1. Bert Jan van der Steeg SharePoint Consultant
trainer
Office 365
&
Identity Federation
consultant
Bert Jan van der Steeg
Bert Jan van der Steeg SharePoint Consultant

2. agenda Intro ADFS 2.0 Overview Federated Authentication in Office 365
Single Sign On Configuration
agenda

3. agenda Intro ADFS 2.0 Overview Federated Authentication in Office 365
Single Sign On Configuration
agenda

5. Identities used to access resources:
On-premise (Active Directory)
Cloud (Office 365)
Available options:
Separate credentials in corporate directory and in Office 365
Migrate existing credentials to Office 365
Identity Federation with ADFS 2.0
IdM options
Identities are used for determining what users may access.
Companies probably have invested in an identity management solution, such as Active Directory
When Office 365 is introduced, the organization has three options:
Maintain separate user accounts both on-premise and in the cloud
Migrate all accounts to the cloud (only for small shops)
Setup Identity Federation

6. Sub-optimal user experience
Painful to manage
Separate password policies
Multiple credentials to manage
Management of sign-in application (BPOS)
Sub-optimal user experience
Log-in each time the service is accessed
2 accounts and/or passwords to manage
Set up of sign-in application with every new computer used by each user (BPOS)
IdM options
Separate credentials
Separate credentials for both Office 365 and on-premise authentication has many disadvantages.
Administration is not efficient
User experience is not optimal

7. migrate existing credentials
No more corporate credentials
Credentials and resources in the cloud
Small shops
No dedicated IT-guy
No local resources
IdM options
migrate existing credentials
Migrating all accounts to Office 365 means there are no more corporate credentials. If at all possible, this would only work for smaller shops.
This would work for starting organizations without a dedicated IT-person.

8. Credential management on-premises Trust with Federation Gateway
Office 365 is Relying Party
Prerequisites
Domain UPN Suffix routable
Own the domain (SSL certificate)
IdM options
identity federation
Credentials are managed on-premise and all corporate account and password policies apply.
The Federation Gateway ensures access to the online environment, handles authentication for other services. MFG is the intermediate between your directory and MSOL
Office 365 is the relying party, in SAMl terminology.
Prerequisites for this to work are that you need to prove that you own the domain by modifying the DNS records at your provider
Also, the internal domain name must be routable over the internet. That could result in a separate project for renaming the domain.

9. user accounts federated identity identity identity federation
federated identity
identity
contoso \charlie
identity
federation
Identity Federation enables seamless authentication (SSO) with on-premise credentials to resources in the cloud (Office 365).
The credentials that is used on-premise is also used for Authorization purposes in Office 365.
Charlie uses his account in many ways to access local resources. When accessing MSOL, he would need to provide a new set of credentials. With federation in place, logging in will be seamless.

10. ten steps
Easy, right?
Configuring federation and synchronisation consists of 10 steps, most of which is preparation.

11. agenda Intro ADFS 2.0 Overview Federated Authentication in Office 365
Single Sign On Configuration
agenda

12. claims history Active Directory Federation Services 2.0
First, a little history.
ADFS comes from a long line of products, with many different names and reputations

13. WS-Federation WS-Trust SAML Claims Based AuthN
Architecture and specification for Identity Federation protocols
WS-Trust
Describes the token exchange procedures
SAML
Describes standard for exchange of AuthN and AuthZ between security realms
Claims Based AuthN

14. federation lingo This.. ..means this STS
Security Token Service (IP-STS, RP-STS)
Identity Provider IdP
System that generates SAML tokens containing claims
Relying Party
Application (service) that can accept claims
WEB Single Sign On
Federated Authentication Systems – AuthN is separated from AuthZ
Federated Sign Out
Signing out from all systems involved
Claim
Assertion about an identity that is used for AuthZ purposes
FederationMetadata.xml (ADFS2.0)
XML file used to exchange information between RP and IP. Should be always available
Claims augmentation
Adding claims into a SAML token based on attribute store information
WAYF
Where Are You From. Home Realm Discovery
federation lingo

15. ADFS 2.0 ADFS 2.0 Users Office 365 Azure Partner Resources
ADFS in an intermediate between Your local Active Directory and possibly a lot of different resources. Those resources must be enabled for Identity Federation, which means in Microsoft terms, they should be based in Windows Identity Foundation. When the resource is outside of the Microsoft realm, it should adhere to Federation standards, such as SAML.
Corp. Resources

16. ADFS 2.0 federation gateway ADFS 2.0 Users Office 365 Azure
Partner Resources
Corp. Resources

17. ADFS 2.0 federation gateway Provisioning Service TRUST ADFS 2.0 Users
SharePoint Online
Federation Gateway
Users AD
ADFS 2.0
federation gateway
Exchange Online
Live ID
IdP
LiveID
Lync Online

18. Online Service based on WS* standards
Connection into Federation ecosystem
Billions of authentication daily
In production since 2006
Trust provisioning service – checks domain ownership through SSL certificate
federation gateway

