1. C Programming language Basic Concepts Prepared By The Smartpath Information systems www.thesmartpath.in

2. Index 1. Brief History of C Language 2. About C Programming Language 3. Characteristics of C programming language 4 C Programming Environment 5. Installing C in Windows 6. C Program Structure 7. C Program Structure – Explained 8. C programming – Syntax 9. C Character Set 10. Keywords 11. Operators in C 12. Operators in C ( continue…..)

3. Index 13. Data Types in C 14. Data Types in C 15. Data Types in C 16. Variables 17. Rules for Variable Declaration 18. Variables Scope 19. Input and Output 20. Decision Making 21. Looping 22. Looping 23. C Libraries 24. Uses of C

4. Brief History of C Language The origin of C is closely tied to the development of the UNIX operating system, originally implemented in assembly language on a PDP-7 by Ritchie and Thompson. The development of C started in 1972 on the PDP-11 Unix system and first appeared in Version 2 Unix. In 1978, Brian Kernighan and Dennis Ritchie published the first edition of The C Programming Language. This book, known to C programmers as "K&R“. ANSI –C - In 1990, the ANSI C standard (with formatting changes) was adopted by the International Organization for Standardization (ISO) as ISO/IEC 9899:1990, which is sometimes called C90. Therefore, the terms "C89" and "C90" refer to the same programming language

5. About C Programming language The C programming language is a structure oriented programming language, developed at Bell Laboratories in 1972 by Dennis Ritchie  C programming language features were derived from an earlier language called “B” (Basic Combined Programming Language – BCPL)  C language was invented for implementing UNIX operating system  In 1978, Dennis Ritchie and Brian Kernighan published the first edition “The C Programming Language” and commonly known as K&R C  In 1983, the American National Standards Institute (ANSI) established a committee to provide a modern, comprehensive definition of C. The resulting definition, the ANSI standard or “ANSI C”, was completed late 1988.

6. Characteristics of C programming language  There is a small, fixed number of keywords, including a full set o flow of control and primitive.  There are a large number of arithmetical and logical operators, such as +, +=, ++, &, ~, etc.  Typing is static but weakly enforced all data has a type, but implicit conversions can be performed; for instance, characters can be used as integers.  Strings are not a separate data type, but are conventionally implemented As null terminated array of characters  Enumerated are possible with the enum keyword. They are not tagged, and are freely interconvertible with integers.

7. C programming Environment The C programming environment consists of - (1) Text Editor - Programs are typed in Text Editor. By default a new file Noname.c is opened. Type your programs here, save it, compile and run. (2) Compiler – Compiler is a System software that is installed on computer to compile and run programs. Most widely Turbo C compiler is used

8. Installing C in Windows To install C in windows first download Turbo C compiler.. 1. unzip the downloaded file. And run the install.exe file 2. Press ‘Enter’ to continue 3. Enter Source drive where C-compiler and editor will be saved. 4. Enter the source path to locate the exe file. Press ‘Enter’ key. 5. using arrow key, scroll down. Select start installation 6. A message is displayed after successful installation. 7. Go to C:\TC\BIN right click TC icon select create shortcut.

9. C Program Structure A C program contains the following – (a) preprocessor commands (b) main( ) function ( c ) variables (d) input and output functions For example : #include /* this is comment line */ #include Void main() { printf(“hello”); getch(); }

10. C Program structure Explained 1. #include - The first two lines are preprocessor commands that tell the compiler that the program is using functions in it. 2.Void main() - This is the main function. Program execution begins with the this function only. 3.Variables - variables hold input and output values. 4. printf() - this is function to give output on the screen. The word “hello” is displayed on output screen. 5. The getch() – It is a function that ends program and returns to program window.

11. C Programming - Syntax for writing programs 1. C language is case sensitive language. Hello and hello are two different words. 2. Programs are written in small caps only ie.. In small letters.Capital words are treated differently. 3. Inside the main() function, each statement is terminated with semicolon. 4. Comments are used for explanation. /* ….. */ format is used to give comments in program. They are not executed.

