Presentation on theme: "ASECNA AGENCY FOR AIR NAVIGATION SAFETY IN AFRICA & MADAGASCAR."— Presentation transcript:

1 ASECNA AGENCY FOR AIR NAVIGATION SAFETY IN AFRICA & MADAGASCAR

2 AGENCY FOR AIR NAVIGATION SAFETY IN AFRICA & MADAGASCAR (ASECNA) BENIN BURKINA-FASO CAMEROON CENTRAL AFR REP CHAD CONGO BRAZZA COTE D IVOIRE EQUAT. GUINEA France GABON MADAGASCAR MALI MAURITANIA NIGER SENEGAL TOGO

3 ORGANIZATION

4 FIR FIRANTANANARIVO BRAZZAVILLE NDJAMENA NIAMEY DAKAR DAKAR OCEANIC ASECNA Agence pour la Sécurité de la Navigation Aérienne en Afrique et à Madagascar Siège Social : Av. Jean Jaurès DAKAR B.P Tél. : Fax : Bénin-Burkina-Cameroun-Centrafrique-Congo-CôtedIvoire-France-Gabon- Guinée Equatoriale-Madagascar-Mali-Mauritanie-Niger-Sénégal-Tchad-Togo 16 millions sq.km 6 FIRs /5 FIC

5 SERVICES ATS COMMUNICATIONS (FIXE/MOBILE) FLIGHT INSPECTION FIRE FIGHTING ENGINEERING

6 RESSOURCES AERONAUTICAL FEES (LANDING & EN ROUTE) MEMBER STATES CONTRIBUTIONS ON THEIR NAT L ACTIVITIES ENTRUST TO ASECNA LOANS

7 COMMUNICATIONS VHF NETWORK EXTENSION FOR MORE CONTROLLED AIRSPACE SATCOM FOR AIR TRAFFIC CONTROL AERONAUTICAL TELECOM NETWORK (ATN) HF / DL - SATELLITE BACK UP

8 NAVIGATION GROUND BASED EQUIPMENTS IN CONTRIBUTION TO LOCAL OR WIDE AREA AUGMENTATION SYSTEMS

9 SURVEILLANCE SSR /NDJAMENA/BRAZZAVILLE AUTOMATIQUE DEPENDANTE SURVEILLANCE (SITA / AIR AFRIQUE / COLLINS/ANAM) AIR SITUATION DISPLAY FOR NON ADS FLIGHT ADS/SSR ADS-B SURFACE MVT GUIDANCE

10 ATM 1/2 AUTOMATIC FLIGHT DATA PROCESSING CONFLICT DETECTION AND CLEAR FLEXIBLE AIR ROUTES (CONTINENTAL/OCEANIC ATL- INDIAN) DARPs CPDLC D-FIS

11 ATM 2/2 REDUCED UPPER AIRSPACE AREA TRAFFIC FLOW MANAGEMENT HARMONIZATION OF TERMINAL AREA (TMAs) LIMITS SUB REGIONAL ATM SYSTEMS INTEGRATION

12 AVIONICS AFI / LOW DENSITY TRAFFIC –FULL AUTONOMOUS AVIONICS ON BOARD OVERSEAS INTL AIRLINES –LACK OF EQUIPMENT ON MAJOR DOMESTIC OR REGIONAL OPERATORS B-RNAV FAIR COST CNS/ATM SYSTEMS (DL/ADS/GNSS) VDL MODE MODULAR BASIS

13 ASECNAS CNS/ATM IMPLEMENTATION COST ACQUISITION/INSTALLATION/OPERA TION (2000/2010) –COMMUNICATION 50 millions US$ –NAVIGATION 33 –SURVEILLANCE 42 –ATM 68 –TRAINING 16 –INFRASTRUCTURE 66 TOTAL 276

14 COST/BENEFITS ANALYSIS

15 FINANCING ASECNAS CASE STUDY DEVELOPMENTS/DEMONSTRATIONS & TRIALS –STOCK FUNDS OPERATIONS INFRASTRUCTURE –TRADITIONAL EUROPEAN & AFRICAN FINANCIAL INSTITUTIONS

16 EXISTING INFRASTRUCTURE AFTN MODERNIZATION INTERCONNECTION OF COMMUNICATIONS NETWORK VHF COVERAGE /DATA LINK X 25 PROTOCOL SADIS IMPLEMENTATION

17 EXISTING INFRASTRUCTURE LADGPS TRIALS IN DAKAR GPS /PRIMARY/SUP. MEAN WGS 84 GNSS IMPLEMENTATION IN AFI STUDY FOR EGNOS TEST BED EGNOS/WAAS INTER OPERABILITY TESTS

18 EXISTING INFRASTRUCTURE ADS IN AFI WITH RKA / COLLINS /SITA ENHANCEMENT TO FANS- /1/A

19 EXISTING INFRASTRUCTURE ATM INTEGRATION AND HARMONIZATION / 40 YEARS

20 TRAINING 15 SEMINARS OF SENSIBILIZATION TRAINAIR PROGRAMM

21
