1. Tetralogy of fallot

2. First anatomic description…Danish anatomist Niels Stensen, in 1672...
Described in detail by fallot in 1888…’la maladie bleue’
Tetralogy of fallot with pulmonary atresia…10%
Rarer variants include tetralogy of fallot with absent (or dysplastic) pulmonary valve and tetralogy of fallot with common atrioventricular canal[<5%]

3. Prevalence … 0.26 to 0.48 per 1,000 live births
In about 70% of tetralogy of Fallot patients, a putative genetic etiology remains to be determined.
Genes identified : NKX2.5, [4%]; JAG1 in Alagille syndrome.; TBX5 in Holt-Oram syndrome.
Sibling recurrence rate …2.5% to 3% if only one sibling is affected…likely to increase substantially if more than one sibling is affected.

4. Environmental factors
maternal diabetes [threefold increased risk], retinoic acids, maternal phenylketonuria (PKU), and trimethadione
Genetic cause : heterogeneous

5. Syndromes and associations…..
DiGeorge/Velocardiofacial syndrome, Down syndrome, Alagille syndrome, cat's-eye syndrome, recombinant chromosome (or San Luis Valley) and Kabuki syndromes, and CHARGE and VATER/VACTERL associations.
Microdeletion on 22q11….seen in
15–35% of TOF patients;
45% of TOF + PA;
65% of those with TOF + APV.

6. Developmental FAULT
Defective embryonic neural crest migration abnormal conotruncal development.
Incomplete rotation and faulty partitioning of the conotruncus during septation….
Malrotation of truncal-bulbar ridges results in misalignment of the outlet and trabecular septum and consequent straddling of the aorta over the malaligned VSD.
Abnormally anterior septation of the conotruncus by the bulbotruncal ridgessubpulmonic obstruction

7. Tetrad …right ventricular outflow obstruction, aortic override, ventricular septal defect, and right ventricular hypertrophy PS
Most characteristic …. subpulmonic stenosis
Obstruction along the entire course of the RVOT and pulmonary arteries (LPA commonly) can occur.
In general, the more severe the proximal obstruction, the greater the likelihood of distal areas of obstruction
Obstruction within the RV body : 1)hypertrophy of the septoparietal muscle bundles ; 2)anatomic displacement of the normal moderator band attachment

8. Pulm valve….bicuspid in 40%
VSD : nonrestrictive…..Few ptsVSD restrictive d/t the accessory TV prolapsing thru the defect
Coronary Anomalies
LAD from RCA (5%) & coursing in front of infund (Sx imp)
Single coronary (4%)
So coronary evaluation before Sx imp
Echo….proximal coronary
If needed … root angio / CAG….. MRI/CT

9. RCA
LAD
LCX AO PA
LAA
LAD
RCC
NCC
RCA
LCx
Pulm.
Valve
MPA

10. Right Aortic A in 25%......Twice more common in TOF+PA
Aortopulmonary Collateral Arteries..MC with TOF + PA…Only type 1, or bronchial artery collaterals, were documented in TOF with PS.:
Stenosis of LPA in 40%
Associated cardiac abnormalities
PFO or a true atrial defect in 83% of hearts with TOF… AVSD (downs)…LSVC(11%)
Left heart lesions are rare…Aortic valve disease may be acquired as a result of surgical trauma, progressive root dilation, or 20 to endocarditis.
TOF with Absence of PA…almost always LPA….PS murmur radiates to Rt chest…CXR..Lt hemithorax small,Lt lung hypovasc,Lt hemidiaphragm elevated

11. Morphology of Pulmonary Arterial Supply
3 major patterns :
(1)most favourable… R/L PA are confluent, and are supplied by an arterial duct [unifocal]
(2)the intrapericardial pulmonary arteries are confluent, but co-­exist with systemic ­to pulmonary CAs.
(3)absence of the intrapericardial pulmonary arteries….so fully supplied by multiple systemic-­to-­pulmonary CAs.

12. Unifocal….. usually the persistently patent arterial duct; rarely solitary systemic-­to-­pulmonary collateral artery/AP window/fistula from the coronary arteries.
Multifocal :MAPCAs: typically 2-6 in number; usually arise from the anterior wall of the aorta opposite the origin of the intercostal arteries. It is a rule that an arterial duct will not be present when a lung is supplied by systemic ­to pulmonary CAs.
The key to complete clinical diagnosis is to establish the course of each artery, to establish whether it runs directly into the lung or makes connections with intrapericardial and central pulmonary arteries, and to identify with precision the sites of these anastomoses.
Acquired CAs[TOF with PA] …. join the pulmonary circulation at immediately precapillary level.

