2. Unleashing Extreme Performance and Scalability
On Oracle Exalogic Elastic Cloud
Gavin Parish
Product Manager
Oracle Exalogic
Sergey Linetskiy
Consulting Member of Technical Staff
Oracle Public Cloud
Sandeep Rohilla
Solutions Architect
Agilent Technologies
October 02, 2014
Copyright © 2014, Oracle and/or its affiliates. All rights reserved. |

4. Program Agenda 1
Exalogic 101 Enhancements OOTB Overview Performance Benchmarks Results Enabling Exalogic Enhancements Tuning for Maximised Performance in the Real world – Agilent Case Study 2 3 4 5

5. Exalogic: Hardware and Software Working Together
Exalogic Elastic Cloud Software
Cloud Management
System Software
App & FMW Enhancements
x86 Compute Nodes
Storage
InfiniBand Switches
InfiniBand HCAs
Infrastructure-as-a-Service
Platform-as-a-Service
Exabus, Oracle Traffic Director
Firmware
Lifecycle tooling
Enhancements to WebLogic, Coherence, JVM, EBS, PeopleSoft, ATG, etc

6. Exalogic System Hardware Overview
Fast. Easy. Open.
Compute
I/O Fabric
Storage
2 socket, 12-core, 2.7 GHz Intel Xeon processors
256 GB of 1600MHz DRAM
(2) 400 GB SSDs
Dual-port QDR InfiniBand HCA (PCIe)
Between 2-4 InfiniBand Gateway Switches
(32) QDR InfiniBand ports
(8) 10GbE ports for datacenter connectivity
40 Gb/sec internal I/O backplane
Enterprise-class, integrated Network Attached Storage
80 TB SAS disk, 6.4 TB read cache, 292 GB write cache
Clones, snapshots, remote replication

7. Exalogic Elastic Cloud System Software
Enterprise Manager
Middleware and Business Applications
WebLogic
Coherence
Tuxedo
Traffic Director
Exalogic Control
Exabus Integration
Exabus Integration
Exabus Integration
Exabus Integration
Oracle Linux Guest OS
Physical Oracle Linux/Solaris
Oracle VM 3 for Exalogic
Exabus
Exalogic Elastic Cloud Hardware
= Exalogic Elastic Cloud Software

8. Exabus is at the Center of Exalogic’s System Software
Exabus is Exalogic’s High-speed I/O Backplane Comprised of Hardware + Software
Traditional
IPoIB
SDP
Native IB
Applications
Middleware
Applications
Middleware
Applications
Middleware
Applications
Middleware
User
Exabus Sockets API
Exabus Sockets API
Exabus Java/C++ APIs
TCP IP
IP over IB
IB Core
HCA Driver
Exalogic
Kernel
TCP IP
NIC Driver
SDP
IB Core
HCA Driver
Ethernet NIC
IB HCA
IB HCA
IB HCA
Hardware
High-speed IB fabric, no application change required
Bypass TCP/IP layer to get even higher performance, minimal app changes
Highest performance, native IB support

9. Seamless, High-performance SR-IOV in Exalogic
Traditional IO
SRIOV in Exalogic
Guest VM
Guest VM
Guest VM
Exalogic HCA
Guest VM
Virtual Switch
Device Driver
Virtual Function
Physical Function
OVM
Server
Physical I/O Port 1 2 3
Device Driver
Device Driver
Device Driver
Virtual Switch
Hypervisor
Device Driver
HCA
Physical I/O Port
Virtual NICs in guest VMs “connect” to Ethernet ports in a vSwitch that runs in hypervisor
Significant I/O performance degradation – all packets cause a guest/hypervisor context switch, and usually multiple buffer copies
I/O performance is at par with Exalogic Physical
Traffic flows directly between guest VM and physical HCA
Complex high-performance technology made readily consumable

10. Exalogic Exabus v2.0 vs v1.1 – Continued Improvement
Exabus v2.0 improves performance across more use cases than previous.
Test system
Exalogic Eighth Rack
“MWM Enterprise” Benchmark
Is a system-level macro-benchmark that emulates a shopping-cart style web interaction and it stresses all aspects of a middleware system, specifically CPU, memory and network. 9X

