Application Note Fiber Connectivity Riedel solutions for broadcast applications 1 Application Note - Fiber Connectivity.

Published byAlexia Sparks Modified over 8 years ago

Similar presentations

Presentation on theme: "Application Note Fiber Connectivity Riedel solutions for broadcast applications 1 Application Note - Fiber Connectivity."— Presentation transcript:

1 Application Note Fiber Connectivity Riedel solutions for broadcast applications 1 Application Note - Fiber Connectivity

2 Application Note Fiber Connectivity 2 Content Fiber Basics Riedel Portfolio Application examples

3 Application Note Fiber Connectivity 3 Fiber Cable – Propagation Modes – Multi-mode Multiple modes travel through the fiber Modes enter in different angles and therefor travel in different speeds through the fiber Modal Dispersion and reflection losses limit the maximum length of multi mode fiber cables Travels fasterTravels slower Different modes

4 Application Note Fiber Connectivity 4 Fiber Cable – Propagation Modes – Single-mode Ony one mode travels through the fiber No modal dispersion or reflection losses -> longer distances possible core cladding

5 Application Note Fiber Connectivity 5 Fiber Cable – Water Peak Attenuation depends on wavelength High attenuation for short and long wavelengths Absorped water in productions process causes attenuation peak = Water Peak 3 windows for optical transmission with low attenuation Rayleigh Infrared 1. window 850nm 2. window 1300nm 3. window 1550nm O-H-Absorption

6 Application Note Fiber Connectivity 6 Fiber Cable – Water Peak Low-Water-Peak-Fiber Improved production process with nearly no water improves attenuation

7 Application Note Fiber Connectivity 7 Fiber Cable – Attenuation Insertion Loss (IL)-> Losses on connector / connector – transitions Attenuation of the fiber-> Losses on the fiber path Splice attenuation-> Losses caused by connecting fibers Return Loss (RL)-> Losses on the fibers end / plug connectors Flat PC (=Physical Contact) The ferrules physically contact each other instead of a air gap in between. Reflection: -30 dB PC (=Physical Contact) The ferrules touch only at their cores. Typical Back Reflection: < -40 dB APC (= Angle Physical Contact) The ferrule has a 8° angle which minimizes back reflection. Typical Back Reflection: < -60 dB Typical average attenuation of fiber cables is between 0.25 and 0.35 dB/km.

8 Application Note Fiber Connectivity 8 Wavelength Division Multiplexing (WDM) Multiplexes 3 colours on a optical carrier signal Uses 3 wavelengths 1310nm, 1490nm and 1550nm

9 Application Note Fiber Connectivity 9 Coarse Wavelength Division Multiplexing (CWDM) Multiplexes 18 channels on a optical carrier signal Uses 18 channels of wavelengths between 1270 and 1610 nm Each channel is 20 nm wide (13 nm channel width + 7 nm security space

10 Application Note Fiber Connectivity SFP Modules (Small form-factor pluggable) 10 Electrical – optical conversion and vice versa Available data rates up to 4,25 Gbit/s Multi-mode and single-mode

11 Application Note Fiber Connectivity Most SFP modules are bidirectional The optical power of a SFP module varies in a defined range 11 Optical Budget RX TX RX TX RX Min. -8.4 dBm Max. -1 dBm Max. -18 dB Min. 0 dB Optical Budget

12 Application Note Fiber Connectivity 12 Optical Budget TX.Min. -8.4 dB RX Max. -18 dB Loss of connectors, MUX / DEMUX etc. ~ 2 dB Loss of connectors, MUX / DEMUX etc. ~ 2 dB 5.6 dB for losses of the fiber 9,6 db = 10km 18 dB = 40km 24 dB =80km Factual Optical Budget

13 Application Note Fiber Connectivity 13 Optical Budget RX TX Mux RX TX Demux Optical budget Loss 10km cable length -8,4-8,9-9,4-9,9-10,4-13,4-13,9-14,4-14,9-15,5 0,5 3

14 Application Note Fiber Connectivity 14 Optical Budget RX TX Mux RX TX Demux Optical budget Loss 20km cable length -8,4-8,9-9,4-9,9-10,4-16,4-16,9-17,4-17,9-18,5 0,5 6

15 Application Note Fiber Connectivity 15 Content Fiber Basics Riedel Portfolio Application examples

16 Application Note Fiber Connectivity 16 Riedel Fiber Cable Extremely rugged TAC (Tactical) fiber cable Very flexible, abrasion & chemical resistant PURE jacket Low bending radius (G.657A specified) No waterpeak – fully CWDM applicable Exclusively with Neutrik opticalCON QUAD or opticalCON DUO connectors

