1 Cisco Confidential © 2010 Cisco and/or its affiliates. All rights reserved. 1 AP Product Portfolio and Roadmap Update April 2013

2 © 2012 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 2 CISCO AIRONET ACCESS POINTS n G2 Series 600 Teleworker Enterprise Class Mission Critical Best in Class 3600 Up to 300 Mbps Seamless Connectivity with Corporate SSID for Remote Office Split Tunneling and Local Resource Sharing* Up to 300 Mbps CleanAir Express* ClientLink 2.0 VideoStream Up to 450 Mbps High Client Scalability CleanAir ClientLink 2.0 VideoStream Second Generation n Up to 1.3 Gbps High Client Density Investment Protection, Future Proof Modularity (Security, ac** or 3G Small Cell***) ac Support HD Video/VDI, VideoStream Best In Class Security ClientLink 2.0, CleanAir * Available as a Software Update in Q4CY13 ** FCS Q2CY13 *** FCS Q4CY13

3 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 3 Indoor AP Series 600 Teleworker Max Data Rate300 Mbps 450 Mbps450 Mbps and 1.3 GbpS with 11ac Module RF Design MIMO:Spatial Stream 2x3:23x3:23x4:3 11n: 4x4:3 11ac: 3x3:3 Performance/Coverage/ Investment Protection  Max No. of Clients ac Module RRM ✔✔✔ CleanAirCleanAir Express** ✔✔ ClientLinkClientLink 2.0 ClientLink 2.0 for agn EBF for ac Max No. of ClientLink 2.0 Clients – ClientLink – ECBF on 11ac Module BandSelect ✔✔✔ VideoStream ✔✔✔ Rogue AP Detection ✔✔✔ Adaptive wIPS ✔✔✔ External Antenna Opt ✔✔✔ Module Options Multiple Local Ethernet Ports WSSI (Security) –Shipping ac - Q2CY13 Cisco 3G SCM – Q4CY13 Starting List Price$419$695$1095 $ AP $500 – WSSI &.11ac Module **Available as a Software Upgrade in H2 CY13

4 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 4 Designed Enterprises seeking High Performing, BYOD Optimized Teleworking Solutions 2x3 ANTENNA DESIGN, 2 SPATIAL STREAMS2x3 ANTENNA DESIGN, 2 SPATIAL STREAMS Fast, reliable & consistent connectivity.Fast, reliable & consistent connectivity. Full n speedsFull n speeds DUAL RADIO SUPPORT Simultaneous 2.4GHz & 5GHz support to minimize and avoid interference caused by many residential devices WIRED ACCESS SUPPORTWIRED ACCESS SUPPORT 4 10/100/1000 local Ethernet ports.4 10/100/1000 local Ethernet ports. Supports up to 2 ports for dedicated corporate network access.Supports up to 2 ports for dedicated corporate network access. PERSONAL DEVICE SUPPORTPERSONAL DEVICE SUPPORT Allows personal network setup and segments personal network traffic from the corporate trafficAllows personal network setup and segments personal network traffic from the corporate traffic IT maintains control to enable or disable personal SSID/wired accessIT maintains control to enable or disable personal SSID/wired access Orderability: NOW FCS: NOW Upcoming New CapabilitiesUpcoming New Capabilities Split-tunnel for local resources – access personal devices on the LAN side while associated to corporate WLAN (2QCY13)Split-tunnel for local resources – access personal devices on the LAN side while associated to corporate WLAN (2QCY13) Basic Firewall, Split-tunnel for internet bound (non-corporate) traffic, Local Web-GUI ease of use enhancements & Voice QoS enhancements (3QCY13)Basic Firewall, Split-tunnel for internet bound (non-corporate) traffic, Local Web-GUI ease of use enhancements & Voice QoS enhancements (3QCY13)

5 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 5 Designed for Value-Minded Customers Looking for Proven Good RF Performance FCS Q2CY13 New Indoor AP Series RadiosDual Band RF Design (MIMO:SS)2x2:23x3:2 Client Count AutonomousFuture ✔ BeamformingECBF ReadyClient Link 2.0 Spectrum IntelligenceClean Air Express RRM ✔✔ VideoStream ✔✔ BandSelect ✔✔ Rogue Detection ✔✔ Adaptive wIPS ✔✔ Limited Lifetime Warranty ✔✔ List Price (Integrated Ant.)$495$695