13. APCs …the Rt upper artery supplies exclusively the RUL in direct fashion…Rt lower artery feeds the middle and lower lobes of the Rt lung through an anastomosis with the intrapericardial arterial tree, shown in blue, at hilar level….Left side…CAs are shown feeding the Lt lung through anastomoses at segmental level.

14. (1)Absent intrapericardial PAs (2) Anastomoses between the CAs and the intrapericardial PAs (extrapulm,hilar,lobar,segmental)

15. Pathophysiology and Hemodynamics
Severe cyanosis in profound RL shunting,
Some pts have a net LRshunt.
Hemodynamic features…RV hypertension because of the large VSD, with normal or low PAP.The low distal PAP is maintained as a result of the various levels of pulmonic obstruction. The PVR in the distal pulmonary arterial bed is usually normal.
The extent and direction of shunting ….determined by the cumulative amount of obstruction to PBF(Subpulmonic obstruction in all; valvular, supravalvular, and branch arteries are also common).

16. Balance between PBF & aortic BF will be determined by the difference in impedance between the unobstructed ,high-resistance systemic vascular bed and the obstructed pulmonary outflow tract and vascular bed.
RVH in proportion to LV mass in nonrestrictive VSD.
In restrictive VSD(suprasyst RVP)..severe RVH
Obstruction to PBF is relatively fixed & variation in cyanosis is determined by the changing SVR
Hypercyanotic episode…thought to result from an acute increase in infundibular obstruction and a proportional decrease in PBF.

17. C/F :
Wide due to variable severity of RV outflow obstruction
USGfetal diagnosis
Newborn & infants…cyanosis; systolic murmur
Acyanotic TOFmild pulmonary overcirculation rarely CHF unless there is a large PDA or aortopulmonary collateral arteries
Pregnancy…poorly tolerated … gest decrease in SVR increases R-L shunt & the labile SVR during labor,delivery leads to abrupt hypoxemia…..high fetal wastage / dysmature offspring

18. HYPERCYANOTIC SPELLS OR TETRALOGY SPELLS :
best described in TOF;can occur with other forms of structural heart disease…. mediated, in part, by dynamic changes (acute increase)in subpulmonic obstruction….. changes in contractility due to ‘endogenous catecholamines or exacerbated by hypovolemia’
other mechanisms[pulmonary atresia and VSD] …. decrease in systemic vascular resistance.
Child may assume squatting posture (instinctive) during spells …
Pathogenetic mechanisms : Vulnerable respiratory control centres ;Increase in HR ; Increase in CO & VR ;Increase in R L shunt; Infundibular contraction may reinforce,but does not initiate

19. TYPICAL SPELL :
The child becomes distressed and inconsolable, without apparent reason, most often in the morning.
Peak incidence2nd-6th m ;few after 2 yrs
Crying is associated with progressively deeper cyanosis and hyperpnea (not tachypnea).
Spells are self-aggravating;
During the spell  diminished/absent murmur
Not infrequently,the spell terminates with unconsciousness and, rarely,convulsions. If the hypoxemia is extreme, permanent neurologic sequelae and even death may ensue. True hypercyanotic spells are rare in neonates, although cyanosis may increase with crying.

20. O/E :
cyanosis ; clubbing ;
Arterial pulses …normal in uncomplicated TOF;
Wide pulse pressure (arterial diastolic runoff)…. aortopulmonary collaterals, palliative surgical shunt or PDA;
Accentuated precordial RV impulse;
LV impulse will not be hyperactive (normal cardiac output);
S2 single& loud (anterior, dextroposed aorta);
S3/S4 are unusual;
Aortic ejection click;
Systolic LUSB. The intensity of the murmur inversely parallels the degree of pulmonic obstruction;
Diastolic murmurs are unusual..Rarely AR murmur;
TOF with PA…..no harsh, obstructive precordial murmurs;
A harsh diastolic murmur, with a harsh murmur of PS, [harsh sawing, to-and-fro murmur ] ……TOF and APV syndrome;
Continuous murmurs….PDA;aortopulmonary collaterals ;may be best heard in the back.

