1. JPSS CGS IDPS Product Generation
January, 2012
Raytheon
David C Smith, JPSS CGS Chief Architect
Kerry Grant, JPSS CGS Chief Scientist

2. One full set resides in each of the 4 Centrals
JPSS System
SDS
NESDIS
AFWA
FNMOC
NAVO
C3 Segment
Field Terminal Segment
GPS
Svalbard
Primary T&C
NPP SMD
TDRSS
Launch
Support Segment
MMC at Suitland
Flight Operations Team
• Enterprise Management
• Mission Management
• Satellite Operations
• Data Monitoring & Recovery
White Sands Complex
LEO&A Backup T&C
A-DCS
SARSAT
HRD
Field
Terminal
LRD
Field Terminal
Aurora MMC
Contingency Operations Team
Data Handling Nodes reside at each Central
15 Globally Distributed Receptor Sites Interconnected by Commercial Fiber
JPSS Stored Mission Data
Command and Telemetry
Interface Data Processing Segment
One full set resides in each of the 4 Centrals
Data Mgt
Infra
Ingest
Process
Data Del
CLASS
NPP Stored Mission Data
Offline Support
NPP (1330)
1330
1730
JPSS & DWSS Satellites
Residuals
Space Segment
DQM
mm/dd/yyyy

3. Remote Sensing System Evolution
DMSP
(Defense Meteorological
Satellite Program)
EOS
(Earth Observing
System)
NPOESS
(National Polar -
orbiting
Operational Environmental
Satellite System)
Sensor data rate: 1.5 Mbps
Data latency: 100
150 min.
1.7
GigaBytes
per day (DMSP)
6.3
per day (POES)
15 Mbps sensor data rate
180 min.
Data availability: 98%
Ground revisit time: 12 hrs.
2.6
TeraBytes
per day (EOS)
2.4
per day (NPP)
20 Mbps sensor data rate
Data latency: 28 min.
Data availability: 99.98%
Autonomy capability: 60 days
Selective encryption/deniability
Ground revisit time: 4
6 hrs.
8.1
per day
POES
(Polar Orbiting
Operational
Environmental Satellites)
NPP
(NPOESS
Preparatory
Project)
1960
2010
2000 –
2020+
1960
1960 - -
2015
2010
2000
2000 - -
2010
2017
2016 +
2010
NPP
NPP
DMSP
DMSP
JPSS
NPOESS
(NPOESS
(NPOESS
(Defense Meteorological
(Defense Meteorological
(Joint Polar Satellite System)
Satellite Program)
Satellite Program)
Preparatory
Preparatory
Project)
Project)
POES
POES
EOS
EOS
(Polar Orbiting
(Polar Orbiting
Operational
Operational
(Earth Observing
(Earth Observing
Environmental Satellites)
Environmental Satellites)
System)
System)
Sensor data rate: 1.5 Mbps
Sensor data rate: 1.5 Mbps
15 Mbps sensor data rate
15 Mbps sensor data rate
20 Mbps sensor data rate
20 Mbps sensor data rate
Data latency: 100
Data latency: 100 - -
150 min.
150 min.
Data latency: 100
Data latency: 100 - -
180 min.
180 min.
Data latency: 28 min.
Data latency: 28 min.
Data availability: 98%
Data availability: 98%
Data availability: 99.98%
Data availability: 99.98%
Ground revisit time: 12 hrs.
Ground revisit time: 12 hrs.
Autonomy capability: 60 days
Autonomy capability: 60 days
Selective encryption/deniability
Selective encryption/deniability
Ground revisit time: 4
Ground revisit time: 4 - -
6 hrs.
6 hrs.
1.7
1.7
GigaBytes
GigaBytes
per day (DMSP)
per day (DMSP)
2.6
2.6
TeraBytes
TeraBytes
per day (EOS)
per day (EOS)
6.3
6.3
GigaBytes
GigaBytes
per day (POES)
per day (POES)
3.4
2.4
TeraBytes
TeraBytes
per day (NPP)
per day (NPP )
mm/dd/yyyy
8.1
8.1
TeraBytes
TeraBytes
per day
per day
The evolution of Government remote sensing systems over the last 40 years. JPSS, the Joint Polar Satellite System, is the next generation low-earth orbiting environmental remote sensing platform. JPSS will play a pivotal role in our nation’s weather forecasting and environmental awareness for the next two decades.
* -- current estimates

4. Mission Data Processing Capabilities
Mission data processing is performed by the Interface Data Processing Segment (IPDS)
The IDP segment combines software and hardware flexibility, expandability, and robustness to meet stringent performance requirements levied by the Joint Polar Satellite System Common Ground System (JPSS CGS) requirements.
Sensor application packets are passed to IDPS. The data stream is broken into granules, which are a subsectioning of the data stream into manageable time intervals. The granules of data can be processed in parallel by IDPS thus ensuring processing of high quality products within latency timelines.
mm/dd/yyyy