6 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 6 f Cost sensitive high-quality design & RF performance Internal integrated antennas Dim: 7” x 7” x 2” Weight: 1.3lbs (0.6kg) Aironet 702i Access Point Designed for Price Sensitive Mid Market, K-12, SP WiFi, and Emerging Markets AIR-CAP702I-x-K9Dual-band a/g/n controller-based access point AIR-CAP702I-xK Pack a/g/n controller-based access point Target Availability: 2QCY13 FCS List Price: $495 Aironet 700 Series Indoor Access Points Key FeaturesAP-702i Max Data Rate300 Mbps Radio Design MIMO:Spatial Stream2x2:2 Module OptionN/A CleanAirSI* BeamformingECBF** Max No. Clients (per Radio)100 BandSelect ✔ VideoStream ✔ Rogue AP Detection ✔ Adaptive wIPS ✔ Monitor Mode ✔ FlexConnect ✔ Autonomous (Future) Data Uplink (Mbps)10/100/1000 Power802.3af, AC Adapter Temperature Range0 to 40° C *TBD, **H/W enabled Cisco CONFIDENTIAL - Shared Under NDA

7 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 7 Part NumberDescriptionUS List Price AIR-CAP702I-x-K9Aironet 700 Series Access Point: n CAP702, 2x2:2SS; Int Ant; x Reg Domain $ AIR-CAP702I-xK910Aironet 700 Series Access Point: n CAP702, 10APs, 2x2:2SS; Int Ant; x Reg Domain $ 4, To verify approval and to identify the regulatory domain that corresponds to a particular country, visit: Software Release supported: R7.5 Orderable: Mid’April 2013 FCS: late May’13

8 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 8 Each AP700 ordered includes: o New AIR-AP-BRACKET-7 (only compatible with AP700) o Existing AIR-AP-T-RAIL-R or AIR-AP-T-RAIL-F o Optional AIR-CHNL-ADAPTER at additional cost ($5 USD). The table below details what mounting options are supported with AP700 series. Mounting Option Description Usable with AP700 Series? AIR-AP-BRACKET-7* NEW * AP-702 Series Mounting BracketYes AIR-AP-T-RAIL-RCeiling Grid Clip for Aironet APs - Recessed MountYes AIR-AP-T-RAIL-FCeiling Grid Clip for Aironet APs - Flush MountYes AIR-CHNL-ADAPTERT-Rail Channel Adapter for Cisco Aironet Access PointsYes AIR-AP-BRACKET n AP Low Profile Mounting BracketNo AIR-AP-BRACKET n AP Universal Mounting BracketNo AIR-AP-BRACKET n AP In-Ceiling Mounting BracketNo AP1130/1240/1250 bracketsBrackets used on legacy productsNo

9 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 9 Powering Options 802.3af/at Power over Ethernet switching New Cisco AIR-PWRINJ5= 802.3af Power over Ethernet injector. Ordered as a spare, List Price = $99 USD Cisco AIR-PWRINJ4= injector also supported but position AIR-PWRINJ5= instead due to smaller size/lower list price. Ordered as a spare, List Price = $149 Existing Cisco AIR-PWR-B= AC/DC adapter. Ordered as a spare, List Price = $39

10 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 10 ModuleWSSI (Security Module) ac3G Femto BenefitsFull comprehensive wireless security posture with off channel scan for WIPS, Rogue Detection, Context Aware, CleanAir, and RRM Support new ac data clients and Smartphones, up to 1Gbps+ wireless speeds Provides extended 3G cellular infrastructure coverage where cell tower signals cannot go (carpet areas in high rises, MDUs) Target MarketsAll Enterprise, Retail (PCI), Healthcare, Manufacturing All Enterprise List Price$500 TBD OrderabilityNowQ2CY13 (Target)Q4CY13 New

11 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 11 Smartphones from 210 Mbps* Tablets from 460 Mbps* High End Laptops from 680 Mbps* ac Performance Table * Assumes ~70% MAC efficiency Not all Clients will be created equal – early chip drops and quality of components - mileage will vary Rate & Range, Environment and Deployment will impact coverage and quality 1x1 2x2 3x3 faster connectivity = shorter active radio time = better battery life Single GbE port on the AP More than sufficient bandwidth from the full duplex GbE port on the AP3600

