Lecture 8 : Spatial Statistics 1 Autocorrelation & GWR Pat Browne

Lecture 8 : Spatial Statistics 1 Autocorrelation & GWR Pat Browne
Spatial Databases First law of geography [Tobler]: Everything is related to everything, but nearby things are more related than distant things. Lecture 8 : Spatial Statistics 1 Autocorrelation & GWR Pat Browne

Spatial autocorrelation
Spatial autocorrelation is the degree of correlation between neighbouring values.Spatial autocorrelation is detected when the value of a variable in a location is correlated with values of the same variable in the neighbourhood (can be measured with Moran I). Moran’s I measures the average correlation between the value of a variable at one location and the value at nearby locations. The essential idea is to specify pairs of locations that influence each other along with the relative intensity of interaction. Moran’s I provides a global view of spatial autocorrelation correlation. Lateest sp manua l 2

Moran’s I The range of the Moran's I statistic depends on the spatial weight matrix. When Moran's I is scaled by its bounds the statistic is restricted to the range ±1 Moran’s I can serve as a tool for modeling spatial dependencies in many data mining techniques.

Same Mean and SD but different Moran’s I

Spatial Autocorrelation: Moran’s I - example
Using rook (4) neighbourhoods.

Moran’s I - example Figure 7.5, pp. 190 Pixel value set in (b) and (c ) are same but their Moran Is are different. Q? Which dataset between (b) and (c ) has higher spatial autocorrelation?

Neigbourhood relationship contiguity matrix

Negative Dispersed Spatial Independence Positive Spatial Clustering Each diagram contains 32 white cell and 32 blue cells = 64 cells. BB = Blue beside Blue BW = Blue beside White WW = White beside White.

Moran’s I Global Moran’s I Local Moran’s I
What is the extent of clustering in the total area? Is this clustering significantly different from a random spatial distribution? Local Moran’s I Do local clusters (high-high or low-low) or local spatial outliers (high-low or low-high) exist? Are these local clusters and spatial outliers statistically significant?

Briggs Henan University 2010
Moran Scatter Plot Scatter Diagram between X and Lag-X, the “spatial lag” of X formed by averaging all the values of X for the neighboring polygons Identifies which type of spatial autocorrelation exists. Low/High negative SA High/High positive SA Low/Low positive SA High/Low negative SA Briggs Henan University 2010

Spatial autocorrelation is determined both by similarities in position, and by similarities in attributes Sampling interval Self-similarity Auto = self Correlation = degree of relatedness correspondence

Moran’s I index

Statistical Spatial Data
In this lecture we consider spatial data contains an attribute e.g. house prices, occurrences of disease, occurrences of accidents, crop yield, poverty patterns, crime rates, etc. Earlier parts of the course covered the representation of physical objects such as houses, counties, and roads. These objects were arranged by theme. Here we consider attributes of those objects e.g. the population of an ED.

Spatial Statistics Spatial statistics is the statistical study of spatial data that varies over discrete space e.g. crime rates broken down by neighbourhood. Spatial statistical models can be used for estimation, description, and prediction based on probability theory (not covered).

Standard statistical concepts: i.i.d
A collection of two or more random variables {X1, X2, … , } is independent and identically distributed if the variables have the same probability distribution, and are independent.

Standard statistical concepts: Examples
Example i.i.d: All other things being equal, a sequence of dice rolls is i.i.d. Example of non i.i.d: bird nesting patterns in wetlands, where the independent variables are distance from water, length of grass, depth of water and the dependent variable would be the presence of a nest site. A uniform distribution of these variables on a map would indicate an even distribution, however a more complex emerges where the variables are spatially dependent.

Standard statistical concepts: Correlation
Correlation: A correlation is a single number that describes the degree of relationship between two normally distributed variables. The variables are not designated as dependent or independent. The value of a correlation coefficient can vary from minus one to plus one. A minus one indicates a perfect negative correlation, while a plus one indicates a perfect positive correlation. A correlation of zero means there is no relationship between the two variables. When there is a negative correlation between two variables, as the value of one variable increases, the value of the other variable decreases, and vice versa.

Standard statistical concepts: Variance and covariance
A measure of variation equal to the mean of the squared deviations from the mean. The variance is a measure of the amount of variation within the values of that variable, taking account of all possible values and their probabilities or weightings. Covariance is measure of the variation between variables, say X and Y. The range of covariance values is unrestricted. However, if the X and Y variables are first standardized, then covariance is the same as correlation and the range of covariance (correlation) values is from –1 to +1.