12. C Character Set The basic C source character set includes the following characters Lowercase and uppercase letters: a–z, A–Z Decimal digits: 0–9 Graphic characters: ! " # % & ' ( ) * +, -. / : ; ? [ \ ] ^ _ { | } ~ Whitespace characters – space, horizontal tab, vertical tab new line, form feed

13. Keywords

14. Operators in C C supports a rich set of operators, which are symbols used within an expression to specify the manipulations to be performed while evaluating that expression. C has operators for 1. Arithmetic operators 2. Relational operators addition + Equals == subtraction - Not Equal != Multiplication * Greater than > Division / Greater than equal to >= Modulus % Less than < Less than equal to <=

15. Operators in C 3. Logical operators logical AND && 8. function call ( ) logical OR || 9. object size sizeof( ) logical NOT ! 10. Bitwise 4. increment ++ left shift << decrement -- right shift >> 5. Assignment operator = 6. Member selection. ->

16. Data Types in C 1. Basic data types Data Type Format Specified Space occupied char %c 1 byte signed char %c 1 byte int %d 2 bytes signed short int %hi 2 bytes long int %ld 4 bytes float %f 4 bytes double %lf 8 bytes long double %Lf 10 bytes

17. Data Types in C 2. Derived data types - The derived data types are (i) Pointer (ii) Array (iii) Structure (iv) Union (v) Function

18. Data Types in C 3. User defined data types - Typedef is used to create user defined data type in C for example structures are declared with typedef to create linked list data structures in C. For Example : typedef struct node { int n; node * p; }

19. Variables Variables in C is valid name in the memory where input given by user is stored and the result of program is stored. When a variable is declared in program, it occupies space in memory according to its size. Such as integer type takes 2 bytes of memory, char type takes 1 byte of memory Example: int sum; float average; char ch; Here int,float, char are basic data types. And Sum, average and ch are variables..

20. Rules for declaring variables 1. A variable name should start with letter. 2. It should not be a keyword 3. It can contains underscore character. 4. It should not contain white spaces and special characters. Example: sum - valid 1sum - invalid emp_id - valid emp id - invalid

21. Variables scope In C language variables have the following scopes 1. Local Scope - Variable declared inside main(), and variable declared inside a function has local scope that is it is recognized inside it local variable can be used inside that block of code. 2. Global Scope - variables declared outside the main() function are global variable. They are recognized throughout the program. They can be used by any function.

22. Input and output C has functions predefined for taking user input in a program and giving output in the screen scanf( ) - the scanf() function takes variable number of arguments from user in predefined format format - scanf(“%d%c%f”, &a, &b, &c); printf() - the printf() function gives output of program on the output screen format - printf(“%d%c%f ”, a, b, c );

23. Decision making Decision making requires that the programmer specify one or more conditions to be evaluated or tested by the program, along with a statement or statements to be executed if the condition is determined to be true, and other statements to be executed if the condition is determined to be false Statements used are - 1. simple if 2. if – else 3. if-else ladder 4. nested if – else 5. conditional operator

24. Decision making Examples : 1. simple if if( condition1) { statements; } if(condition 2) {statements ; } 2. if – else if(condition true) { statements; } else { condition false}

25. Looping There may be a situation, when you need to execute a block of code several number of times. In general, statements are executed sequentially: The first statement in a function is executed first, followed by the second, and so on. Statements inside the loop are executed till condition is true or condition gets False. There are three types of loops in C 1. For Loop 2. While Loop 3. Do -While Loop

26. Looping Examples : 1. For Loop for(initialization ; condition; increm / decrem) { statements; } 2. While Loop while(condition) { statements ; } 3. Do -While Loop do { statements } while( condition );

27. C Libraries C language contains set of files header files called library. These header files Have ‘.h’ extension. They contain functions for various types of operations Performed in a program. To use them we have to include them in a program Through include statement. Some of C Library header files are – stdio.h conio.h stdlib.h graphics.h

28. Uses of C C is widely used for "system programming", including implementing operating systems and embedded system applications, due to a combination of desirable characteristics such as code portability and efficiency, ability to access specific hardware addresses, ability to match externally imposed data access requirements, and low run-time demand on system resources. C can also be used for website programming using CGI as a "gateway" for information between the Web application, the server, and the browser Some reasons for choosing C over interpreted languages are its speed, stability, and near-universal availability C has also been widely used to implement end-user applications, but much of that development has shifted to newer, higher-level languages.