11. WebLogic Optimizations for Exalogic – Re-cap
Socket Direct Protocol Optimizations
SDP over InfiniBand for JDBC
SDP over InfiniBand for Replication network channels
Work Manager and I/O Optimizations
Scatter/gather I/O for reduced buffer copies
Parallel muxer using Java NIO for increased throughput
Multi-core aware Thread Pool Increments for quick load ramp-up
Cluster optimizations
Enhanced session replication - multi-channel/socket one-way RMI plus lazy de-serialization
Further Sockets Direct Protocol Optimization
SDP Inbound HTTP (routed from OTD)
Messaging Optimization
JMS Lockless Request Manager
Web Optimization
JSP Factory Caching
HTTP Client Request Thread Pooling
Operational Optimization
Fast Cluster Service Recovery (fast server death detection)
WebLogic Server 11gR1 PS3 (10.3.4) – January 2011

12. Message Compression Further Enhances Persistent JMS Performance 5X
Messages/Second
Application
Application
I/O traffic optimizations increase throughput:
Leverage abundant compute resources to optimize I/O intensive processing
Server side message compression
Messages persisted in compressed format 5X
JMS
JMS
ZFS Storage
ZFS Storage
No Compression
Compression

13. Cooperative Memory Management - WebLogic 12.1.3
Threading
JMX
Enables greater density of deployments within memory constraints
Lowest layer computes “memory pressure” in JVM (0 to 10)
Lowest layer updates JMX MBean accessible to WLS components
WLS components reduce memory consumption under “memory pressure”
JDBC
Parsers
ResourcePressureMBean
Analyze memory state, compute “memory pressure”

14. JMS Replicated Memory Store – WebLogic 12.1.3
WebLogic Dynamic Cluster
RAM
Machine 1
WebLogic 1
JMS Server
store
queue …
WebLogic N
Machine N
Daemon Cluster
RS Daemon
RDMA over Infiniband
WebLogic Messaging Services (JMS) can use Replicated Stores as a high performance alternative to existing File and JDBC storage options.
A Replicated Store stores data in local Exalogic node memory and replicates it to memory on a second node providing high availability with no single point of failure
Yields linearly scalable performance.
CLIENT MACHINE 1
JMS Sender/Receivers working with distributed Queues
CLIENT MACHINE N
JMS Sender/Receivers working with distributed Queues

15. JMS Replicated Store - WebLogic 12.1.3 on Exalogic - Scaling
14x boost over disk storage
Linear Scalability
Higher relative performance possible
Test system
Exalogic Quarter Rack
Performance, Density, Scalability
“JPERF JMS” Benchmark
Micro-benchmark that emulates real messaging application using MDBs (message driven beans). Stresses the WebLogic persistent store for JMS. Adjusted client JVMs to maximize throughput.

16. Enabling WebLogic Enhancements for Exalogic pt1
Auto-enables:
Scatter/Gather I/O
Java NIO Muxer
Multi-core aware Thread Pool incrementer
Lockless Request Manager
JSP Factory Caching
HTTP Client Request Thread Pooling
Toplink auto-tuning (12.1.3)

17. Enabling WebLogic Enhancements for Exalogic pt2
Enabling JDBC Store Exalogic Optimizations
Select Oracle Piggyback Commit Enabled in the JDBC Persistent Store Service.
Session Replication
Create Replication Channel for each server, specifying Port Range and enabling SDP
Customise cluster settings, enabling One Way RMI and Lazy Replication
JDBC over SDP (also Ensure DB Server is configured for SDP)
Add JVM arg -Doracle.net.SDP=true
Use SDP in Oracle DB data-source URLs rather than TCP
In the Data SourceConfigurationOracle properties, select “Oracle Enable JavaNet Fastpath” (reduces data copies in the driver)
JMS Replicated Store
Create Replicated Store under ServicesPersistent Stores

