3. Gene Expression Data Analyses Dong Xu Computer Science Department 109 Engineering Building West E-mail: xudong@missouri.edu 573-882-7064 http://digbio.missouri.edu

4. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

5. Time/Condition Expression (relatively levels to reference point at 0) Gene expression profiles

6. Goal of Microarray Experiments Microarray data Biological pathway Gene expression  Regulation/function in pathway/cellular state/phenotype  Disease diagnosis / disease gene identification

7. What Microarray Can Tell Us l Differentially expressed genes å Under different conditions å Different genotypes (mutant vs. wild type) l Co-expression and gene function inference l Regulatory network inference

8. Regulatory Networks l Which gene controls what? l Current methods for network reconstruction å Boolean networks X qualitative representation (on/off relationship) X computationally more manageable å differential equations X give “detailed” dynamic properties of networks X mathematically/computationally more problematic å Bayesian networks X define regulatory relationship X Widely used l E-Cell Project (http://www.c-cell.org/): network modelinghttp://www.c-cell.org/

9. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

10. Similarity between Profiles Similarity measure:  Euclidean distance  Correlation coefficient  Trend  … Correlation coefficient often works better. 0 expression time Expression profile

11. Pearson Correlation Coefficient l Compares scaled profiles! l Can detect inverse relationships l Most commonly used n=number of conditions x=average expression of gene x in all n conditions y=average expression of gene y in all n conditions s x =standard deviation of x S y =standard deviation of y

12. Correlation Pitfalls Correlation=0.97

13. Correlation coefficient Gene X Gene Y S(X,Y) {0+}

14. Euclidean Distance l Scaled versus unscaled l Cannot detect inverse relation ships For Gene X=(x 1, x 2,…x n ) and Gene Y=(y 1, y 2,…y n )

15. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

16. Data-Mining through Clustering Degradation Synthesis Chromatin Glycolysis Assumptions for clustering analysis:  Expression level of a gene reflects the gene’s activity.  Genes involved in same biological process exhibit statistical relationship in their expression profiles.

17. Clustering: group objects into clusters so that o objects in each cluster have “similar” features; o objects of different clusters have “dissimilar” features Idea of Clustering

18. Methods of Clustering discriminant analysis (Fisher,1931) K-means (Lloyd,1948) support vector machines (Vapnik, 1985) self-organizing maps (Kohonen, 1980) single linkage (dendrogram) hierarchical clustering minimum spanning tree based clustering

19. Issues in Cluster Analysis l A lot of clustering algorithms l A lot of distance/similarity metrics l Which clustering algorithm runs faster and uses less memory? l How many clusters after all? l Are the clusters stable? l Are the clusters meaningful?

20. Which Clustering Method Should I Use? l What is the biological question? l Do I have a preconceived notion of how many clusters there should be? l How strict do I want to be? Spilt or Join? l Can a gene be in multiple clusters? l Hard or soft boundaries between clusters

21. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

22. K-means clustering for expression profiles Step 1: Transform n (genes) * m (experiments) matrix into n(genes) * n(genes) distance matrix Step 2: Cluster genes based on a k-means clustering algorithm To transform the n*m matrix into n*n matrix, use a similarity (distance) metric.

23. K-means algorithm The most popular algorithm for clustering What is so attractive? Simple Mathematically correct Fast Invariant to dimension Easy to implement

24. K-Means Clustering l Basic Ideas : using cluster centre (means) to represent cluster l Assigning data elements to the closet cluster (centre). l Goal: Minimize square error (intra-class dissimilarity) : = l There is no hierarchy. l Must supply the number of clusters (k) into which the data are to be grouped. 2

25. Initialization 1 Specify the number of cluster k -- for example, k = 4 gene conditions Expression matrix Each point is called “gene” K-means Clustering : Procedure (1)

26. Initialization 2 Genes are randomly assigned to one of k clusters K-means Clustering : Procedure (2) or choose random starting centers

27. Calculate the mean of each cluster (1,2) (3,2) (3,4) (6,7) [(6,7) + (3,4) + …] K-means Clustering : Procedure (3)

28. Each gene is reassigned to the nearest cluster Gene i to cluster c K-means Clustering : Procedure (4)

29. K-means Clustering : Procedure (5) Iterate until the means are converged

30. Convergence of K-means algorithm Example : 111 data points in 9-dimensional space N= # of starts for achieving global solution # of Clusters2 342030 N1000 10000 30000 40000 1000000 For each set of starting centers we’ll get a local minimum Increase number of starts!

31. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

32. Hierarchical clustering (1) Step 2: Cluster genes based on distance matrix and draw a dendrogram until single node remains Step 1: Transform genes * experiments matrix into genes * genes distance matrix

33. 12 345 Hierarchical clustering (2)

34. Hierarchical Clustering Results

35. K-Means vs Hierarchical Clustering

36. Lecture Outline l Gene expression l Similarity between gene expression profiles l Concept of clustering l K-Means clustering l Hierarchical clustering l Minimum spanning tree-based clustering

37. Graph Representation Represent a set of n-dimensional points as a graph o each data point (gene) represented as a node o each pair of genes represented as an edge with a weight defined by the “dissimilarity” between the two genes n-D data points graph representation 0 1 1.5 2 5 6 7 9 1 0 2 1 6.5 6 8 8 1.5 2 0 1 4 4 6 5.5. distance matrix

38. Minimum Spanning Tree  Spanning tree: a sub-graph that has all nodes connected and has no cycles  Minimum spanning tree (MST): a spanning tree with the minimum total distance (b) (c) (a)

39. Prim’s algorithm and Kruskal’s algorithm Kruskal’s algorithm  step 1: select an edge with the smallest distance from graph  step 2: add to tree as along as no cycle is formed  step 3: remove the edge from graph  step 4: repeat steps 1-3 till all nodes are connected in tree. 10 3 (b) 4 3 (c) 4 3 5 (d) 4 7 3 5 (e) How to Construct Minimum Spanning Tree 4 6 7 3 5 8 (a) 14

40.  Significantly simplifies the data clustering problem, while losing very little essential information for clustering.  We have mathematically proved: Foundation of MST Approach A multi-dimensional clustering problem is equivalent to a tree-partitioning problem!

41. Clustering by Cutting Long Edge 1 Hierarchical cutting 1 st cut: longest edge 2 nd cut: second longest edge … Work well for “easy” cases. Produce many clusters with single element for some “difficult” cases. 2

42. Tree-Based Clustering  For each edge, calculate the assessment value  Find the edge that give the minimum assessment value as the place to cut g*g*  Clustering using iterative method  guarantee to find the global optimality using tree-based dynamic programming

43. Automated Selection of Number of Clusters Select “transition point” in the assessment value as the“correct” number of clusters.

44. Transition Profiles indicator[n] = (A[n-1] – A[n]) / (A[n] – A[n+1]) A[k] is the assessment value for partition with k clusters Our clustering of yeast data

45. Reading Assignments (1) l Suggested reading: å Chapter 10 in “Neil C.Jones and Pavel A. Pevzner: An Introduction to Bioinformatics Algorithms (Computational Molecular Biology). MIT Press, 2004.” å Chapter 11 in “Current Topics in Computational Molecular Biology, edited by Tao Jiang, Ying Xu, and Michael Zhang. MIT Press. 2002.”

46. Reading Assignments (2) l Optional reading: 1. Ying Xu, Victor Olman, and Dong Xu. Clustering Gene Expression Data Using a Graph-Theoretic Approach: An Application of Minimum Spanning Trees. Bioinformatics. 18:526-535, 2002. 1. Dong Xu, Victor Olman, Li Wang, and Ying Xu. EXCAVATOR: a computer program for gene expression data analysis. Nucleic Acid Research. 31: 5582-5589. 2003.

47. Develop a program that implement the K-means clustering algorithm 1. Allow several random initializations, and compare their clustering results. Choose the one that has the best value for objective function. 2. Test the program using the gene expression data sent to the mailing list. 3. Output gene IDs for each cluster. Project Assignment 2
