1 POWERPOINT PRESENTATION ON BRIDGE ENGINEERING

2 Introduction To Bridge Engineering

3 DEFINITION A bridge is structure that allows people or vehicles to cross an obstacle such as river or canal or railway….

4 Deck Abutment Piers Bearing COMPONETS

5 Components Of Bridge

6 Definition of Components of bridge Deck A bridge with an upper horizontal beam that carries roadway.

7 Abutment It supports the ends of the bridge and transfer the loads from the superstructure into the ground.

8 PIERS The main supports for a bridge upon which the bridge rests are called piers.

9 Bearing A bridge bearing is a component of a bridge which typically provides a resting surface between bridge piers and the bridge deck.bridge piersbridge deck

10 CLASSIFICATION OF BRIDGES According to type of superstructure  Slab bridge  Beam bridge  Truss bridge  Arch bridge  Cable suspended bridge

11 Slab bridge

12 Beam Bridge

13 Truss bridge

14 ARCH BRIDGE

15 CABLE SUSPENSION BRIDGE

16 TYPES OF BRIDGE (According to Material)  Timber bridge  Concrete bridge  Stone bridge  R c c bridge  Steel bridge  P c c bridge  Composite bridge

17 TIMBER BRIDGE

18 Concrete Bridge

19 Stone bridge

20 R.C.C. Bridge

21 Steel Bridge

22 Composite bridge

23 IMPORTANCE OF BRIDGES  Improvement of environment for emergency care.  Improvement of convenience of public transportation.  Ease of traffic jam and reduction of railroad crossing.

24 Improvement of environment for emergency

25 Improvement of convenience of public transportation

26 Ease a traffic jam and reduction of a railroad crossing

27 Investigation For Bridge

28 GENERAL DATA COLLECTION  location of bridge site.  Transportation of bridge site.  Nature of crossing and affordability.  Availability of local material.  Traffic volume.  Availability of local bridge builders.  Temporary crossing.  Local participation.

29 DATA DRAWING

30 Important Definition  Linear water way.  Economical span.  Design discharge.  Scour depth.  Vertical clearance above HFL.

31 LINEAR WATER WAY A river or canal,or other body of water serving as a route or way of travel.

32 Economic span Economic span depend upon the cost of :  Substructure  Superstructure

33 Scour Depth The depth which is produced due to scouring action of water Depth of scour below the high flood level Scour depth has important in determination depth of foundation Mean scour depth(d)=9.2m Max.scour depth for piers=2d =18.4m

34 VERTICAL CLEARANCE Minimum vertical clearance of 5m should be ensure over the full width of roadway. The vertical clearance should be measured with regard to the highest point of carriageway. Allowance for any future raising of pavement is also be made.

35 SELECTION OF BRIDGE TYPE

36 a)Geometric condition of the site(road alignment, design flood and highest water mark) b)Traffic capacity. c)Structural stability. d)Foundation conditions and strength of a abutment. e)Available material. f)Knowledge and equipment of the contractor. g)Clearance requirement above and below the road way. h)General requirements with respect to location,financing and community values. POINTS FOR SELECTION OF BRIDGE TYPE

37 Traffic Projection

38