12 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 12 Field-upgradable ac module for the 3600 Series, enables a seamless migration to next generation wireless No rip and replace of APs, plug-in and go! ac - 5 GHz Module 1.3 Gbps PHY SS with 256 QAM (Wave 1 – Draft 5) 3 Spatial Streams, 20/40/80 MHz channels, 256 QAM SU-MIMO Explicit Compressed Beam Forming (ECBF) support as per the ac specification AP3600 operates 3 active radios, 2.4 and 5 GHz integrated and the ac 5 GHz module Supporting b/g/n on 2.4 GHz and a/ac/n on 5 GHz 18w of Power required for the 3600 with the ac Module installed Power draw with ac Module exceeds 15.4 Watts (802.3af), and will require either Enhanced PoE, 802.3at PoE+, Local Supply or Power Injector 4 Single GbE port on the AP More than sufficient bandwidth from the full duplex GbE port on the AP3600 Each module ships with a Universal Mounting Brackets (Bracket-2) FCS Q2CY13

13 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 13 Integrated Notebook devices – Anticipated in CY13 – but not yet announced Intel based Ultrabooks – 2x ac Wave 1 Apple – 1x1, 2x2 and 3x ac Wave 1 Integrated Mobile devices – Announced not yet shipping Samsung S 4 - HTC ONE – ZTE Grand Memo - USB Clients - Shipping LinkSys AE6000 – 1x1 - adapter_stcVVproductId VVcatId553466VVviewprod.htmhttp://store.linksys.com/linksys-ae6000-wifi-wireless-ac-dual-band-mini-usb- adapter_stcVVproductId VVcatId553466VVviewprod.htm Asus – USB-AC53 – 2x2 - NetGear – A6200 – 2x2 - Belkin - 2x2 - D-Link – 2x2 - Bulffalo – 2x2 - Edimax – 2x2 - Ethernet to ac Bridges - Shipping LinkSys (Belkin) WUMC bridge_stcVVproductId VVcatId550467VVviewprod.htmhttp://store.linksys.com/en-us/linksys-WUMC710-wireless-media-connector-wifi-5ghz- bridge_stcVVproductId VVcatId550467VVviewprod.htm Buffalo WLI-H4-D

14 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 14 Product Offer – 3G + Wi-Fi Enterprise Capability3G/HSPA n RFBand II/V or I n 2.4/5GHz RF Power3G 100mW at Ant. Port Antenna3G: 1x1 SISO n 4x4 3SS / Beamforming RF BW5 MHz Base PlatformCisco 3600 AP Platform Throughput21/5.7 Mbps HSPA+ 3G Feature Set 16 Active users; 200 idle ;3GPP R99 & R7 HSPA+ ; Iuh / TR-069, TR-196v1 Open Mode Mobility3G Active CS/PS and Idle Mode Resel SON / HetNet3G : Network Listen; : Clean Air Power SupplyPoE+ or 48V DC (25W) Size / Weight1.5L ; 1.4kg (complete unit) DeploymentIndoors 16 User 3G Open Mode Module <100mW Transmit Power (same as ETSI ) Compatible with 3600i/3600e Wi-Fi AP Supports powering through PoE+ R99 WCDMA Voice Calls Up to 21Mbps DL / 5.76Mbps UL HSPA data Available in 3GPP Band II/V (USA/LATAM) or I (Rest of World) Roadmap to include 32 user count, DC- HSPA+ and LTE

15 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 15 GIG-E MEETS REAL WORLD NETWORK SITUATION - 1 Gbps+ throughput requires a “perfect storm” where 1)multiple clients (2.4 and 5GHz, 3SS) need to reside physically nearby to AP (best case wireless conditions) 2)with all traffic pushing in a single direction (worst case traffic pattern) 3)and with full airtime efficiencies (very few management and control frames and retries) 4)all above must be met in order to achieve Gbps peak (only 11% excess of 950 Mbps Gig-E theoretical) ac STANDARD and WFA CERTIFICATION - Neither IEEE nor Wi-Fi Alliance mandate 2 (or more) GigE ports – do NOT allow the competition to successfully assert otherwise ! COSTS - another Cat5e line to the AP and consuming an extra switch port – all for running another cable that would typically cost in the area of % of the ASP for new AP for capacity that is not required CONCLUSION: For the first wave of 11ac access points, the use of a single GigE port is a technologically practical and economically prudent implementation choice. 2.4GHz 11n radio 150 Mbps max 5GHz 11ac radio 910 Mbps max AP Gigabit Ethernet 950 Mbps max 1.06 Gbps HDX vs. 1.9 Gbps FDX

