1. WCL201 Windows Vista Application Compatibility and the Microsoft Application Compatibility Toolkit (ACT) 5.0 (WCL201)
Suma SaganeGowda
Program Manager
Application Compatibility Toolkit
Microsoft Corporation
Peg McNicol
Product Manager
Application Compatibility Toolkit
Microsoft Corporation

2. Agenda Windows Vista – Innovation and Compatibility
Top Compatibility Issues in Windows Vista
Application Compatibility Toolkit (ACT) 5.0
Call To Action
Resources
Question and Answer

3. Innovation and Compatibility
4/20/2017 9:09 AM
Innovation and Compatibility
Windows Vista Pillars
Security
Reliability
Application Compatibility (most applications just work)
Performance
Feedback and Supportability
Improvements in Windows Vista occasionally break compatibility. Microsoft has created these tools and services to help with Application Compatibility
Application Compatibility Toolkit 5.0 (ACT)
Windows Vista Upgrade Advisor 1.0
Vista Readiness Assessment Tool
Application Compatibility Factory
Windows Logo programs
SWAT team and on campus labs

4. Agenda Windows Vista – Innovation and Compatibility
Top Compatibility Issues in Windows Vista
Application Compatibility Toolkit (ACT) 5.0
Call To Action
Resources
Question and Answer

5. Top Compatibility Issues With Windows Vista
User Account Control (UAC)
Windows Resource Protection (WRP)
Internet Explorer 7 Protected Mode
Windows Vista 64-bit
Windows Filtering Platform
Deprecations/GINA/Session 0 (High Impact/Low Frequency)
Operating System Version Change
Overall, high compatibility in Windows Vista

6. User Account Control (UAC)
4/20/2017 9:09 AM
User Account Control (UAC)
Description
Enabling users to run with a standard user account
Security feature to reduce introduction of vulnerabilities (Malware, Trojan, Viruses)
Issues
Custom installers and updaters need administrator privileges
Unnecessary administrator checks
Writing to file or registry locations that are not virtualized
Mitigation
Some common shims - Virtualization shims, Force Admin Access
Relax ACL's on files and folders

7. Windows Resource Protection (WRP)
4/20/2017 9:09 AM
Windows Resource Protection (WRP)
Description
Increase system stability by protecting Windows resources (files, folders, registry).
Issues
Application installers that attempt to replace, modify, or delete OS files and/or registry keys that are protected will fail with an access denied error message because the resource could not be updated.
Remedies
Never repackage Microsoft redistributables (use the Microsoft provided redistributable package instead).
Do not write to system files and registry keys.

8. Internet Explorer 7 Protected Mode
4/20/2017 9:09 AM
Internet Explorer 7 Protected Mode
Description
Internet Explorer 7 runs in Protected Mode, with greatly restricted privileges
Issues
IE cannot modify user files, registry keys
Applications may not know how to handle new prompts requesting user permissions
Mitigation
Add the site in question to the trusted sites list.

9. Windows Vista 64-bit Description Issues Remedies
Windows Vista fully supports the 64-bit architecture processors from AMD and Intel.
The 64-bit version of Windows Vista can run all 32-bit applications with the help of the WOW64 emulator.
Issues
Applications or components that use 16-bit executables, 16-bit installers or 32-bit kernel drivers will either fail to start or will function improperly on a 64-bit edition of Windows Vista.
Remedies
Remove all 16-bit components.
Convert 16-bit installers to 32-bit or 64-bit installers
Ensure that all 64-bit drivers are digitally signed

10. Windows Filtering Platform
Description
The Windows Filtering Platform (WFP) API allows developers to create code that interacts with the filtering that takes place at several layers in the networking stack and throughout the operating system .
Publicly supported APIs.
Issues
Network scanning anti-virus and firewall applications will fail
Remedies
Update applications to use the new WFP APIs
Microsoft is engaged with networking, firewall and anti-virus vendors to adopt the new platform

11. Deprecations Description Issues Remedies
Deprecations – removal of APIs or DLLs from Windows Vista that existed in Windows XP
Issues
Applications lose functionality or don’t start up correctly
Remedies
Search MSDN to look for replacement of API

