Presentation on theme: "Chapter 10 PLC Math Instructions Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Objectives Program the add instruction."— Presentation transcript:

1

2 Chapter 10 PLC Math Instructions

3 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Objectives Program the add instruction in the PLC ladder logic diagram. Program the subtract instruction in the PLC ladder logic diagram. Program the multiply instruction in the PLC ladder logic diagram. Program the divide instruction in the PLC ladder logic diagram.

4 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Addition Add (ADD) instruction has three operands:Add (ADD) instruction –Two operands hold source data (Source A and Source B), which are added together. –Either both sources can be registers or one source can be a register while the other one is a number. –Third operand is the destination.

5 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Addition (Cont.) Add instruction for Allen-Bradley SLC 500 series PLC displayed in block format.

6 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Description of Status Bits

7 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Subtraction Subtract (SUB) instruction has three operands:Subtract (SUB) instruction –Two operands, Source A and Source B, hold the source data. –Content of Source B is subtracted from Source A. –Result is placed in the destination.

8 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Subtraction (Cont.) Subtract instruction for the Allen-Bradley SLC 500 series PLC displayed in block format.

9 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Multiplication Multiply (MUL) instruction has three operands:Multiply (MUL) instruction –Two operands hold the source data (Source A and Source B). –Either both sources can be registers, or one source can be a register while the other one is a number. –Destination must be a register.

10 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Multiplication (Cont.) Multiply instructions in SLC 500 series PLCs displayed in block format.

11 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Division Divide (DIV) instruction has three registers:Divide (DIV) instruction –Two registers hold the source data (Source A and Source B). –Either both sources can be registers or one source can be a register while the other one is a number. –Destination must be a register.

12 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Division (Cont.) Divide instructions in SLC 500 series PLCs displayed in block format.

13 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions Advanced math instructions are used to perform mathematical computations.

14 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions (Cont.) Compute (CPT) instruction may be used to solve mathematical equations.

15 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions Example Given the following equation, you can use the CPT instruction to solve it. Y = (A × (ln B) × e C ) + (tan D)

16 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions Example (Cont.) First assign floating point register locations for the parameters in the equation. Note that integer registers such as N7:0 hold integer numbers. Floating point registers such as F8:0 hold a real number that has both integer and fractional part.

17 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions Example (Cont.) Assigned registers are: A = F8:0 B = F8:1 C = F8:2 D = F8:3 Y = F8:4

18 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Advanced Math Instructions Example (Cont.) Normally open contact I:1/0 is closed, equation in CPT instruction block calculated. Result is placed in floating point register four (F8:4).

19 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. PLC Ladder Logic Diagram

20 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Commonly Used Math Instructions

21 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Glossary Add (ADD) instruction - Instruction that calculates the sum of Source A and Source B. Divide (DIV) instruction - Instruction that calculates the quotient that results from dividing Source A by Source B.

22 Permission granted to reproduce for educational use only.© Goodheart-Willcox Co., Inc. Glossary Multiply (MUL) instruction - Instruction that calculates the product of Source A and Source B. Subtract (SUB) instruction - Instruction that calculates the difference between Source A and Source B.