5. Mission Data Processing Subsystem Capabilities
Ingest (ING)
The ING Subsystem creates sensor Raw Data Records (RDR) from multiple Sensor Application Packet streams received from C3S. It separates the incoming streams into granules by sensor. Ingest extracts JPSS Auxiliary data from Stored Mission Data (SMD) and create RDRs or Bus TM and S/C Diary information. It also accepts external Ancillary data sets that are required for EDR processing.
Processing (PRO)
The PRO Subsystem encapsulates all of the data algorithms that must be executed to turn the RDRs into higher level products. First processing creates sensor specific SDRs or Temperature Data Records (TDRs) from RDRs. These are corrected, calibrated and geolocated sensor data. A complex set of processing chains (see Figure 6) is then used to produce the required 46 EDRs. Some of these are produced as individual products or one algorithm may yield a group of related EDR products.
Data Management (DMS)
The DMS Subsystem provides internal short-term (24 hour requirement) storage of all JPSS data, as well as management of shared memory (cache), which is a critical component of the IDPS in meeting data product latency.
Infrastructure (INF)
The INF Subsystem provides the Workflow management functions for IDPS. It has total control of process startup, monitoring, shutdown and re-start upon error conditions. INF also provides common utilities and tools, such as logging, debug, timers, performance monitoring, data availability and accounting, and HW monitoring.
Data Delivery (DDS)
The DDS Subsystem is the single provider of all data between IDPS and the local Central. It converts requested products into Hierarchical Data Format 5 (HDF5) format with data and metadata aggregation. HDF5 is a self-describing data format with community supplied implementation libraries.
Data Quality Monitoring (DQM)
The DQM Subsystem provides the Data Quality Engineer automated and ad-hoc processing in support of Data Quality Notifications from the Processing system. The Data Quality Engineer is provided with a tool kit of Geographic Information System based modules that allow the IDPS data to be registered to a geographic grid and analyzed, viewed, and trended. The DQM and the DQE support the program’s larger Calibration and Validation (Cal/Val) activities and supports the troubleshooting of data anomalies.
mm/dd/yyyy

6. JPSS EDR Latency
The JPSS sensor suites on the JPSS vehicles produce data at up to a 20 MB/sec rate. This is an increase over DMSP of more than 13:1. The total xDR (RDR, SDR and EDR) products produced by an instance of IDPS per day have a volume increase over DMSP of 2000:1 In addition to handling these increased rates, latency requirements (defined as time from sensing of phenomena to production and delivering of products) decreases by a factor of 4. A graphical representation of the latency requirements that are imposed on JPSS CGS and projected actual performance is contained in Figure 3.
mm/dd/yyyy

7. Algorithm Workflow
JPSS products are generated from a complex network of processing algorithms.
A number of interdependencies between algorithms exist in order to provide the required data quality to the end User.
The following slides illustrate the interdependencies between products and processes within the IDPS needed to produce the NPP- era SDRs, EDRs, and Gridded Intermediate Products (GIP’s).
The execution of this processing flow for each granule of data is managed within the Infrastructure SI by the Workflow Manager (WFM) component through the use of a configurable Data Processing Guide (DPG).
mm/dd/yyyy

8. VIIRS Algorithm Data and Control Flow
mm/dd/yyyy

9. CrIMSS Algorithm Data and Control Flow
Figure 1 - - - -
Interface Data Processing Segment Architecture
CrIMSS Algorithm Data and Control Flow
Geoid &
DEM
NCEP
Data
QST
GIP
ATMS
APs
Ephem. &
Pointing
Atm Vert
Moist Profile
CrIS
SDRs
CrIS
APs
CrIS
Cal Tables
CrIS
RDRs
Atm Vert
Press Profile
ATMS
SDRs
CrIS SDR
ATMS
Cal Tables
CMN GEO
Atm Vert
Tempr Profile
ATMS
TDRs
CrIS RDR
ATMS
RDRs
ATMS Remap
ATMS RDR
CrIMSS
ATMS SDR
ATMS
SDRs
(remapped)
CMN GEO

10. OMPS Algorithm Data and Control Flow
mm/dd/yyyy
mm/dd/yyyy

11. Interface Data Processing Segment Architecture
mm/dd/yyyy

12. IDPS Hardware Architecture
INF
ING
Hot Spare
Admin
DQM
I&T ING
I&T INF
I&T DQM
Internal Web
External Web
HMC 1
HMC 2
RDBMS-1
RDBMS-2
RDBMS-3
RDBMS-4
ACI Fiber Channel Switches
PRO1
PRO2
DDS
I&T PRO1
I&T PRO2
I&T DDS
4Gbps IDPS Fiber Channel Switches
Ethernet Switches
IDPS utilizes a mix of IBM System p servers and Storage Area Network (SAN) / Fibre Channel technology to meet the program’s demanding data product latencies, assure fast and successful delivery of data to Users, provide very high operational availability, and allow for significant expandability to meet any changes to support JPSS objectives.
mm/dd/yyyy

13. SUMMARY
JPSS data processing is designed to provide high-quality environmental and meteorological data to the JPSS System Users with very low latency
Leverages highly flexible and expandable, robust hardware to maximize data availability, operational availability, and assured delivery
The SW architecture provides an efficient solution for NPP and provides a scalability to meet future JPSS needs.