21. ECG
QRS axis … same as that of a normal newborn
RVH…Tall monophasic R in V1 with an abrupt change to an rS pattern in V2 (Tall R extends into adj precordial leads in TOF + APV)
Reduced PBF+ underfilled LVrS in V2-V6
Balanced shunt …qR in V5,V6
L-R shuntQR in V5,V6
LAD with counterclockwise depolarisn TOF+AVSD

22. CXR: Normal sized heart; [may be large in PA]
upturned apex; attenuated & concave left heart border (infundibular and PA hypoplasia)….boot-shaped heart, or coeur en sabot…small underfilled LV that lies above horiz IVS, inferior to which is a concentric hypertrophied nondilated RV
Diminished pulmonary vascularity in proportion to the degree of cyanosis.
Absent thymic shadow in the newborn may indicate associated chromosome 22q11.2 microdeletion (DiGeorge syndrome).
RAA in roughly 25%...accompanied by Rt DA on Rt side
In PA..lacy reticular pattern (d/t the anast b/w lobar/segm PAs & CAs)
Syst arterial collaterals rarely cause rib notching as they do not run in intercostal grooves.

24. ECHO : PLAX : VSD; degree of aortic override; ?bilateral conus; AR;
Doppler… low velocity R-L shunt;
dilated CS…..?LSVC;
Absent DA..R/O RAA
Cranial tilt of the transducer…..infundibulum and the proximal pulmonary arteries. [location and degree of infundibular, valvular, and arterial hypoplasia]
Basal SAX:
RVOT and proximal pulmonary arteries…degree of PS….PDA?
VSD [just below the RCC, or at 10 o'clock position]. Tricuspid-aortic continuity confirms the perimembranous nature.
Coronaries…origin and course … echo showed sensitivity of 82%, specificity of 99%, and accuracy of 98.5% in a study by Need et al
high parasternal and suprasternal views will provide visualization of the pulmonary arteries and aorta, respectively

25. LAD
RCC
NCC
RCA
LCx
Pulm.
Valve
MPA
The anomalous LAD crossing the RVOT in TOF is identified when the transducer is swept superiorly in the parasternal short -axis view . This allows visualization of the anomalous LAD that is situated anterior to the RVOT

26. RCA Ao
LAA
Pulm valve Ao
Here a normal LAD (arising from the LCA and coursing posterior to the pulmonary valve) and a normal RCA are shown in the top frames for comparison.

27. 64-slice HRCT : Questions about preoperative pulmonary artery anatomy, coronary artery anatomy, and systemic or pulmonary venous anatomy can frequently be resolved even in newborns with 64-slice high-resolution CT scans. CMR : Assessment of pulmonary anatomy Postoperative assessment of RV function, myocardial scarring, and PR fraction

28. Cardiac Catheterization
Less often needed ;
Diagnostic
Therapeutic
foremost goal …. clarification or better definition of anatomic characteristics, such as pulmonary arterial or coronary arterial anatomy
coronary artery anatomy … either by aortic root angio, selective coronary artery injection, or a combination of both.
Definition of any aortopulmonary collaterals ….usually originate from the descending aorta.

29. MANAGEMENT

30. Medical Management
ductal-dependent pulmonary blood flow ?......neonates with critically restricted antegrade blood flow need to be started on prostaglandin E1and considered for either total repair or a systemic-to-pulmonary shunt.
Most newborns with TOF do not have ductal-dependent pulmonary blood flow and may be followed without specific early intervention.
Parental education for recognition of cyanotic spells [even acyanotic TOF are at risk for the development of spells in the first months of life].
IE Prophylaxis for cyanotic/palliated patients ; patients for 6 months after patch repair surgery, and those with prosthetic valves

31. Hypercyanotic spells …Rx lowering impedance to pulmonary flow and further increasing systemic vascular resistance.
Rx…..oxygen, volume expansion, sedation with morphine or ketamine, and, if needed, vasopressors[phenylephrine]
Refractory to above …..
Transfusion of whole blood/red cells
Balloon angioplasty of pulm annulus
Emergent surgical palliation or repair
Propranolol …having some efficacy in minimizing or extinguishing the occurrence of spells. It may be used for patients who are awaiting surgical intervention or who have a medical contraindication to either complete repair or aortopulmonary shunt.

