1. NN-CS596S Steam Microwave Oven

2. NN-CS596S Oven Specification

3. Placement of Oven Counter Top Only

9. Display Window

10. Control Panel

11. Dial Feature

12. To Test Circuit Breaker 1. Ensure the switch of Circuit Breaker is in the “I” position. 2. Press the 'TEST' key,if the switch goes back to “O” position, it means the Breaker is working correctly. Circuit Breaker

13. E.g ： During microwave High Power, 5 minutes, when desired to add 2 minutes, Simply to turning the Time/Weight dial clockwise (Maximum adding time is 10 min. Quick Min Time Setting (This feature allows you to add or reduce time During Cooking) Add cooking time by turning Time/Weight dial

14. Steam & Micro Power Start Steam & Micro Power Setting Set desired time Notes: 1 、 Always check the water into tank before use 2 、 In “Steam & Micro power” function, the microwave power level is “medium-low” or “low”. 3 、 If setting “Steam & Micro power” function as the first stage, it needs 1 minute for preheating. * This 1 minute is not included in the original setting cooking time. * “Steam & Micro power” feature can only be used once and can not be used with Grill and Combination. * If “Steam & Micro power” is the 2 nd stage,no matter the 1 st stage is which cooking,MWO will not preheat. Press once

15. There are two power levels of Steam & Micro Power Setting. You can press [ Steam & Micro Power ]pad or turn [Menu/Power/Temp.] dial to select. Steam & Micro Power Setting

16. When [start] pad is pressed, oven starts to preheat (Steam Heater + 30sec. Upper Heater.),when the temperature of Steam Heater rises above 200C, the water supply begins. It will take approx 1 minute for preheating. *After 1 minute preheating is completed, it will turn into actual cooking process. Steam & Micro Power Setting

17. E.g ： Add 1 minute during convection Steam Shot Setting Convection proceeding Keep pressing for 2 seconds and 1 minute will be added. If you want to add 3 minutes, press [Steam & Micro Power] pad twice again within 5 seconds after step 2.

18. Notes ： 1 、 This feature allows you add steam just during Convection, Grill Convection or grill setting. 2 、 When using “Steam Shot” function ， the original setting is still counting down 。 3 、 The setting time can not exceed the remaining cooking time. 4 、 This feature allows you to add steam most for 3 minutes. 5 、 If steam shot functions during the grill heaters work, the heaters have to be stopped a while to keep the steam shot works normally. ( To prevent excess input current) 6 、 Always check the water in the tank before use. Steam Shot Setting

19. Water Tank &Water Level Indication

20. Water Tank & Light

21. Water Tank & Slot Water Tank Assembly Connector Light up LED

22. Water Tank & Valve Spring to close Valve Washer to stop leaking water when water tank is removed from oven Valve Washer Tank spring

23. Water Tank Seal/Connector Rubber gasket for sealing 350 cc Plug connector

24. Water Flow Route Water Tank Pump Evaporating Channel

25. Steam Generator Steam Evaporating Channel Nozzle A

26. Steam Reheat setting Setting to get higher or lower temperature (according to the favor or actual ) window appears “MORE + ” or “ LESS - ” （ Optional step ） Sensor Reheat /Steam Reheat Start Press twice

27. Steam Reheat setting Notes: 1 、 Best performance of this function shall be amount of 200g—600g. （ If less than 100g, it is difficult to detect by sensor and may be possible over heated ） 2 、 If the temperature of the cavity is too high, display window will appear "HOT", steam reheat feature can not be used. 3 、 This feature is only suitable for cooked rice or meal. 4 、 This feature is not suitable for reheating liquids. 5 、 Do not cover or wrap. 6 、 Always check the water into tank before use.

