1. ADMS Automatic Data Master Server
Data collection server system based on B/S structure

2. Content System Function System Structure Terminal connection solution
Database
Features
Successful Cases
Push SDK

3. System Function
Remotely monitor and manage hundreds of T&A terminals under complex network condition (WLAN)；
All data collected at terminals will be automatically transferred to the server；
Manage personnel information and the collected data at server；
Flexible database interface supports many kinds of database

4. ADMS Data Device System Device maintenance Device operation logs
Transaction monitor
Department
ADMS
Data
Employee
Transaction
Data from device
System
Command to device
Administration log

5. ADMS System Diagram TCP/IP, GPRS,WIFI TCP/IP, GPRS,WIFI Web Server
Database
T&A Devices with Fingerprint or RFID
T&A Devices with Fingerprint or RFID
ADMS
TCP/IP, GPRS,WIFI
TCP/IP, GPRS,WIFI
Web Server

6. Terminal connection solution
Supporting the popular
Web access method, e.g.
Router, NAT, Http proxy
and so on
The system adopts HTTP,
the T&A terminals will take
the initiative in connecting
with server and transferring
data.
Supporting complex modes
of connecting with network,
such as TCP/IP, WIFI,GPRS
and so forth.

8. Supported Databases MySQL (Default) Microsoft SQL Server
Other database need Customize

9. Flexible disposition of the server
Enterprise Intranet server
Private line server
VPN

10. Remotely monitor and manage terminals
Content 01
Content 02
Content 03
Content 02
Manage terminal such as
firmware upgrade
upload personnel info
backup data
delete records
delete operation records of terminals
etc
Check online or offline status of the terminal
Monitor and export all the transactions of employees from the terminal

11. Management of employees’ data and upload & download attendance logs1
The employees’ data can be added or managed at server, including personnel information and att logs. The data of employee can be downloaded from existing terminals. 2
All T&A devices will transmit the latest att logs to the server interval 1 minute through setting up interval of automatic data transmission , say ,setting up internal as 1 minute.

12. Manage system database
Server: Flexible exporting and writing real-time attendance log
The customers usually have their own T&A, HR, Payroll management system, the data collected from server would be automatically write into the existed database at real-time through configuration and simple customization, in this way, it will realize seamless integration between the different systems.
Manage system database HR
Payroll
T&A
ADMS database

13. System：To be extended and flexibly system according to different applications
T&A management system
Collect user info & transactions from T&A modules
Based on the modularized B/S structure, the system could be extended easily according to customers’ requirements
Conference management system
a management system of meeting attendance
Enterprise management system
Head office manage data from all branches
Examinee management system
a fingerprint enrolling and verifying system for examinee
Patrol management system
connecting with the patrol management modules

14. Att Software+ADMS Solution
Linkage between two databases
Data Collection
All terminals push user info and att transactions to ADMS server automatically
The trigger link two databases,
synchronize data from ADMS to att soft
Attendance rules & Shift
GENERATE REPORT
Constitute the att rules and assign shift for employees
Generate a series of att
reports which based on the att rules and shift

15. Successful Cases
A department of PING AN INSURANCE (GROUP) COMPANY OF CHINA ,LTD.:
China Telecom:
China Merchants Bank
To establish an online T&A management system, for a department at China Merchants Bank, in which data can be imported to SAP HR system at real time (over 1000 sites )
To set a patrol,
supervising and alarming integrated system, for a subsidiary company of China Telecom (more than 600 different sites)
Collecting Attendance data from more than 800 different sites in China

16. What could we offer
Push SDK for those who want to develop application like ADMS or other complex web-based application;
Flexible ADMS customization: specified data format, specified database, data synchronization, etc;
Most time and attendance models with ADMS function except some special devices for this web-based application.

17. PUSH SDK Hardware: Machines with ADMS function.
(Note: only those machines with ADMS function can use this SDK.)
Development platform: Windows, Linux
(The DEMO program ZKTeco provided
only for Windows O/S)
PUSH SDK
Program language: Python, Java, asp.net etc.
Function: After buying machines with ADMS
(browser/server) function, it can communicate with
attendance device by adopting HTTP protocol to
automatically upload data in real-time and upload
data, send command to device and get configuration
from equipment from time to time.

18. Please visit our test server to experience:
