1. DO NOW
Sketch each figure. CD GH AB
Line m
Acute ABC
XY II ST

3. Geometry Week 3 of 9 Unit 1: Logic & Reasoning
Basic Constructions
Geometry
Week 3 of 9
Unit 1: Logic & Reasoning
9/9 & 9/10

4. Standards & Objective Standard 16.0 Objective:
Students perform basic constructions with a straightedge and
compass, such as angle bisectors and perpendicular bisectors.
Objective:
Use a compass and a straightedge to construct congruent segments and congruent angles
Use a compass and a straightedge to bisect segments and angles

5. Example: Constructing Congruent Segments
Construct a segment congruent to a given segment Given: AB Construct: CD so that CD = AB Step 1: Draw a ray with endpoint C Step 2: Open the compass to the length of AB Step 3: With the same compass setting, put the compass point on point C. Draw an arc that intersects the ray. Label the point of intersection D.

6. Practice: Constructing Congruent Segments
Construct XY congruent to AB.
Construct VW so that VW = 2AB
A ● ● B inches

7. Example: Constructing Congruent Angles
Construct an angle congruent to a given angle. Given: A Construct: S so that S = A Step 1: Draw a ray with endpoint S Step 2: With the compass point on point A, draw an arc that intersects the sides of A. Label the points of intersection B and C. Step 3: With the same compass setting, put the compass point on point S. Draw an arc and label its point of intersection with the ray as R. Step 4: Open the compass to the length BC. Keeping the same compass setting, put the compass point on R. Draw an arc to locate point T. Step 5: Draw ST

8. Practice: Constructing Congruent Angles
Construct D so that D = C C

9. Constructing the Perpendicular Bisector
Construct the perpendicular bisector of a segment. Given: AB Construct: XY so that XY AB at the midpoint M of AB Step 1: Put the compass point on point A and draw a long arc as shown. Be sure the opening is greater than ⅟2 AB. Step 2: With the same compass setting, put the compass point on point B and draw another long arc. Label the points where the two arcs intersect as X and Y. Step 3: Draw XY. The point of intersection of AB and XY is M, the midpoint of AB. XY AB at the midpoint of AB, so that XY is the perpendicular bisector of AB. Draw ST. Construct its perpendicular bisector.

10. Practice: Constructing the Perpendicular Bisector
Construct the perpendicular bisector of AB
● ● A B

11. Finding Angle Measures
Definition of Angle Bisector Substitute Add 25 to each side Subtract 3x from each side Divide each side by 2 Substitute 15 for x
Angle Bisector: a ray that divides an angle into two congruent angles. KN bisects JKL so that m JKN = 5x-25 and m NKL = 3x+5. Solve for x and find m JKN. m JKN = m NKL 5x – 25 = 3x + 5 5x = 3x x = 30 X = 15 m JKN = 5x – 25 = 5(15) – 25 = 50 m JKN = 50

12. Practice: Finding Angle Measures
GH bisects FGI. a) Solve for x b) Find m HGI c) Find m FGI F H
(3x -3)
(4x – 14) G I

13. Constructing the Angle Bisector
Construct the bisector of an angle Given: A Construct: AX, the bisector of A Step 1: Put the compass point on vertex A. Draw an arc that intersects the sides of A. Label the points of intersection B and C. Step 2: Put the compass point on point C and draw an arc. With the same compass setting, draw an arc using point B. Be sure the arcs intersect. Label the point where the two arcs intersect as X. Step 3: Draw AX. AX is the bisector of CAB.
