2. Storport Smorgasbord Keith Frechette
A selection of today’s hottest Storport topics
Keith Frechette
Software Development Engineer
Device & Storage Technologies

3. Agenda Half-duplex Mode: Not appropriate for shipped products
StorPortCompleteRequest: Fouled-up beyond all repair?
VPD Page 0x83 Data: Storport changes that you should test now
New Storport event log interface
NUMA and multiprocessor improvements
Performance Tip: Completing requests during StartIo
New Storport miniport sample
Virtual Miniports: When are they appropriate?

4. Not appropriate for shipped products
Half-duplex Mode:
Not appropriate for shipped products

5. Don’t Ship Them! Half-duplex mode:
Is intended only for short-term use during the initial porting of a miniport from SCSIport to Storport
Restricts port/miniport synchronization to that of SCSIport miniports
Results in more time spent at device IRQL
Reduces concurrency in I/O processing, leading to lower performance
Is not compatible with new Storport interfaces and optimizations
Is not appropriate for use in shipping products
If you continue to ship a half-duplex-based miniport, you risk compatibility problems with future Storport revisions.

6. StorPortCompleteRequest: Fouled-up beyond all repair?

7. Background: How did it ever work?
The design and implementation were inherited from SCSIport
Intended as a convenience function for simplified reset recovery
Works well with non-reentrant model of SCSIport
SCSIport
Miniport calls ScsiPortCompleteRequest to fail all outstanding requests
Miniport
SCSIport detects an I/O timeout and issues a reset
Meanwhile, a new request is received
They are sent to the miniport
ScsiPortCompleteRequest completes
I/O requests arrive
Miniport clears its queue
Recovery complete!
I/O resumes
I/O Queue
Read: sectors 10-15
Read: sectors
Read: sectors
Write: sector 11
Read: sectors 10-15
“Outstanding” Requests
Read: sectors
Read: sectors
Write: sector 11
Read: sectors 10-15
ScsiPortCompleteRequest

8. The Problem
Storport miniports are reentrant, so StorPortCompleteRequest leads to:
Confusion over which requests were completed and which weren’t
“Double completions” and “never completions”
Storport
Miniport calls StorPortCompleteRequest to fail all outstanding requests
Miniport
Storport detects an I/O timeout and issues a reset
StorPortCompleteRequest completes
Meanwhile, a new request is received
Uh-oh. 
Miniport clears its queue
I/O Queue
Read: sectors
Write: sector 11
Read: sectors 10-15
Read: sectors 10-15
Read: sectors
“Outstanding” Requests
Read: sectors
Write: sector 11
Read: sectors 10-15
Read: sectors
StorPortCompleteRequest

9. The Recommendation
The miniport individually flushes the outstanding requests
Pause the Storport I/O queue
Call StorPortNotification( RequestComplete ) for each outstanding request
Resume the Storport I/O queue
Storport
Miniport
Miniport calls StorPortNotification (RequestComplete) for each request
Miniport calls StorPortPauseDevice
Storport detects an I/O timeout and issues a reset
Miniport calls StorPortResumeDevice
Meanwhile, a new request is received
Miniport clears its queue
Recovery complete!
I/O resumes
I/O Queue
Read: sectors
Write: sector 11
Read: sectors 10-15
Read: sectors 10-15
Read: sectors
StorPortResumeDevice
StorPortPauseDevice
“Outstanding” Requests
Read: sectors
Read: sectors 10-15
StorPortNotification
(RequestComplete)
Read: sectors
Write: sector 11

10. The Plan At present, StorPortCompleteRequest should not be used.
The miniport should manually complete all outstanding requests.
StorPortCompleteRequest will remain so that existing miniports continue to function.
Although there is currently no Windows Logo Program requirement, you can expect that we’ll start checking for the use of StorPortCompleteRequest and warning vendors about likely side-effects.
Based on Microsoft development priorities and on IHV feedback, StorPortCompleteRequest may be:
Redesigned to work properly, although miniport changes may be required
Completely replaced with a new interface designed to fit the Storport model
Simply left as-is to let existing miniports continue to run.

