1 Richard Leymeister Law Enforcement Liaison

2 Introduction Section 3751 of Title 75, Pennsylvania’s Consolidated Statutes (Vehicle Code) requires police agencies to investigate, upon notification, all crashes involving death, injury, and/or damage to any one vehicle to such an extent that it cannot be driven from the scene without further damage and therefore requires towing. Furthermore, the investigating agency must report these crashes within 15 days to the Department of Transportation on a form designed and supplied by the Department; which is one of the approved electronic forms. Crashes are, by definition, a failure in the Commonwealth's Transportation System. The primary objective when investigating crashes is to obtain information that can be used to develop crash prevention and crash reduction programs.

3 Crash A crash is the result of an un-stabilized situation which includes at least one incident of personal injury or vehicular damage that is not a direct result of a cataclysm or deliberate intent. Reportable Crash The incident must occur on a highway or trafficway that is open to the public by right or custom and involve at least one motor vehicle in transport. The definition for a reportable crash can be found in Section 3746(a) of Title 75, Pennsylvania's Consolidated Statutes. It states a crash is reportable if it involves: Injury to or death of any person; and/or Damage to any motor vehicle to the extent that it can not be driven under its own power in its customary manner without further damage or hazard to the vehicle, other traffic elements, or the roadway, and therefore requires towing.

4 Non-Collision Crash A non-collision crash is any crash other than a collision crash. A Police Crash Report Form should be prepared if the resultant incident meets the definition of a reportable crash. Examples: Sudden stop causes an occupant to be injured Vehicle overturning Breakage of any part of the vehicle, resulting in injury or further property damage Explosion or tank rupture of any part of the vehicle while the vehicle was in transit Fire starting in the vehicle while in motion (not parked) Fall or jump from a moving vehicle Occupant hit by an object in, or thrown against some part of the vehicle Object falling on the vehicle

5 Fatal Crash A Fatal Crash is a crash category where a fatality occurred to at least 1 person involved in the crash as a direct result of the crash. A Fast FARS must be submitted within 24hrs of Fatal Crash Furthermore, death must have occurred within 30 days of the crash. That determination comes from the cause of death from the coroner’s report. Motor Vehicle in Transport A motor vehicle in transport is any motorized vehicle moving or stopped (not parked) being used in the transportation of person(s) or property. There must be at least one motor vehicle in transport involved in every crash reported to PENNDOT. Cataclysm A cataclysm is a cloudburst, cyclone, earthquake, flood, hurricane, lightning, tidal wave, torrential rain, tornado, volcanic eruption, etc. Crashes that result from a cataclysm are not reportable. Motor vehicles driven into water when a bridge is washed out during a hurricane or flood. Motor vehicles driven into falling materials covering a roadway during a landslide or avalanche.

6 Phantom Vehicle A phantom vehicle is a unit involved in the crash but where there is no contact between it and any other unit in the crash. In a sense, it is a unit that causes something to happen but is not directly involved in it. (There must be evidence or witness statements to corroborate existence of a phantom vehicle). Example: A car slams on the brakes to avoid a pedestrian. The vehicle following it swerves to avoid contact and strikes the curb causing towable damage to the front wheel assembly. The first car in this scenario is a phantom vehicle because there was no contact with the second vehicle. The pedestrian could also be considered a phantom, but since it is not a vehicle, they would not be included. You would not include pedestrian action in this scenario.

7 Travelway that have some form of traffic control. A travelway is an area intended for traffic, including highways, local streets, private roads, and trafficways within private property area that have some form of traffic control. A travelway is NOT a residential driveway, parking stall, parking stall lane, open area on private property, utility, logging or walking trail, bike paths or any areas not intended for motor vehicle travel. Example 1: A convenience store parking lot is often just an open area once you enter the driveway from the main road. Even though cars travel through this area to get to the gas pumps and parking stalls, it is not marked for traffic. Once a vehicle leaves the roadway, it is considered private property and not a travelway. Example 2: A shopping plaza often will have a travelway from the main road through the parking area leading up to the travelway that runs by the storefronts (usually with a fire lane). These travelways are usually marked off and do not have any parking stall access. Once a vehicle leaves these areas and pulls into the parking stall lanes, it is considered private property and not a travelway.