32. Infants with very severe RVOT stenosis and those with TOF + PA,with SaO2<70%, should have surgery within a few weeks after birth.
Infants with moderately severe stenosis and marked cyanosis (SaO2 70–90%) should have corrective surgery by 2–4 months.
Corrective surgery should be performed in all other infants with tetralogy of Fallot by 6 months.
Contraindications for repair in early infancyPalliation initially
LAD from RCA crossing infundibulum
Severely hypoplastic PAs
Pulmonary atresia

33. Palliative Procedures
Classic BT shunt[1945]…SCAPA on side opposite AA
Modified BT… esp in small infants <6 months…side to side anastom with interposition graft of PTFE or Gore-Tex b/w SCA & PA [on the same side of AA]
Waterston shunt : Side-side anastomosis of RPA to AA
Potts : Side - side anastomosis of LPA to DA
Waterston/Potts shunts : complications
Excessive PBF  HF [20%] & PHTN
Difficulty taking shunt down at time of correction
Distortion of Rt/Lt PA ; Right/Left PA aneurysm

34. BT shunt-advantages :
(a)low incidence of problems from excess PBF
(b)No pericardial adhesions as pericardium is not entered
(c)Easy to time of complete repair..ligating its distal part just proximal to anastom with PA
(d)Less distortion of PAs
CENTRAL SHUNT :connecting a short tubular graft of Teflon or GoreTex from the aorta to the MPA.
advantages vs other shunts:
the size of the communication could be controlled by selecting a tube with a diameter appropriate for the patient;
branch PAs are not disturbed so that reconstruction is not required at the time of corrective surgery.

35. CLASSIC BT shunt

36. POTTS SHUNT WATERSTON SHUNT

37. Interventional procedures :
In patients with severe annular hypoplasia….. palliation of significant cyanosis by balloon valvuloplasty or RVOT stent placement can be done… Improvement in antegrade flow is thought to simultaneously enhance pulmonary arterial growth by augmenting PBF
Balloon angioplasty of the pulmonary valve annulus is preferable to a shunt procedure as it is
less traumatic,
it avoids a thoracotomy,
reduces the likelihood of distortion of the pulmonary arteries
Coil embolization of APCs ….Coiling of vessels that perfuse pulmonary segments already supplied by pulmonary arterial flow serves to reduce LV volume loading as well as to eliminate runoff into the pulmonary arterial bed during CPB

38. Surgery
relieving all possible sources of RVOTO;
If possible, pulmonary valve function is preserved by avoiding a transannular patch
Closure of VSD (dacron patch)
To relieve RVOTOpulmonary valvotomy, the insertion of an outflow tract patch or a transannular patch are often required.
Surgery during early infancy, when the pulmonary annulus is markedly stenotic, frequently requires the insertion of a long and wide transannular patch.
Consequently, most patients acquire PR as a result of the repair. PR may be well tolerated by many in the early postoperative years, but in the long term chronic PR is associated with reduced exercise capacity, RV dilatation, ventricular arrhythmias, and sudden death.

39. PVR : Early PVR in selected patients results in beneficial remodelling of the right ventricle Optimal timing is critical for preserving RV function (not too late) and avoiding the need for early re-operation (not too early). Amelioration of RV function following PVR has to be weighed against the risk of subsequent re-operation for homograft failure. Studies…RV end-diastolic volume may become a helpful indicator for defining both a lower limit (150 mL/m2) and an upper limit for re-intervention (200 mL/m2).[normal ] CMR is the gold standard for evaluation of RV volumes and quantification of the degree of PR & TR.

40. SURGERY in TOF contd…
VSD closure : Done thru’ RA approach whether or not a trans-annular patch is used, as this approach allows to minimise the length of the right ventriculotomy (length only necessary to relieve the RVOT obstruction and not for the VSD exposure).
Efficacy of the RA approach ….
Preserves the right ventricular function, …..
Resultant PR after limited transannular patching is less severe than that which occurs after transventricular repair
Less incidence of ventricular/atrial arrhythmias is
Easier to preserve the integrity & function of the tricuspid valve.
Concerns of right ventriculotomy (classical RV approach)
Low cardiac output in the early postoperative period,
a higher incidence of arrhythmias,
Risk of late sudden death

41. In case of a major coronary artery crossing the RVOT…an external conduit or homograft would be necessary;
Risk factors for early death after repair:  1) very young age 2) older age 3) severity of annular hypoplasia 4) small size of pulmonary arteries 5) need for transannular patch (debatable) 6) high peak RV to LV pressure ratio 7) previous palliative operations 8) multiple VSDs 9) co-existing cardiac anomalies

42. Advantages of early total correction
Prevents cerebral hypoxia,cerebral embolism, abscess and hematological changes
Decrease RVPprevent persistent myocardial hypertrophy and probably reduce the risk of fibrosis of the RV
Providing adequate PBF will optimize the opportunity for normal growth of the main and branch PAs…also normal pulmonary circulation may be important for lung development.
Tendency for progressive hypertrophy of the RV infundibular region is largely abolished by early repair.
Early separation of MAPCAs from aorta reduces the risk of PVOD

