Sony’s Vandal-Resistant Cameras with IK10 Rating.

Similar presentations


Presentation on theme: "Sony’s Vandal-Resistant Cameras with IK10 Rating."— Presentation transcript:

1

2 Sony’s Vandal-Resistant Cameras with IK10 Rating

3

4 24 hours a day, 365 days a year, security cameras must keep on working even in the most challenging environments.

5 Camera attack before attempted car theft

6 Senseless vandalism on school campus

7 Warehouse intruder tries to avoid detection

8 Violent armed raid on a cash machine

9 Camera attack before attempted car theft Senseless vandalism on school campus Warehouse intruder tries to avoid detection Violent armed raid on a cash machine

10 Buyer beware! Not all ‘vandal-resistant' cameras are created equal! Some are IK10 rated, others are not!

11 What is Vandal Resistance? Hard to break into –Screws inaccessible without special screwdrivers (Torx, Security Torx, etc.) Hard to smash –High impact resistance

12 Hard to smash How do scientists measure impact energy? –In “joules” –1 joule = 1 watt-second = the impact of a small apple dropped three feet

13 Hard to smash How does industry rate impact resistance? –Under specified lab conditions –European standard EN –International standard IEC –International “IK code” –The enclosure must withstand five hits –At specified impact energies (joules) –At specified attack angles

14 Cracking the Code IK Code and Impact Energy IK Code IK00IK01IK02IK03IK04IK05IK06IK07IK08IK09IK10 Impact energy (joule) * Highest Rating Lowest Rating

15 Cracking the IK Code IK06 = 1 joule –1.1 lb. (0.5 kg ) –Plastic ball –Dropped 8 inches (20 cm)

16 Cracking the IK Code IK08 = 5 joules –3.75 lbs. (1.7 kg ) –Steel ball –Dropped 12 inches (30 cm)

17 Cracking the IK Code IK10 = 20 joules –11 lbs. (5 kg) –Steel ball –Dropped 16 inches (40 cm)

18 An IK10-rated camera can withstand an impact of 20 joules Actual testing Hammer weight: 11lbs (5kg) Height: 16 (40cm)

19 An IK10-rated camera can withstand an impact of 20 joules Actual testing Hammer weight: 11lbs (5kg) Height: 16 (40cm)

20 An IK10-rated camera can withstand an impact of 20 joules Actual testing Hammer weight: 11lbs (5kg) Height: 16 (40cm)

21 Sony’s K10-rated vandal-resistant security cameras SNC-DH110T SNC-DH210T SNC-DH120T SNC-DH140T SNC-DH220T SNC-DH240T SNC-ZM551 SNC-DH160 SNC-DH180 SNC-DH260 SNC-DH280 SNC-HM662 SNC-XM632 SNC-XM636 SNC-XM637 SNC-EM601 SNC-EM631 SNC-VM601 SNC-VM631 SNC-EM602R SNC-EM632R SNC-VM602R SNC-VM632R SNC-WR602 SNC-WR632 SNC-ER585 HD vs. Full HD

22 Even in your most demanding monitoring environments Sony has the answer SNC-DH110T SNC-DH210T SNC-DH120T SNC-DH140T SNC-DH220T SNC-DH240T SNC-ZM551 SNC-DH160 SNC-DH180 SNC-DH260 SNC-DH280 SNC-HM662 SNC-XM632 SNC-XM636 SNC-XM637 SNC-EM601 SNC-EM631 SNC-VM601 SNC-VM631 SNC-EM602R SNC-EM632R SNC-VM602R SNC-VM632R SNC-WR602 SNC-WR632 SNC-ER585 HD vs. Full HD

23 ©2014 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part with out written permission is prohibited. Features and specifications subject to change without notice. Some images in this PPT movie are simulated. Sony does not guarantee that its network cameras can withstand multiple hammer impacts.

24 Text color #1 (R - 216, G - 207, B - 198) Text color #2 (R -243, G -144, B -29)