8

9  Validation error messages will appear at the right / bottom of the current web page.  There will also be changes to which vehicles riders can be ejected. This is in response to new federal requirements and will include a new value for ejection path. ATVs, Snowmobiles, truck beds, etc. will now allow for ejection from vehicle exterior. Federal requirements still state that you cannot be ejected from a 2 wheeled unit, so 2 wheeled motorcycles will still not allow an ejection to be entered. Three (3) wheeled motorcycles will be added as a separate vehicle type in the near future.

10 LOGGING ON TO THE CRASH REPORTING SYSTEM CRASH SYSTEM WELCOME SCREEN WEB ADDRESS (URL) Once the user has entered the Web Site; to log in to the Crash Reporting System click Log In on the left side of the page

11 Logging in with a Temporary Password Important – The first time you sign in with a new account or after you have been assigned a temporary password by your administrator you must supply all 4 fields on the log in screen in order to sign in: User ID – the User ID assigned by your local administrator Password – the temporary password you were provided New Password – make up an new password that is at least 6 characters and contains at least one letter and one number Confirm Password – carefully type in the new password once again keeping in mind that the password is CaSe SeNsiTiVe. Once your new password has been chosen and you have successfully logged into the system, the new password is permanent. You will only need to enter your User ID and current password.

12 PAGE ONE Block 1, 2 & 3

13 Midblock - (Non-intersection) -Crash occurred between intersections; crashes that are not intersection-related 4 Way Intersection - Any 4-legged intersection. "T"-Intersection - Any 3-legged intersection in which one roadway ends at a section of another roadway "Y"-Intersection - Any 3-legged intersection other than a "T". Location Types

14 Traffic Circle/Roundabout - Intersection that merges traffic from multiple roadways into a counter-clockwise circle where normally all turns are right-turns. Multi-Leg Intersection - Intersection that has five or more intersecting roads. Crossover - An opening on a limited access highway to be used by authorized emergency vehicles to get to the opposite side of the highway. Location Types (2)

15 On Ramp - Ramp merging onto the mainline roadway. Off Ramp - Exiting off the mainline roadway to the ramp. Railroad Crossing - is a crossing on one level ("at-grade intersection") - without recourse to a bridge or tunnel - of a railway line by a roadway. It also applies when a light rail line with separate right-of- way(or a reserved track tramway) crosses a road. Location Types (3)

16 Other - An intersection type not mentioned such as an "L" intersection and other less common intersection types. Virtually all intersections fit into one of the listed types, so this selection should only be used for especially unusual circumstances. Channelization - is considered part of the intersection, such as a right hand turn lane. NOTE: Do not confuse intersection "channelization" with ramps. To be considered a "ramp”, the road must be connected at one end to an expressway or freeway Location Types (4)

17 Page 1, Cont. Blocks 4,6,7, 8 & 9

18 Active RRCrossing Passive RR Crossing Other type TCD

19 degrees, minutes, seconds, and decimal seconds. When using your GPS device set the format setting to display the data in degrees, minutes, seconds, and decimal seconds. (See Page 29 in Web manual for conversion) Crash Location (GIS Lookup) The GIS lookup can be used in several ways. The user can interact with a map to identify the crash location. This procedure requires only a county and municipality be entered in the location page prior to requesting the generation of a map. The user then interacts with a map and identifies the crash location with a mouse click at the crash location. GPS / GIS Look Up GPS

20 Motor Vehicle in Transport - Any motorized vehicle moving or stopped (not parked) being used in the transportation of person(s) or property. Pedestrian - is a person travelling on foot, whether walking or running, and refers to someone walking on a road, sidewalk, or footpath. Hit & Run Vehicle - a motor vehicle that hits something or someone and leaves the scene of the incident. Pedestrian on Skates, in Wheelchair, etc. - People in wheelchairs, motorized or not; skateboards; skates; strollers; non-motorized scooters. This is also referred to as "Pedestrian Conveyance". This item does NOT include bicycles (see Non-Motorized Vehicle) Illegally Parked - A vehicle parked in a no-parking zone. Disabled From Previous Crash - A vehicle that has sustained enough damage from a previous crash that it cannot move under its own power. Legally Parked - Where permitted, means the temporary storing of a vehicle whether occupied or not. Train - a series of rail vehicles that move along guides to transport freight or passengers from one place to another. Non-Motorized - Bicycle, horse and rider, horse and buggy, etc Phantom Vehicle - A unit involved in the crash but is one where there is no contact between it and any other unit in the crash. In a sense, it is a unit that causes something to happen but is not directly involved in it. (There must be evidence or witness statement to corroborate existence of phantom vehicle). Drop Down Box Block 10