17 Application Note Fiber Connectivity 17 Riedel Products with Wavelength Division Multiplexing (WDM) WDM Option for MediorNet Compact with Neutrik QuadCon 1310nm 1490nm 1550nm

18 Application Note Fiber Connectivity 18 Riedel Products with Wavelength Division Multiplexing (WDM) WDM Option for MediorNet Compact with Dual LC 1310nm 1490nm 1550nm

19 Application Note Fiber Connectivity 19 Riedel Products with Wavelength Division Multiplexing (WDM) Fiber Accessories – MC-WDM WDM Dual Multiplexer and Demultiplexer for up to 6 duplex fiber connections Total 25Gbit/s bandwidth in combination with MediorNet 6 duplex fiber links can be connected via WDM single-mode SFPs

20 Application Note Fiber Connectivity 20 Riedel Products with Coarse Wavelength Division Multiplexing (CWDM) MN-LNK8-CWDM(80) Max. 25.6 Gbit/s net bandwith 4 internal SFP ports 4 external fiber ports via LC connectors (1351nm, 1371nm, 1391nm, 1411nm) CWDM80 version is equipped with high power SFP for max. 80 km of fiber length

21 Application Note Fiber Connectivity 21 Riedel Products with Coarse Wavelength Division Multiplexing (CWDM) MN-LNK8-CWDM(80)-H Same features as MN-LNK8-CWDM(80) 4 external fiber ports via LC connectors (1551nm, 1571nm, 1591nm, 1611nm)

22 Application Note Fiber Connectivity 22 Coarse Wavelength Division Multiplexing (CWDM) in MediorNet MN-LNK10-CWDM Max. 32 Gbit/s net bandwith 8 internal SFP ports 2 external fiber ports via LC connectors

23 Application Note Fiber Connectivity 23 Coarse Wavelength Division Multiplexing (CWDM) in MediorNet MN-LNK18-CWDM Max. 57.6 Gbit/s net bandwith 8 internal SFP ports 10 external fiber Ports via LC connectors (already multiplexed)

24 Application Note Fiber Connectivity 24 Coarse Wavelength Division Multiplexing (CWDM) in MediorNet Fiber Accessories – MC-CWDM CWDM Dual Multiplexer and Demultiplexer for up to 18 duplex fiber connections 18 duplex fiber links must be connected via WDM single-mode SFPs Additional LC connector

25 Application Note Fiber Connectivity 25 Riedel SFPs Artist SFPs Item Nr.MatchcodeConnectorProducts 1090002ART-Z-SFP-CPU-MM-850-8,5-1,25GbpsLC DuplexCPU-128F G2 SET 1090003ART-Z-SFP-CPU-MM-1310-10-1,25GbpsLC DuplexCPU-128F G2 SET 1090004ART-Z-SFP-CPU-MM-1310-10,5-1,25GbpsLC DuplexCPU-128F G2 SET 1090083ART-Z-SFP-PMX-SM-TX1310/RX1550-18-155MbpsLC SimplexPMX 2004; PMX 2008 1090084ART-Z-SFP-PMX-SM-TX1550/RX1310-18-155MbpsLC SimplexPMX 2004; PMX 2008 MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

26 Application Note Fiber Connectivity 26 Riedel SFPs MADI SFPs Item Nr.MatchcodeConnectorProducts 1990047SFP-MADI-MM-850-14-155MbpsLC Duplex MADI-108-G2 SET PMX 2004; PMX 2008; RN 334 MD RP; MN-MA2-EO 1990002SFP-MADI-MM-1310-7,5-155MbpsLC Duplex 1990003SFP-MADI-SM-1310-19-155MbpsLC Duplex MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

27 Application Note Fiber Connectivity 27 Riedel SFPs MediorNet Video / HDMI SFPs Item Nr.MatchcodeConnectorProducts 1990014MN-Z-SFP-SM-1310-9,6-3GbpsLC DuplexMN-HDO-4IO 1990041MN-Z-SFP-HDMI-InHDMIMN-HDO-4IO 1990042MN-Z-SFP-HDMI-OutHDMIMN-HDO-4IO 1990043MN-Z-SFP-CompositeHD-BNCMN-HDO-4IO 1990048MN-Z-SFP-SDI-3GbpsHD-BNCMN-HDO-4IO 1990044MN-Z-SFP-GV-LC-1310-9,6LC DuplexMN-GV-2 (Spare) MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

