2. Smart Client Architecture Principles
Brenton Webster
Solutions Architect
D&PE Architecture Strategy Team Microsoft, Redmond, USA

3. Agenda What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

4. Agenda What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

5. Industry Momentum is Building for a New Client
“Web-based solutions just can’t provide the rich users interface and performance which users like our traders need.”
“The problems with browser-based approaches … have become all too well-known”
“The current enthusiasm for a browser-based enterprise is shortsighted. As firms trade in their desktop clients for browsers they’ll find: primitive functionality… bandwidth gluttony… terrible usability.”
“…It sounds a bit like heresy, but the web-based portal does not really make a very effective interface to functionality that resides in many systems"
“As proof of their disillusionment, a staggering one-third of IT decision makers report having plans for migrating some applications back to richer client environments.”
“The Client is Back” Jonathan Schwartz,
Sun’s president and COO
Opening remarks at JavaOne 2004
IBM Puts New Spin On Client Computing
(May 2004)

6. Smart Clients The Best Of Both Worlds
4/28/2017 1:56 PM
Smart Clients The Best Of Both Worlds
Smart Clients
Rich Clients
Thin Clients
Smart Data
Management
Rich User Experience
Network Dependency
Tough To Deploy
Easy To
Update
Offline Capable
Tough To
Update
Easy To
Deploy
Limited User Experience
High Developer
Productivity
Easy To
Manage
Fragile
“DLL Hell”
Responsive &
Flexible
Rich UI
Complex to
Develop
Smart Connection
Management
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

7. Smart Client Tenets Utilizes Local Resources Connected – Web Services
4/28/2017 1:56 PM
Smart Client Tenets
Utilizes Local Resources
Connected – Web Services
Support On- & Offline Scenarios
Intelligent Deployment & Update
Device Flexibility
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

8. Microsoft Smart Client Platforms
Windows Forms
Office System 2003
Windows Mobile
Current
Generation
Version 1.1
XML
Version 1.1
Next
Generation
Version 2.0
“Whidbey”
Version 2.0

9. Smart Client Examples Microsoft Thomson Dell
Alchemy
Project “Elixir”
Thomson
ThomsonONE
Dell
Dell Integrated Desktop
Commonwealth Bank of Australia

10. Alchemy Marketing MS Sales Siebel Clarify CRM 4/28/2017 1:56 PM
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

11. Customer Explorer Architecture
Microsoft Outlook
Alchemy Web Services
Customer Explorer AddIn
Siebel Read
Siebel Write
Other
Web Services
Elixir Outlook
Managed SDK
Outlook Object
Model
Siebel
AppServer
Other
Middleware
Siebel
OLTP

12. Thomson Financial

13. Dell Dell Integrated Desktop Improved call centre user experience
Improved end customer experience
Time per call: reduced 10%
Training time: reduced 45%
Significantly increased margins per sale
Better information available to call center rep
Anticipated 9x ROI
Case study

14. Commonwealth Bank of Australia
“Which new Bank” initiative
Excel in customer service
Empower and equip customer-facing staff
Simplify processes
CommSee: Bank-wide service solution
CommSee application
Infrastructure for new applications
Integrate existing apps
Consume backend services built across the bank
Tomorrow 12:20-13:50 Southport “Case Study: Commonwealth Bank of Australia”

15. Agenda Thin Client and Smart Client Architecture
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

16. Thin Client Architecture
4/28/2017 1:56 PM
Thin Client Architecture
Client
Web Server
‘Deployment’
Browser
Page
Data
UI Logic UI
Page
Business
Logic
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

17. Smart Client Architecture
4/28/2017 1:56 PM
Smart Client Architecture 3
Client
Web Server
Deployment 4
Smart
Client
Smart Client
Business
Logic
User Interface 5
Web Service 2
Business
Logic 1
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

18. Agenda Smart Client Architectural Issues What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Handling Data
Going Offline
Deployment
Security
Using Multiple Threads
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

19. Types of Data Read-only Reference Data Transient data
Static reference or lookup data
Used for
Data validation
Formulate service request
Versioned, time-stamped
Eg: pick lists, country codes, price lists
Transient data
Editable data
Need to keep track of changes
Consider concurrency and volatility
Eg: customer details, orders etc…

