Numerical Analysis 1 EE, NCKU Tien-Hao Chang (Darby Chang)

2
In the previous slide Why numerical methods? –differences between human and computer –a very simple numerical method What is algorithm? –definition and components –three problems and three algorithms Convergence –compare rate of convergence 2

3
In this slide Error (motivation) Floating point number system –difference to real number system –problem of roundoff Introduced/propagated error Focus on numerical methods –three bugs 3

4
Let’s start from error Numerical methods are generally designed to determine approximation solutions 3 categories of error types –modeling: made when you decide the algorithm –discretization/truncation: conversion from continuous to discrete and/or truncation of an infinite series –roundoff/data: not due to the formulation of a numerical method, caused by the data representation (in computer) 4

5
Can be analyzed Numerical methods are generally designed to determine approximation solutions 3 categories of error types –modeling: made when you decide the algorithm –discretization/truncation: conversion from continuous to discrete and/or truncation of an infinite series –roundoff/data: not due to the formulation of a numerical method, caused by the data representation (in computer) 5

6
Should be prevented Numerical methods are generally designed to determine approximation solutions 3 categories of error types –modeling: made when you decide the algorithm –discretization/truncation: conversion from continuous to discrete and/or truncation of an infinite series –roundoff/data: not due to the formulation of a numerical method, caused by the data representation (in computer) 6

7
1.3 7 Mathematics on the Computer Floating Point Number Systems

8
8

9
Restriction of d 1 9 d 1 must not be zero (except when the number being represented is 0 )

10
Floating point vs. real number Discrete vs. continuous –continuous means that between any two numbers, there are infinitely many other numbers Finite vs. infinite –number of element and range of values –a floating point number system contains its smallest/largest element underflow/overflow 10

11
Any Questions? 11

12
Floating point vs. real number Nonuniform vs. uniform –real numbers are uniformly distributed –in a floating point number system, the elements **** *** **** are more closely spaced think about the difference between two adjacent elements while the exponent changes 12 hint

13
Floating point vs. real number Nonuniform vs. uniform –real numbers are uniformly distributed –in a floating point number system, the elements **** *** **** are more closely spaced think about the difference between two adjacent elements while the exponent changes 13

14
Floating point vs. real number Nonuniform vs. uniform –real numbers are uniformly distributed –in a floating point number system, the elements near the zero are more closely spaced think about the difference between two adjacent elements while the exponent changes 14

15
Floating point system is 15 discrete, finite and nonuniform

16
Roundoff error When the number is outside the system Select an element to represent the number –chop –round A number to its floating point equivalent – y → fl(y) 16

17
17

18
18

19
Roundoff error When the number is outside the system Select an element to represent the number –chop –round A number to its floating point equivalent – y → fl(y) 19

20
Formal definition 20

21
An example 21

22
In general case (chopped) 22

23
In general case (chopped) 23

24
Machine precision/epsilon The error bound is independent of the number, y It depends on –base ( β ) –the number of digits ( k ) The bound is a function of the hardware implementation Cause of roundoff error 24

25
Formal definition 25

26
Another term about precision 26

27
27

28
So far, 28 we talked about floating point number systems in abstract

29
Then, 29 what systems are we likely to encounter in practice?

30
Real floating point system 1970s –begun to develop a standard binary floating point numbers to eliminate inconsistencies 1985 –IEEE –Binary Floating Point Arithmetic Standard 754 The IEEE Standard –F(2,24,-125,128), single precision –F(2,53,-1021,1024), double precision 30

31
IEEE standard single precision 31

32
1.4 32 Mathematics on the Computer: Floating Point Arithmetic

33
Motivation Floating point arithmetic stands for the mathematics on the computer, but why should we know that? The IEEE Standard – 5.96 x 10 -18 –seems pretty accurate However, 33

34
Numerical methods 34 perform a sequence of calculations on computer, where each operation introduces some roundoff error

35
35 when they are accumulated http://www.radgraphics.net/images/main/atomic%20explosion%20-%204.jpg

36
Typical arithmetic Three steps –operand → its floating point equivalent –the exact arithmetic –result → its floating point equivalent 36