28 Application Note Fiber Connectivity 28 Riedel SFPs MediorNet Ethernet SFPs Item Nr.MatchcodeConnectorProducts 1990022MN-Z-SFP-ETH-SM-1310-15LC DuplexMN-ETH6 1990017MN-Z-SFP-100baseT-CAT5RJ45MN-ETH6 MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

29 Application Note Fiber Connectivity 29 Riedel SFPs MediorNet LNK SFPs Item Nr.MatchcodeConnectorProducts 1990001MN-Z-SFP-MM-850-5-4,25GbpsLC DuplexMN-LNK2, MN-LNK4 1990005MN-Z-SFP-SM-1310-9,6-4,25GbpsLC DuplexMN-LNK2, MN-LNK4 1990006MN-Z-SFP-SM-1310-18-4,25GbpsLC DuplexMN-LNK2, MN-LNK4 1990039MN-Z-SFP-SM-1550-18-4,25GbpsLC DuplexMN-LNK2, MN-LNK4 1990040MN-Z-SFP-SM-1550-24-4,25GbpsLC DuplexMN-LNK2, MN-LNK4 MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

30 Application Note Fiber Connectivity 30 Riedel SFPs MediorNet CWDM SFPs, 18dB Item Nr.MatchcodeConnectorProducts 1990008 MN-Z-SFP-SM-C1xx1-18-4,25GbpsLC Duplex MN-LNK8-CWDM MN-LNK8-CWDM-H MN-LNK8-CWDM80 MN-LNK8-CWDM80-H MN-LNK10-CWDM MN-LNK18-CWDM 1990009 1990018- 1990021 1990023- 1990034 MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

31 Application Note Fiber Connectivity 31 Riedel SFPs MediorNet CWDM SFPs, 24dB Item Nr.MatchcodeConnectorProducts 1990106- 1990123 MN-Z-SFP-SM-C1xx1-24-4,25GbpsLC Duplex MN-LNK8-CWDM MN-LNK8-CWDM-H MN-LNK8-CWDM80 MN-LNK8-CWDM80-H MN-LNK10-CWDM MN-LNK18-CWDM MN-Z-SFP-SM-1310-9,6-3Gbps Single-mode WavelengthOpt. Budget Data Rate

32 Application Note Fiber Connectivity 32 Content Fiber Basics Riedel Portfolio Application examples

33 Application Note Fiber Connectivity 33 WDM Application Examples MediorNet Compact 25Gbit/s full redundant network with Neutrik QuadCon 25 Gbit/s redundant net signal capacity can be shared by all devices (50 Gbit/s non-redundant) High capacity on a low number of cables  Ideal for mobile applications Each frame can connect 12 HD (720p or 1080i) signals to the network (maximum amount of SDI interfaces per frame)

34 Application Note Fiber Connectivity 34 WDM Application Examples MediorNet network with Compact and Modular Fiber Accessories with WDM to connect Modular with Compact over Quad Con Cable 12 HD-SDI signals over one fiber cable

35 Application Note Fiber Connectivity 35 WDM Application Examples What to order for each connection 1310nm 1490nm 1550nm Item NrMatchcode 1930002MN-LNK2 1930003MN-LNK4 1990025MN-Z-SFP-SM-C1311-18-4,25Gbps 1990025MN-Z-SFP-SM-C1311-18-4,25Gbps 1990028MN-Z-SFP-SM-C1491-18-4,25Gbps 1990028MN-Z-SFP-SM-C1491-18-4,25Gbps 1990031MN-Z-SFP-SM-C1551-18-4,25Gbps 1990031MN-Z-SFP-SM-C1551-18-4,25Gbps 1972002MC-WDM-Q Order List:

36 Application Note Fiber Connectivity 36 25.6 Gbit/s net CWDM Application Examples LNK8-CWDM with LNK4 on ADD port

37 Application Note Fiber Connectivity 37 CWDM Application Examples LNK8-CWDM with LNK4 on ADD port 8 high-speed links configured for fiber connectivity 8 high-speed links left for video connectivity LNK8-CWDM LNK4 Video

38 Application Note Fiber Connectivity 38 CWDM Application Examples LNK-8 CWDM: 2 Options of the Card available: External Wavelengths: 1351nm, 1371nm, 1391nm, 1411nm External Wavelengths: 1551nm, 1571nm, 1591nm, 1611nm

39 Application Note Fiber Connectivity 39 CWDM Application Examples LNK-8 CWDM: 2 Options of the Card available: LNK8-80 is equiped with high power SFPS for longer distances

