Radial Nerve Palsy Tendon Transfers Episode II What is a tendon transfer? The tendon of a functioning muscle is detached from its insertion and reattached.

Similar presentations


Presentation on theme: "Radial Nerve Palsy Tendon Transfers Episode II What is a tendon transfer? The tendon of a functioning muscle is detached from its insertion and reattached."— Presentation transcript:

1

2 Radial Nerve Palsy Tendon Transfers Episode II

3 What is a tendon transfer? The tendon of a functioning muscle is detached from its insertion and reattached to another tendon or bone to replace the function of a paralysed muscle or injured tendon. The transferred tendon remains attached to its parent muscle with an intact neurovascular pedicle.

4 What is a tendon transfer? “Using the power of a functioning muscle unit to activate a non functioning nerve/muscle/tendon unit”. Tendon transfers work to correct: – instability – imbalance – lack of co-ordination – restore function by redistributing remaining muscular forces

5 Indications Paralysed muscle – Nerve injury – peripheral or brachial plexus – High cervical quadriplegia (needs some input to brachial plexus/hand) – Neurological disease – Nerve repair with early transfer as internal splint Injured (ruptured or avulsed) tendon or muscle – Considerations Graft vs. transfer (adhesions more likely in graft – 2 anastomoses) Quality of available donors Length of time since injury Nature of tendon bed Balancing deformed hand e.g. cerebral palsy or rheumatoid arthritis Some congenital abnormalities

6 General principles 1. Only justified in restoring functional motion of the hand, not just motion Not all patients require the same functions/motions 2. Patient factors Age Functional disabilities with poor non operative prognosis Ability to understand nature and limitations of surgery, including aesthetic goals Motivated to co-operate with post operative physiotherapy

7 General principles 3. Recipient site “Tissue Equilibrium” concept as per Steindler/Boyes Tissue bed into which transfer is placed should be soft and supple Good soft tissue coverage Stable underlying skeleton Full passive range of motion of joints to be powered Area to be powered must be sensate

8 General principles 4. Donor muscle factors (APOSLE) Amplitude of the donor muscle – Should be matched to the unit being replaced Finger flexors  mm, finger extensors and EPL  mm, wrist flexors / extensors  mm, brachioradialis  mm – Amplitude of motion of any tendon can be increased by :- Increasing the number of joints its crosses eg the amplitude of a tendon crossing the wrist joint is increased by 20 – 30mm by full ROM of wrist Tenodesis effect during active movement Freeing fascial attachments to donor tendons Inserting the tendon closer to the joint being moved, but this requires a motor unit of increased power (due to leverage); and vice versa

9 General principles Power of the donor muscle – Any transferred muscle loses at least one grade of strength, so only Grade 5 muscles are satisfactory (Grade 4, or 85% normal strength, can be sufficient for some transfers). Donor muscle strength should be maximised pre- operatively. – Strongest are brachioradialis and FCU. Donor power correlated roughly with cross sectional area of muscle and fibre length – Overly powerful muscles will unbalance and, over time, deform a joint. So muscle power should be matched if possible. – Effective power of a transfer can be increased by placing the tendon insertion farther from the joint axis and as close to 90° as possible

10 General principles One tendon, One function – Effectiveness reduced in transfer designed to produce multiple functions Synergistic muscle groups are generally easier to retrain – Fist group – wrist extensors, finger flexors, digital adductors, thumb flexors, forearm pronators, intrinsics – Open hand group – wrist flexors, finger extensors, digital abductors, forearm supinators – Use of synergistic muscles tends to help retain joint balance

11 General principles Line of transfer – Should approximate pull of original tendon if possible – Acute angles should be avoided Expendability – Transfer must not cause loss of an essential function

12 General principles 5. Other muscle factors of secondary importance – Innervation - Donor muscle should be independently innervated and not act in concert with other motors (eg lumbricals) – Availability or necessity of antagonists eg brachioradialis is an effective wrist extensor only if triceps is functioning to resist its normal elbow flexor action 6. Tension of the transfer – “All transfers should be sutured at the maximum tension in the position that reverses their proposed activity” (Lister’s 4th Edn) 7. Location and nature of pulley if required