37
37

38
Not associative (0.1329+1.543)+23.21=1.676+23.21=24.89 0.1329+(1.543+23.21)=0.1329+24.75=24.88 We should perform the arithmetic in ********* order to obtain the most accurate result 38 question

39
All 39 intermediate results have been rounded

40
Any Questions? 40

41
Not associative (0.1329+1.543)+23.21=1.676+23.21=24.89 0.1329+(1.543+23.21)=0.1329+24.75=24.88 We should perform the arithmetic in ********* order to obtain the most accurate result 41

42
Not associative (0.1329+1.543)+23.21=1.676+23.21=24.89 0.1329+(1.543+23.21)=0.1329+24.75=24.88 We should perform the arithmetic in Ascending order to obtain the most accurate result 42

43
In FP arithmetic, 43 always notice the number of significant digits and the least significant bits

44
Not distributive 44

45
45 Accumulation of roundoff error

46
46

47
Introduced/propagated error 47

48
Propagated error 48 can be large even if the introduced error is small

49
A notation in the analysis 49

50
In multiplication 50

51
In division 51

52
The relative error propagates slowly The absolute error can grow rapidly, when multiplying by a large number or dividing by a small number 52

53
Propagated error 53 in addition and subtraction

54
In addition and subtraction 54

55
Absolute vs. relative error Multiplication and division may result large absolute error Addition and subtraction may result large relative error –more crucial –cancellation error two nearly equal numbers are subtracted Algorithms should avoid the subtraction of nearly equal numbers 55

56
56 Recall that http://www.dianadepasquale.com/ThinkingMonkey.jpg

57
Should be prevented Numerical methods are generally designed to determine approximation solutions 3 categories of error types –modeling: made when you decide the algorithm –discretization/truncation: conversion from continuous to discrete and/or truncation of an infinite series –roundoff/data: not due to the formulation of a numerical method, caused by the data representation (in computer) 57

58
To prevent, 58 we need to know the floating point system

59
59 Bug 1 http://rinat.relcom.net/Gallery/slides/bug.jpg

60
60

61
± 61 be careful

62
62 In action http://thomashawk.com/hello/209/1017/1024/Jackson%20Running.jpg

63
In action 63

64
Analysis The larger root – 239.4 (actual root: 239.4246996 ) –is the floating point equivalent of the actual root The smaller root – 0.15 (actual root: 0.1253003555 ) –nearly 20% relative error 64

65
Any Questions? 65

66
An intuitive question How to solve the quadratic formula problem? Reformulate the calculation of the smaller root 66 hint

67
67

68
68

69
69 Bug 2 http://rinat.relcom.net/Gallery/slides/bug.jpg

70
70

71
Multiplier -1/6 71 The world is cruel :p You got -1.667

72
72

73
73 After one pass of Gaussian elimination http://i5.tinypic.com/4yqudc7.jpg

74
74

75
The next multiplier 75 fl(-3.333/0.0001)

76
76 -33330 http://www.radgraphics.net/images/main/atomic%20explosion%20-%204.jpg

77
77

78
Cascade of effects Cancellation error led to a small pivot element A small pivot led to a large multiplier A large and then led to loss of significant digits 78

79
4.167 disappeared 79

80
80 Bug 3 http://rinat.relcom.net/Gallery/slides/bug.jpg

81
Values of a function Even evaluating a function can prove difficult f(x) = e x – cosx – x, where x → 0 – e x → 0 – cosx → 0 81

82
82

83
83

84
How reformulate 84 When seeing cosx, sinx and e x, Taylor series

85
Reforming with Taylor series 85

86
86

87
More precision These bugs are under F(10,4,-,-) Just add more precision –FORTRAN REAL*8 → REAL*16 –C/C++ float → double Not always work –Introduced by Rump and reconsidered by Aberth, Precise Numerical Methods Using C++, 1998 87

88
88

89
Need at least 37 digits 89

90
Any Questions? 90

91
Good, 91 that means we would like to have exercises

92
Exercise 92 2010/3/25 9:00am Email to darby@ee.ncku.edu.tw or hand over in class. You may arbitrarily pick one problem among the first three, which means this exercise contains only five problems.darby@ee.ncku.edu.tw

93
93

94
94

95
95

96
96

97
97

98
98

99
99
