Alternating Current Physics 102 Professor Lee Carkner Lecture 23
2
PAL #22 RL Circuits Solenoid: 5 cm long, 1 cm diameter 0.1 V of emf is induced by increasing the current from 0 to 3 A in 0.5 seconds = -L( I/ t) L = t/ I = [(0.1)(0.5)]/(3)= L = 0 N 2 A/l N = (Ll/ 0 A) ½ N = [(0.0167)(0.05) / (4 X10 -7 )( )(0.005) 2 ] ½ N =
3
A switch is closed, starting a clockwise current in a circuit. What direction is the magnetic field through the middle of the loop? What direction is the current induced by this magnetic field? A)Up, clockwise B)Down, clockwise C)Up, counterclockwise D)Down, counterclockwise E)No magnetic field is produced
4
The switch is now opened, stopping the clockwise current flow. Is there a self- induced current in the loop now? A)No, since the magnetic field goes to zero B)No, self induction only works with constant currents C)Yes, the decreasing B field produces a clockwise current D)Yes, the decreasing B field produces a counterclockwise current E)Yes, it runs first clockwise then counterclockwise
5
To step down 120 household current to 12 volts, we would need a transformer with a ratio of turns between the primary and secondary transformer of, A)1 to 1 B)10 to 1 C)12 to 1 D)100 to 1 E)120 to 1
6
Sine Wave = angular frequency = number of radians per second f = frequency = number of cycles per second T = period = time for one cycle 1 cycle = 2 radians f = /2 T = 1/f = 2 / ¼ cycle t = ¼ T /2 rad. ½ cycle t = ½ T rad. ¾ cycle t = ¾ T /2 rad.
7
AC vs. DC Voltage and current vary sinusoidally with time Voltage and current will have a frequency and angular frequency in radians per second Capacitors and inductors can produce resistance-like effects Circuits have natural oscillation frequencies May get resonance
8
V and I in Phase
9
Time Dependence The current and voltage values vary with time But, the variation follows a known pattern sine wave We can discuss certain key values Namely, The maximum value (V max, I max ) Can think of as an average
10
Max Values The value at any time is just the maximum value times the sinusoidal factor: V = V max sin t I = I max sin t Note: Ohm’s Law still holds
11
rms Values Since the current varies in a systematic manner we would like to have some sort of average value However the average of a sinusoidal variation is 0 Since power depends on I 2 (P =I 2 R) it does not care if the current is positive or negative
12
Finding rms
13
rms Current and Voltage We can write the rms (root mean squared) current as: I rms = I max /(2) ½ = 0.707 I max We can write a similar relationship for the voltage V rms = V max /(2) ½ = 0.707 V max e.g. V max = I max R and V rms = I rms R
14
Resistors and AC We can use Ohm’s law in an AC circuit with a resistor The current and the potential difference are in phase Large V produces large current
15
AC Circuit with Resistor
16
Today’s PAL Consider a AC circuit with a 240 resistance lightbulb connected to V rms = 120 V, 60 Hz household current. For the lightbulb, what is: the rms current the maximum current the maximum power the average (rms) power the power at time equals 1/120 second
17
Capacitors and AC Consider a capacitor connected to an AC voltage source When the current changes direction it moves the charge back and decreases the voltage The capacitor is constantly being charged and discharged In a AC circuit the current will vary with some average rms value that depends on the voltage and the capacitance Capacitor acts as a resistor
18
AC Circuit with Capacitor
19
Reactance The capacitor impedes the flow of the current X C = 1/( C) The reactance, current and voltage across the capacitor are related by: V C = IX C At high frequency the capacitor never gets much charge on it The voltage and the current across the capacitor are not in phase
20
Phase The voltage and current across the capacitor are offset Since the capacitor offers no resistance As voltage increases current decreases We say the voltage lags the current by 90 degrees Voltage and current are offset by 1/4 cycle
21
AC Capacitor Phase Lag
22
Capacitor Power Since P = VI, we can see if the power is positive or negative based on the sign of I and V P is positive half the time and negative half the time The capacitor draws energy from and returns energy to the generator in equal measure
23
Next Time Read 21.13 Homework: Ch 21, P 58, 60, 61, 62