28. 1 、 If the cavity is too hot,"HOT" will appear and “Steam defrost” function does not allow to be used. 2 、 Always check the water in the tank before use. Defrost by Steam setting Steam Defrost Start The serving/weight (0.1Kg – 3.0 Kg) Press once Set required weight

29. Drain Function Steam Defrost Start Drain function Keep Pressing more than 2 seconds 1.When using Drain function, water tank must be removed unless water remains in the tank will be also drain. 2.It can be used up to 3 times. For further use, wait for 10 minutes.

30. Cleaning Function Auto Cook 26 (clean cavity) Start 1 、 Use with full of water in water tank Wait until timer elapsed and cooled down oven 5 Beeps !!!!! 1 2 3 4 5 2 、 This feature ， 30 minutes is needed

31. Cleaning Function Program Auto cook “26” for Cavity Cleaning After oven beeps 5 times, remove the softened dirt by using damp cloth

32. Notes: 1 、 Best performance of this function shall be amount of 200g—600g. （ If less than 100g, it is difficult to detect by sensor and may be possible over heated ） 2 、 The initial default temp. is 70 ℃. For second time, if the first temp was between 55 ℃ ~ 75 ℃, that will become as default temperature. 3 、 If the oven cavity temperature is too high like after grill cooking, “HOT” to indicated and need cooling down oven to use this sensor reheat. 。 4 、 The plastic film should cover the food tightly. 5 、 Temperature setting is 5 ℃ increment. Sensor Reheat /Steam Reheat Start Press once IR(Infrared) Sensor Set desired temperature (-10 ℃ - 90 ℃ )

33. Display After setting the desired the temperature of food and pressing [Start] pad, the setting temperature will appear in the right side of windows, After detecting for a period of time (about 50 seconds to 1 minute),the approximate current temperature will appear in the left side of window, and rise gradually. IR sensor detects the temperature at each point in the oven, and regards the maximum temperature as the actual temperature. If using straight-sided container with narrow necks (such as feeder), due to the speed of rising temperature where in mouth position is faster than the other positions, so the senor error would become great, and will cause the MWO would finish reheating though the food/drink temperature have not reach the set value. IR(Infrared) Sensor Detecting temperature

34. IR SENSOR Location of IR(Infrared) Sensor

35. IR(Infrared) Sensor Temperature Monitor Hole

36. How to Measuring Temperature Move IR sensor to monitor 8 x 19 points IR Sensor Oven front Shelf Position 8 eyes

37. Sensor Reheat How to arrange the containers

38. This feature provides 4 modes to select ： Convection, Grill Convection, Grill & Combination Heater Select Setting

39. Without Preheat Heater Select Start After preheating (put the food into oven) Set desired Temperature (100 ℃ - 300 ℃ ) Convection/ Grill Convection Convection Operation With Preheat Start Set time (Max time, 90 min. 00 sec.) 1 time for preheat Default 110 ℃ * To select “Convection”: Press once * To select “Grill Convection”: Press twice

40. Placement of Crispy Pan please insert into the support shelf as illustrated in the figure. Do not put oven tray directly on the support shelf or ceramic plate to avoid the risk of fire. Convection Operation Convection/ Grill Convection

41. 1 、 During Convection and Grill Convection, you can turn 【 Menu/Power/Temp. 】 dial to adjust the temperature. 2 、 During Convection and Grill Convection, you can press 【 Heater Select 】 pad to display the setting temperature. Notes: Convection/ Grill Convection Convection Operation If only convection heater works, convection fan & cooling fan would rotate for 5 minutes after cooking to cool oven and electric components.

42. Ferment Operation Heater Select Start Turn the dial anti- clockwise to set 40 ℃ Set time (Max time, 90 min. 00 sec.) Press once

43. Combination Grill / Combination feature Grill

44. Variable power cooking control Micro Power

45. 1 、 After Heater operation Cooling fan Extend 5 minutes Fan operation 2 、 More than 3 minutes MWO operation 3 、 More than 2 times MWO cooking with less than 10 minutes interval Extend 1 Minute Fan operation Post Fan Operation 5 min. 1 min.
