1 1 Pertemuan 02 Database environment Matakuliah: >/ > Tahun: > Versi: >

2 2 Learning Outcomes Pada akhir pertemuan ini, diharapkan mahasiswa akan mampu : Mahasiswa dapat Menerangkan 3 level arsitektur Ansi SPARC

3 3 Outline Materi Arsitektur three level AnsiSPARC Level eksternal Level conceptual Level Internal Logikal independensi dan physical independensi data

4 4 Chapter 2 Database Environment Transparencies

5 5 Chapter 2 - Objectives u Purpose of three-level database architecture. u Contents of external, conceptual, and internal levels. u Purpose of external/conceptual and conceptual/internal mappings. u Meaning of logical and physical data independence. u Distinction between DDL and DML. u A classification of data models. u Purpose/importance of conceptual modeling. u Typical functions and services a DBMS provide. u Software components of a DBMS. u Meaning of client–server architecture and advantages of this type of architecture for a DBMS. u Function & uses Transaction Processing Monitors. u Function and importance of the system catalog.

6 6 Objectives of Three-Level Architecture u All users should be able to access same data. u A user’s view is immune to changes made in other views. u Users should not need to know physical database storage details.

7 7 Objectives of Three-Level Architecture u DBA should be able to change database storage structures without affecting the users’ views. u Internal structure of database should be unaffected by changes to physical aspects of storage. u DBA should be able to change conceptual structure of database without affecting all users.

8 8 ANSI-SPARC Three-Level Architecture

9 9 u External Level –Users’ view of the database. –Describes that part of database that is relevant to a particular user. u Conceptual Level –Community view of the database. –Describes what data is stored in database and relationships among the data.

10 10 ANSI-SPARC Three-Level Architecture u Internal Level –Physical representation of the database on the computer. –Describes how the data is stored in the database.

11 11 Differences between Three Levels of ANSI- SPARC Architecture

12 12 Data Independence u Logical Data Independence –Refers to immunity of external schemas to changes in conceptual schema. –Conceptual schema changes (e.g. addition/removal of entities). –Should not require changes to external schema or rewrites of application programs.

13 13 Data Independence u Physical Data Independence –Refers to immunity of conceptual schema to changes in the internal schema. –Internal schema changes (e.g. using different file organizations, storage structures/devices). –Should not require change to conceptual or external schemas.

14 14 Data Independence and the ANSI-SPARC Three-Level Architecture

15 15 Database Languages u Data Definition Language (DDL) –Allows the DBA or user to describe and name entities, attributes, and relationships required for the application –plus any associated integrity and security constraints.

16 16 Database Languages u Data Manipulation Language (DML) –Provides basic data manipulation operations on data held in the database. u Procedural DML –allows user to tell system exactly how to manipulate data. u Non-Procedural DML –allows user to state what data is needed rather than how it is to be retrieved.

17 17 Database Languages u Fourth Generation Language (4GL) –Query Languages –Forms Generators –Report Generators –Graphics Generators –Application Generators.

18 18 Data Model Integrated collection of concepts for describing data, relationships between data, and constraints on the data in an organization. u Data Model comprises: –a structural part; –a manipulative part; –possibly a set of integrity rules.

19 19 Data Model u Purpose –To represent data in an understandable way. u Categories of data models include: –Object-based –Record-based –Physical.

20 20 Data Models u Object-Based Data Models –Entity-Relationship –Semantic –Functional –Object-Oriented. u Record-Based Data Models –Relational Data Model –Network Data Model –Hierarchical Data Model. u Physical Data Models

21 21 Conceptual Modeling u Conceptual schema is the core of a system supporting all user views. u Should be complete and accurate representation of an organization’s data requirements. u Conceptual modeling is process of developing a model of information use that is independent of implementation details. u Result is a conceptual data model.

22 22 Functions of a DBMS u Data Storage, Retrieval, and Update. u A User-Accessible Catalog. u Transaction Support. u Concurrency Control Services. u Recovery Services.

23 23 Functions of a DBMS u Authorization Services. u Support for Data Communication. u Integrity Services. u Services to Promote Data Independence. u Utility Services.

24 24 Components of a DBMS

25 25 Components of Database Manager (DM)

26 26 Multi-User DBMS Architectures u Teleprocessing u File-server u Client-server

27 27 Teleprocessing u Traditional architecture. u Single mainframe with a number of terminals attached. u Trend is now towards downsizing.

28 28 Teleprocessing Topology

29 29 File-Server u File-server is connected to several workstations across a network. u Database resides on file-server. u DBMS and applications run on each workstation. u Disadvantages include: –Significant network traffic. –Copy of DBMS on each workstation. –Concurrency, recovery and integrity control more complex.

30 30 File-Server Architecture

31 31 Client-Server u Server holds the database and the DBMS. u Client manages user interface and runs applications. u Advantages include: –wider access to existing databases; –increased performance; –possible reduction in hardware costs; –reduction in communication costs; –increased consistency.

32 32 Client-Server Architecture

33 33 Alternative Client-Server Topologies

34 34 Transaction Processing Monitors u Program that controls data transfer between clients and servers in order to provide a consistent environment, particularly for Online Transaction Processing (OLTP).

35 35 Transaction Processing Monitor as middle tier of a three-tier client-server architecture

36 36 System Catalog u Repository of information (metadata) describing the data in the database. u Typically stores: –names of authorized users; –names of data items in the database; –constraints on each data item; –data items accessible by a user and the type of access. u Used by modules such as Authorization Control and Integrity Checker.

37 37 Information Resource Dictionary System (IRDS) u Response to an attempt to standardize data dictionary interfaces. u Objectives: –extensibility of data; –integrity of data; –controlled access to data.

38 38 IRDS services interface