11. Storport changes that you should test now
VPD Page 0x83 Data:
Storport changes that you should test now

12. Overview
Storport’s evaluation of vital product data (VPD) Page 0x83 data has been changed with respect to identifying when a LUN has changed.
Why? Because the current implementation:
Gives equal weight to globally-unique and non-globally-unique identifiers
Causes Storport to fail to detect a disk swap when the two otherwise- unique devices share a non-globally-unique identifier.
The new approach gives precedence to globally-unique identifiers.
Applications that relied on the older approach may behave incorrectly.

13. New Handling: Pseudo-Code
bool CompareIdentiferData( CurrentIdSet, PreviousIdSet ) { if (neither ID set has page 0x83 IDs) if (page 0x80 exists for both ID sets and is identical) return Match; else return NoMatch; if (only one of the ID sets has page 0x83 IDs) return NoMatch; if (both ID sets have type 2/3/8 IDs) if (any IDs of type 2/3/8 match) if (both ID sets have type 1 IDs) if (any IDs of type 1 match) if (both ID sets have type 0 IDs) if (any IDs of type 0 match) return NoMatch; }
Notes
Identifier types
0h – Vendor specific
1h – T10 vendor ID based
2h – EUI-64 based
3h – NAA
8h – SCSI name string
Only LUN-associated IDs are compared.

14. Test It with Your Products!
You should test your storage configurations now and provide feedback.
These changes are very significant and will impact some scenarios.
Example: A firmware update that replaces all the globally-unique IDs but leaves an existing non-globally-unique ID.
With old VPD page 0x83 handling, Storport does not detect a disk swap.
With new VPD page 0x83 handling, Storport detects a disk swap.

15. New Storport event log interface

16. Overview Alternative to using StorPortLogError
Provides same capabilities as IoWriteErrorLogEntry
Miniport-specific event codes and strings
Miniport-specific “dump data”
Callable at IRQL <= DISPATCH_LEVEL
Includes Storport-specific information
Path/Target/LUN IDs
Storport-specific event codes and strings
Miniport decides which device object to associate
Adapter device object for adapter- or target- associated events.
LUN device object for LUN-associated events.
Implemented as a Storport extended function
Enables backward compatibility with older versions of Storport

17. Usage (At a Glance) STOR_LOG_EVENT_DETAILS logEvent;
PWSTR logStrings[3]; .
logEvent.PathId = path;
logEvent.TargetId = target;
logEvent.LunId = lun;
logEvent.EventAssociation = StorEventLunAssociation;
logEvent.StorportSpecificErrorCode = FALSE;
logEvent.ErrorCode = MY_MINIPORT_CUSTOM_STATUS_CODE;
logEvent.DumpDataSize = sizeof(MY_MINIPORT_EVENT_DATA);
logEvent.DumpData = &MyEventData;
logEvent.StringCount = ARRAYSIZE(logStrings);
logEvent.StringList = logStrings;
StorPortLogSystemEvent( pMyDeviceExtension, &logEvent, NULL );

18. Interface Description: Function Interface
StorPortLogSystemEvent
Format: StorPortLogSystemEvent( HardwareExtension, LogDetails, MaximumSize )
PVOID HardwareExtension
Hardware extension for the adapter.
PSTOR_LOG_EVENT_DETAILS LogDetails
Information to appear in the system event log entry.
int * MaximumSize
Optional (can be NULL). Variable to receive the maximum combined size of the miniport’s dump data and strings. Only returned if the function failed with STOR_STATUS_INVALID_BUFFER_SIZE.

19. Interface Description: Event Log Details
typedef struct _STOR_LOG_EVENT_DETAILS { ULONG InterfaceRevision; // Revision of this interface ULONG Size; // Size of this structure ULONG Flags; // Special flags to control this interface STOR_EVENT_ASSOCIATION_ENUM EventAssociation; // See STOR_EVENT_ASSOCIATION_ENUM enumeration ULONG PathId; // Path portion of SCSI address ULONG TargetId; // Target portion of SCSI address ULONG LunId; // LUN portion of SCSI address BOOLEAN StorportSpecificErrorCode; // TRUE if error code is specific to Storport (SP_xxx) ULONG ErrorCode; // Error code, either SP_xxx or standard NTSTATUS code ULONG UniqueId; // Often used to indicate the location of the error ULONG DumpDataSize; // Size in bytes of private data block PVOID DumpData; // Private data block ULONG StringCount; // Count of NUL-terminated Unicode strings PWSTR * StringList; // Unicode strings used for substitution within // log messages (%2, %3, %4...) } STOR_LOG_EVENT_DETAILS, *PSTOR_LOG_EVENT_DETAILS;

