1. Applications Have Changed. Why Hasn’t the Firewall? Dave Smith 214.674.7854 dsmith@paloaltonetworks.com Von Nguyen 713.301.9929 vnguyen@paloaltonetworks.com

2. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 2 | About Palo Alto Networks Founded by security visionary Nir Zuk World class team with strong security and networking experience Built family of next generation firewalls with control of 600+ applications Named Gartner Cool Vendor in 2008 Best of Interop Grand Prize, Best of Interop Security 2008

3. © 2007 Palo Alto Networks. Proprietary and Confidential Page 3 | Leading Organizations Trust Palo Alto Networks Health Care Financial Services Government Mfg / High Tech / Energy Education Services Media / Entertainment / Retail

4. Why Palo Alto Networks?

5. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 5 | Applications Have Changed – Firewalls Have Not The gateway at the trust border is the right place to enforce policy control - Sees all traffic - Defines trust boundary Need to Restore Visibility and Control in the Firewall Collaboration / Media SaaS Personal

6. © 2007 Palo Alto Networks. Proprietary and Confidential Page 6 | Today’s Architecture – Appliance Bloat Packet Shaping INTERNET HTTP/FTP Proxy IPS/IDS Content-Filtering IM Proxy Logging/Reporting User Correlation Present day firewalls require many “helper” appliances to try and stop the leakage. Unfortunately, application visibility and control is STILL lacking and the evasiveness continues unabated!

7. © 2007 Palo Alto Networks. Proprietary and Confidential Page 7 | Identifies over 700+ applications regardless of port, protocol or evasive tactic Policy based decryption, identification and control of SSL applications Application Command Center (ACC) for granular visibility & policy control of applications FlashMatch™ engine for real-time threat prevention Dedicated hardware processing for 10 Gbps in-line operation with no network degradation Designed to transparently augment existing firewall Palo Alto – Next Generation Firewall Next-generation firewall based on App-ID™ traffic classification technology

8. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 8 | Identification Technologies Change the Game App-ID Identify the application User-ID Identify the user Content-ID Scan the content

9. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 9 | App-ID: Comprehensive Application Visibility Policy-based control over more than 600 applications distributed across five categories and 25 sub-categories Balanced mix of business, internet and networking applications and networking protocols ~ 5 new applications added weekly

10. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 10 | Powerful Policy-Based Control Browse more than 600 applications based on name, category, technology or characteristic Immediately translate results into positive enforcement model firewall rules Examples: - Allow all business and networking apps - Allow IM but block file transfer capabilities - Block all P2P Policy enforcement by end-user / group identities from Active Directory or IP address

