1
The N-Queens Problem lab01

2
**The N-Queens Problem Suppose you have N chess queens…**

…and a N by N chess board Can the queens be placed on board without conflicts? Conflict: Any two queens on board attacking each other is a conflict.

3
**Attacking of queens Two queens are attacking each other if they are**

in the same row in the same column in the same diagonal

4
**Denoting the positions of queens**

A 4 by 4 chess board. (4 rows, 4 columns) row 3, column 1 row 2, column 3 row 1, column 1

5
**A 8 by 8 chess board. (8 rows, 8 columns)**

6
**Pseudocode of N-queens Problem**

Initialize a stack s where we can keep track of the placement of queens Place the first queen, push its position onto s and set filled to 0. int filled =0;

7
**Continued… Repeat these steps: if there are no conflicts**

else if there is a conflict and there is room to shift the current queen rightward else if there is a conflict and there is no room to shift the current queen rightward increase filled by 1. If filled is now N, then algorithm is done. Otherwise move to the next row and place a queen in the first column. Push its position onto the stack. Move the current queen rightward, adjusting the record on top of stack to indicate the new position. Keep popping the stack, and decrease filled by 1 until a row is reached where the queen can be shifted rightward. Shift the queen rightward and adjust the record on top of stack to indicate the new position.

8
**Example:4-queues problem(4 queens on a 4 by 4 board)**

Initialize a stack s where we can keep track of the placement of queens top Stack s bottom

9
**Place the first queen, push its position onto s and set filled to 0.**

int filled =0;

10
**there are no conflicts, increase filled by 1.**

11
**move to the next row (row 2) and place a queen in the first column**

move to the next row (row 2) and place a queen in the first column. Push its position onto the stack.

12
If there is a conflict (yellow line), then we shift the new queen to the next column. (rightward ). Adjust the record on top of stack to indicate the new position (ROW 2, COL 2).

13
If there is a conflict (yellow line), then we shift the new queen to the next column. (rightward ). Adjust the record on top of stack to indicate the new position (ROW 2, COL 3). ROW 2, COL 3

14
**there are no conflicts, increase filled by 1.**

ROW 2, COL 3

15
**move to the next row and place a queen in the first column**

move to the next row and place a queen in the first column. Push its position onto the stack. ROW 3, COL 1

16
there is a conflict and there is room to shift the current queen rightward. Move the current queen rightward, adjusting the record on top of stack to indicate the new position. (ROW 2, COL 2)

17
there is a conflict and there is room to shift the current queen rightward. Move the current queen rightward, adjusting the record on top of stack to indicate the new position. (ROW 2, COL 3)

18
there is a conflict and there is room to shift the current queen rightward. Move the current queen rightward, adjusting the record on top of stack to indicate the new position. (ROW 2, COL 4)

19
there is a conflict and there is no room to shift the current queen rightward. Keep popping the stack, and decrease filled by 1 until a row is reached where the queen can be shifted rightward. Shift the queen rightward. Adjust the record on top of stack to indicate the new position (ROW 2, COL 4). ROW 2, COL 4

20
**there are no conflicts, increase filled by 1**

move to the next row and place a queen in the first column. Push its position onto the stack (ROW2, COL 1).

21
there is a conflict and there is room to shift the current queen rightward. Move the current queen rightward, adjusting the record on top of stack to indicate the new position. ROW 3, COL 1 ROW 3, COL 2

22
**3 3 there are no conflicts. Increase filled by 1.**

move to the next row and place a queen in the first column. Push its position onto the stack. ROW 4, COL 1 ROW 3, COL 2 ROW 3, COL 2 3 3

23
**there is a conflict and there is room to shift the current queen rightward.**

Move the current queen rightward, adjusting the record on top of stack to indicate the new position. ROW 4, COL 1 ROW 4, COL 2 ROW 3, COL 2 ROW 3, COL 2 3 3

24
**there is a conflict and there is room to shift the current queen rightward.**

Move the current queen rightward, adjusting the record on top of stack to indicate the new position. ROW 4, COL 2 ROW 4, COL 3 ROW 3, COL 2 ROW 3, COL 2 3 3

25
ROW 4, COL 3 ROW 4, COL 4 ROW 3, COL 2 ROW 3, COL 2 3 3

26
**there is a conflict and there is no room to shift the current queen rightward**

Keep popping the stack, and decrease filled by 1 until a row is reached where the queen can be shifted rightward. Shift the queen rightward. Adjust the record on top of stack to indicate the new position (ROW , COL ) ROW 4, COL 4 ROW 3, COL 2 ROW 3, COL 3 3 2

27
ROW 3, COL 3 ROW 3, COL 4 2 2

28
**there is a conflict and there is no room to shift the current queen rightward**

Keep popping the stack, and decrease filled by 1 until a row is reached where the queen can be shifted rightward. Shift the queen rightward. Adjust the record on top of stack to indicate the new position (ROW , COL ) ROW 2, COL 4 ROW 2, COL 4 ROW 1, COL 1 2 1=filled

29
**Keep popping the stack, because current queen can not move rightward.**

decrease filled by 1 Shift the queen rightward. Adjust the record on top of stack to indicate the new position (ROW 1 , COL 2). ROW 2, COL 4 ROW 1, COL 1 ROW 1, COL 2 1=filled 0=filled

30
**2=filled 1=filled Two steps are omitted here. ROW 1, COL 2**

31
ROW 3, COL 1 ROW 2, COL 4 ROW 1, COL 2 3=filled

32
**4=filled if there are no conflicts increase filled by 1.**

If filled is now N(N=4), then algorithm is done. ROW 4, COL 3 ROW 3, COL 1 ROW 2, COL 4 ROW 1, COL 2 4=filled
