1 Principles of Design

2 Individuality Design is all about Individuality! No one will ever have the same design concept for one plan. Your own ideas and feelings go into your design. Creativity is key. But remember, the homeowner is the boss! If they dont like it you might have to change it.

3 Principles of Art & Design Serve as structures and guidelines for design development. The principles of Design manipulate, influence, and control the principles of Art.

4 Principles of Art Line Form Texture Color

5 Line Causes physical and/or visual movement. Leads the eyes through the landscaped space. Defines space. Lines are used in all aspects of the landscape. Steer physical or visual movement directly through the environment.

6 Construct Lines… By using contrasting plant materials By forming patterns with similar plant materials Examples – Ground patterns, Edges of contrasting plant materials, and Tree tops meeting the sky

7 Lines contd Straight lines – formality or a contemporary concept Intersecting lines – hesitation, change of view or direction, or a pause Curved lines – relaxed, slower movement; casual & informal concept

8 Straight Lines

9 Curved Lines

10 Form 2 or 3 – Dimensional shape and structure of an object or space. Form is Line surrounding Space. Air space created by two plant materials set side by side is also an expression of form. Trees are good examples of form.

11 Common Forms Round Conical Oval Weeping Horizontal Upright


13 Forms contd Tailored plants and shrubs = formal design Irregular or natural forms = informal design

14 Texture Surface quality of any plant material or structure in the landscape. Texture is relative. Comparison is how we determine texture in a landscape. One plant might be fine in certain surroundings but in others course. Examples – Smooth, Rough, Shiny, or Dull.


16 Texture contd Fine texture = eyes move easy Course texture = focus eyes

17 Color Light is the source of color Color is visible wavelengths White is all light Black is the absence of light The color you see is the reflected wavelength

18 Color Color Wheel Primary colors Red, yellow, blue Secondary colors Primary + Primary Violet, green, orange Tertiary colors Primary + Secondary Name begins with Primary Red-orange, yellow- green RED BLUE YELLOW

19 Hue – pure color Tint (pastel) – add white & decrease the value Tone – add gray Shade – add black Warm colors – yellow, red, orange = excitement Cool colors – blue and green = calm Color contd

20 Principles of Design The selection is based on the principles of art or design. The principles of design referred to in the book include: Repetition Variety Balance Emphasis Sequence Scale.

21 Repetition Repeating or using an element more than once throughout a design. Provides a common feature throughout the design that pulls the design together. Use the same plant in a couple of different places

22 Variety This is where you provide variety in the design by selecting some plants with different qualities of line, form, texture, or color from the mass of plants In other words dont use the same plant over and over again

23 Balance This is where the design is classified as formal or informal. Formal is where the design is symmetrical and has the same plantings on each side of the view Informal designs are said to be asymmetrical and have different plants and different sizes of plants on each side of the view

24 Balance Symmetrical

25 Asymmetrical Balance

26 Emphasis It indicates dominance of some elements of the design over others.

27 Sequence is the uniformity of change from one item in the landscape to the next. Changes of at least one quality of form, texture, or color form one area of the planting to anther gives transition The apparent flow of lines, textures, and colors that express a feeling of motion rather than confusion.

28 Scale is the proportion of one object to another. It also means the relationship of an object with a designated standard such as a building or a person

29 Out – of – scale

30 In – scale

31 Landscaping Design What is Landscape Design? It is the practice of creating a plan to make the best use of available space in the most attractive way Relationships between the land, buildings, plants, and people are considered

32 Landscaping Design Professional Designers have two main purposes in mind when designing landscapes plans for the home or a building: 1 st show off the home and building to its best advantage 2 nd Create both an attractive and useful setting for the inhabitants

33 Landscaping Design What is a landscape Architect? They are trained in engineering, graphic arts, and architectural technology. They are skilled in designing functional plans based on the interrelationships of people and their surroundings

34 Landscaping Design What is a landscape Designer? They are trained in the art of design and the science of growing the horticultural plants. They work primarily with residential home designs and small commercial sites

35 Landscaping Design A landscape Designer will have the following: Knowledge of plant ID Cultural Requirments of plants Construction practices Principals of Design They will work at local nurseries, garden centers, and landscaping companies.
