2. Integrating CICS applications into SOA
Franz Konrad
Integrating CICS applications into SOA

3. Agenda Session Overview: CICS Applications and SOA SOA Options
Integrating CICS applications into SOA
CICS Applications and SOA
SOA Options
Transaction Server native options
Indirect options
Contrasting options to needs

4. Market Forces - IT Challenges
Service Oriented Architecture is maturing
Adoption of SOA increasing throughout IT
Move to service-enable applications
Infrastructure for composition
Extend use of applications
Legacy applications need to participate
Minimize risk
Composite Services
(Integrated / more business context)
Atomic-Level Service Components
(Granular)

5. CICS Applications and SOA
CICS applications generally pre-date SOA architectural guidelines
Typically CICS applications are monolithic
UI and logic have no clear separation
Even when separated, use of components are not assumed asynchronous
SOA is an architecture that assumes
Applications are built from distributed ‘remote’ services
Service use is asynchronous
Services are composable
Application Architeture

6. SOA Options At a high level Migrate to new architecture (platform)
Involves rewrite of application
Re-hosting is not a solution to architecture
Evolve applications (break them into services)
Available with new Transaction Server additions
Indirect access through appended infrastructure

7. Three Evolutionary Options
Native technology to current CICS platform
Leverage existing CICS tools
z Series
CICS TS
COBOL
App
TS 3.1
Integrated
Web services
Extended SOA
Network
CICS
Bridge Exit or
UI Access
CICS
COMMAREA
Access

8. Factors to Consider SOA strategy Skill-sets Mainframe capacity
2 tier versus 3 tier
Technology direction
Skill-sets
Skills for implementation
Long-term skill requirements
Mainframe capacity
Impact to existing infrastructure
Impact to existing applications
Invasive vs. non-invasive approach

9. Transaction Server Web Services
Native technology to current CICS platform
Leverage existing CICS tools
CICS TS 3.1
Cobol App
Integrated
Web services

10. CICS Integrated Web Services
System Programmer
Process it with the Web Services Assistant to populate Unix System Service (HFS) files (WSDL & WSBIND)
Configure CICS URI Mapping, WebService and Pipeline resource definitions
Make the WSDL available to the programmer to build the Web Service client (service Requester)
Application Manager
Find / Learn app language Structure -- copybook
Generate WSBIND and WSDL
HFS
Config
WS Bind
WSDL
CICS/Web Services Assistance
WSDL
IDE Tools
WS Bind
File
Language
Structure
CICS Web Services
Generate WSBIND and WSDL files -- Application Manager
Create a TCPIPService resource def -- System Programmer
Create a PIPELINE resource def and conf file -- sys prog
Install TCPIPSERVICE and PIPELINE def –WEBSERVICE and URIMAP defs (auto-created) -- sys prog
Publish WSDL -- Sys proge
for each Commarea application,
-          Find and understand the correct language structure (copybook)
-          Process it with the Web Services Assistant to populate Unix System Service (HFS) files (WSDL & WSBIND).
-          Possibly configure CICS URI Mapping, WebService and Pipeline resource definitions.
-          make the WSDL available to the programmer to build the Web Service client (service Requester)
Each request is XML parsed on the host, converted to EBCDIC, processed by the business logic, converted back to UTF-8 and XML generated.
URI
Def
Pipeline
Service Requester
Business Logic
Conversion
CICS TS 3.1

11. Attributes of Native Approach
High availability
Available with provider application
QoS of CICS extended to services
Inherit performance characteristics of platform
2-Tier approach reduces security exposure
Extends CICS Skill-sets to service layer

12. Factors Needs application level interactions
Legacy CICS applications may need modifications
Logic separate from UI
SOAP service needs to be invoked directly
Puts processing burden on the mainframe
Legacy system provides service
Leverages, but necessitates CICS skill-sets
For service creation
For on-going alignment with business processes
Base services built w/ CICS skills, composite services with mid-tier skills

13. Appropriate Use Good when a standards based approach is desired
This direct SOAP approach is open standards based and fully integrated into CICS Transaction Server and uses open standards based
This is a useful approach for:
Enterprise modernization (legacy modernization)
New MF application development needs
Business integration in a robust CICS shop
Web services implementation
Best for new development

14. Indirect Approach COMMAREA CICS 3270 Bridge support
Uses a proxy or gateway to aggregate transactions for use in services
Proxy or gateway can reside on or off mainframe, but is a logical middle-tier regardless
CICS 3270 Bridge support
Uses bridge exits available in recent CICS Transaction Server versions
Does not require a middle-tier other than for convenience