11. © 2007 Palo Alto Networks. Proprietary and Confidential Page 11 | Comprehensive Application Visibility File Sharing (28) afp aim-file-transfer boxnet carbonite cvsup dotmac dropboks esnips foldershare ftp gtalk- file-transfer ibackup jubii mediamax megaupload mozy ms-ds-smb msn-file-transfer nfs omnidrive openomy rsync sosbackup tftp titanize uucp xdrive yahoo-file-transfer General Internet (28) atom daytime dealio-toolbar discard echo facebook finger google-safebrowsing google- toolbar gopher hi5 livejournal msn-toolbar myspace nntp razor rsh rss rusers send-to- phone spark stumbleupon web-browsing web- crawler webdav webshots whois yahoo-toolbar Instant Messaging (39) aim aim-audio aim-video camfrog ebuddy fix google-talk gtalk-voice ichat-av icq iloveim imhaha imvu irc jabber koolim mabber meebo meetro meebo-repeater meebome meetro messengerfx msn msn-video msn-voice myspace-im oovoo p10 qq radiusim spark-im swapper userplane webaim xfire yahoo-im yahoo-webcam yoomba zoho-im Networking (sample of 154 total) Activenet bgp chargen compaq-peer dhcp dns eigrp gre icmp igmp ipip ipv6 isis mgcp ms-wins netbios-dg netbios-ns netbios-ss ospf pim rip stun vrrp Proxy (10) bypass bypassthat hopster http-proxy http-tunnel httport jap pingfu socks socks2http Database (7) Dabbledb db2 mssql-db mssql-mon mysql oracle postgres Media (45) cooltalk eyejot flash folding-at-home foonz gizmo google-earth google-picasa h.245 h.323 http-audio http-video itunes joost lifecam live365 logitech-webcam metacafe miro mms move-networks neokast netmeeting pandora pna rdt rtmp rtp rtsp sccp shoutcast sip skype skype-probe sling socialtv sopcast teamspeak uusee vakaka ventrilo veohtv yahoo-voice youtube Peer to Peer (34) 100bao allpeers applejuice ares azureus babelgum bittorrent direct-connect emule fasttrack flashget freenet generic-p2p gnutella goboogy hotline imesh kazaa mute neonet openft peerenabler poco pplive ppstream soribada soulseek tesla thecircle tvants vuze warez-p2p winmx xunlei Remote Access (23) avocent beinsync citrix crossloop fastviewer foldera l2tp logmein ms-rdp netviewer pcanyware pptp r-exec r-services radmin rlogin teamviewer telnet unyte vnc x11 xdmcp Email (7) blackberry imap ms-exchange outlook-web pop3 seven-email smtp Business Applications (82) active-directory adobe-connect altiris apple- update avamar avaya-phone-ping backweb big- brother ca-mq-service campfire centriccrm convoq corba cpq-wbem cups cvs distcc dynamicintranet eiq-sec-analyzer elluminate eroom-host eroom-net filemaker flexnet gkrellm google-calendar google-desktop google-docs gotomeeting groupwise hp-jetdirect innovative ipp jaspersoft kaspersky kerberos ldap live-meeting lpd mcafee meeting-maker mount ms-dtc ms-frs ms-groove ms-iis ms- netlogon ms-scheduler ms-update msrpc nagios ncp ndmp norton-av ntp perforce portmapper radius rpc rstatd salesforce seamless-phenom securemeeting snmp snmp- trap soap spirent subversion symantec syslog tacacs tacacs-plus time trendmicro vmware vyew webex webex-weboffice ypserv yugma Encrypted Tunnel (11) ciscovpn hamachi ike ipsec-ah ipsec-esp ipsec- esp-udp secure-access ssh ssl swipe tor Webmail (7) aim-mail fastmail gmail hotmail myspace-mail yahoo-mail yousendit Gaming (11) bomberclone knight-online little-fighter party- poker poker-stars source-engine steam subspace war-rock wolfenstein worldofwarcraft Policy-based control for over 600 applications across categories

12. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 12 | Content-ID: Real-Time Content Scanning Detect and block a wide range of threats, limit unauthorized file transfers and control non-work related web surfing - Stream-based, not file-based, for real-time performance  Uniform signature engine scans for broad range of threats in single pass  Vulnerability exploits (IPS), viruses, and spyware (both downloads and phone-home) - Block a wide range of file transfers by type  Looks into file to determine type – not extension based - Web filtering enabled via fully integrated URL database  20M URLs across 54 categories  Local database ensure highly scalable solution (1,000’s!)

13. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 13 | … … User-ID: Enterprise Directory Integration Users no longer defined solely by IP address - Leverage existing Active Directory infrastructure Understand users application and threat behavior based on actual AD username, not just IP Manage and enforce policy based on user and/or AD group Investigate security incidents, generate custom reports Active Directory Server(s) User Identification Agent(s)

14. © 2007 Palo Alto Networks. Proprietary and Confidential Page 14 | User-Based Application Visibility Drill into specific user activity - Top users of an application - List of applications used by a user - Malware and other threats detected by user Application Command Center (ACC) - View exactly what applications are running on the network - View by top applications, high risk, and category

15. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 15 | Enables Executive Visibility

16. Purpose-Built Architecture Flash Matching HW Engine Palo Alto Networks’ uniform signatures Multiple memory banks – memory bandwidth scales performance Multi-Core Security Processor High density processing for flexible security functionality Hardware-acceleration for standardized complex functions (SSL, IPSec, decompression) Dedicated Control Plane Highly available mgmt High speed logging and route updates 10Gbps Flash Matching Engine RAM Dual-core CPU RAM HDD 10 Gig Network Processor Front-end network processing offloads security processors Hardware accelerated QoS, route lookup, MAC lookup and NAT CPU 16. SSLIPSec De- Compression CPU 1 CPU 2 10Gbps Control Plane Data Plane RAM CPU 3 QoS Route, ARP, MAC lookup NAT