16 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 16 Cisco Aironet Outdoor n AP Series 1552I Low Profile 1552I 1552E 1552EU Versatile 1552E 1552EU 1552C 1552CU MSO / Cable 1552C 1552CU Integrated Antennas Low Power Consumption Seamless Connectivity CleanAir, ClientLink External Antennas, Deployment Flexibility High Power Gain Fiber SPF Option PoE Out CleanAir, ClientLink Integrated DOCSIS 3.0 Cable Modem Cable Plant Powered High Power Gain Deployment Flexibility CleanAir, ClientLink 1552H 1552S Industrial 1552H 1552S ATEX Certified Class 1/Div 2/Zone 2 Integrated Honeywell Sensor Gateway (S) Fiber SPF Option PoE Out CleanAir, ClientLink

17 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 17 © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential Presentation_ID Outdoor AP Series1552E/EU1552C/CU1552I TypeExternal antennasCable modemInternal antennas Antennas E: Ext. dual-band EU: Ext. single band C: Internal CU: Ext. single-band Internal CleanAir ✔✔✔ ClientLink ✔✔✔ Fiber SPF optics ✔ PoE out (802.3af) ✔ Cable modem ✔ Battery backup option ✔ Power optionsAC, 12 VDC, PoE 40-90V cable plant 12 VDC AC, 12 VDC Data rate300 Mbps Radio design Tx-Rx:SS 2x3:2 BandSelect ✔✔✔ VideoStream ✔✔✔ Rogue AP detection ✔✔✔ FlexConnect ✔✔✔ Wireless mesh ✔✔✔ Temperature range °C-40 to 55 List Price$4495 (E) / $4495 (EU)$5295 (C) / $4995 (CU)$4495

18 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 18 Key Features Small Form Factor Dual Radio 2.4/5GHz Integrated or External Antenna Option Configurable Dual- or Single-band connectors for external antennas -30 to 65C Temperature Range Power 802.3at or VDC IP67 BandSelect, VideoStream, Mesh, and Autonomous/Bridge Support FCS Q4CY13

19 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 19 Antenna Gain: 5/6 dBi (2/5GHz) (preliminary) 2G: 3x3:3 (Tx/Rx/3SS) 5G: 2x3:2 Tx Power 2G: 24 dBm/Tx = 29 dBm; EIRP= 34 dBm 5G: 24 dBm/Tx = 27 dBm; EIRP= 33 dBm Power Interface: PoE or DC (48V) Power Consumption: 25-30W (TBD) LAN port LTE & WiMAX Coexistence (2.1/2.3 GHz; 30 dB; 2.5 GHz; 35 dB rejection) Spectrum Intelligence (potential future SW release) India Extended Band: GHz IP to +65 ºC

20 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 20 2G: 4 dBi8 dBi 5G: 7 dBi8 dBi Dual-BandSingle-Band 5G: 8 dBi14 dBi 8 dBi 14 dBi 13 dBi2G: 8 dBi Same PID SW Configurable: Single OR Dual-Band Connectors 2G: 2x2:2 5G: 2x2:2 Tx Power (2G) = 24dBm/Tx => Conducted Power= 27 dBm Tx Power (5G) = 24dBm/Tx => Conducted Power= 27 dBm Bridge FunctionalityWGB as Bridge-Like replacement (1310 or 1410) 30x120º 30x30º

21 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential E 1532E 1552Parameter1532 # AntennasX Direct AC power input X Battery BackupX SFP backhaulX PoE OutX Cable backhaulX CleanAirX ClientLinkX GPSX

22 22 Cisco Confidential© 2011 Cisco and/or its affiliates. All rights reserved. Volume:11.0 Liters vs.3.5 Liters(68% smaller) Weight:7.9 kg vs.2.7 kg (66% lighter) Size: 31 x 22 x 16 cmvs.26 x 17 x 10 cm Color: White vs.Gray Profile: Horizontal vs.Vertical along pole Cover: No vs.Yes (paint to blend in)