Standard statistical concepts: Correlation
Correlation is a measure of the degree of linear relationship between two variables, say X and Y. While in regression the emphasis is on predicting one variable from the other, in correlation the emphasis is on the degree to which a linear model may describe the relationship between two variables. In regression the interest is directional, one variable is predicted and the other is the predictor; in correlation the interest is non-directional, the relationship is the critical aspect. The correlation coefficient may take on any value between plus and minus one (-1 < r < 1). Scatterplots We can graph the data used in computing a correlation coefficient. Essentially, with the Pearson Product Moment Correlation, we are examining the relationship between two variables - X and Y. By plotting each data pair (you will have sets of scores for X and Y), you will have created a graph call a scatterplot or scatterdiagram. Thus, if you were graphing height and weight for all of the children in a first grade class with twenty students, you would place a single dot on the graph at the point where each student's height and weight intersect. For correlation, it does not make any difference which variable goes on the x-axis and which variable goes on the y-axis. However, for linear regression, the variable that is the predictor goes on the x-axis. The variable being predicted goes on the y-axis. To evaluate the degree of relationship, one looks at both the slope of the line that would best fit through the data points as well as the degree of scatter from that same line. In correlation, we do not draw the line; in linear regression, we compute the position of the line. The more dispersed the data points, the lower the correlation. The closer all of the data points are to the line, in other words the less scatter, the higher the degree of correlation. The scatterplots presented below perhaps best illustrate how the correlation coefficient changes as the linear relationship between the two variables is altered. When r=0.0 the points scatter widely about the plot, the majority falling roughly in the shape of a circle. As the linear relationship increases, the circle becomes more and more elliptical in shape until the limiting case is reached (r=1.00 or r=-1.00) and all the points fall on a straight line. A number of scatterplots and their associated correlation coefficients are presented below in order that the student may better estimate the value of the correlation coefficient based on a scatterplot in the associated computer exercise. When examining the scatterplots below, examine both the size (degree of the relationship) as well as sign (positive or negative correlation).

Standard statistical concepts: Regression
Regression: takes a numerical dataset and develops a mathematical formula that fits the data. The results can be used to predict future behaviour. Works well with continuous quantitative data like weight, speed or age. Not good for categorical data where order is not significant, like colour, name, gender, nest/no nest. Example: plotting snowfall against height above sea level.

Standard statistical concepts: Regression
Y = A + BX; The response variable is y, and x is the continuous explanatory variable. Parameter A is the intercept. Parameter B is the slope. The difference between each data point and the value predicted by the line (the model) us called a residual

Standard statistical concepts: Null hypothesis
The null hypothesis, H0, represents a theory that has been put forward, either because it is believed to be true, but has not been proved. For example, in a clinical trial of a new drug, the null hypothesis might be that the new drug is no better, on average, than the current drug H0: there is no difference between the two drugs on average. In general, the null hypothesis for spatial data is that either the features themselves or of the values associated with those features are randomly distributed (e.g. no spatial pattern or bias).

Relation of i.i.d., regression, and correlation with spatial phenomena.
The first law of geography according to Waldo Tobler is "Everything is related to everything else, but near things are more related than distant things." In statistical terms this is called autocorrelation where the traditional i.i.d. assumption is not valid for spatially dependent variables (e.g. temperature or crime rate) we need special techniques to handle this type of data (e.g. Moran’s I). These techniques usually involve including a weight matrix which contains location information. The non-i.i.d. nature of spatially dependent variables carries over into regression and correlation which require spatial weights

Relation of i.i.d., regression, and correlation with spatial database
Spatial databases are used for spatial data mining, which includes statistical techniques and more specialised DM techniques such as association rules.. In this case the data mining algorithms need to have a spatial context. We must explicitly include location information where previously with the i.i.d. assumption it was not required Typical generic data mining activities such as clustering, regression, classification, association rules, all need a spatial context. Spatial DM is used in a broad range scientific disciplines, such as analysis of crime, modelling land prices, poverty mapping, epidemiology, air pollution and health, natural and environmental sciences, etc. The analyst must be aware the special techniques required for SDM. Epidemiology is the study of factors affecting the health and illness of populations, and serves as the foundation and logic of interventions made in the interest of public health and preventive medicine. It is considered a cornerstone methodology of public health research, and is highly regarded in evidence-based medicine for identifying risk factors for disease and determining optimal treatment approaches to clinical practice. In the study of communicable and non-communicable diseases, the work of epidemiologists ranges from outbreak investigation to study design, data collection and analysis including the development of statistical models to test hypotheses and the documentation of results for submission to peer-reviewed journals. Epidemiologists also study the interaction of diseases in a population, a condition known as a syndemic. Epidemiologists rely on a number of other scientific disciplines such as biology (to better understand disease processes), biostatistics (the current raw information available), Geographic Information Science (to store data and map disease patterns) and social science disciplines (to better understand proximate and distal risk factors).