20. Transient data Predicted validity Offline: Yes
Low Volatility
Low Concurrency
High Volatility
High Concurrency
Predicted validity
P(Valid) = 1.0
P(Valid) = 0.0 My
Calendar
Your
Calendar
Inventory
Stock
Quotes
Offline: Yes
No body else will ever edit it
Typically “single user” or “private”
Offline: No
Chance of data being valid is low
Typically “multi user” or “public”

21. Handling Data Caching Design for concurrency Security Going Offline
For performance and/or offline
Long term / Short term
Data expiration & constraints
Design for concurrency
Pessimistic
Optimistic
Security
Only provide data to which the user is authorized
Protected sensitive data
Use encryption and/or ACL’s
Consider multi-user scenarios
Going Offline
Decide what data and logic is required
Synchronizing changes

22. Agenda Smart Client Architectural Issues What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Handling Data
Going Offline
Deployment
Security
Using Multiple Threads
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

23. Connected & Disconnected
4/28/2017 1:56 PM
Connected & Disconnected
‘Connectedness’
Always – Network connection essential
Mostly – Infrequently disconnected
Sometimes – Disconnected for significant amount of time
Intermittent – Connectivity nice to have and/or expensive
Offline – Explicitly offline
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

24. RDBMS-Based Merge Replication
4/28/2017 1:56 PM
Data Centric Approach
RDBMS-Based Merge Replication
Advantages
Data changes direct
Infrastructure provided
Disadvantages
Heavy-weight client-side Infrastructure
Tight coupling between client and server
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

25. Message Centric Approach
4/28/2017 1:56 PM
Message Centric Approach
Message-Based Data Synchronization
Advantages
Loose coupling between client and server
Light-weight client infrastructure
Disadvantages
Data changes indirect
Need to provide conflict resolution code
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

26. Offline Application Block
4/28/2017 1:56 PM
Offline Application Block
Offline block provides
Pluggable & extensible set of components
Enables message oriented smart client applications to operate offline
Storage & execution of deferred service requests
Pluggable online/offline detection component
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

27. Agenda Smart Client Architectural Issues What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Handling Data
Going Offline
Deployment
Security
Using Multiple Threads
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

28. Smart Client Deployment
4/28/2017 1:56 PM
Smart Client Deployment
Deploy the .NET framework
Pre-install
Enterprise Deployment Tools – SMS
Group policy
Require users install it (Windows Update, file share etc..)
Install with application
Bake into MSI
Built into Windows 2003 Server, Longhorn and beyond
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

29. Smart Client Deployment (2)
Application deployment
No-Touch Deployment
Hybrid: No-Touch Deployment with application update stub
XCOPY
Run from file share
MSI
Visual Studio 2005 “Whidbey” – ClickOnce

30. No-Touch Deployment Deployment Server Client Application Download
4/28/2017 1:56 PM
No-Touch Deployment 1
Application URL
Deployment
Server
App
Client
Config 3
Application
Download
Cache 2
Assembly
Config
Assembly
App
Config
.NET Framework
Assembly
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

31. NTD Limitations Config files not downloaded by default
Restricted default security settings
Write to disk
Use unmanaged code
Deploy things requiring registration
Access resources no on originating server
Un-reliable offline functionality
Lazy downloading
IE cache
Dependant on IE “Offline” setting
No transacted installation

32. NTD + Update stub Deployment Server Client Application Application
4/28/2017 1:56 PM
NTD + Update stub 3
Updater
Downloader
Validator
Post-Proc
Deployment
Server
Stub 2 4
Manifest
Client 6
App
Application
Config
Assembly
Application
Folder
App
Assembly
Config 5
Config
Assembly
.NET Framework 1
Policy
Changes
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

33. Requires policy changes
Decisions, Decisions…
NTD
NTD + stub
File share
Xcopy
MSI
Reliable Offline Y
Full trust functionality
Requires policy changes
Non-power user install
Depends
Low system impact
Windows shell integration
Unrestricted installation
Transacted installation
Modify client security policy
Y – for elevated perms
Y – app stub

34. Recommendations No touch deployment is problematic
Not suitable for most Smart Clients
Use NTD Hybrid or Windows Installer
Different in initial invoke mechanism
Goto URL
Goto URL, click “Open”
Favor Windows Installer
Visual Studio 2005
Click Once
Windows Installer

35. Updating Somewhat orthogonal to deployment No-touch deployment
Update web server
Automatic Updates
Build features into app
Updates from a file share
Update file share
Xcopy updates
Copy over files
Windows Installer
Patch package (*.msp)
Update existing MSI
Create new MSI