40 Application Note Fiber Connectivity 40 CWDM Application Examples LNK8-CWDM with LNK4 on ADD port Item NrMatchcode 1930006MN-LNK8-CWDM 1930003MN-LNK4 1990018MN-Z-SFP-SM-C1351-18-4,25Gbps 1990019MN-Z-SFP-SM-C1371-18-4,25Gbps 1990020MN-Z-SFP-SM-C1391-18-4,25Gbps 1990021MN-Z-SFP-SM-C1411-18-4,25Gbps Order List: LNK8-CWDM80 with LNK4 on ADD port Item NrMatchcode 1930006MN-LNK8-CWDM80 1930003MN-LNK4 1990110MN-Z-SFP-SM-C1350-24-4,25Gbps 1990111MN-Z-SFP-SM-C1370-24-4,25Gbps 1990112MN-Z-SFP-SM-C1390-24-4,25Gbps 1990113MN-Z-SFP-SM-C1410-24-4,25Gbps Order List:

41 Application Note Fiber Connectivity 41 CWDM Application Examples LNK8-CWDM-H with LNK4 on ADD port Item NrMatchcode 1930006MN-LNK8-CWDM 1930003MN-LNK4 1990031MN-Z-SFP-SM-C1551-18-4,25Gbps 1990032MN-Z-SFP-SM-C1571-18-4,25Gbps 1990033MN-Z-SFP-SM-C1591-18-4,25Gbps 1990034MN-Z-SFP-SM-C1611-18-4,25Gbps Order List: LNK8-CWDM80-H with LNK4 on ADD port Item NrMatchcode 1930006MN-LNK8-CWDM 1930003MN-LNK4 1990120MN-Z-SFP-SM-C1551-24-4,25Gbps 1990121MN-Z-SFP-SM-C1571-24-4,25Gbps 1990122MN-Z-SFP-SM-C1591-24-4,25Gbps 1990123MN-Z-SFP-SM-C1611-24-4,25Gbps Order List:

42 Application Note Fiber Connectivity 42 32 Gbit/s net CWDM Application Examples LNK10-CWDM with LNK2 on ADD port

43 Application Note Fiber Connectivity 43 CWDM Application Examples LNK10-CWDM with LNK2 on ADD port MN-LNK10-CWDM 10 high-speed links configured for fiber connectivity 6 high-speed links left for video connectivity Video MN-LNK2 Video

44 Application Note Fiber Connectivity 44 CWDM Application Examples LNK10-CWDM with LNK2 on ADD port Total net data rate 32 Gbit/s External ports are multiplexed passively to the MUX port  Frame with card has no access to signals ! Removable 3dB attenuation Calculated fiber length in data sheet:

45 Application Note Fiber Connectivity 45 CWDM Application Examples LNK10-CWDM with LNK2 on ADD port Item NrMatchcode 1930004MN-LNK10-CWDM 1930002MN-LNK2 1990008MN-Z-SFP-SM-C1431-18-4,25Gbps 1990009MN-Z-SFP-SM-C1451-18-4,25Gbps Order List:

46 Application Note Fiber Connectivity 46 57.6 Gbit/s net CWDM Application Examples LNK18-CWDM with LNK10 and LNK2 on ADD port

47 Application Note Fiber Connectivity 47 CWDM Application Examples LNK18-CWDM with LNK10 and LNK2 on ADD port MN-LNK18-CWDM Video MN-LNK10-CWDM MN-LNK2 8 high-speed links configurated for fiber connectivity 8 high-speed links left for video connectivity 10 high-speed links configurated for fiber connectivity 6 high-speed links left for video connectivity

48 Application Note Fiber Connectivity 48 CWDM Application Examples Total net data rate 57.6 Gbit/s External ports are multiplexed passively to the MUX port  Frame with card has no access to signals ! Removable 3dB attenuation Calculated fiber length in data sheet: LNK18-CWDM with LNK10 and LNK2 on ADD port

49 Application Note Fiber Connectivity 49 CWDM Application Examples LNK18-CWDM with LNK10 and LNK2 on ADD port Item NrMatchcode 1930006MN-LNK18-CWDM 1930003MN-LNK10-CWDM 1990031MN-LNK2 1990032MN-Z-SFP-SM-C1431-18-4,25Gbps 1990033MN-Z-SFP-SM-C1451-18-4,25Gbps Order List: 1431nm 1451nm 1271 – 1451nm

50 Application Note Fiber Connectivity Thank you. For more information please visit www.riedel.netwww.riedel.net