12. Graphical Identification and Authentication (GINA)
Description
Windows Vista introduces a new authentication model (new Credential Provider API)
Issues
Users will not be able to logon using Custom logon applications. These may include:
Biometric devices (fingerprint reader)
Custom UI for logon
Virtual private network (VPN) solutions for remote users with custom logon UI
Remedies
The applications or components that use the GINA technology will need to be re-authored to use the new logon authentication model for Windows Vista
For all credential provider information and questions, send to the Shell Credential Provider alias:

13. Session 0 Description Issues Remedies
Services are isolated to run in their own private Session (Session 0) to enhance security.
Users no longer share this session
Issues
Services with user interaction may hang as UI is not visible to the user
Remedies
Update Apps, to ensure services do not display UI
In-box mitigation where notification is sent to current user when there is UI in Session 0

14. Operating System Version Change
Description
The internal version number for Windows Vista is changed to 6. The GetVersion function will now return this version number to applications when queried.
Issues
Any application that specifically checks for the OS version will get a higher version number which it may not be designed to handle
Application installers may prevent themselves from installing and applications may prevent themselves from starting.
Mitigation
Use compatibility administrator and apply XP SP2 layer or version lie shim

15. Agenda Windows Vista – Innovation and Compatibility
Top Compatibility Issues in Windows Vista
Application Compatibility Toolkit (ACT) 5.0
Call To Action
Resources
Question and Answer

16. Application Compatibility Toolkit
Customer Target
Medium/Large Businesses and Large Enterprises
Mission
A lifecycle management tool that assists in identifying and managing your overall application/device/computer portfolio, reducing the cost and time involved in resolving application compatibility issues, and helping you quickly deploy Windows Vista and Windows Updates.
Strategy
Help detect, diagnose, and mitigate compatibility issues found in Windows Vista
Microsoft Compatibility Exchange to facilitate exchange of compatibility data between ISV/IHV, Microsoft, and customers
Deliver tools that are timely and relevant to Windows releases

17. ACT 5.0 - High Level Architecture4
Compatibility Exchange
Desktop Topology
Europe
North America HR
Finance 2
Log Processing Service
Internet 1
Agent Framework/Compatibility Evaluators 3
Inventory IE
UAC
UCE
Etc…
Local
ACT DB
Application Compatibility Manager
Betty
Wilma

18. ACT Methodology Collect Data Analyze Test
4/20/2017 9:09 AM
ACT Methodology
Collect Data
Analyze
Test
Inventory Applications and Devices
Gather
high-level compatibility evaluator
data
Prioritize and Categorize
Synchronize data with Microsoft Compatibility Exchange
Identify high-level issues
In-depth testing with dev/test tools
Log test data
Build and test mitigations

19. COLLECT
Inventory and Compatibility Data 19

20. ACT Data Collection Architecture
Data Collection Packages
Inventory Collector
IE Evaluator
UAC Evaluator
Vista Evaluator
Application Compatibility Manager
ACT Database
Log Processing Service
Desktop Topology 20

21. Compatibility Evaluators for Vista
Inventory Collector
Gathers data on a computer regarding applications, devices (device manager), and system information.
User Account Control
Detects which applications may have issues with running as Standard User on Vista
Windows Vista
Deprecations - identifies applications that are loading binaries or using APIs that will be removed in Vista
GINA - identifies applications that installed a Graphical Identification and Authentication (GINA) DLL
Session 0 - identifies applications with interactive services
Internet Explorer
Detects compatibility issues with web applications due to IE security features

22. Compatibility Evaluator for Updates
Detects applications impacted by Windows Updates
Windows Updates
Enterprise Desktop Topology
Update
Compatibility
Evaluator
Update Manifest
Update Compatibility Evaluator Data
Application Compatibility Manager

23. 4/20/2017 9:09 AM
ACT - Collect

24. ANALYZE
Prioritize, Categorize, Rationalize, Synchronize and Manage compatibility data 24

25. Prioritize, Categorize, Rationalize
Application A 1.0
Application A 1.1
Application B 1.0
Application Test List with Redundancy Removed
Business Critical
Important
Nice to Have
Unimportant
Software Vendor
Third Party
Custom
Microsoft Corporation
Test Complexity
High
Medium
Low
Division
Research and Development
Finance
Sales
Region
North America
Europe
Asia 25

26. Consolidated view from all data providers
Application Compatibility Manager
My Assessment
Vendor Assessment
Certified for Windows Vista
Works with Windows Vista
Community Assessment
Microsoft Assessment

