs, the publisher periodically issues a checkpoint This is a defined restart point for new subscribers BEGIN-CKPT, bunch-of-messages, END-CKPT New subscribers start at a recent checkpoint They see the BEGIN, messages, END Then they see subsequent messages Ongoing subscribers skip checkpoints They are designed as places to start new subscriptions

What’s a Checkpoint? Monolog
A checkpoint is a well-defined starting place for new subscriptions Publishers explicitly define checkpoints Checkpoints include messages just for new subscribers Existing subscribers skip over checkpoints Only monologs annotated as CHECKPOINTED may have checkpoints Monolog … Checkpoint#1 … Checkpoint#2 … … … Checkpoint#3 … …

Offline and Online: Points on a Spectrum
All online emissary work is really a flavor of offline The data is always a snapshot Offline just requires caching more snapshot reference data The fiefdom must cope with stale requests All requests will be somewhat stale… Sub-second access to the fiefdom Disconnected for days Staleness of the snapshot data used to prepare the request to the fiefdom

Emissaries & Offline Processing
An emissary works with 2 kinds of data: Snapshots of data published by a fiefdom, and Per-client information You can package up an emissary, along with its snapshot data and download it to a smart client On the client, the emissary prepares requests Requests are queued up until reconnection

Bringing Enough Content Along
“Online” applications don’t need to bring along snapshot reference data They go fetch it on demand Offline applications need to bring reference data with them Organizing what to bring and how to group it together is a new challenge

Working With Autonomous Fiefdoms Working Across Fiefdoms Tentative Work Canceling and Confirming Tentative Work Bounding Uncertainty Conclusion

Transactions Don’t Work Across Fiefdoms
Fiefdoms will not agree to share transactions with outsiders No self-respecting fiefdom would hold locks waiting for some other fiefdom How can work get coordinated across fiefdoms??? Transaction

Tentative Operations Sometimes fiefdoms will accept requests for tentative operations Similar to a reservation, this can be cancelled later on…. If the operation is cancelled, the invoked service must deal with the effects Tentative Op Cancellation

Semantics of Tentative Operations
Because a tentative operation may be cancelled later, they must be commutative Commutative means reorderable… When we cancel, we compensate Other stuff may have happened in between It is important to ensure that the operation and the cancellation are commutative Tentative Op Cancel 1 2 3

Semantics of Cancellation
When a tentative operation is cancelled, somehow, the invoked service must compensate for the operation This is not an undo It is another operation that makes things right… Part of supporting tentative operations is to ensure the operation is cancelable Again, commutativity is the main technique used to support cancelable operations You can reorder the cancellation with other work

Relinquishing the Right to Cancel
When an invoking fiefdom chooses to never cancel, it may confirm the operation When you confirm, you give up the right to cancel Every tentative operation will be either confirmed or cancelled

Increasing & Decreasing Uncertainty
Each tentative operation increases your uncertainty You get more and more confused each time you accept a tentative operation Each confirmation or cancellation decreases your uncertainty It resolves the confusion imparted by the tentative operation it is confirming or canceling Uncertainty More Uncertain Less Tentative Operation Cancellation or Confirmation

Bounded Uncertainty You can track the worst case situations for data values you are managing If you keep inventory, you can know the lowest possible and highest possible values Tentative operations move lowest and highest values apart This increases uncertainty Confirmations and cancellations move lowest and highest values together This decreases uncertainty Knowing the bounds, you have Bounded Uncertainty Widget Inventory Probability Maximum Widgets Possible Minimum

Acting on Bounded Uncertainty
Knowing bounds on uncertainty allows many different business rules: Refuse an order which may (in the worst case) result in widgets overflowing the warehouse Calculate probability of worst case overflowing the warehouse Cost of temporary storage vs. value of accepting order… Order food for hotel restaurant based on reservations and probabilities May result in interesting work by applying risk management algorithms…

Working With Autonomous Fiefdoms Working Across Fiefdoms Conclusion

Rambling Philosophy… Atomic transaction are singularities
Locking makes them appear to be at a single point in time Two-phase commit removes distribution concerns The new challenges happen when spreading work across space and time Different fiefdoms are in different spatial locations Work across different messages gets processed at different times Commutativity helps relax space and time By reordering with acceptable answers, it’s OK Note that DB write is not commutative Emissaries don’t have concurrency problems They only deal with read-only and single-user data They make things “stick” by sending requests to fiefdoms The fiefdom must have commutative requests… it sorts out the interleaving of work

Terminology Autonomous Autonomous Computing Fiefdom Fiefdom Emissary
A style of computing supporting the interaction of independent systems. Autonomous Computing Not controlled by others or by outside forces; independent Autonomous Fiefdom 1. The estate or domain of a feudal lord Something over which one dominant person or group exercises control Fiefdom An autonomous computing entity with private data and logic. Emissary An agent sent on a mission to represent or advance the interests of another. Emissary Code that goes out into the world to assist in working with a fiefdom. Snapshot Data A copy of data sent out to an emissary as a references source. For example, a price-list. Snapshot A photograph take with a small hand-held camera. Stable Resistant to change of position or condition; steadfast. Immutable; permanent; enduring. A place where horses live. Stable Data Data that doesn’t change… it’s meaning is clear anytime and anywhere. Appropriate for messages and snapshots. Bounded Uncertainty The management of ongoing work to track tentative operations and their confirmation and cancellation. Uncertainty Unsure about someone or something. A lack of assurance or conviction. Idempotent Request A request message that may be repeatedly processed while still giving behavior the same as a single execution. Essential to cope with retries… Idem Something that has been mentioned previously; the same. Potent Possessing inner or physical strength; powerful.

Summary Autonomous Computing
Allows distrusting systems to cooperate Defines a framework for the distribution of data to use in messages Loosely-coupled collections of tightly coupled services Explains web, offline, B2B, B2C, long-running work, etc. The .NET architecture is really about autonomous computing Services, messages, content-syndication… Autonomous Computing describes how to build loosely-coupled .NET applications We should be designing platforms and tools to support this model!

Autonomous Computing Fiefdoms and Emissaries