18. Enabling Exalogic Enhancements - Exabus
Leveraging SDP for Exalogic to Exadata Communications
Exabus communications between Exalogic and Exadata can provide up to 960Gb/s throughput, as opposed to traditional 1Gb/s or more modern 10Gb/s.
Enabling it is as simple as updating the data source:
DESCRIPTION= (ADDRESS_LIST=(LOAD_BALANCE=YES)(FAILOVER=YES) (ADDRESS=(PROTOCOL=tcp)(HOST=xd01client01-ibvip)(PORT=1521)) (ADDRESS=(PROTOCOL=tcp)(HOST=xd01client02-ibvip)(PORT=1521))) (CONNECT_DATA=(SERVICE_NAME=dbservice)))
Take the configuration one step further to gain better performance by utilizing SDP.
Enable SDP for further performance gains:
DESCRIPTION= (ADDRESS_LIST=(LOAD_BALANCE=YES)(FAILOVER=YES) (ADDRESS=(PROTOCOL=sdp)(HOST=xd01client01-ibvip)(PORT=1521)) (ADDRESS=(PROTOCOL=sdp)(HOST=xd01client02-ibvip)(PORT=1521))) (CONNECT_DATA=(SERVICE_NAME=dbservice)))

19. Coherence Optimizations for Exalogic – Re-cap
Exabus Latency Optimizations
RDMA with kernel bypass
MessageBus utilizes JVM IB API
Scalable Networking
Messagebus per service
Simplified deployments
Elastic Data Optimizations
Improved heuristics for optimized Exalogic SSD
Cluster Rebalancing
Increases Availability

20. Coherence Elastic Data
Greatly increase size of data-set that can be held in a cluster
Or reduce number of host machines required
Manage memory more efficiently
Transparently overflow from RAM to SSD
Negligible performance impact when overflowing from RAM to SSD
Ideal when large Solid State Disks (SSDs) are locally accessible
Elastic Data
RAM
SSD

21. Coherence MessageBus Performance on Exabus
Typically run 4-8 Coherence JVMs per Exalogic compute node
Reduces latencies
Used for all data transfers
Addresses a common challenge for typical Coherence clusters
Existing UDP protocol still used for cluster management
Coherence performance is usually very sensitive to network latency
Pluggable high performance messaging implementation for Exabus
Alloc
SEND
RDMA WRITE
RDMA READ
JAVA
RECEIPT
End to End Latency (50µs)
Write Latency (~5µs)
Sender (“Client”)
Coherence Services
TCP
Message Bus
SDP
RDMA
Receiver (“Server”)
cache.get() latency of ~100µs (vs ~350µs for on normal systems)

22. Coherence Benchmark Performance
Coherence on Exalogic vs. COTS (10gE):
Up to 4 times Transactions/Sec
Using Performance CPU Frequency Scaling Governor
Test System
Exalogic Eighth Rack
6 Coherence Cache Servers on each compute node
Coherence / Java Hotspot1.7
“Coherence Bench” Benchmark
Sends requests from Coherence tcmp clients to Coherence cache servers. It stresses the Coherence layer and the network protocol layer (Exabus). 4X 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22

23. Enabling Coherence MessageBus Configuration for Exalogic
Typically you will get the best performance with the default auto-selected transport protocol for your platform.
IMB (Infiniband Message Bus) is enabled by default when running on Exalogic Linux.
There are 2 ways to change the protocol if needed:
Edit the cluster's operational override file (tangosol-coherence-override.xml)
Java command line argument: -Dtangosol.coherence.transport.reliable=protocol
Other transport protocols available:
tmb: TCP MessageBus
sdmb: SDP message bus. SDMB is only available on Exalogic.
sdmbs: SDP message bus with SSL. SDMBS is only available on Exalogic.
imb: Infiniband MessageBus (default for Exalogic Linux)
datagram: legacy UDP

24. Tuxedo Optimizations for Exalogic – Re-cap
Better Performance for Intra-domain communication
Leverage Exabus
Reduces buffer copies
Eliminates BRIDGE as inter-machine bottleneck
Efficient algorithm for lock management
Sockets Direct Protocol – SDP
Faster network communication at lower CPU cost
Dynamic Spincount
Shared APPDIR across all nodes
Ease of application maintenance
Zero Copy using Shared Memory Queues