43. SURGERY IN TOF + PA :
PA anatomy not favourable? ….Palliative procedures… Central shunt vs reconstruction of RVOT using a patch/conduit while leaving open the VSD
If PA anatomy appears amenable to reconstruction, procedures leading to complete repair are indicated.
Such procedures include RV outflow reconstruction for inducement of central pulmonary artery growth using a valved conduit / aortic or pulmonary homograft
If there is a connection between RV & PT  correction can be achieved with a patch reconstruction

44. Adequate for VSD closure 1.2 Inadequate <0.8 for VSD closure
PA anatomy assessment
McGoon ratio: (Diameter of RPA/DAo + Diameter of LPA/DAo)
Normal 2.1
Adequate for VSD closure 1.2
Inadequate <0.8 for VSD closure
2) Nakata Index:(CSA of RPA + CSA of LPA)/BSA
Normal value > 200 mm2/m2 > 150 mm2/m2 is adequate. (Not usable preoperatively when MAPCAs are the major source of PBF & one-stage unifocalization + full repair is planned).

45. 3) Total Neo-Pulmonary Artery Index (TNPAI) = APC index + Nakata Index
APC index is the sum of CSA of all usable APCs/BSA >250 - suitable for one-stage repair including VSD closure (These pts. have low RV/LV pressure ratio postoperatively).
Critique of all these indices: These indices consider only the size of proximal vessel and not consider the condition of distal parts of the vessels (which may be stenosed).
Recently the value of all these has been questioned

46. MAPCAs : management : 2 options 1)Obliterate them by Sx ligation/coil embolisation 2)Surgical unifocalisation : if it is the sole supply to many segments …..connecting all MAPCAs, as well as the small native pulmonary arteries, to one source of blood flow from the RV [ie to a central PA confluence or prosthetic PA confluence]….. If performed early,it avoids the dvpt of PVOD changes, as well as stenoses in the MAPCAs. If the pulmonary vascular morphology and resistance are such that adequate PBF can be accommodated…then RVP after correction will be low enough to close the VSD.

47. To assess whether this is likely, surgeons at the University of California in San Francisco perfuse blood from the perfusion system through the pulmonary artery at a rate of 2.5 L/min per m. If PA mean pressure is <25 mmHg, it is considered safe to close the VSD. If it is not closed, the patient is followed; the PVR may decrease over time, allowing later closure. Also, if stenoses in pulmonary vessels are noted, relief by balloon angioplasty, with stenting if necessary, may permit RVP to fall and permit closure of the defect.
Post surgery if the RVP/LVP is >0.75….RVF may result…avoid closure VSD / fenestrated patch closure

48. Hypoplastic PAs … intervene early …. Encourage them to grow
Reconstruction of RVOT with a patch or valveless conduit
Placement of a central AP shunt
If MPA,RPA & LPA are present, even though very small (diameter 3 mm), they are capable of considerable enlargement if blood flow through them is increased.
Creating an AP window early in infancy sufficient enlargement of the pulmonary arterial tree to later perform successful repair using the normal pulmonary arteries and a unifocalization procedure can be avoided.

49. Dvpt of small pulmonary arteries
(A) Before central shunt was performed, the Nakata index was 64 and the McGoon ratio was (B) One hundred seventy-four days after operation, the Nakata index rose to 89 and the McGoon ratio to 1.1.

50. Post Repair for TOF in general
Current surgical survival, even for symptomatic infants <3 months of age, is excellent.
Hospital and 1-month survival rates of 100% have been reported.
Earlier age at repair (<1 year of age) did not adversely affect the rate of reintervention; so primary repair should be regarded as the preferred management strategy.
Twenty-year survival for hospital survivors, irrespective of management strategy, was 98% for patients who have TOF with PS and slightly lower for patients with PA, reflecting the overall excellent long-term survival of these patients.