20. Example 1: Standard Storport Error Code
void LogBadFirmware( SAMPLE_DEVICE_EXTENSION * pDeviceExtension, ULONG CurrentRevision ) { STOR_LOG_EVENT_DETAILS logEvent; SAMPLE_PRIVATE_LOG_DATA privateData; privateData.CurrentRevision = CurrentRevision; memset( &logEvent, 0, sizeof(logEvent) ); logEvent.InterfaceRevision = STOR_CURRENT_LOG_INTERFACE_REVISION; logEvent.Size = sizeof(logEvent); logEvent.EventAssociation = StorEventAdapterAssociation; logEvent.StorportSpecificErrorCode = TRUE; logEvent.ErrorCode = SP_BAD_FW_ERROR; logEvent.DumpDataSize = sizeof(privateData); logEvent.DumpData = &privateData; StorPortLogSystemEvent( pDeviceExtension, &logEvent, NULL ); }

21. Example 2: Custom Error Code and Strings
void LogBadFirmware( SAMPLE_DEVICE_EXTENSION * pDeviceExtension, PWSTR pCurrentRevString, PWSTR pMinSupportedRevString ) { STOR_LOG_EVENT_DETAILS logEvent; PWSTR logStrings[2]; logStrings[0] = pCurrentRevString; logStrings[1] = pMinSupportedRevString; memset( &logEvent, 0, sizeof(logEvent) ); logEvent.InterfaceRevision = STOR_CURRENT_LOG_INTERFACE_REVISION; logEvent.Size = sizeof(logEvent); logEvent.EventAssociation = StorEventAdapterAssociation; logEvent.StorportSpecificErrorCode = FALSE; logEvent.ErrorCode = SAMPLE_INVALID_FIRMWARE_ERROR; logEvent.StringCount = ARRAYSIZE(logStrings); logEvent.StringList = logStrings; StorPortLogSystemEvent( pDeviceExtension, &logEvent, NULL ); }

22. NUMA and multiprocessor improvements

23. Summary of New Interfaces
New Multiprocessor Interfaces
StorPortGetCurrentProcessorNumber
StorPortGetGroupAffinity
StorPortGetActiveGroupCount
New NUMA Interfaces
StorPortGetNodeAffinity
StorPortGetActiveNodeCount
StorPortGetHighestNodeNumber
StorPortGetLogicalProcessorRelationship
Related Interfaces for Memory Allocation
StorPortAllocateContiguousMemorySpecifyCacheNode
StorPortFreeContiguousMemorySpecifyCache

24. New Multiprocessor Interfaces
Use these functions if your miniport can optimize its performance based on knowledge of the underlying processor topology.
ULONG StorPortGetCurrentProcessorNumber( PVOID HardwareExtension,
PPROCESSOR_NUMBER ProcNumber )
Description
Returns the system-assigned number of the current processor on which the caller is running.
ULONG StorPortGetGroupAffinity( PVOID HardwareExtension,
USHORT GroupNumber,
PKAFFINITY GroupAffinityMask )
Description
Constructs a mask of the active processors in the requested group.
ULONG StorPortGetActiveGroupCount( PVOID HardwareExtension,
PUSHORT NumberOfGroups )
Description
Returns the number of groups present in the system.
Continued…

25. New Multiprocessor Interfaces
…continued
ULONG StorPortGetLogicalProcessorRelationship( PVOID HardwareExtension,
PPROCESSOR_NUMBER ProcessorNumber,
LOGICAL_PROCESSOR_RELATIONSHIP_TYPE RelType,
PSYSTEM_LOGICAL_PROCESSOR_INFORMATION_EX Info,
PULONG Length )
Description
Returns a specified type of relationship information about groups, physical processors, and nodes in the host system.

26. New NUMA Interfaces
Use these functions if your miniport can optimize its performance based on knowledge of the underlying NUMA/memory topology.
ULONG StorPortGetNodeAffinity( PVOID HardwareExtension,
ULONG NodeNumber,
PGROUP_AFFINTY NodeAffinityMask )
Description
Constructs a mask of the active processors in the requested NUMA node.
ULONG StorPortGetActiveNodeCount( PVOID HardwareExtension,
PULONG NumberOfNodes )
Description
Returns the number of nodes present in the system.
ULONG StorPortGetHighestNodeNumber( PVOID HardwareExtension,
PULONG HighestNode )
Description
Returns the largest possible node number on the system.

