1. Metric Measurement

2. Measuring Distance The basic metric unit for distance is meters (m)
Centimeters (cm) or millimeters (mm) are best for measuring very short distances.
100 cm in 1 meter.
10 mm in 1 centimeter
What is the length of this line in cm? In mm?

3. Kilometers (Km) is the best unit for measuring long distances
Kilometers (Km) is the best unit for measuring long distances. There are 1000 meters in 1 km.
How many meters to Athabasca Falls?
How many centimeters to Athabasca Falls?

4. Measuring Volume
The amount of space occupied by a 3 dimensional object.
Volume of regular shaped solids can be determined using simple equations like = L x W x H
For volume of a liquid, use graduated cylinder.
For irregular shaped solids, use the water displacement method.
For solids, use cm3 or m3
For liquids, use mL or L
Conversion: 1 cm3 solid = 1 mL liquid

6. Calculate the volume for each solid shape below
Calculate the volume for each solid shape below. The unit for each measurement is cm. 1 4 1 11 2 3 6 5 3 4 9 5
The formula for the volume of a rectangular prism is:
Length x Width x Height = cm3

7. Calculate the volume for each solid shape below
Calculate the volume for each solid shape below. The unit for each measurement is cm. 1
11 cm3 4
24 cm3 1 11 2 3 6 5
120 cm3
135 cm3 3 4 9 5
The formula for the volume of a rectangular prism is:
Length x Width x Height = cm3

8. Volume of Irregular Objects
A rock was placed into a graduated cylinder containing 100 milliliters of water. The diagram to the right illustrates the new level of water. What is the volume of the rock? (A) 42 cm3 (B) 142 cm3 (C) 42 mL (D) 142 mL
Modified from NY State Regents Exam: Biology Jan. 24, 2001

9. Volume of Irregular Objects
A rock was placed into a graduated cylinder containing 100 milliliters of water. The diagram to the right illustrates the new level of water.
What is the volume of the rock?
(C) 42 cm3
142 mL (end) – 100 mL (start) = 42 mL or 42 cm3
Each line = 2 mL increments
This method is called “displacement”

10. Measuring mass The amount of matter in an object.
Use an electric balance to determine
mass
For solids use g, or kg
For liquids, use the same method and units but remember to subtract the mass of the container from the total mass to find the mass of the liquid only.
Example: 200g total mass – 40g beaker = 160g of liquid

11. Weight is related to mass, but they are not the same.
Weight is the measure of gravitational force on an object, which is different on earth than on the moon or other planets. But weight is really the only way to measure mass.
Mass is just the amount of matter in an object, so it never changes.

12. Measuring Temperature
Degree Celsius (° C) measures temperature.
Water freezes at 0 °C and boils at 100 °C
Use a thermometer to measure temperature.