13 General principles 8. Selected arthrodeses – Simplify polyarticular system – Stabilise joints – Arthrodeses useful in providing stable pinch grip Thumb MPJ and IPJ Index PIPJ and DIPJ

14 General principles 9. Timing – “The timing of tendon transfers depends upon the aetiology and prognosis of motor imbalance, the neurophysiologic problems for the patient, and the constitution of the involved extremity” (Omer GE: Timing of tendon transfers to the hand. Hand Clin 4(2):317, 1988) – Usually last stage in reconstruction, after skeletal stability, soft tissue coverage, sensation and joint mobility “tissue equilibrium” – Brown suggested early transfer if expected poor results Nerve gap>4cm Large wound or extensive scarring Skin loss over nerve 10. Comparison to alternatives – Nerve repair or transfer – Tendon repair or graft – Tenodesis (joint stabilisation by anchoring tendons that move the joint) – Arthrodesis – Amputation – Muscle lengthening, release or denervation (in spasticity)

15 General principles 11. Contraindications – Age – due to joint stiffness, decreased need for power movements and difficult rehabilitation – Motivation – patients must be concerned about disability and highly motivated to perform hand rehabilitation – Task analysis – transfers must be designed to accomplish tasks rather than just specific motions. Eg opening doors requires grasp and twist – Nature of disability – systemic and local disease factors must be controlled before reconstruction attempted 12. Disadvantages – No increase in strength – Normal function of transferred muscle is lost – Transferred tendon may perform a different force, amplitude of movement and functional pattern – Transferred tendon must learn a new movement/function

16 Selecting donor tendons Based on Smith & Hastings (Principles of tendon transfers to the hand. Instr Course Lect 29:129, 1980) 1. List functioning muscles 2. List which of those muscles are expendable 3. List hand functions requiring restoration 4. Match #2 and #3 5. Staging

17 Maximising Success / Surgical Technique 1.Incisions should not cross the path of the transferred tendon 2.Avoid interference with normal structures 3.Tendon should insert into the joint of motion at 90  to maximise power and excursion. Insertion can be moved away from the joint to improve power, but this is at the expense of decreased excursion 4.The transferred tendon should insert into another tendon or bone. Strong insertions allow earlier mobilisation.

18 Maximising Success / Surgical Technique 5. A single insertion is best. Dual insertions tend to provide motion to the tighter insertion. Can be an advantage in complex movements, where one insertion is tighter during one phase of motion, and the other takes over during another phase. 6. Tension should be set to produce the necessary joint movement with maximal muscle contraction. Some initial over correction should be planned, as some tendon stretch is usual.

19 Maximising Success / Surgical Technique 7.Joint should be initially immobilised in a position that relieves tension at the insertion of the transfer 8.Reverse order – harvest grafts, prepare recipient site and tunnel before raising muscle

20 General Post Operative Management Rehabilitation is equally important in tendon transfer success as surgical execution Rehabilitation / physiotherapy is essential in – Regaining joint mobility lost during splinting – Training tendon to glide in new course – Teaching patients to activate a new muscle to achieve a certain function, which requires development of new neural pathways The more that a patient notices a disability, the greater the motivation, so the easier the retraining Children are usually managed with static protocols or longer protective phase

21 Basic Principles of Post Operative Rehabilitation Described by Toth Protective phase Begins at surgery and lasts 3 – 5 weeks Objectives:- – Protective splinting – Oedema control – Mobilise uninvolved joints 2. Mobilisation phase Begins when tendon healing is adequate for activation (usually 3 – 5 weeks post op) Objectives – Mobilise tendon transfer – Immobilise soft tissue – Continue immobilisation of uninvolved joints to prevent joint stiffness from disuse – Reinforce preoperative teaching and patient education – Continue oedema control and protective splinting – Begin home rehabilitation program Usually day time dynamic splinting with nightly static splinting