27. New Memory Interfaces
Use these function to dynamically allocate and free contiguous memory blocks. A preferred NUMA node can be specified.
ULONG StorPortAllocateContiguousMemorySpecifyCacheNode(
PVOID HardwareExtension,
SIZE_T NumberOfBytes,
PHYSICAL_ADDRESS LowestAcceptableAddress,
PHYSICAL_ADDRESS HighestAcceptableAddress,
PHYSICAL_ADDRESS BoundaryAddressMultiple,
MEMORY_CACHING_TYPE CacheType,
NODE_REQUIREMENT PreferredNode,
PVOID * BufferPointer )
Description
Allocates a range of physically contiguous, cache-aligned memory.
ULONG StorPortFreeContiguousMemorySpecifyCache( PVOID HardwareExtension,
PVOID BaseAddress,
SIZE_T NumberOfBytes,
MEMORY_CACHING_TYPE CacheType )
Description
Frees a buffer allocated by StorPortAllocateContiguousMemorySpecifyCacheNode.

28. Completing requests during StartIo
Performance Tip:
Completing requests during StartIo

29. Completing Requests During StartIo Handling
By completing I/O requests in its HwStorStartIo routine, a miniport can:
Spend less time at device IRQL, thus improving system responsiveness
Take advantage of new Storport optimizations that further improve system responsiveness and I/O throughput
To take advantage of the new Storport optimizations, a miniport:
Must enable DPC redirection via StorPortInitializePerfOpts
Must use StorPortNotification(RequestComplete) while in its HwStorStartIo routine to notify Storport of completed I/O requests
Should indicate its intention to do completion-during-StartIo by setting the STOR_PERF_OPTIMIZE_FOR_COMPLETION_DURING_STARTIO flag in its call to StorPortInitializePerfOpts
While in its HwStorStartIo routine, a miniport should check for completed requests after starting the requested I/O operation

30. New Storport miniport sample

31. Sample Overview
Port of LSI production SYM_U3 SCSIport based driver to Storport
Supports LSI Ultra160 Parallel SCSI adapters
Older technology SCSI controller hardware (minimal intelligence)
Very simple custom 8-bit RISC processor, 8K internal RAM (circa 1999)
Hardware and scripts limited to use 256 queue tag values per adapter
Hardware and scripts designed to SCSIport capabilities
Adjustments in miniport match Storport advanced functionality to limited hardware capabilities
Porting required about 3 weeks (develop/test)
Will be the Storport miniport sample in the next version of the WDK

32. Porting Activities Summary of SCSIport to Storport porting activities
Remove all NextRequest and NextLuRequest calls
Rename all ScsiPortxxx calls to StorPortxxx
Add BuildIo routine (moved about 75% of code from StartIo)
Convert driver to full-duplex operation
Add queue management routines (error handling, adapter restart)
Add LUN and target reset support
Add code to assign queue tags internally (hardware limitation)
Add synchronization routines for bus reset and full adapter restart
Add support for SRB_FUNCTION_POWER (adapter shutdown via SRB)
Add StorPortSetDeviceQueueDepth call—LUN queue depth of 31

33. Virtual Miniports: When are they appropriate?

34. When Are They Appropriate?
A virtual miniport is appropriate when:
It is entirely simulating a device (e.g. a RAM disk)
It has no hardware of its own but is using another device (e.g. a network adapter) as a transport for I/O requests
A virtual miniport is inappropriate when:
It is directly controlling real hardware

35. New Bus Types for Virtual Miniports
BusTypeVirtual
Virtual miniport equivalent of BusTypeUnknown
Use when a more-specific bus type isn’t available for the virtual device
Example: RAM disks that are volatile (aren’t persisted)
BusTypeFileBackedVirtual
Indicates that the virtual device persists its “contents” to a data file
Example: A logical disk whose I/O is redirected to an image file on a physical disk drive

36. Additional Resources
Storage in the WDK Documentation on MSDN
Related Sessions
Session
Day / Time
Storport Drivers from the Ground Up
Tues. 8:30-9:30 and
Wed. 9:45-10:45
Storport Smorgasboard
Wed

37. Questions?