25. Tuxedo 12.1.3 on Exalogic Elastic Cloud4
Current Architecture
with GW Between Nodes
1. Client sends msg to the local GW through IPC
2. GW sends msg through network to remote GW
3. GW sends the msg to the server through local IPC
4. Server retrieves msg from local IPC
Architecture on Exalogic
Eliminating GW
1. Client writes msg directly to remote server’s queue using RDMA
2. Server retrieves msg from local queue
FASTER DELIVERY, HIGHER THROUGPUT
Single Connection GW GW
TCP over Ethernet 2 3
Tuxedo
Tuxedo 1 2
RDMA over InfiniBand
Tuxedo
Tuxedo 25

26. Tuxedo 12.1.3 on Exalogic Elastic Cloud
Improved Availability and Scalability with Exadata
Dynamic Database configuration
FAN UP, DOWN, and Real time Load Advisory events to move database connection to an appropriate instance
Simplified configuration
High availability for Tuxedo applications – transactions are routed to available RAC instance automatically
Real time load balancing across RAC instances

27. Tuxedo 12.1.3 on Exalogic Elastic Cloud
High Performance Domains
Reduced buffer copies
Simplified configuration
Use of Exabus/RDMA for direct communication, bypassing TCP/IP stack 4X

28. Enabling Tuxedo Configuration for Exalogic
As long as the option EECS in OPTIONS of UBBCONFIG *RESOURCES section is specified, the following features are enabled:
Direct Cross Node Communication Leveraging RDMA
Direct Cross Domain Communication Leveraging RDMA
Self-Tuning Lock Mechanism
SDP Support
Use of Shared Memory for Inter Process Communication
Read-only Optimization for XA
XA Affinity
Common XID
Single Group Multiple Branches (SGMB)
FAN Integration

29. Oracle Traffic Director – Overview
Built-in Application Delivery Controller for Load Balancing over InfiniBand
High Availability
Quality of Service
DATACENTER SERVICE NETWORK
Built-in HA on engineered systems
Back-end Offline Health check
Assign back-end servers as Backup
Dynamic reconfiguration
Request, content-based routing
Request rate acceleration
Request rate & connection limiting
Quality of service tuning
Oracle Traffic Director
WAF
High Performance
Security
Built-in HTTP, TCP load balancing
Native Exabus integration
SSL & TLS offloading
Content caching & HTTP Compression
Throughput: 10k HTTP, 5k HTTPS req/sec on 2 vCPU with 2ms response time.
HTTP Reverse proxy
Support for SSL 3.0 and TLS 1.0
Web-application firewall
Application

30. Enabling OTD to WebLogic Enhancements
In WebLogic tier
Create HTTP Channel for each server
Specific new port (eg. 7103)
In Advanced Properties select SDP Enabled
Re-start each server
In Oracle Traffic Director
For each Origin Server (WLS instance) in Origin Server Pool
Specify Address Family field as “inet-sdp”
Change Listen Port to the new value (eg. 7103)

31. EECS Optimization Documentation
Exalogic Enterprise Deployment Guide Optimization
Administering Oracle WebLogic Server on Exalogic (12.1.3)
Tuning Performance of Oracle WebLogic Server 12c (12.1.3)
Optimizing Persistence Applications for Oracle Exalogic using Toplink
Oracle Tuxedo/Oracle Exalogic Users Guide

32. Customer Case Study: Agilent Technologies Sandeep Rohilla, Solutions Architect
ATG, Tai.
Exact bullets. For metrics.
Ratios. Gain %% etc.
Request hardware from slide 12.