51. COURSE
In unrepaired TOF….increasing cyanosis due to progressive infundibular obstruction. Beyond the neonatal period, they are also at increasing risk for developing hypercyanotic spells.
Older children with unrepaired or palliated TOF … complications a/w chronic cyanosis ,polycythemiastroke, brain abscess, and pigment gallstones.
Now rare …
‘infant repair is the rule’
PVOD in TOF : rare
large surgical systemic-to-pulmonary artery shunts
persisting large aortopulmonary collaterals

52. REPAIRED TOF : b)Recurrent RVOTO :
Outcomes : excellent…recent reports…mortality <3%
Problems that may develop include
a)Residual VSDs
Persistent defects at the patch margin or
Previously unrecognized or underestimated additional defects in the muscular septum.
Partial patch dehiscence
b)Recurrent RVOTO :
Muscle bundles obstruct the os infundibulum in 3%
Nontransannular patches…annulus becomes restrictive as child grows
Transannular patch…restriction at the distal insertion of the patch into the branch pulmonary arteries.
Stenosis owing to compression from an aneurysmal RVOT patch …. should be approached surgically with revision of the patch and repair of the proximal obstruction.
may dvp additional sites of peripheral PS over time.

53. c)Progressive aortic root dilation &AR :
Intrinsic dvptal abnormalities of aortic valve/root
Palliative shunts or significant APCs left-to-right shunt volume contribute to aortic dilation.
Progressive dilation of aorta correlate with longer time between palliation & repair ; Pulmonary atresia ; right AA & male gender.
d) RV dilation;syst/diast dysfunction later RHF
excess volume load from pulmonary regurgitation
pressure load from outflow obstruction,
Hypoxemic coronary perfusion,
surgical incision, patch and scarring, and post–cardiopulmonary bypass ischemia reperfusion injury—possibly superimposed on tetralogy associated congenital abnormalities of the myocardium.

54. e) LV dysfunction … consequence of adverse ventricular interaction
e) LV dysfunction … consequence of adverse ventricular interaction. f) Rhythm disturb./SCD : Long-term mortality …. 3% to 6%. A review of 125 adult patients with TOF suggested that a greater degree of PR, a history of sustained VT, QRS duration >180 ms, or LV dysfunction was a predictor of sudden death g) Lower IQ h) Life time increased risk for IE i)Membranous subaortic stenosis …..may be seen years after the initial repair in a few patients…may require surgical excision. j)Small coronary-to-RV fistulas, thought to relate to the excision of muscle in the right ventricular outflow tract.

55. Post repair TOF + PA :
Need for reoperation/ transcatheter balloon dilation and stenting of an obstructed conduit in RV to PA conduit surgery patients.
Ongoing risk for recurrent peripheral PS…serial catheterizations are indicated for ongoing pulmonary artery rehabilitation
higher risk for progressive aortic root dilation and AR

56. TOF + AVCD :
risk for atrioventricular valve incompetence …. TR right ventricular dilation, and dysfunction.

57. Congenital Absence of Pulmonary Valve Syndrome
Chever in 1847
incompletely formed, rudimentary pulmonary valve that typically is both stenotic and regurgitant ; aneurysmally dilated PA, and a large malaligned outlet VSD.
PDA is always absent….has been postulated as being responsible for its pathogenesis and PA dysplasia.
Other clinical features fairly typical in this disorder include the common association of airway abnormalities that may lead to severe respiratory failure .
The conal septal abnormalities and infundibular obstruction, however, in distinction to typical tetralogy, are less severe or absent, and much of the PS results from annular hypoplasia.

58. Typically present in the neonatal period, and are diagnosed based on the presence of their characteristic murmur and the presence of cyanosis.
A significant proportion of patients will present with associated respiratory distress or frank respiratory failure, often requiring mechanical ventilation.
harsh to-and-fro murmur of PS followed by the diastolic murmur of PR….sound of ’sawing wood’
CXR…Massively dilated Pas ; Infundibular dilation project leftward as a hump shaped shadow ; Pulmonary vascularity is normal

59. Some neonates present with severe bronchial obstruction and require immediate tracheal intubation and mechanical ventilation, followed by early surgical repair.
Moderate resp obstruction … lying prone may help … by relieving the anterior vascular compression of bronchi
Mild or no airway obstruction may require no additional support in the neonatal period and go on to elective repair later in infancy.
The surgical repair….. in addition to ventricular septal defect closure and right ventricular outflow reconstruction, involves reduction of the aneurysmal mediastinal pulmonary arteries to relieve bronchial compression.

60. Outcome of TOF + APV depends largely on the severity of airway disease.
Even after Sx,some pts continue to have bronchial obstruction
Residual airway hypoplasia and deformity
Abnormally branching segmental pulmonary arteries compressing the intraparenchymal bronchi
As these patients grow, however, pulmonary function tends generally to improve as PAP fall and the maturing tracheobronchial tree develops less compressible walls and larger caliber.

61. THANK YOU
