26 February 2013 - M. Pezzetti – CERN Cryogenics group2 SEMINARIO CERN a LNL/INFN CERN/UNICOS un oppurtunita per il rifacimento del sistema di controllo.

Similar presentations


Presentation on theme: "26 February 2013 - M. Pezzetti – CERN Cryogenics group2 SEMINARIO CERN a LNL/INFN CERN/UNICOS un oppurtunita per il rifacimento del sistema di controllo."— Presentation transcript:

1

2 26 February M. Pezzetti – CERN Cryogenics group2 SEMINARIO CERN a LNL/INFN CERN/UNICOS un oppurtunita per il rifacimento del sistema di controllo criogenico al LNL? Dr Marco Pezzetti

3 CERN distributed control system

4

5 1) Retrieve and structure information 5) PLC programming 6) PVSS programming 2) DOC: Operational Logic 3) DOC: UNICOS Spec 4) UNICOS DB 7) DOC Final Report UNICOS PLC components UNICOS PVSS components UNICOS DB template UNICOS generator

6 UNICOS advantages Provides PLC components that simplifies PLC programming Provides PVSS components that simplifies supervision programming Ensures coherence between documentation, PLC program and supervision program Sets a STANDARD for cryo operation (lower costs….)

7 Sulzer-Linde TCF20 in CERN/BA4 K. Brodzinski - CRG HiLumi #1_ At SPS BA4 there is a 4.5 K cryogenic infrastructure used last time about 8 years ago for COLDEX experiment. Upgrade in progress for 2 K refrigeration – UNICOS refurbishment is underway Cold box TCF20 2 K pumping groups recovered from AMS Renovated compressor + elec. motor – run test done New power supply panel for compressor station Revised, labeled and qualified pressure control system / oil removal system TCF20 Cold box

8 TE-CRG-CE Coldex – status & planning TN Cryogenic control system SCADA data servers Ethernet backbone CCC BA4 control room PLCOWS Surface Cavern I/O BA4 Electrical cabinet Cold box Electrical cabinet Compressor

9 LNL Refurbishing underway to be completed in March

10 Cryogenic UNICOS collaboration for cryo refurbishing project

11 ALPI & LNL distributed UNICOS control system??

12 CONCLUSION UNICOS is a way to – simplify – STANDARDIZE the control approach – Better operation 1000 different ways to achieve your control goals... LNL will acquire the technology for its own uses with a modern and advanced tool!!

13