19. a adfs 2.0 topology Fsconfig /createsqlfarm cloud adfs proxy 1
topology
adfs 1
adfs 2
ADFS uses SQL local database (WID) which can be shared between two ADFS servers
Fault tolerance is achieved when ADFS is set up in a SQL Farm (command line only)
ADFS Proxies can be places in the DMZ, if exposing the ADFS servers is a problem.
Hostnames for proxies and for the ADFS servers are the same. Manage through split DNS or HOSTS file.
Publishing the ADFS servers or proxies can be a challenge, due to complex URL’s
Fsconfig /createsqlfarm

20. Statements made about users which are understood & trusted by both partners in a federation
name, identity, group, role, privilege, capability
Used for authorization purposes within applications
Begins at the identity provider when the user provides credentials
Inserted into security tokens (SAML tokens) which follow a secure, standardized method of packaging the data for transport to a trusted partner
claims

21. adfs claims engine Stage 1: Accepting claims Stage 2:
Claims Provider Trust
adfs
claims engine
Incoming Claims
Stage 1:
Accepting claims
Stage 2:
Authorizing claims
Stage 3:
Issuing Claims
Acceptance Transform Rules
Issuance
Transform Rules
Permit
Relying
Party
Trust
Outgoing Claims
Issuance Authorization
Rules
Deny

22. adfs 2.0 components
Target Application
AuthN Store
Office 365
Active Directory
trust relationships

23. adfs 2.0 components endpoints
1. Passive Federation Endpoint – Browser based connections
2. Active Federation Endpoint – Rich clients (Lync 2010)
3. EAS Endpoint - Activesync, Outlook 2010, Exchange Web Services

24. adfs 2.0 components
acceptance transform
rules
c:[Type ==
=> issue(store = "Active Directory", types = (" " query = "samAccountName={0};userPrincipalName,objectGUID;{1}", param = regexreplace(c.Value, "(?<domain>[^\\]+)\\(?<user>.+)", "${user}"), param = c.Value);
c:[Type == "
=> issue(Type = " Value = c.Value, Properties[" = "urn:oasis:names:tc:SAML:1.1:nameid-format:unspecified");
c:[Type == "
=> issue(Type = " Value = regexreplace(c.Value, "
issuance transform rules
claim rules

25. agenda Intro ADFS 2.0 Overview Federated Authentication in Office 365
Single Sign On Configuration
agenda
Moving to the last topic, configuring Single Sign On through Identity Federation

26. add domain
convert
to federated later

27. $cred=Get-Credentials <credentials>
Connect-MsolService –Credential $cred
Set-MsolADFSContext –Computer <FQDN ADFS Server>
configure federation
connect to
MSOL
The first step is to connect to the MSOL environment by providing your credentials. This is the account that has Global Administrator in MSOL
When entering the MsolADFSContext, use the ADFS computer’s FQDN instead of the Federation Service name.

28. configure federation
New-MsolFederatedDomain –DomainName <domainname> -SupportMultipleDomain
add federated domain
Add the domain that is going to be federated through PowerShell.
Enter the information returned in your DNS configuration
Repeat the command, which will check if the DNS changes were correct
Result is the creation of a Relying Party Trust in ADFS

29. Directory Synchroni-zation
Directory Synchronization is used between Active Directory on-premises and Office 365
Federation requires DirSync in this scenario
Users’ UPNs are leveraged for account matching
Directory Synchroni-zation
The next step is configuring Directory Synchronization by connecting running the DirSync tool from a separate server. This tool cannot be run from the same server that runs ADFS
Only after DirSync is configured and the users are synced to MSOL, they can be associated with a license plan. So, Federation is technically not dependent on DirSync, but effectively it won’t work without.

30. Start-OnlineCoexistenceSync Directory Synchroni-zation
Configuring Dirsync is a multistep process.
Enable DirSync in MSOL Portal. This can take up to 24 hours.
Install the DirSync tool on a server
Connect both environments
Run Full Synchronization
Force Sync through PowerShell

31. login sequence sharepointlabs.nl ADFS 2.0 302 - Redirect cloud
Sign-In Service
cloud AD
ADFS 2.0
SharePoint Online
302 - Redirect
Authentication Token
UPN:
Source ID:
Exchange Online
SAML Logon Token
UPN:
Source ID: ABC123
404 - Authenticate … …
client

32. login sequence

33. Domain joined computer in corporate network
ADFS Server can use Windows Integrated AuthN
Domain joined computer, roaming
Publish ADFS Server
Home or public computer
User signs in with corporate credentials
Smartphone
Microsoft Outlook or other clients
Scenarios

34. Troubleshooting tools
MOSDAL (Microsoft Online Services Diagnostics and Logging) Support Toolkit
Fiddler
trouble
shooting

35. adfs additional reading
Update Rollup 1 for Active Directory Federation Services (AD FS) 2.0
Multiple Issuer Support
Client Access Policy Support
Congestion Avoidance Algorithm
Additional AD FS 2.0 performance counters kb
adfs additional reading

36. Web Services Federation Language (WS-Federation) Version 1
WS-Trust Version 1.3:
Security Assertion Markup Language (SAML) 2.0:
Microsoft AD FS 2.0 Release to Web (RTW) download:
Identity federation definition from Wikipedia:
more info

37. Microsoft Office 365 Single Sign-On (SSO) with AD FS 2.0
more info

38. Microsoft Office 365 Single Sign-On (SSO) with AD FS 2.0
more info