27. Microsoft Compatibility Exchange
4/20/2017 9:09 AM
Microsoft Compatibility Exchange
Works for me!
1. Community
See risk rating and/or issues summary
IT Pro (Enterprise A)
IT Pro (Enterprise B)
Compatibility Exchange
Internet
Features:
IT Pros helping each other out by sharing of application compatibility rating with community
Secure and privacy compliant transactions
Simple and easy to share
Submission can be anonymous or by user name
Partner with MCS and deployment specialist in building and seeding community data
Scalable solution
Analysis
and Reporting
App Compat Testing
Certify app works or
Publish issues
ISV
Microsoft Logo
and Certification
2. Authoritative Sources
Features:
Feedback mechanism to vendors on most requested applications
Authoritative data compliments community rating
Leverage existing Microsoft data repositories (test, certification, logo, vendor portal)
Limited data due to dependencies on Vendor Portal and test team

28. 4/20/2017 9:09 AM
ACT - Analyze

29. TEST AND MITIGATE
Test, Debug, Resolve, Deploy Solutions 29

30. Developer and Tester Tools
Standard User Analyzer
Provides a way for testers to further test the LOB applications to determine what will fail as Standard User on Vista
Internet Explorer Test Tool
Provides a way for testers to further test the intranet web applications to understand the exact issue and determine which of their web applications will not work with IE 7
Setup Analysis Tool
Detects issues such as WRP, installing of 32 bit kernel mode drivers, 16 bit components to flag any of your packages which could run into this issue
Compatibility Administrator
Helps IT Admins, Developers, Testers create and test compatibility shim/fixes (no code changes required)

31. 4/20/2017 9:09 AM
ACT – Test and Mitigate

32. Standard User Analyzer
The Standard User Analyzer is a tool to help diagnose potential issues with an application when it is run as a standard user
Based on LUA Predictor technology in Application Verifier (AppVerifier)
Intercepts common API calls which usually require elevated privileges
Predicts whether these API calls would have succeeded as a standard user 32
3232

33. SUA - API Coverage File system access (e.g. Program Files)
Registry access (e.g. HKLM)
INI WriteProfile (privileged locations)
Token checking (explicit checks)
Privilege (e.g. enabling SeDebugPrivilege)
Namespace (creating global objects)
Other securable objects (events, mutexes, waitable timers, semaphores, etc.)
Process creation (attempting to launch another process which requires elevation) 33

34. Internet Explorer Compatibility Test Tool
Installs the IE Compatibility Evaluator
Enables Internet Explorer logging
Compatibility issues are recorded in the event log
IECE processes the event log to list events
You can see the events real time, helps for easy debugging 34

35. ACT Feature Comparison
ACT 5.0 Beta
ACT 5.0 RTW
Client tool for Reporting and Analysis 
Configuration Wizard
Inventory Collector
Internet Explorer Compatibility Evaluator (websites)
UAC Compatibility Evaluator
Update Compatibility Evaluator
Microsoft Compatibility Exchange
Website Reports (integrated in ACM)
Prioritize, Categorize, and Deployment Tracking
Devices Support
Vista Compatibility Evaluators (GINA, Session 0, Deprecated Components)
Compatibility Administrator (fix applications)
Filter and Custom Report
Developer Tester Tools (IE, SUA, Setup Analysis)
Integration with SMS

36. Call To Action Download ACT 5.0 RC Now!!
Windows Vista Application Compatibility Training
2.5 days of intense learning to detect, troubleshoot and mitigate Windows Vista application compatibility issues
Day 1: Windows Vista Application Compatibility Fundamentals - Lectures and demos to recognize and resolve the most common Windows Vista app compatibility issues: User Account Control (UAC), Windows Resource Protection (WRP), Session 0 Isolation, IE7 protected mode and more
Day 2: Application Compatibility tools and techniques - Lectures and hands-on-labs about ACT 5.0, Standard User Analyzer, LUA Buglight, Shims and other troubleshooting techniques
Day 3: Debugging Demystified - Hands-on-labs for setting up a debugging environment, debugging failed apps with WinDbg, and handling crash dumps
Provided free of charge by the AE SWAT team
Contact:
Leverage services provided by Microsoft and Partners
Application Compatibility Factory, On campus labs, Windows Logo Program