Relation of i.i.d., regression, and correlation with spatial database
Spatial databases are also used for pure statistical research (e.g. environmental studies). Those variables that are spatially dependent (e.g. the PH of the soil) need to be clearly identified and special techniques applied to take into account their spatial bias.

Unique features of spatial data Statistics
General Statistics assumes the samples are independently generated, which is may not the case with spatial dependent data, where: Like things tend to cluster together. Change tends to be gradual over space.

Spatial Autocorrelation1.
Autocorrelation: degree of correlation between neighbouring values. Spatial dependency: neighbouring values are similar (i.e. positive spatial autocorrelation). Moran’s I enable assessment of the degree to which values tend to be similar to neighbouring values. We can observe how autocorrelation varies with distance. The Moran scatter plot relates individual values to weighted averages of neighbouring values. The slope of a regression line fitted to the points in the scatter plot gives the global Moran’s I. Lloyd: Spatial Data Analysis, Chapter 8, Oxford University Press.

Spatial Autocorrelation: Moran’s I
Moran’s I measures the average correlation between the value of a variable at one location and the value at nearby locations. The essential idea is to specify pairs of locations that influence each other along with the relative intensity of interaction. Moran’s I provides a global view of spatial autocorrelation correlation. We will look at details later The range of the Moran's I statistic depends on the spatial weight matrix. When Moran's I is scaled by its bounds the statistic is restricted to the range ±1 Moran’s I can serve as a tool for modeling spatial dependencies in many data mining techniques. Moran’s I quantifies the degree of SAC between points in each distance category. This measure is essentially a correlation coefficient, but in using and interpreting its values correctly, you must remember that unlike the usual non-spatial correlation coefficients, it can take on values greater than one. To most clearly show the pattern of SAC in your data, we plot two different results against the distance categories for pairs of points: Moran’s I itself, and a transformed value of Moran’s I (a z-value that has a standard normal distribution). This transformed value allows an easy visual assessment of how the statistical significance of SAC changes with distance. This is especially important, since at larger and larger distances there are typically fewer and fewer pairs of data points with which to estimate Moran’s I, resulting in some high (but non-significant) estimates of correlation. Thus, the key questions to ask with the results of this part of the tool are: A). Is there significant, or near-significant SAC for any distance class? If not, then you can proceed to collect and analyze data without worries that spatial dependency will influence the results. B) If SAC is significant at short distances, at what distance does it fall to insignificant values? If it is feasible to space subsequent samples at distances larger than this threshold, you can again avoid dealing further with the problems of SAC.

Spatial Autocorrelation: Case Study
Nest locations Distance to open water Vegetation durability Water depth

Spatial Autocorrelation Classical Statistical Assumptions (i. i
Spatial Autocorrelation Classical Statistical Assumptions (i.i.d) do not hold for spatially dependent data

Unique features of spatial data Statistics First Law of Geography
First law of geography [Tobler]: Everything is related to everything, but nearby things are more related than distant things. People with similar backgrounds tend to live in the same area Economies of nearby regions tend to be similar Changes in temperature occur gradually over space (and time) (equator V poles).

Spatial Autocorrelation: Moran’s I - example
Using rook (4) neighbourhoods.

Moran’s I - example Figure 7.5, pp. 190 Pixel value set in (b) and (c ) are same but their Moran Is are different. Q? Which dataset between (b) and (c ) has higher spatial autocorrelation?