23 23 Cisco Confidential© 2011 Cisco and/or its affiliates. All rights reserved. < $3,000 $4,000 - $6,500 $5500 $4000 Basic 2 SS ASP  $900 Moto x3:2 $2299 Aruba 175 2x2:2 $2295 Ruckus x3:2 $1999 Ruckus x3:3 $2999 BelAir 100N 2x2: GHz $4200 BelAir 100SNE 3x3:3 + CM BelAir 100LT 3x3:3 + Cable LTE Cable Modem 3x3:3 ASP: MSO today  $1500 $3000 Modular 3 SS; 11n + CM Licensed Radio Ruckus 7761-CM 3x3:2 + CM $3999 Ruckus 8800 Modular Platform 3x3:3 + CM+ LTE $6,499 Ruckus 7781-CM 3x3:3 + CM $4999 1H/CY13 Cisco 1552C 2x3:2 + CM $5295 Cisco 1552E 2x3:2 $4495 CORFU (11n, 3x3:3) Ultra Low Profile Indoor AP1600 in NEMA box - Stop-Gap Option BelAir 20EO 2x2:2 Functionality List Price Cisco missing 3Q/CY13 Budgetary $2500

24 24 Cisco Confidential© 2011 Cisco and/or its affiliates. All rights reserved. s/w release Controller-based AP Software New AP – AP3600 New AP – AP2600 (MR1) AP Groups and RF Profiles Phase 1  abg data rates, Tx Power Threshold min/max  Max User limits per Radio/SSID RRM TPCv2 (co-channel) Custom QoS Profiles Stadium Vision (HD) CleanAir  PDA Sharing  Unclassified Interference  Tunable EDRRM OEAP600  Manual Ch & Tx power  Ethernet port, Personal SSID disable  3 CORP SSID  Dedicated VLANs Outdoor AP1552  UNII2 DFS (US)  Local & Flex Mode RAP – 7.2MR1 New AP – AP3600 New AP – AP2600 (MR1) AP Groups and RF Profiles Phase 1  abg data rates, Tx Power Threshold min/max  Max User limits per Radio/SSID RRM TPCv2 (co-channel) Custom QoS Profiles Stadium Vision (HD) CleanAir  PDA Sharing  Unclassified Interference  Tunable EDRRM OEAP600  Manual Ch & Tx power  Ethernet port, Personal SSID disable  3 CORP SSID  Dedicated VLANs Outdoor AP1552  UNII2 DFS (US)  Local & Flex Mode RAP – 7.2MR Cisco Confidential – NDA Only 7.5 Q2CY Sep 2012 Q1CY13 Q2CY13 New AP – Outdoor AP1552CU and AP1552EU AP Groups and RF Profiles Phase 2 Rx Sensitivity, RSSI, Multicast, CCA, BandSelect Split Tunnel and Local Resources for FlexConnect AP based rate limiting per SSID per client AP Serviceability Outdoor AP1552 Extended band RAP Feature Parity w/Indoor CleanAir on 5GHz VoWLAN Support EPON support on 1552E/1552EU New AP – Outdoor AP1552CU and AP1552EU AP Groups and RF Profiles Phase 2 Rx Sensitivity, RSSI, Multicast, CCA, BandSelect Split Tunnel and Local Resources for FlexConnect AP based rate limiting per SSID per client AP Serviceability Outdoor AP1552 Extended band RAP Feature Parity w/Indoor CleanAir on 5GHz VoWLAN Support EPON support on 1552E/1552EU New AP – AP1600 New Module for AP3600 – WSSI (security) Module AP3600  LLDP  Tx Power Boost  Security Monitor Module for AP3600  Off channel scan for RRM, WIPS, CleanAir, Rogue Detection, and Location Awareness in 2.4 and 5GHz Outdoor AP1552  GPS module support  Cable Modem monitoring by NCS (NCS Rel 2.1) New AP – AP1600 New Module for AP3600 – WSSI (security) Module AP3600  LLDP  Tx Power Boost  Security Monitor Module for AP3600  Off channel scan for RRM, WIPS, CleanAir, Rogue Detection, and Location Awareness in 2.4 and 5GHz Outdoor AP1552  GPS module support  Cable Modem monitoring by NCS (NCS Rel 2.1) New AP – AP700 New Module for AP3600 – ac  Per Data Rate stats visibility  256-bit AES based DTLS AP to WLC AP3600 Domain -Z support the 3600 OEAP600  Local Resource Sharing (Printers)  vWLC support for OEAP Outdoor AP1552  Dedicated QoS for sensor traffic New AP – AP700 New Module for AP3600 – ac  Per Data Rate stats visibility  256-bit AES based DTLS AP to WLC AP3600 Domain -Z support the 3600 OEAP600  Local Resource Sharing (Printers)  vWLC support for OEAP Outdoor AP1552  Dedicated QoS for sensor traffic Q4CY13 New AP - AP3700 integrated 11ac – aIOS and NGWC ac on NGWC with AP3600 New Module for AP3600 and AP Cisco 3G Small Cell Module New AP - Corfu and 1552WU– Outdoor AP OEAP: Basic Firewall, Web-GUI enhancements QOS Voice Enhancements Split-tunnel (internet traffic) AP1600 CleanAir Express AP1552/Outdoor Indoor Feature Parity - FlexConnect Support on Mesh Mesh without MAC filter list (alternate MESH MAP authentication) PMIPv6 MAG (Mobility Access Gateway) component. As a MAG, the AP MUST support IPv4 and IPv6 on the interface that faces the LMA (Local Mobility Anchor) New AP - AP3700 integrated 11ac – aIOS and NGWC ac on NGWC with AP3600 New Module for AP3600 and AP Cisco 3G Small Cell Module New AP - Corfu and 1552WU– Outdoor AP OEAP: Basic Firewall, Web-GUI enhancements QOS Voice Enhancements Split-tunnel (internet traffic) AP1600 CleanAir Express AP1552/Outdoor Indoor Feature Parity - FlexConnect Support on Mesh Mesh without MAC filter list (alternate MESH MAP authentication) PMIPv6 MAG (Mobility Access Gateway) component. As a MAG, the AP MUST support IPv4 and IPv6 on the interface that faces the LMA (Local Mobility Anchor) Committed In Planning 8.0