21 AA SECTION 11 - VEHICLE DRIVER / PEDESTRIAN INFORMATION This section is used to collect information that identifies the vehicle driver or pedestrian and some information about their physical and mental state at the time of the crash and if any vehicle code violations have occurred. When using the WEB CRS, Driver information can be obtained and confirmed using the DRIVER LOOKUP.

22 SECTION 12 - VEHICLE INFORMATION This section is used to collect information that identifies and categorizes the vehicle including insurance information. This whole section may be skipped for a pedestrian WEB CRS users can obtain or confirm Vehicle information using VEHICLE LOOKUP.

23 Not Applicable Right Lane (Curb) Right Turn lane Left Lane Left Turn Lane Two-Directional Center Turn Lane Vehicle Position Direction of Travel: North, South East, West

24 Other Forward Moving Lane Oncoming Traffic Lane Left Of Trafficway Right Of Trafficway HOV Lane - (High Occupancy Vehicle lane specifically designated for use by two or more occupants (i.e. carpool, etc.) Shoulder Right Shoulder Left One-Lane Roadway Other Unknown (Blank) Not applicable (pedestrian, etc.)

25 Description Going Straight Slowing/Stopping in Lane Stopped in Traffic Lane Passing/Overtaking Vehicle Leaving a Parked Position Parked Entering a Parked Position Trying to Avoid Animal, Pedestrian, Object, Vehicle, etc. Turning Right on Red Turning Right Turning Left on Red Turning Left Making a U-Turn Backing Up Changing Lanes or Merging Negotiating Curve - Right Negotiating Curve - Left Other Unknown

26 Vehicle Type DescriptionExample Automobile Motorcycle Bus Small Truck Large Truck Sport Utility Vehicle (SUV) Van Snowmobile Farm Equipment Construction Equipment All Terrain Vehicle (ATV)

27 Other Type Special Vehicle Unknown Type Special Vehicle Unicycle, Bicycle, Tricycle Other Pedalcycle Horse & Buggy Horse & Rider Train Trolley Other Unknown

28 Special Usage DescriptionExample Not Applicable Fire Vehicle Ambulance Police Other Emergency Vehicle Pupil Transport Commercial Passenger Carrier Taxi Tractor Trailer Twin Trailer Triple Trailer

29 Modified Vehicle Unknown

30 Initial Impact Point DescriptionExample Non-Collision Clock Points Top Undercarriage Towed Unit Unknown

31 Damage Indicator Gradient Road Alignment This will finish page two, you should Save the page then Validate the Page and correct any errors if any then continue to next page

32 CRS Page 3

33 Block 14 (Page 3) G - Ejection H - Ejection Path I - Extrication Same As Operator: Use for all number 1 persons

34 From PENNDOT’s perspective, this is the most important section on the entire police crash report form. This section identifies how the crash will be classified and how much importance will be associated with this crash.

35 Driver Actions This section is critical in determining whether or not a crash is caused by Aggressive Driving and also to determine funding for Aggressive Driving Enforcement. For Aggressive Driving crashes you must use two or more of the approved Aggressive Driving causal factors

36  Making Illegal U-turns  Turning from wrong Lane  Running Stop sign  Failure to Respond to Traffic Control Device  Improper / Careless Turning  Proceeding without clearance after stop  Running Red light  Tailgating  Careless Passing or Lane change  Making improper Entrance to Highway  Making improper Exit from Highway  Driver Fleeing Police  Sudden Slowing or Stopping  Passing in No Passing Zone  Speeding  Driving too Fast for Conditions

