1
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India

2
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India LINEAR PROGRAMMING SIMPLEX METHOD 3 CHAPTER

3
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 3 Learning Objectives –Convert LP constraints to equalities with slack, surplus, and artificial variables. –Set up and solve both maximization and minimization LP problems with simplex tableaus. –Interpret the meaning of every number in a simplex tableau.

4
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 4 Crisis at Bhilpur Type A Vehicle Type B Vehicle Total Available (a) Carrying Capacity2 Tons3 Tons- (b) Diesel Required100 Litres200 Litres4000 Litres (c) Drivers Required1130 (d) Numbers Available 2615-

5
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 5 Crisis at Bhilpur Convert inequalities to equalities by adding slack variables

6
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 6 Crisis at Bhilpur The problem can be formulated as:

7
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 7 Initial Tableau Basic Variables CjCj Qty AB

8
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 8 Identify incoming variable (maximum positive value in row). This is key column. Replacement ratio (RR) = Qty/key column. Outgoing row is row with minimum positive RR and key number is intersection of key column and key row.

9
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 9 Carry out pivot operations New incoming row = Key row/Key number New row element = Old row element – (old row element in key column X corresponding element in replaced row)

10
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 10 Identify incoming variable (maximum positive value in row), outgoing row (row with minimum positive replacement ratio) and identify key number. Incoming variable Outgoing Variable Basic Variables CjCj A B Qty ∞ RR Key number B

11
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 11 Again carry out pivot operations. New incoming row = Key row (outgoing row)/Key number New row element = Old row element – (old row element in key column X corresponding element in replaced row)

12
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 12 Identify incoming variable (maximum positive value in row), outgoing row (row with minimum positive replacement ratio) and identify key number. Incoming VariableOutgoing Variable Key Number

13
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 13 Again carry out pivot operations. New incoming row = Key row (outgoing row)/Key number New row element = Old row element – (old row element in key column X corresponding element in replaced row)

14
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 14 Since all values in the row are now negative, no further improvement is possible. The optimal solution has been reached. Mr. Confused Singh should use: –20 Type A Vehicles and 10 Type B Vehicles –Maximum Coal sent 70 tons

15
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 15 Simplex Steps For Maximisation 1. Choose the variable with the greatest positive value to enter the solution. 2. Determine the row to be replaced by selecting the one with the smallest (non-negative) replacement ratio. 3. Calculate the new values for the key row. 4. Calculate the new values for the other row(s). 5. Calculate the and values for this tableau. If there are any values greater than zero, return to Step 1.

16
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 16 Minimisation Case (Big M Method) VitaminsFoodDaily Requirement V2440 W3250 Cost per unit Rs 3Rs 2.50

17
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 17 Minimisation Case The problem can be formulated as:

18
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 18 Surplus And Artificial Variables Convert inequalities to equations denotes the quantity of Vitamin V more than 40 units that the mix of foods may produce. It is called a surplus variable. If initially we buy no food, then - 40 units of Vitamin V cannot exist. The problem is overcome by introducing an artificial variable,which can be viewed as a substitute for Vitamin V. Since should not appear in the solution, its cost is taken as very high (M or 1 million). The equation is written as

19
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 19 Surplus And Artificial Variables The model can now be written as

20
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 20 Initial Simplex Tableau Identify incoming variable (greatest negative value in row) Identify outgoing variable (least positive RR value) Identify key number B.V32.500MMQtyRR AB M M M6M-M MM90M 3-5M2.5- 6M MM00 Incoming variable Outgoing variable Key number

21
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 21 Carry out pivot operations in same manner as for a maximisation case Identify new incoming and outgoing variables B.V32.500MMQtyRR AB B M M M -M M M25+ 30M M M M M 0 Incoming variable Outgoing variable Key number

22
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 22 Carry out pivot operations As there is no negative value in the row, optimal solution has been reached. Buy 15 units of Food A and 2.5 units of Food B. B.V32.500MMQty AB B A M – M – 0.875

23
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 23 Minimisation Case (Two Phase Method) Formulate model Convert inequalities into equations Let the contribution of artificial variables to the objective function be 1 Assume the contribution of all other variables (decision and surplus) to be zero Solve for minimisation. This is solution for Phase 1.

24
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 24 Minimisation Case (Two Phase Method) For Phase 2, start with the solution of Phase 1. Omit artificial variable columns. Restore contribution values of decision variables. Recalculate row. If all values are positive, an optimal solution has been reached, else continue pivot operations as for minimisation till optimal solution is reached.