25 25 Cisco Confidential© 2011 Cisco and/or its affiliates. All rights reserved. Committed Split Tunnel Local Resource sharing (Printers) Split Tunnel Local Resource sharing (Printers) Cisco Confidential – NDA Only Q2CY13 Q4CY13 1HCY14 In Planning S/W release7.5 Digital Image Signing Digital Image Signing Support for Self Signed Certificates Support for Self Signed Certificates QOS Enhancements for Voice QOS Enhancements for Voice Web-GUI Enhancements Next-Gen OEAP -H/W-assist encryption -Class 0/2 PoE Out -USB 3G/4G backhaul -Dual-radio, ac Next-Gen OEAP -H/W-assist encryption -Class 0/2 PoE Out -USB 3G/4G backhaul -Dual-radio, ac Extending OEAP Platform Capabilities Basic Firewall Split Tunnel Internet Traffic Split Tunnel Internet Traffic Cisco IT deploying OEAP-600 across global employee base (1,200 planned units thru end of FY13 – w/ additional in FY14) Cisco IT deploying OEAP-600 across global employee base (1,200 planned units thru end of FY13 – w/ additional in FY14)

26 © 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 26 Aironet AP Series End Of Sale Announcement End of Sale Date HW End of Support Software Release Support Recommended Aironet n G2 Series Indoor 1130, 1240  Jan 2013Jul 2013Jul 2018Last MD release – 8.0.x  Aug 2011Jan 2012Jan 2017Last MD release – 8.0.x ,  Apr 2013 Oct 2013 Sep 2018 Oct 2018 Last MD release – 8.0.x Last feature release – TBD , 1140 for EU/ETSI  ♯ Aug 2012Dec 2012Sep 2018 Last MD release – 8.0.x Last feature release – TBD No plans currently Beyond Outdoor 1310Jul 2012Jan 2013Q1 CY18Last feature release – 7.0.x  Oct 2011Mar 2012Q1 CY17 Last MD release – 8.0.x Last feature release – SB  ♯ Mar 2013Jun 2013Q2 CY18 Last MD release – 8.0.x Last feature release –  Only hardware support in 8.0 for 1130,1240, 1250 and New features introduced in 8.0 will not be supported. ♯ Earlier EOS timeline for EU/ETSI due to new DFS rules starting 2013

27 Thank you.