37 Hit Culvert - A culvert is a conduit used to enclose a flowing body of water. It may be used to allow water to pass underneath a road, railway, or embankment. Culverts can be made of many different materials; steel, polyvinyl chloride (PVC) and concrete are the most common. Hit Bridge Pier - A Bridge Pier is a supporting structure at the junction of connecting spans of a bridge. -or- Hit Abutment &endash; An Abutment is an end support of a bridge superstructure. Bridge Piers Abutment Hit Parapet End - Parapets are used on bridges and other highway structures (such as retaining walls) to prevent vehicles, and other users such as pedestrians, cyclists and horse riders, from falling where there is a vertical or near-vertical drop. In addition, parapets may be designed to restrict views, prevent debris passing onto traffic below, and act as noise barriers. Hit Bridge Rail - Bridge railings, although technically classified as longitudinal barriers, are listed separately here because they have been previously tested under criteria different from roadside barriers. Hit Impact Attenuator - An impact attenuator, also known as a crash cushion or crash attenuator, is a device intended to reduce the damage done to structures, vehicles, and motorists resulting from a motor vehicle collision. Impact attenuators are designed to absorb the errant vehicle's kinetic energy and/or redirect the vehicle away from the hazard. Guide Rail Attenuator Sand Attenuator Examples of some less common Harmful events

38 Hit Traffic Island - A traffic island can be a median strip. It can also be a narrow strip between roads that intersect at an acute angle. Some traffic islands may serve as refuge islands for pedestrians. Non-collision harmful Overturn/Roll Over Struck By Thrown Or Falling Object Pot Holes Or Other Pavement Irregularities

39 Jackknife - It applies to vehicles with trailers most commonly to semi-trailers that go out of control and swing around at an acute angle to the tractor. Fire in Vehicle - A fire in a vehicle on a roadway constitutes a reportable crash even if the vehicle has not collided with anything. Such as in this photo of a fire in the bed of a pickup truck. Other Non-Collision - An example of this would be a driver or passenger falling out/off of the vehicle and sustaining an injury or a fatality whether deliberate or not. Examples would include suicide attempts or accidents such as car surfing.

40 Contributing Information Items in the contributing information blocks (block 18) are non-harmful events and/or factors contributing to the crash but do not, in and of themselves, cause damage or injury. Factors can lead to the crash’s occurrence, but do not actually cause the damage. They might include environmental factors, vehicle failures or violations of law that you would list in the Primary Vehicle Code Violations Section on page 2. The Indicated Prime Factor should be chosen from the factors listed in the Environmental/Roadway Factors, Vehicle Failures, Driver Actions or Pedestrian Factors sections on page 4. Officers should choose the factor that they think contributed most to the cause of the crash based upon their investigation. Aggressive Driving Factors If the crash is the result of aggressive driving then you need to use two driver actions for this crash to be considered as an aggressive driving crash.

41 Environmental/Roadway Potential Factors Possible Vehicle Failures Driver Action Pedestrian Action

42 Indicated Prime Factor, Page 4 This factor is the one the officer identifies, based upon his/her investigation, as the most contributing factor to the occurrence of this crash. This factor must be one of the listed factors / actions contained in either Environmental, Vehicle, Driver or Pedestrian sections.

43 PAGE FIVE (5); DIAGRAM, NARRATIVE A Diagram is required with every crash report. If using the CRS you can complete your diagram using Easy Street Draw 4 which will attach your diagram to the report. If using your Departments RMS software you will need to complete a diagram using a another source and send it to Penn DOT with the report. If you arrive at the scene after the units have been removed, recreate the crash scene from statements of witnesses and physical evidence. DO NOT draw a diagram indicating the position of the vehicles UPON ARRIVAL. SHOW HOW the crash occurred. Position Units just prior to impact. Narrative There is no PENNDOT requirement to repeat anything here that has been covered in the codes. However, anything not covered in codes that is needed by local investigating agencies should be included in the narrative. Such items would include witness testimony, observations made by the investigator, the extent and details of damage and injuries sustained etc. Accident Investigation Notice and Property Damage are now required fields and must be completed

44 ADDITIONAL PAGES WORK ZONE

45 COMMERCIAL PAGE

46 FATAL PAGE

47 PEDESTRIAN PAGE

48 MOTORCYCLE PAGE

49 PEDALCYCLE - PAGE

50  Test Site https://www.dotuat6.state.pa.us/crash.nsf  CRS Web Site https://www.dot6.state.pa.us/crash.nsf

51 ANY QUESTIONS ? THANK YOU Rick Leymeister CRS Project Coordinator CR-LEL Area