Moran’s I - example Moran I statistic for map 1 is 0.55316092
> moran.test(map1$RAINFALL, nb2listw(map1.nb)) Moran's I test under randomisation data: map1$RAINFALL weights: nb2listw(map1.nb) Moran I statistic standard deviate = , p-value = alternative hypothesis: greater sample estimates: Moran I statistic Expectation Variance > moran.test(map2$RAINFALL, nb2listw(map2.nb)) data: map2$RAINFALL weights: nb2listw(map2.nb) Moran I statistic standard deviate = , p-value = Moran I statistic for map 1 is Moran I statistic for map 2 is

Moran’s I - example

Spatial Autocorrelation : Moran Scatterplot Map
São Paulo WZ Q4 = LH Q1= HH a Q2= LL Q3 = HL z Old-aged population

Spatial Heterogeneity.
Spatial heterogeneity; Is there such a thing as an average place with respect to some property (e.g. vegetation). is difficult to imagine any subset of the Earth’s surface being a representative sample of the whole. GWR (later) addresses the localness of spatial data. The Earth’s surface displays almost incredible variety, from the landscapes of the Tibetan plateau to the deserts of Australia and the urban complexity of London or Tokyo. Nowhere can be reasonably described as an average place and it is difficult to imagine any subset of the Earth’s surface being a representative sample of the whole. The results of any analysis over a limited area can be expected to change as that limited area is relocated, and to be different from the results that would be obtained for the surface of the Earth as a whole. These concepts are collectively described as spatial heterogeneity, and they tend to affect almost any kind of spatial analysis conducted on geographic data. Many techniques such as Geographically Weighted Regression (Fotheringham, Brunsdon, and Charlton, 2002, discussed in Section of this Guide) take spatial heterogeneity as given — as a universally observed property of the Earth’s surface — and focus on providing results that are specific to each area, and can be used as evidence in support of local policies. Such techniques are often termed place-based or local.

Neigbourhood relationship contiguity matrix

Spatial autocorrelation is determined both by similarities in position, and by similarities in attributes Sampling interval Self-similarity Auto = self Correlation = degree of relatedness correspondence

In the following slide, each diagram contains 32 white cell and 32 blue cells = 64 cells. BB = Blue beside Blue BW = Blue beside White WW = White beside White.

Negative Dispersed Spatial Independence Positive Spatial Clustering Each diagram contains 32 white cell and 32 blue cells = 64 cells. BB = Blue beside Blue BW = Blue beside White WW = White beside White.

Spatial regression (SR)
Spatial regression (SR) is a global spatial modeling technique in which spatial autocorrelation among the regression parameters are taken into account. SR is usually performed for spatial data obtained from spatial zones or areas. The basic aim in SR modeling is to establish the relationship between a dependent variable measured over a spatial zone and other attributes of the spatial zone, for a given study area, where the spatial zones are the subset of the study area. While SR is known to be a modeling method in spatial data analysis literature in spatial data-mining literature it is considered to be a classification technique

Negative Dispersed Spatial Independence The grids A and B represent two different spatial resolutions over the same area. Grid A contains 16 cells and Grid B contains 64 cells. The strength of spatial autocorrelation is often a function of scale or spatial resolution, as illustrated in above using black and white cells. High negative spatial autocorrelation is exhibited in A since each cell has a different colour from its neighbouring cells. In B each cell can be subdivided into four half-size cells, assuming the cell’s homogeneity. Then, the strength of spatial autocorrelation among the black and white cells increases, while maintaining the same cell arrangement. his illustrates that spatial autocorrelation varies with the study scale The strength of spatial autocorrelation is a function of scale, increasing from 4-by-4 case to the 8-by-8 case. Positive Spatial Clustering The strength of spatial autocorrelation is often a function of scale or spatial resolution, as illustrated in above using black and white cells. High negative spatial autocorrelation is exhibited in A since each cell has a different colour from its neighbouring cells. In B each cell can be subdivided into four half-size cells, assuming the cell’s homogeneity. Then, the strength of spatial autocorrelation among the black and white cells increases, while maintaining the same cell arrangement. This illustrates that spatial autocorrelation varies with the study scale The strength of spatial autocorrelation is a function of scale, increasing from 4-by-4 case to the 8-by-8 case.

Summary of spatial stats
Moran’s I measures the average correlation between the value of a variable at one location and the value at nearby locations. Local Moran statistic measures spatial dependence on a local basis, allowing the researcher to see its variation over space, and by Geographically Geographically Weighted Regression allows the parameters of a regression analysis to vary spatially. GWR helps in detecting local variations in spatial behavior and understanding local details, which may be masked by global regression models. GWR, regression coefficients are computed for every spatial zone.

Moran’s I A contiguity matrix may represent a neighborhood relationship defined using adjacency or Euclidean distance. There are several definitions adjacency include a four-neighbourhood or an eight-neighborhood. Given a gridded spatial framework, a four-neighborhood assumes that a pair of locations influence each other if they share an edge (rook). An eight-neighborhood assumes that a pair of locations influence each other if they share either an edge or a vertex (queen).