37. Application Compatibility Resources
4/20/2017 9:09 AM
Application Compatibility Resources
For IT Professionals:
Application Compatibility in Windows Vista
Business Desktop Deployment Solution Accelerator
Download ACT 5.0 RC
For Developers:
Application Compatibility Cookbook
Windows Vista Application Development Requirements for User Account Control
Questions related to SUA
ACT Newsgroup:

38. Related Sessions Breakout Sessions/Chalk Talks HOL’s
WCLCT07 – Windows Application Compatibility and the Microsoft Application Compatibility Toolkit (ACT 5.0), Thu Nov 16 10: :00
WCLCT05 - Business Desktop Deployment (BDD) 2007 and Vista Deployment Best practices, Thu Nov 16 13: :45
MGTCT07 - Drilldown into SoftGrid Application Virtualization, Fri 17 Nov 13:30 -14:45
MGT324 - Vista and Office 2007 in a Flash: Accelerating your Vista and Office 2007 Deployments with SoftGrid and SMS 2003, Fri 17 Nov 9: :15
MGT320 - Using Application Virtualization to Decrease Your Application Management TCO, Fri 17 Nov 15: :30
HOL’s
WCLHOL09 - Application Compatibility Toolkit for Windows Vista (ACT 5)

39. Ask The Experts Get Your Questions Answered
You can find us at the Microsoft Ask the Experts area, located in the Exhibition Hall:
Thursday 16 November 14:45 – 15:45
Friday 17 November 10:15 – 10:45
Friday 17 November Lunch

42. Compatibility Evaluators – Supported Platforms
Agent
Windows 2000
Windows XP
Windows Server 2003
Windows Vista
Collector
Yes
IECE No
Yes (with IE7)
UACCE
Vista (Deprecations/ GINA/Session 0)
IE Test Tool
Setup Monitor
Yes - Guest only
SUA
UCE

43. Inventory Collector
Scans computer for devices, application, and system information
Locations we search for applications -
.Msi (Windows Installer database)
Add/Remove Programs
(HKEY_LOCAL_MACHINE\Software\Microsoft\Windows\CurrentVersion\Uninstall\*)
Windows Shell (Start menu)
App Path (HKEY_LOCAL_MACHINE\Software\Microsoft\Windows\CurrentVersion\App Paths\*)
Locations pointed to by path environment variables (%PATH%)
Registered file extension handlers (HKEY_LOCAL_MACHINE\Software\Classes\*)
Registry Run (HKEY_LOCAL_MACHINE\Software\Microsoft\Windows\CurrentVersion\Run\*)
Service Control Manager (HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services\*)
(Filters out Windows Components/Features)

44. User Account Control Compatibility Evaluator
Detects what applications will have issues with running as Standard User on Windows Vista
Issues Detected -
File Operations
Lets the user know if the file will be virtualized
If not, lets the user know the access is restricted (e.g. locations like Program Files which only admins have access)
Registry Operations
Lets the user know if the registry key will be virtualized
If not, lets the user know the access is restricted (e.g. locations like HKLM which only admins have access)
Profile API operations
Checks if any applications are writing into any system ini files (including win.ini)
Elevation Detection
Detects applications that need to run elevated/ as administrator (i.e. setup.exe)

45. Internet Explorer Compatibility Evaluator
Detects Compatibility issues with web applications due to IE security features
Issues detected -
(IE6) - LMZL, Mime Handling, Windows Restrictions, Zone Elevation, Binary Behaviors, Object Caching, ActiveX Blocking, Popup Blocking, Download Blocking, CURL - Centralized URL Parsing, International Domain Names (IDN) Support, SSL, XDom Barrier, Manage Add-ons, Anti-Phishing, Cross Frame navigation, CSS fixes
(IE7) - All of the above plus: Protected Mode
More details about the issues

46. Windows Vista Upgrade Advisor
Customer Target
Consumer and small businesses
Mission
Assist customers in upgrading from Windows XP to Windows Vista
Features
Scans a single computer to create compatibility report for upgrading to Windows Vista
Provide reports on system, device, and application compatibility issues
Helps you choose the edition of Windows Vista best fits the way you use your computer

48. ©. 2006 Microsoft Corporation. All rights reserved
© 2006 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. MICROSOFT MAKES NO WARRANTIES, EXPRESS OR IMPLIED, IN THIS SUMMARY.
