1. Object retrieval with large vocabularies and fast spatial matching
James Phibin1, Ondrej Chum1, Michael Isard2,Josef Sivic1, and Andrew Zisserman1
1Department of Engineering Science, 2University of Oxford
Microsoft Research,Silicon Valley
CVPR 2007

2. Overview Problem Objective Improvement
Input: a user-selected region of a query image
Return: a ranked list of images retrieved from a large corpus.
Containing the same object
Objective
a promising step towards “web-scale” image corpora
Improvement
Improving the visual vocabulary
Incorporating spatial information into the ranking
Examples

3. Datasets Source Oxford 5K dataset 100K dataset 1M dataset Flickr
“Oxford Christ Church,” “Oxford Radcliffe Camera,”… with “Oxford”
5,062 (1,024*768) images
100K dataset
145 most popular tags
99,782 (1,024*768) images
1M dataset
450 most popular tags
1,040,801 (500*333) images

4. Indexing the dataset Image description Model Search engine
Affine-invariant Hessian regions
3,300 regions on a 1,024*768 image
SIFT descriptor
128-D
4×4× 8-direction gradient histogram
Model
bag-of-visual-words
Quantize the visual descriptors to index the image
Search engine
L2 distance as similarity
tf-idf weighting scheme
more commonly occurring = less discriminative = smaller weight
2×2 8-direction gradient histogram

5. K-mean Approximate k-mean (AKM) Hierarchical k-mean (HKM)
Train the Dictionary
K-mean
Approximate k-mean (AKM)
Hierarchical k-mean (HKM)

6. AKM v.s.HKM Traditional k-mean Strategy Quantization effect
2D k-d tree
Traditional k-mean
single iteration
O(NK)
Strategy
Reduce the number of candidates of nearest cluster heads
AKM
Approximate nearest neighbor
replace the exact computing nearest neighbors with
8 randomized k-d tree of cluster heads
Less than 1% of points are assigned differently from k-mean for moderate values of K
HKM
“vocabulary tree”
A small number (K=10) of cluster centers at each level
Kn clusters at the n-th level
Quantization effect
Conjunction of trees
Overlapping partition
Points can additionally be assigned to some internal nodes

7. Comparing vocabularies
K-mean v.s. AKM
HKM v.s.AKM
Scaling up with AKM

8. Ground Truth Dataset Searching Labels 5K dataset Manual Entire
For 11 landmarks
Labels
Positive
Good: nice, clear
OK: more than 25% of the object
Null
Junk: less than 25%
Negative
Absent: object not present

9. 5 queries for each landmark

10. Evaluation Precision Recall Average precision (AP)
# of retrieved positive images / # of total retrieved images
Recall
# of retrieved positive images / # of total positive images
Average precision (AP)
The area under the precision-recall curve for a query
Mean average precision (mAP)
Average AP for each of the 5 queries for a landmark
Final mAP = average for mAP for each landmark

11. K-mean v.s. AKM

12. HKM v.s.AKM

13. Recognition Benchmark
D. Nistér and H. Stewénius. Scalable recognition with a vocabulary tree. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), volume 2, pages , June 2006.

14. Scaling up with AKM

15. Spatial re-ranking

16. Use Spatial Info. Usage Procedure Re-ranking the top ranked results
Estimate a transformation for each target image
Refine the estimations
Reduce the errors due to outliers
LO-RANSAC
RANdom SAmple Consensus
Additional modeL Optimization step
Re-rank target images
Scoring target images to the sum of the idf value for the inlier words
Verified images above unverified images

17. Restricted transformation
Degree of freedom
3 dof
Isotropic scale
Covering the changes in zoom or distance
4 dof
Anisotropic scale
Covering foreshortening, either horizontal or vertical
5 dof
Anisotropic scale and vertical shear
NOT
In-plane rotation
foreshorten
(perspective)
shear

18. Comparing spatial rankings
Different transformation types
Large datasets
Examples
Examples of errors

19. Different transformation types

20. Large datasets

21. Examples

22. Examples of errors

23. Conclusion Conclusion Future work
Scalable visual object-retrieval system
Future work
More evaluation for higher scale
Including spatial info. into the index
Moving some of the burden of spatial matching to the first ranking stage

24. RANSAC

25. RANSAC example