Moran’s I Using a normalised weight matrix the values of I range from -1 to 1. Value = 1 : Perfect positive correlation Value = 0 : No autocorrelation Value = -1: Perfect negative correlation A Moran’s I may appear low (say 0.17) but is statistically significant pattern is clustered since index is above 0. The Global Moran I statistic of about 0.5 (P<0.01) would indicate a positive moderate autocorrelation. The values of Local Moran I statistic in different areas (say above 5) would show that values in these areas have higher local spatial autocorrelation and suggesting that adjacent regions have similar values with each other. However, if there are some areas where the Local Moran I statistic was negative this would indicate that these areas have different values, and suggesting the existence of spatial heterogeneity. The larger the sample size, the more reliable the local and global Moran test statistics. The mean of all the Local Moran Is = Global Moran’ I.

Moran’s I Global Moran’s I Local Moran’s I
What is the extent of clustering in the total area? Is this clustering significantly different from a random spatial distribution? Local Moran’s I Do local clusters (high-high or low-low) or local spatial outliers (high-low or low-high) exist? Are these local clusters and spatial outliers statistically significant?

Moran’s I: A measure of spatial autocorrelation
Given sampled over n locations. Moran I is defined as Where and W is a normalized contiguity matrix. Row-standardized means that the rows sum to one. Distribution of extents of a particular class value of a. Fig. 7.5, pp. 190

Negative Dispersed Spatial Independence The grids A and B represent two different spatial resolutions over the same area. Grid A contains 16 cells and Grid B contains 64 cells. The strength of spatial autocorrelation is often a function of scale or spatial resolution, as illustrated in above using black and white cells. High negative spatial autocorrelation is exhibited in A since each cell has a different colour from its neighbouring cells. In B each cell can be subdivided into four half-size cells, assuming the cell’s homogeneity. Then, the strength of spatial autocorrelation among the black and white cells increases, while maintaining the same cell arrangement. his illustrates that spatial autocorrelation varies with the study scale The strength of spatial autocorrelation is a function of scale, increasing from 4-by-4 case to the 8-by-8 case. Positive Spatial Clustering The strength of spatial autocorrelation is often a function of scale or spatial resolution, as illustrated in above using black and white cells. High negative spatial autocorrelation is exhibited in A since each cell has a different colour from its neighbouring cells. In B each cell can be subdivided into four half-size cells, assuming the cell’s homogeneity. Then, the strength of spatial autocorrelation among the black and white cells increases, while maintaining the same cell arrangement. This illustrates that spatial autocorrelation varies with the study scale The strength of spatial autocorrelation is a function of scale, increasing from 4-by-4 case to the 8-by-8 case.

How to decide the weight wij ?
The weight indicates the spatial interaction between entities. Binary wij, also called absolute adjacency. Covers the general case answering the question is a value in a region similar or different to its neighbours. wij = 1 if two geographic entities are adjacent; otherwise, wij = 0. Choice of adjacency definition queens(8) or rooks(4).

How to decide the weight wij ?
The weight indicates the spatial interaction between entities. 2) The distance between geographic entities. Often the inverse distance is used, further objects get less weight, near object get more weight e.g. centre of epidemic. wij = f(dist(i,j)), dist(i,j) is the distance between i and j. 3) The length of common boundary for area entities. Policing borders, smaller borders less weight. wij = f(leng(i,j)), leng(i,j) is the length of common boundary between i and j.

How to decide the weight wij ?1
The choice of weights should ultimately be driven by a rationale for including those areas as neighbors that have a spatial effect on a given location. This rationale can be derived from theory or be the result of using ESDA to experiment with different weights and connectivity orders. Since weights matrices are used to create spatial lags that average neighboring values, the choice of a weights matrix will determine which neighboring values will be averaged. For instance, since rook weights will usually have fewer neighbors than queen weights, on average, each neighboring observation has more influence. 1. Tips in Geoda by Luc Anselin

How to decide the weight wij ?1
The question of which weights to choose is more pertinent in the context of modeling than ESDA since modeling is based on substantive notions of spatial effects while ESDA prioritizes the rejection of spatial randomness. Therefore, if there are no substantive reasons to guide the choice of weights in ESDA, using a weights file with as few neighbors as possible (such as rook) makes sense. Especially with irregular areal units (as opposed to grids), the difference between rook and queen weights is often minimal. However, it is advisable to test how sensitive your results are to your weights specifications by comparing multiple weights matrices. 1. Tips in Geoda by Luc Anselin

Spatial Outlier Detection
Global outliers are observations which appear inconsistent with the remainder of that data set. Global outliers deviate so much from other observations that it may be possible that they were generated by a different mechanism. Spatial outliers are observations that appear inconsistent with their neighbours.

