The New Congo jr Console from ETC Compact Modular All the power of Congo Same Channel Count Same Output Count.

Similar presentations


Presentation on theme: "The New Congo jr Console from ETC Compact Modular All the power of Congo Same Channel Count Same Output Count."— Presentation transcript:

1

2

3

4 The New Congo jr Console from ETC Compact Modular All the power of Congo Same Channel Count Same Output Count

5 The New Congo jr Console from ETC Same command keypad Single theatre-style playback 6 Independents (3 rotary faders, 3 switches) Condensed Moving Light / Softkey / Direct Select area with graphical LCD

6 The New Congo jr Console from ETC Two DMX512-A Outputs (XLR) MIDI in and out Remote Trigger Audio in and out Phone Remote (no cRRFU) Dual DVI/SVGA Video Card (Y-cable required)

7 The New Congo jr Console from ETC USB on rear and front panel Mouse and keyboard included Littlite / Worklight connector with dimmer

8 Congo jr Master Playback Wing

9 Optional Master Playback Wing Provides 40 Master Playback faders Two graphical LCDs for labeling Direct Select mode

10 Congo jr Master Playback Wing Attach to either side of console… Or use the wing separately, connected via USB cable…

11 Congo jr Master Playback Wing Congo jr supports only one wing. The wing is not supported by the big Congo console, or any Congo accessory at this time. There will be more wings in the future, stay tuned!

12 What comes with each unit? Master Playback Wing ships with: Power Supply (international, same as SmartFade) USB Cable (2m/6’) Printed Setup Guide Dust Covers (one to fit wing only, one to fit wing/console combined) Congo jr Console ships with: Mouse and US keyboard Three IEC power cables (US/UK/EU) Printed User Manual Dust Cover (fits console only) USB Flash Drive (256MB or better)

13 Congo jr Output Upgrades Same as Congo Base Congo jr has 1024 outputs (2 Universes) Upgrades in 256-output blocks, up to 12 universes Two part numbers: –4320A1001 Congo jr with dual video 1024 Outputs –Or – –4320A1102 Congo jr, dual video, Outputs, plus –7310A1002 Congo Output Upgrade +256

14 Congo jr in a system Compatible with: –Congo Client PC –Congo Offline Editor –Phone Remote –ETCNet2 DMX Node –Net3 DMX/RDM Gateways Not Compatible With: –ETCNet2 Video Node – use a Client PC –cRRFU (a new RRFU is coming…) – use Phone Remote

15