17. © 2007 Palo Alto Networks. Proprietary and Confidential Page 17 | Flexible Deployment Options Firewall Replacement Replace existing firewall Provides application and network-based visibility and control, consolidated policy, high performance Application Visibility Connect to span port Provides application visibility without inline deployment Transparent In-Line Deploy transparently behind existing firewall Provides application visibility & control without networking changes

18. © 2007 Palo Alto Networks. Proprietary and Confidential Page 18 | Palo Alto Networks Next Generation Firewalls Performance Remote Office/ Medium Enterprise Large Enterprise PA-2000 Series 1Gb PA-4000 Series 500Mb 2Gb 10Gb 10Gb with XFPs

19. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 19 | PAN-OS Features Strong networking foundation: - Dynamic routing (OSPF, RIPv2) - Site-to-site IPSec VPN, - Tap mode – connect to SPAN port - Virtual wire (“Layer 1”) for true transparent in-line deployment - L2/L3 switching foundation Zone-base architecture: - All interfaces assigned to security zones for policy enforcement Annual Subscriptions: - Threat prevention +20% - URL filtering +20% High Availability: - Active / passive - Configuration and session synchronization - Path, link, and HA monitoring Virtual Systems: - Establish multiple virtual firewalls in a single device (PA-4000 Series only) Legacy firewall support: - Application-based rules complement inbound and outbound port-based firewall rules Visibility and control of applications, users and content are complemented by core firewall features

20. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 20 | PA-4000 Series Specifications - 2U, 19” rack-mountable chassis - Dual AC power supply, Removable 80GB hard drive - Dedicated out-of-band management port - 2 dedicated HA ports - DB9 console port PA-4020 2 Gbps FW 2 Gbps threat prevention 500,000 sessions 16 copper gigabit 8 SFP interfaces $35,000 PA-4050 10 Gbps FW 5 Gbps threat prevention 2,000,000 sessions 16 copper gigabit 8 SFP interfaces $60,000 PA-4060 10 Gbps FW 5 Gbps threat prevention 2,000,000 sessions 4 XFP interfaces 4 SFP interfaces $80,000

21. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 21 | PA-2000 Series Specifications - 1U rack-mountable chassis - Single non-modular power supply - Removable 80GB hard drive (Non hot-swappable) - Dedicated out-of-band management port - RJ-45 console port, user definable HA port PA-2050 1 Gbps FW 500 Mbps threat prevention 250,000 sessions 16 copper gigabit 4 SFP interfaces $16,000 PA-2020 500 Mbps FW 200 Mbps threat prevention 125,000 sessions 12 copper gigabit 2 SFP interfaces $12,000

22. Customer Use Case Examples

23. © 2007 Palo Alto Networks. Proprietary and Confidential Page 23 | “We now know what we didn’t know. And it’s scary what our users and contractors were doing.” ………. Mark Rein Senior Director, Information Technology Mercy Medical Center MANY SOLUTION USE CASES and BENEFITS Application Visibility & Control User-based App Visibility & Control Real-time Threat Prevention Identify & Control SSL Content Security & DLP Monitor & Control Web Surfing Consolidate Security Devices @ Wire Speed Firewall Replacement Significant Human and Capital ROI Palo Alto Networks - Use Cases

24. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 24 | Customer Example: Nordson Corporation “The PA-4020 has simplified the tasks of managing security at our remote site. And it gives us visibility that no one else can match, telling us exactly which applications are on the network.” ………. Tim Harr Manager, Corporate Information Technologies, Nordson Problem Needed cost-effective remote office security solution Was looking at a complex 3-box solution Solution PA-4000 Series deployed as primary firewall for visibility and control over applications and threats Consolidates multiple devices Results Complete coverage - firewall, application control, threat prevention - one box Easy remote management - one UI Deployed in 3 locations internationally including headquarters Industry: Manufacturing Statistics: 30 Countries, 4100 employees, 2007 revenue - US$994M

25. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 25 | Customer Example: Greenhill Capital “The PA-4000 Series enables us to manage applications and users – which are far more relevant to our business that ports and protocols.” ………. John Shaffer Greenhill Problem No visibility into which applications were running on the network Couldn’t control webmail, attachments and unmonitored email a major issue Tired of adding appliances and vendors to security racks Solution PA-4000 Series deployed as the firewall for visibility and control over applications Results Complete coverage - firewall, application control, threat prevention - one box Easy remote management - one UI Easier vendor management – one support line, one vendor Industry: Financial Services, M&A research and analysis Statistics: 250 employees, 2007 revenue - US$400M

26. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 26 | Customer Example: Constellation Energy “The PA-4000 Series helps us be proactive in our security, allowing us to set and enforce application policies and protect our business assets much more effectively.” ………. Frank Chambers Director of Information Security Management, Constellation Energy Problem Lack of visibility and control over applications traversing the network. Want to be more proactive to enable more rapid deployment of new businesses and technology Heavy traffic across (2) DS3 pipes was forcing them to look at costly OC3 expansion Solution PA-4000 Series provides unmatched visibility and control over applications and web traffic traversing the centralized Internet connections Results Constellation found significant amounts of IM and P2P traffic traversing the network – which it is now able to control Industry: Energy, Energy Trading Statistics: F117, 9700 employees, 2007 revenue - US$21B

27. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 27 | Customer Example: SanDisk Corporation “With Palo Alto Networks, we are now for the first time able to identify rogue applications on the network such as P2P and Skype, and then block them accordingly.” ………. Justin Smith Senior Network Engineer SanDisk Problem Unable to manage applications on the network – concerned about various “threats” moving over rogue applications Solution PA-4000 Series brings increased visibility and control over applications and web traffic Results Able to see which applications and users are utilizing the network Able to take action – created policies to permit/deny groups or specific applications/users Provide a level of assurance that networks are being used for business purposes Industry: High-Tech Manufacturing Statistics: 3000 employees, 2007 revenue - US$3.9B

28. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 28 | Customer Example: Sisters of Mercy Health “Palo Alto Networks enables us to provide real-time access to critical applications while stopping threats and risky applications.” ………. Dan Schulte Manager of Network Security Sisters of Mercy Health System Problem Couldn’t manage which applications ran on the network Application-level threats impacting business IPS up for renewal Solution PA-4000 Series consolidates firewall, URL filtering and threat prevention Enables visibility and control over applications, web traffic and threats Results Visibility and control of applications Able to stop a broad range of threats (exploits, viruses, spyware) Industry: Health Care Statistics: 9 US States, 28,000 employees, over 4000 beds

29. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 29 | Customer Example: Louis Dreyfus Energy “Palo Alto Networks enables us not only to stop threats, but to understand how our networks are being used.” ………. Dave Baker Manager, Systems Administration Louis-Dreyfus Highbridge Energy Problem Firewalls couldn’t stop threats Solution PA-4000 Series enables visibility and control over applications and threats Results Visibility and control of applications Able to stop a broad range of threats (exploits, viruses, spyware) Very happy with customer responsiveness and support Industry: Financial Services Statistics: 290 employees, 2007 enterprise value – US$1B

30. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 30 | Customer Example: ESPN “We needed an IPS that could keep up with our business, and that could deal with today’s threats.” ………. Scott Messina Director of Security ESPN Problem ISS IPS was struggling to handle ESPN’s traffic load Solution PA-4000 Series deployed primarily as a threat prevention solution Enables visibility and control over threats and applications Results Visibility and control of applications Able to stop a broader range of threats (exploits, viruses, spyware) than previous IPS Integrates with Active Directory for user- and group-specific policy Performance that keeps pace with business Industry: Media Statistics: over 50 outlets – television, radio, publishing, ESPN.com

31. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 31 | Customer Example: Nicolet National Bank “We can now meet bank examiners expectations regarding visibility and control on our network.” ………. Jon Biskner AVP and Chief Information Security Officer, Nicolet National Bank Problem Couldn’t maintain security posture in the face of evasive application traffic Couldn’t control data leaving network Too many appliances Solution PA-4000 Series deployed as primary firewall for visibility and control over applications and threats Results Visibility, control and easier compliance Reducing and simplifying security infrastructure Industry: Financial Services/Banking Statistics: Regional; 6 branches, over $530M in assets

32. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 32 | Customer Example: City and Schools of Staunton “Our legacy firewall simply couldn’t deliver in terms of performance or visibility. The PA-4000 Series keeps pace easily, and provides a level of visibility and control that translates into real and enforceable acceptable use policies.” ………. Kurt Plowman Chief Technology Officer City of Staunton Problem Existing port-based firewall could not keep up with traffic – slowing the business of the city Couldn’t manage which applications ran on the network Application-level threats impacting business Solution PA-4000 Series consolidates multiple devices - enables visibility and control over applications, threats and web traffic Results High-speed firewall Visibility and control of applications Able to stop a broad range of threats (exploits, viruses, spyware) Industry: Government Statistics: over 2000 employees and students

33. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 33 | Customer Example: Lenox Hill Radiology “After evaluating the PA-4000 Series, its ability to control applications and perform access control, as well as inspect content for threats and vulnerabilities – all through an easy, simple management structure – just blew us away.” ………. Joe Funaro IT Director Lenox Hill Radiology Problem Application-level threats impacting business Looking at IPS + AV to stop threats Solution PA-4000 Series deployed as primary firewall enabling application visibilty and control Replaces multiple security appliances (firewall, IPS, Proxy, AV) Results Visibility and control of applications Able to stop a broad range of threats (exploits, viruses, spyware) Firewall + application visibility + threat blocking in one policy, one appliance Industry: Health Care Statistics: 3 locations in New York Metro area, 400 employees

34. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 34 | Customer Example: Western & Southern Insurance “We had every security device imaginable, all in- line, but couldn’t stop layer 7 threats.” ………. Doug Ross Chief Technology Officer Western & Southern Financial Group Problem Couldn’t tell what was on the network, despite firewall, IPS, DLP. Couldn’t catch L7 threats Solution PA-4000 Series enables visibility and control over applications Results Visibility into what’s on network Enable positive use of applications while controlling port-agile apps, ID malicious code on desktops that nothing else could find Long term, consolidate FW, URL filtering, IPS devices as they near end-of-life Industry: Financial Services Statistics: $4.8B, Ranked 480 on Fortune 1000 list, privately held

35. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 35 | Customer Example: Sonic Solutions “Our existing security solution is blind to traffic flowing across port 80. Palo Alto Networks provides us with user-based application visibility and control” ………. Roger Blakely VP of Information Security Sonic Solutions Problem Had no control over port 80 traffic, no ability to understand which users were doing what Solution PA-4000 Series for application visibility and control Results Visibility and control over applications and users traversing the network Long term will enable replacement of Cisco PIX and Fortinet firewalls Industry: High tech, software development Statistics: 600 employees, multiple sites worldwide

36. © 2008 Palo Alto Networks. Proprietary and Confidential. Page 36 | Customer Example: Garland ISD “Not only did the PA-4000 Series give us total control over all applications, we saw a significant performance increase in our network performance.” ………. Neil Moss Network Engineer Garland ISD Industry: K-12 Education Statistics: Largest district in TX, 57,000 students, 12,000 employees, 74 sites Problem Students circumventing IT security controls with tools such as UtraSurf and TOR - No visibility into user behavior, application use Existing firewalls not keeping up - Rate of change in applications - Sheer throughput Solution PA-4000 Series deployed as primary enterprise firewall Results Policy control by application and user - No longer struggle to keep up with new/changed applications Improved performance Saved $80K in year one

37. Application Level Visibility & Control (700+ Signatures) User-based & Group-based Visibility & Policy Control via Microsoft AD Integration Tightly integrated and Comprehensive Threat Prevention (URL filtering, Anti- Virus, Anti-Spyware, Anti-Malware & Anti-Vulnerability Protection) Aggressive Platform-based Subscription Pricing (vs. Costly User-based!) Embedded Virtual System Support (VSYS) Embedded Zone Protection (Denial of Service, Reconnaissance Port Scan) User-based Activity Reports and Ad-Hoc and Scheduled Reports Single Management Interface for all features on a single appliance Built-in Hardware/Software SSL Decryption capabilities 100% security protection during failover to the standby system Sensitive Data Protection - SSN & Credit Card numbers (Q4, 2008) Traffic Tagging Capability Now – Full Traffic Shaping Coming (1H, 2009) © 2007 Palo Alto Networks. Proprietary and Confidential Page 37 | Palo Alto Networks - Competitive Advantages

38. Thank You!