25
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 25 Minimisation Case (Two Phase Method) Consider the same problem. The model is

26
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 26 Phase 1. Initial Tableau. Identify incoming variable (greatest negative value in row) Identify outgoing variable (least positive RR value) Identify key number B.V000011QtyRR AB Incoming variable Outgoing variable Key number

27
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 27 Carry out pivot operations in same manner as for a maximisation case Identify new incoming and outgoing variables B.V000011QtyRR AB B Incoming variable Outgoing variable Key number

28
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 28 Carry out pivot operations in same manner as for a maximisation case As there are no negative values in the row, the solution to Phase 1has been achieved. B.V000011Qty AB B A

29
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 29 Set up Phase 1 solution as the initial solution for Phase 2. As all values in row are positive, optimal solution has been reached. It is the same as for the Big M Method B.V Qty AB B A

30
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 30 Shadow Prices Shadow Price: Contribution of one unit of a scarce resource to the objective function –Found in Final Simplex Tableau in Row –Value in Slack Variable Column Consider the Maximisation problem final simlex tableau

31
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 31 S 1 has a value of This implies that for every additional litre of diesel, an additional 0.01 tons of coal can be carried. S 2 has a value of For every additional driver, 1 ton of coal can be carried.

32
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 32 Consider the minimisation problem. B.V Qty AB B A Every additional unit of Vitamin V will increase the cost by Rs and every additional unit of Vitamin W will increase the cost by Rs 0.875

33
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 33 Primal and Dual A problem may be viewed as a maximisation or as a minimisation problem. We can maximise output for given resources or minimise resources for given output. This is the concept of primal and dual.

34
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 34 Steps to form the Dual If the primal is maximisation, the dual is minimisation, and vice versa. The right-hand-side values of the primal constraints become the objective coefficients of the dual. The primal objective function coefficients become the right-hand-side of the dual constraints. The transpose of the primal constraint coefficients become the dual constraint coefficients. Constraint inequality signs are reversed

35
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 35 Primal and Dual PrimalDual

36
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 36 B.V Qty AB B A B.V Qty XY Y X Comparison Primal and Dual Final Tableaus

37
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 37 Sensitivity Analysis It is a ‘What if?’ analysis. It analyses what would happen if some changes were made. It analyses one factor at a time. Changes in objective function coefficients Changes in RHS of the equations Introduction of a new variable

38
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 38 Changes in Objective Function Coefficients Consider ‘Crisis at Bhilpur’ problem. The current objective function is: Type A vehicle carries 2 tons of coal. By how much can this tonnage carried vary without altering the solution?

39
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 39 Examine the graphic solution of the problem. The slope of the isoprofit line is dependent on the coefficients of A and B. Type A Vehicles Type B Vehicles The solution would remain the same as long as the isoprofit line touched the Point (20,10)and did not enter the solution area. The slope variations can range between the blue and the red lines.

40
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 40 The range can be calculated from the final simplex tableau. Divide the row by the A row. We get: /2 0 0 The least positive quotient is the answer as to how much the capacity of each Type A vehicle could increase and the least negative quotient is how much the capacity can decrease without changing the solution. Type A vehicle capacity can vary between 1.5 and 3 tons.

41
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 41 Divide the row by the B row. We get: The least positive quotient is the answer as to how much the capacity of each Type B vehicle could increase and the least negative quotient is how much the capacity can decrease without changing the solution. Type B vehicle capacity can vary between 2 and 4 tons. Similarly, we can find the range of carrying capacity of Type B vehicles

42
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 42 Right Hand Side Ranging What would happen if the level of resources available changed, or the right hand side of the constraints changed? If we were to be offered more diesel, without increasing the number of drivers, we would first take as many Type B vehicles as possible, since Type B vehicles carry more i.e. 15 vehicles. We would have 15 drivers left with which we can utilise 15 Type A vehicles. A total of 4500 litres of diesel would be needed.

43
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 43 Right Hand Side Ranging Similarly, if we were required to shed diesel, we would first utilise all Type A vehicles as they consume less diesel, i.e. 26 vehicles. The remaining 4 drivers would be used by deploying 4 Type B vehicles. A total of 3400 litres of diesel would be needed. Shadow prices remain constant within these ranges.

44
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 44 We can also do RHS ranging from the final simplex tableau Divide the Quantity column by the slack column for S 1. We get: The least positive quotient (600) is the answer as to how much diesel can be reduced and the least negative quotient (500) is how much it can be increased without affecting the shadow prices. The range of diesel is 3400 to 4500 litres.

45
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 45 Similarly, we can compute the range for drivers. Divide the Quantity column by the slack column for S 2. We get: The least positive quotient (5) is the answer as to how many drivers can be reduced and the least negative quotient (3) is how many drivers can be increased without affecting the shadow prices. The range of drivers is 25 to 33.

46
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 46 Adding another Variable If a Type C truck was made available which can carry 4.5 tons of coal but consumes 400 litres of diesel, should we consider it ? The shadow price per litre of diesel is.01 tons of coal and the shadow price of one driver is 1 ton of coal. Since the Type C truck consumes 400 litres of diesel and 1 driver, it should deliver 5 tons of coal at the existing shadow prices Since its capacity is less, we should not consider introducing it in our solution.

47
Quantitative Techniques for Decision Making M.P. Gupta & R.B. Khanna © Prentice Hall India Page 47 Technical Issues Infeasibility – when artificial variables are still in solution. Unbounded Solution – if all replacement ratios are negative or infinity. Degeneracy – when a variable though in solution has a value of zero. Two rows may have the same replacement ratio. Multiple Optima – multiple solutions. Two rows have the same replacement ratio.