15. COMMAREA Access Gateway or proxy access to API
Use of API access to transactions
CICS TS
Cobol App
CICS
DPL Access
ECI, EXCI, RPC, CWS

16. CICS DPL Services copybook COPYBOOK Service Operation Host Transaction
Design Studio
System Programmer
Install listener (optional)
copybook
Application Manager
Find / Learn app language structure -- copybook
Describe operations for service
Create Service
Publish Service (WS, EJB, .NET Class…)
CICS
DPL Access
Cobol App IP
Listener
Generate WSBIND and WSDL files -- Application Manager
Create a TCPIPService resource def -- System Programmer
Create a PIPELINE resource def and conf file -- sys prog
Install TCPIPSERVICE and PIPELINE def –WEBSERVICE and URIMAP defs (auto-created) -- sys prog
Publish WSDL -- Sys proge
for each Commarea application,
-          Find and understand the correct language structure (copybook)
-          Process it with the Web Services Assistant to populate Unix System Service (HFS) files (WSDL & WSBIND).
-          Possibly configure CICS URI Mapping, WebService and Pipeline resource definitions.
-          make the WSDL available to the programmer to build the Web Service client (service Requester)
Each request is XML parsed on the host, converted to EBCDIC, processed by the business logic, converted back to UTF-8 and XML generated.
COPYBOOK
Service Operation
Host Transaction

17. Attributes of Gateway / Proxy
DPL
Access
Non-invasive to host or application
Links to existing transactions
Leverage existing APIs (ECI, EXCI,...)
High performance characteristics
3-Tier approach
Reduces MF processing
Transaction service can reside on any platform,
Or can reside in zOS, a CICS, or linux region
Service can be made native to service consumer: Web service, J2EE, .NET, etc...

18. Factors with Gateway / Proxy
DPL
Access
Needs transaction level interactions
Only works with CICS logic
Logic must be separate from UI
Loses process logic in UI
UI typically contains business processes
Need knowledge of the CICS application’s constraints
No control over granularity
Legacy system provides transaction as base service
Orchestration/ BPM assumed for building services with business context

19. CICS 3270 Bridge Access BMS or terminal access to CICS applications
Appended infrastructure within CICS
Cobol App
CICS 3270
Bridge
Client
I/F

20. CICS 3270 Bridge Access CICS TS 2.2 (+) Design Studio Cobol App Bridge
Application Manager
Learn application  business processes
Describe operations for service
Create Service
Publish Service (WS, EJB, .NET Class…)
System Programmer
Install Verastream Bridge Engine
Mid-Tier Admin
Load Client Interface on Server
Design Studio
TCP/IP
Cobol App
CICS TS 2.2 (+)
Bridge
Engine
Client
I/F

21. Attributes with CICS 3270 Bridge
High availability
Available with provider application
Inherit performance characteristics of platform
2-Tier approach reduces security exposure
Abstracts CICS Skill-sets from service layer
Has access to full CICS application details
BMS maps, terminal controls, invoked transactions
Retains process logic embedded in UI
Full control over granularity (business context) of services

22. Factors with CICS 3270 Bridge
Needs 3270 application UI
Does not see stand-alone transactions
Works with symbolic names if on BMS map
3270 app must be within CICS
May put processing overhead on the mainframe
CICS region provides service
Removes VTAM from process overhead
'This can be a net benefit'

23. Appropriate Use Transactions are not separate from UI
Useful approach for:
Enterprise modernization (legacy modernization)
Integration projects that need CICS application use
Web services implementation
Best when tight integration needs are combined with low CICS skill requirements
This is a non-invasive application approach that uses a CICS resident access method
Services are typically built with only terminal or systems analyst application level knowledge

24. General Mainframe Integration
Encapsulate data and logic via the screen interface
(UI Data Stream)
Supported Interfaces:
3270
VT420
AS/400
HP700/92
HP2392A

25. CICS Options Summary Useful for new development
Great for logic mixed with UI
Low impact to host and host application
z Series
CICS TS
COBOL
App
TS 3.1
Integrated
Web services
Extended SOA
Network
CICS
Bridge Exit or
UI Access
CICS
COMMAREA
Access

26. Transaction Integrator
Summary
Access
Low Host Skills
Low Host impact
Mixed Logic
2-Tier
Products
TS Web Services x
COMMAREA access
Bridge Access
General Access
Transaction Integrator
Bridge Integrator
Host Integrator
