2. WHO IS SIMATEK BULK SYSTEMS?
Development, sales, and servicing of bucket elevators since 1983
Flexible, gentle, and space-saving conveying system
Combined horizontal and vertical conveying of bulk products
Built in modules – individual customer solutions
The food processing industry, the pet food
industry, the grain and seed industry,
and the chemical industry
The first bucket elevator developed by
Simatek Bulk Systems. Today it
transports snacks and popcorn.

3. Marketing Coordinator
ORGANISATION - EMPLOYEES
Poul Andersen
Managing Director
Allan Andersen
Chief Accountant
Jakob S. Jensen
After Sales Manager
Claus Egemar
Engineer / Technology
Lars Nordal
Engineer / Technology
Torben Drost Larsen
Engineer / Technology
Thomas Kirchheiner
Engineer / Technology
Connie B. Søllested
Controller
Marc Kierdorf
Area Sales Manager
Mette B. Hansen
Marketing Coordinator
Jens Meng
Service Engineer
Per Jensen
Service Engineer
Klaus Holm
Workshop
Ulrik Aarup
Workshop

4. WHERE IS SIMATEK BULK SYSTEMS?

5. Simatek Bucket Elevator

6. SIMATEK BUCKET ELEVATOR - STANDARD
The most distinct advantages of Simatek bucket elevators:
Gentle conveying
Space-saving conveying system
Abrasive as well as fragile products
Flexible system
Variation
No risk of product mixing
Energy saving
Trouble-free cleaning
Easy maintenance
ATEX zone 21 and 22

7. SIMATEK BUCKET ELEVATOR - EASY CLEAN
Inspection doors and an open
construction ensure easy
access for cleaning and inspection
Produced in stainless steel
with a smooth finish
CIP-station for simple and
efficient cleaning
of buckets and chain
New inlet with inspection doors
for easy cleaning

8. SIMATEK BUCKET ELEVATOR – 12E
The small conveying solution
Small construction form
Bucket contents = 1.2 liters
Max. capacity = 5.0 m3/h

9. SIMATEK BUCKET ELEVATOR - CAPACITY
Type 12:
Bucket contents = 1.2 liters at 100% filling Max. capacity = 5.0 m³/h
Type 33:
Bucket contents = 3.3 liters at 100% filling Max. capacity = 13.4 m³/h
Type 110:
Bucket contents = 9.7 liters at 100% filling Max. capacity = 26.5 m³/h
Type 160:
Bucket contents = 16.0 liters at 100% filling Max. capacity = 45.7 m³/h
Type 200:
Bucket contents = 20.0 liters at 100% filling Max. capacity = 60.0 m³/h

10. SIMATEK BUCKET ELEVATOR – BUCKET QUALITY
PP-bucket (white)
Polypropylene approved for
the food industry
Max. temp.: 60°C (continuously)
PP-bucket (blue)
Polypropylene approved for
the food industry
Max. temp.: 60°C (continuously)
PP-bucket (+glass)
Polypropylene added glass for temperature stabilisation
Max. temp.: 90°C (continuously)
Antistatic bucket
Polypropylene in
anti-static execution
Max. temp.: 60°C (continuously)
Detectable bucket
Detectable polypropylene
- FDA-approved
Max. temp.: 60°C (continuously)
Stainless steel bucket
Bucket produced in
stainless steel
- AISI 304/316
Electroplate bucket
Electroplate bucket produced in mild steel (st. 37)

11. Simatek Accessories

12. ACCESSORIES – PRODUCT DISPENSER
(patent pending, PA )
Developed especially to optimize the capacity of bucket elevators
Extended operating reliability
Minimized product waste
Gentle product handling
Optimum and simple capacity control
Minimum maintenance required
Even and constant filling degree
Increased capacity
Longer life time on service parts and elevator

13. ACCESSORIES – CIP-STATION
Optimum cleaning inside and outside of the buckets
Elimination of bacterial growth contamination at product change
Optional programming of the cleaning cycle
Minimum consumption of water and air
Easy access for service purposes
External control and monitoring
Also mountable on existing machines

14. ACCESSORIES – MOBILE WASHING UNIT
Mobile washing unit for cleaning of several elevators
Produced to meet the still growing demands on hygienic conveying
of bulk products
Mountable on all Simatek bucket elevators
Efficient cleaning of buckets and chain
PLC-control
Optional programming of the cleaning cycle
Easy access for service purposes

15. ACCESSORIES – VIBRATING FEEDER
Ensures uniform product flow
Maximum use of elevator capacity
Minimal product wastage
No time wasted due to a blocked inlet
Variable settings for load-filling
Easy access for inspection and cleaning
Straightforward assembly and connection

16. ACCESSORIES – VIBRATING FEEDER
Ensures uniform product flow
Maximum use of elevator capacity
Minimal product wastage
No time wasted due to a blocked inlet
Variable settings for load-filling
Easy access for inspection and cleaning
Straightforward assembly and connection

17. ACCESSORIES – INTERMEDIATE OUTLET
May be installed according to requirements on the horizontal sections
CAD-designed curve guides ensure low friction and minimum wear
Activated by a compressed air cylinder
The cylinder is equipped with position indicators
with ”reed-switches”
The cylinder is controlled by a magnetic switch

18. ACCESSORIES – AUTOMATIC CHAIN TENSION
Extended operating reliability
A constant optimum chain tension
Extended lifetime of chains
Low maintenance costs
Also mountable on existing machines

19. ACCESSORIES – AUTOMATIC CHAIN LUBRICATION
Automatic chain lubrication system for the bucket elevators
Lower power consumption
Less noise
Higher reliability
Longer service life
Fewer interruptions of operation

20. Simatek After-Sales Service

21. SIMATEK AFTER-SALES SERVICE
- Individual service agreement
Advantages of a service agreement on Simatek bucket elevators:
Shutdowns minimised
Servicing carried out by specially trained service engineers
24-hour ”hotline” telephone service
Increase in total user-life of machines
On-going optimisation of machines and equipment
Detailed service report of each elevator once service is complete

22. Simatek Product References

23. SIMATEK PRODUCT REFERENCES
Fish feed
Fly ash
Grass seed
Dog biscuits
Cracklings
Marble
Chips
Caramels
Chewing gum
Meatballs
Wooden pellets
Peanuts
Pastilles
Spices
Rape
Petfood

24. SIMATEK GLOBAL SALES Scandinavia Europe Russia Asia USA
The Middle East
South America
Australia
