1 The State of the Art in Distributed Query Processing by Donald Kossmann Presented by Chris Gianfrancesco

2 Introduction Distributed database technology is becoming an increasingly attractive enhancement to many database systems  Cost and scalability  Software integration Legacy systems  New applications  Market forces

3 Introduction Topics covered in this paper  Basics of distributed query processing  Client-server distributed DB models  Heterogeneous distributed DB models  Data placement techniques  Other distributed architectures

4 Client-Server Database Systems Relationships between distributed nodes take a client-server form Client: makes requests of the servers, usually the source of queries Server: responds to client requests, usually the source of data System architectures: peer-to-peer, strict client-server, middleware/multitier

5 Architectures: Peer-to-Peer All nodes are equivalent Each can be either a client or server on demand (can store data and/or make requests) Ex: SHORE system Peer Node Server or Client Peer Node Server or Client Peer Node Server or Client

6 Architectures: Strict Client-Server Client or server status is pre-defined and can never change Clients supply queries, servers supply data Most common architecture in commercial DBMS’s Client Query source Server Data source

7 Architectures: Middleware/Multitier Multiple levels of client-server interaction Nodes act as clients to those below them and servers to those above SAP R/3, web servers with DB backends Node 1 Client to Node 2 Node 2 Server to Node 1, Client to Node 3 Node 3 Server to Node 2

8 Architectures: Evaluation Peer-to-Peer  Simplest setup  Equal load sharing Strict Client-Server  Specialization  Administration for servers only Middleware/Multitier  Functionality integration  Scalability

9 Client-Server Query Processing Queries initiated at clients, data stored at servers Where do we execute the query? Query shipping: move the query down to the data Data shipping: move the data up to the query Hybrid shipping: combination of both

10 Query Shipping SQL query code is sent down to the server Server parses and evaluates query, returns result Used in DB2, Oracle, MS SQL Server

11 Data Shipping Client parses query and requests data from server Server provides data, then client executes query Data can be cached at client (main memory or disk)

12 Hybrid Shipping Mix-and-match data shipping and query shipping Query parts can be executed at any level according to query plan Data is cached when beneficial

13 Evaluation Query Shipping  Reliant on server performance  Scales poorly with increasing client load Data Shipping  Good scalability  High communication costs Hybrid  Potential to outperform other options  More complex optimizations

14 Hybrid Shipping Observations Some observations of optimal performance using hybrid shipping Preference to not use a client cache  If network transfer cost < client access cost Shipping down cached data  If in main memory & execution at server Multiple small updates  Maintain at client and post to server only when necessary

15 Query Optimization Query plans must also specify where the query pieces are executed Data shipping: all execution done at client Query shipping: all execution done at server Hybrid: choice can be made for each operator Results display to user is always at client

16 Distributed Query Plans Each operator is annotated with a logical site of execution – plans are shareable client means an operator is executed from the client where the query is issued server means:  for scan operators, execute at a location that has the necessary data  for updates, execute at all locations with the relevant data

17 Query Optimization: Where? Should optimization occur at the client or the server? At client: less load on servers, better scalability At server: more information about system statistics, especially server loads Potential solution: primary parsing and query rewriting at client, further optimization at server

18 Query Optimization: Statistics Even when optimization is done at a server, that server does not usually have full knowledge of the system System can either:  Guess the status of other servers – less accuracy, less cost  Ask other servers their status – fully accurate, additional communication costs

19 Query Optimization: When? Tradeoff of accuracy vs. cost Traditional-style: optimize once, store plan  No support for changing DB conditions  No incurred cost for query execution Plan sets: optimize for possible scenarios  Generate a few query plans for diff. conditions  Choose plans based on runtime statistics On-the-fly: observe intermediate results  Re-optimize query if different from expectations

20 Query Optimization: Two-Step Compile-time: generate join order, etc. Runtime: perform site selection Reasonable cost at each end Responds well to changing server loads Fully utilizes client data caching

21 Two-Step Optimization: Downside 1.Optimal plan is generated traditional-style 2.Site selection is performed 3.True optimal plan was missed Optimal was missed because first optimization step was done with no knowledge of the system

22 Query Execution Techniques Standard fare: row blocking, multithread when possible Issues: transactions with both updates and retrieval queries using hybrid shipping  We want to wait to propagate updates for efficiency’s sake  Other option: perform query before update and temporarily pad results

23 Questions? Comments?