Detecting spatial outliers has important applications in transportation, ecology, public safety, public health, climatology and location based services. Geographic objects have a spatial (location, shape, metric & topological properties) & non-spatial component (house owner, sensor id., soil type).

Spatial neighbourhoods may be defined using spatial attributes & spatial relations. Comparisons between spatially referenced objects can be based on non-spatial attributes. A spatial outlier is a spatially referenced object whose non-spatial attribute values differ from those of other spatially referenced objects in its spatial neighbourhood.

Data for Outlier detection
In diagram on left G,P,S,Q show a big change in attribute for a small change in location. The right hand diagram shows a normal distribution (corresponds to attribute axis in left diagram)

The upper left & lower right quadrants of figure 7.17 indicate a spatial association of dissimilar values; low values surrounded by high value neighbours (P & Q) and high values surrounded by low values (S).

Moranoutlier is a point located in the upper left or lower right quadrant of a Moran scatter plot.

Moranoutlier is a point located in the upper left or lower right quadrant of a Moran scatter plot. WZ Q4 = LH Q1= HH Cb Db a Q2= LL Q3 = HL z values in a given location

Model Evaluation Consider the two-class classification problem ‘nest’ or ‘no-nest’. The four possible outcomes (or predictions) are shown on the next slide. The desired predictions are: 1) where the model says the should be a nest and there is an actual nest (True Positive) 2) where the model says there is no nest and there is no nest (True Negative) The other outcomes are not desirable and point to a flaw in the model.

Model Evaluation

Spatial Statistical Models
A Point Process is a model for the spatial distribution of points in a point pattern. Examples: the position of trees in a forest, location of petrol stations in a city. Actual real world point patterns can be compared (using distance) with a randomly distributed point pattern random.

Case Study Distance to open water Nest locations Water depth
Vegetation durability Example showing different predictions: (a) the actual locations of nests; (b) pixels with actual nests; (c) locations predicted by one model; and (d) locations predicted by another model. Prediction (d) is spatially more accurate than (c).

Classical statistical assumptions do not hold for spatially dependent data

Case Study The previous maps illustrate two important features of spatial data: Spatial Autocorrelation (not independent) Spatial data is not identically distributed. Two random variables are identically distributed if and only if they have the same probability distribution.

Geographically weighted regression (GWR)
GWR is an effective technique for exploring spatial non-stationarity, which is characterized by changes in relationships across the study region leading to varying relations between dependent and independent variables. Hence there is a need for better understanding of the spatial processes has emerged local modeling techniques. GWR has been implemented in various disciplines such as the natural, environmental, social and earth sciences.

Spatial Regression1 The assumption of i.i.d. underlying ordinary least squares regression rarely holds for spatial data. There are several techniques that handle the spatial case; Moving window regression Geographic Weighted Regression (GWR) We will look at GWR

Geographic Weighted Regression (GWR) 1
The steps are; Go to a location Conduct regression using the raw data and a geographic weighting scheme. Move to next location go back to stage 2 until all locations have been visited. The output is a set of regression coefficients (e.g. slope and intercept) at each location

Coords of observations, variables
Coords of observations, variables. distance from first observation, and geographic weights point x y Var 1 Var 2 dist Geo w 1 25 45 12 6 2 44 34 52 0.995 3 21 48 32 41 5 0.8825 4 27 8 0.7261 16 31 11 22 0.278 42 35 14 9 20 0.0889 7 65 56 43 26 0.034 29 76 75 67 0.006 61 66 0.0002

Location of points for previous table

Regression using previous table and locations, the geographic weighting pulls the line towards the points with larger weights

Summary of spatial stats
Moran’s I measures the average correlation between the value of a variable at one location and the value at nearby locations. Local Moran statistic measures spatial dependence on a local basis, allowing the researcher to see its variation over space, and by Geographically Geographically Weighted Regression allows the parameters of a regression analysis to vary spatially. GWR helps in detecting local variations in spatial behavior and understanding local details, which may be masked by global regression models. GWR, regression coefficients are computed for every spatial zone.

References Applied Spatial Data Analysis with R
Bivand, Pebesma, Gómez-Rubio Lloyd: Spatial Data Analysis