36. Application Updater Block
4/28/2017 1:56 PM
Updater
Downloader 1
Validator
Deployment
Server 2
Post-Proc
Manifest
Client
App 4
Application
Application
Folder
Config
Assembly 3
Config
App
Assembly
Config
.NET Framework
Assembly
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

37. Decisions, Decisions… NTD Application Updater File share Xcopy
Windows Installer
Non-power user update Y
Depends
Centralized management
Updates d/l when app run
Federate update infrastructure
Per user/group updates
Transacted updates
Built in support for version control

38. Recommendations Build update infrastructure into your app
Suits most scenarios
You have to build stuff
Application Updater Block available
Leverage Windows Installer
Good for enterprise scenarios

39. Agenda Smart Client Architectural Issues What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Handling Data
Going Offline
Deployment
Security
Using Multiple Threads
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

40. Security Considerations
The service is the trust boundary
The client can not be trusted
Defense in depth
Authentication
Authorization
Data Validation
Protecting sensitive data
Auditing and Logging
Exception Management
Change Management

41. Sensitive Data Avoid caching sensitive data where possible
If you have to cache it, protect it
Ensure only authorised users can access
EFS
DPAPI
Store hashed values, not plain text
Isolated storage for partially trusted applications
Protect private keys
Validate all requests at the server

42. Code Access Security Partial Trust is great in theory…
Most Smart Client apps will want to
Access servers other than the originating host
Access local file system
Interact with local applications eg Office
Access unmanaged code eg COM objects
Most Smart Client apps will require full trust
Full trust != free for all
Still subject to underlying OS security

43. Agenda Smart Client Architectural Issues What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Handling Data
Going Offline
Deployment
Security
Using Multiple Threads
Summary
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

44. Using Multiple Threads
4/28/2017 1:56 PM
Using Multiple Threads
Use Background Thread For
Interacting with services over a network
Lengthy local processing - IO bound
App startup & initialization
Using Threads
Thread Object
Delegates, Web Service Proxy
Thread Pool
UI Thread
All UI interactions MUST occur on UI thread
VS 2005: BackgroundWorker
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

45. Service Agents and Tasks
4/28/2017 1:56 PM
Service Agents and Tasks
Client
Web Server
Service
Agent
Web Service
Main Form
Task Object
Worker
Thread
Control.Invoke
UI Thread
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

46. Agenda Summary What is a Smart Client?
4/28/2017 1:56 PM
Agenda
What is a Smart Client?
Thin Client and Smart Client Architecture
Smart Client Architectural Issues
Summary
Resources
Q&A
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

47. Summary Smart Clients Handling Data Utilises local resources
Consumes Web Services
Supports on/offline scenarios
Intelligent deployment and update
Device flexibility
Handling Data
Minimum data and make sure it’s secure
Design for concurrency
Cache reference data appropriately
Keep track of tentative changes to writable data

48. Summary (2) Going Offline Deployment and update
Decide what functionality you need when offline
Synchronization
Keep dependencies between service requests to a minimum
Be prepared for concurrency errors
Deployment and update
Today’s NTD has problems
MSI + Auto Update great for most scenarios
VS 2005: ClickOnce

49. Summary (3) Security Using Multiple Threads
4/28/2017 1:56 PM
Summary (3)
Security
You can not trust the client
Authentication
Authorisation
Protect sensitive data
Code Access Security
Partial trust great in theory
Many applications will require full trust
Using Multiple Threads
Only UI thread to service UI
Hide nasty-ness: Task pattern or BackgroundWorker
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

50. Smart Client Resources
4/28/2017 1:56 PM
Smart Client Resources
Learn about the .NET Framework
Sample code, forums, articles, etc.
Check out the Windows Forms Quick Start in the SDK
Visual Studio Tools for Office, etc.
dotnet.framework.windowsforms
office.developer.*
MSDN Architecture Center
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

51. patterns & practices Resources
4/28/2017 1:56 PM
patterns & practices Resources
Smart Client Architecture Guide
Application Blocks
Offline Application Block
Application Updater Block
V2 coming soon…
Enterprise Library (inc Caching)
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

52. Q&A Please fill in your evals! 4/28/2017 1:56 PM
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.

53. 4/28/2017 1:56 PM © 2005 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. MICROSOFT MAKES NO WARRANTIES, EXPRESS OR IMPLIED, IN THIS SUMMARY.
© 2004 Microsoft Corporation. All rights reserved.
This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