33. Agilent Technologies – Fact Sheet
Agilent is a leader in life sciences, diagnostics and applied markets.
The company provides laboratories worldwide with instruments, services, consumables, applications and expertise, enabling customers to gain the insights they seek.
Key Markets:
Chemical and Energy
Pharma & Biotech
Environmental and Forensics
Food
Diagnostics and Clinical
Research
US $3.9 Billion Revenue
11,000 Employees

34. Project Methodology Go-Live Date: 22-Feb-2014
URL:
Implementation Time: 6.5 Months
eCommerce Platform
MS Commerce Server 2007
Search
MS SharePoint 2007
Database
MS SQL 2005
Application Server
.NET 3.0
Analyze As Is
Collaborate
Launch
Transform
eCommerce Platform
Oracle ATG Web Commerce 10.1
Search
Oracle Endeca Search
Database
Oracle 11g
Application Server
Oracle WebLogic Server

35. Site Performance Results

36. Product Versions & Tools
Products and Technologies
Oracle ATG Web Commerce
Oracle ATG Web Commerce Merchandising
Oracle ATG Content Administration
Oracle Endeca MDEX Engine 6.3.0
Oracle Endeca Platform Services 6.1.3
Oracle Endeca Frameworks with EM 3.1.0
Oracle Endeca CAS 3.0.2
Oracle Endeca Experience Manager 3.1.0
Oracle Exalogic Hardware
Oracle WebLogic Server
Oracle Traffic Director & Oracle http server
Oracle 11g (Database)
Oracle EMOC for monitoring
HTML5/CSS3/Bootstrap/jQuery/JSON
Tools
Adobe Dreamweaver, Photoshop & Flex SDK
Apache Eclipse, SQL Developer
Hudson, SVN
OWASP Zed Attack Proxy (ZAP)
PMD, Checkstyle, SONAR
Selenium Web driver
Soap UI
JMeter
Jupiter - Eclipse plugin for code review
HP Quality Center
JIRA & MPP
Fiddler & WireShark
Open SSL & SSL Tap
JRockit with mission control
VisualVM & Dynatrace
TDA, GC Viewer & Samurai

37. Questions

38. Join the Exalogic Community
Twitter
Facebook
Exalogic Blog
LinkedIn
YouTube
Visit us at: oracle.com/exalogic

39. Join Us for Other Exalogic Sessions
Session Title
Date
Location
Oracle Exalogic Roadmap: Hardware, Software, Platform News
Monday, 2:45 p.m. - 3:30 p.m.
Moscone South Room 270
VMware vs Oracle Exalogic: A Fair and Balanced Comparison
Monday, 5:15 p.m. - 6:00 p.m.
Moscone South Room 304
How to Deliver Oracle Fusion Middleware-as-a-Service to Your Organization
Monday, 4:00 p.m. - 4:45 p.m.
Moscone South Room 262
Zero Downtime for Oracle E-Business Suite on Oracle Exalogic
Tuesday, 3:45 p.m. - 4:30 p.m.
Customer Innovations on Oracle Engineered Systems
Wednesday, 11:30 a.m. - 12:15 p.m.
Building Application Private Clouds with Engineered Systems
Wednesday, 11:30 a.m. – 12:15 pm
Moscone West
Building a Scalable Private Cloud with Oracle Exalogic, Nimbula, and Openstack
Wednesday, 4:45 p.m. - 5:30 p.m.
Exalogic Innovation Awards
Wednesday, 5:00 p.m. - 5:45 p.m.
Yerba Buena Lam Research Center
PeopleSoft High Performance & MAA Guidelines on Oracle Exalogic & Oracle Exadata
Thursday, 10:45 a.m. - 11:30 a.m.
Marriott Marquis Salon 14/15
Increasing Your Application Availability with Oracle Traffic Director
Thursday, 12:00 p.m. - 12:45 p.m.
Thriving with Oracle Exalogic: The Definitive Owner/Operator Lifecycle Handbook
Moscone South room 304
Oracle Exalogic, Oracle Solaris & Oracle SuperCluster: More Versatile Than Ever
Thursday, 1:15 p.m. - 2:00 p.m.
Unleashing Extreme Performance and Scalability on Oracle Exalogic Elastic Cloud
Thursday, 2:30 p.m. - 3:15 p.m.
Moscone South Room 200
Extreme SOA: Secure, Fast, Scalable and Reliable: Delivered on Oracle Exalogic ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