22 Basic Principles of Post Operative Rehabilitation 3. Intermediate phase Begins 5 – 8 weeks post operatively Gradually increases hand activity and passive range of motion exercises Limited functional movements permitted 4. Resistive phase Beginning at 8 – 12 weeks Tendon junctions are strong enough to withstand increasing resistance Therapeutic objective is to increase endurance and strength of transferred muscles Work related simulated tasks are begun to patient tolerance

23 Radial Nerve Palsy Need to differentiate between complete radial nerve palsy (includes triceps) and posterior interosseous palsy – Brachioradialis and ECRL are innervated prior to termination into posterior interosseous and sensory branches of radial nerve Severe impairment due to loss of extension power to the wrist, fingers, thumb and loss of radial abduction of the thumb Wrist extension is critical for stability, which is essential for grip and assisting the function of many tendons crossing the wrist

24 Tendon Transfers Well defined and highly effective, aiming to replace – Wrist extension – Finger extension – Thumb extension and abduction Standard – accredited to Riordan 1964

25 Radial Nerve Palsy Non-Operative Treatment – Splintage Burkhalter observed grip strength increased 3-5 by simply stabilising the wrist with splintage Tailor to needs of patient Brand recommended that if wrist splint during day then need night finger extension splint because lose length of flexor muscle fibres making it more difficult to achieve normal balance after nerve recovery or after tendon transfers – Maintenance of full passive ROM in all joints of the wrist/hands and prevent contractures

26 Radial Nerve Palsy Early transfers (“Internal Splintage”) – Burkhalter believes greatest functional loss is grip strength therefore advocated early PT to ECRB Therefore eliminate need for external splint plus also restore grip strength – 3 indications: Works as substitute during early regeneration Works as helper by adding power to reinnervated muscle Acts as substitute in cases which results of nerve repair are poor (eg chronic/crush injuries or elderly)

27 Riordan Transfer DonorInsertionFunction PT ECRB Wrist dorsiflexion FCU EDC IF - LF Finger extension PL EPL (rerouted) Thumb extension

28 PT to ECRB

29 FCU to EDC

30 PL to EPL

31 DonorInsertionFunctionReference PT FCR FCU ECRL & ECRB EPL, EPB, APL & EDC IF EDC MF – LF Wrist extension Thumb & index extension, thumb abduction Finger extension Jones 1921 PT FDS MF FCU ECRB EPL (re routed) EDC Wrist extension Thumb extension & abduction Finger extension Goldner 1974 PT PL FCR ECRB EPL EDC Wrist extension Thumb extension Finger extension Brand 1975 PT FCR FDS RF FDS MF ECRL & ECRB APL & EPB EPL & EIP EDC via interosseous m Wrist extension Thumb abduction Thumb & index extension Finger extension Boyes 1970 PT PL FDS LF FDS RF ECRB APL EPL EDC Wrist extension Thumb abduction Thumb extension Finger extension Beasley 1970 PT FCU ECRB EDC & EPL Wrist extension Digit extension Smith & Hastings

32 Brand transfers for radial nerve palsy

33 Boyes/Brand believes that finger extension is best monitored by synergistic FCR, and that EPL remains motored by PL – FCU too strong and excursion too short for finger extensors – FCU function as a prime ulnar stabiliser of wrist makes it too important to sacrifice Boyes also concluded that FDS excellent for finger extensors because of greater excursion (70mm) therefore – FDS MF to EDC – FDS RF to EPL and EI (more independent control to thumb and IF)

34 Direct Nerve Transfers Transfer of intact nerves to denervated muscles. MacKinnon and associates – Median nerve supplies redundant branches to FDS and therefore available for transfer – Or branches to PL and FCR (if these tendons not used for transfer)

35 Post-Operatively Long arm splint immobilisation for 4 weeks –  pronation – wrist 40  extension – MPJ  flexion – Thumb in maximal extension and abduction – PIPJ fingers left free ROS & change splint at days AROM hand therapy begins at 4 weeks Removable short arm splint to extend fingers, thumb and wrist for further 2 weeks, only removed for exercises
